Title: Boating Skills


1
Boating Skills Seamanship
  • Lesson 11
  • Lines Knots for Your Boat

2
Lesson Objectives
  • Materials used in making rope
  • Use, selection and care
  • How to store rope
  • About rope/line hardware
  • Useful knots
  • How to secure the boats line

3
Marlinspike Seamanship
  • Art of handling working all kinds of fiber,
    synthetic wire rope
  • Includes
  • Knotting, splicing, worming, parceling, serving
    fancy work
  • What to a landlubber is - ROPE
  • To a seaman is - LINE

4
Type of Line
  • Natural
  • Manila, Sisal
  • Shrink when wet and rot when dry
  • Weaker size for size than synthetics

5
Type of Line (contd)
  • Synthetics
  • Nylon
  • Strongest size for size of synthetic
  • Stretches most, resists chafing
  • Does not shrink when wet
  • Good for dock lines, towing and anchoring

6
Line
  • Natural fiber
  • Manila, Sisal, Hemp, Jute, Cotton, Flax
  • Synthetic
  • Nylon, Polyester (Dacron), Polypropylene
  • Wire Rope
  • Steel strands

7
Natural Fiber Line
  • Best is Manila
  • Has strength, durability minimal stretch
  • Sisal is cheaper, but inferior
  • Disadvantages
  • Shrink when wet
  • Rot if stowed wet
  • Size for size, weaker than synthetic

8
Synthetic Line
  • General - good wet/dry strength, resists water,
    mildew rot
  • Nylon - strongest, resists chafe, has most
    stretch, good for anchor and mooring

9
Synthetic Line (contd)
  • Polyester - costs more than nylon, easier
    smoother to handle, use anytime, no stretch
  • Polypropylene - floats, costs less, deteriorates
    in sunlight, hard, slips on cleats, cuts

10
Manufacture of Line
  • Laid
  • Right laid
  • Left laid
  • Braided
  • Single braided
  • Double braided

11
Kinds of Rope
Braid
Twist
12
Composition of Right Laid Line
13
Double Braided Line
core
14
Wire Rope
  • Maximum STRENGTH
  • Minimum STRETCH
  • Used mostly on sailboats for standing and running
    rigging
  • Used on davits

15
Yachting Ropes
16
Ends of Line
  • Ends need to be protected from fraying unlaying
  • Ends can be
  • Whipped with thread/small stuff
  • Taped with waterproof tape
  • Dipped in plastic liquid
  • Melted with heat/flame

17
Temporary Whipped
start
finish
Pull cut
18
Making Up Lines
  • Faking
  • Laying out line in figure eights so it is free to
    run without tangles
  • Flemishing
  • Neat, ornamental way to store line on deck
  • Coiling
  • Proper way to put line away in a locker or
    compartment

Coiling Faking Flemishing
19
Losing Strength in Rope
  • No knots or splices
  • Anchor or Fishermans bend
  • Timber hitch
  • Round turn
  • Two Half-hitches
  • Bowline
  • Clove hitch
  • Sheet bend or Weavers knot
  • Square or Reef knot
  • Eye splice
  • Long splice
  • Short splice

20
Parts of a Line
Overhand Loop
Working End
Underhand Loop
Standing Part
Bitter End
21
Round Turn
22
Basic Mariners Knots Bends
  • Figure 8
  • Square Knot
  • Clove Hitch
  • Sheet of Becket Bend
  • Anchor Bend
  • Timber Hitch
  • Bowline
  • Half Hitches
  • Rolling Hitch

23
Figure 8
  • The Stopper Knot
  • It can be untied after being jammed
  • Used on all lines on sailboat except spinnaker
    sheets

24
Square Knot
  • Reef Knot - Alternate name
  • Used to secure reefed sail to boom
  • Fasten two lines of equal size
  • Difficult to untie if jammed
  • To tie
  • Right over left, then
  • Left over right

25
Clove Hitch
  • Used to tie line to piling
  • Knot will jam under load
  • Difficult to untie if load cannot be relieved

26
Sheet Bend
  • Becket Bend - alternate name
  • Ties two unequal sized lines together
  • Easy to untie after heavy strain

27
Two Half Hitches
  • Used to tie a line to a Ring, Piling, Post or
    Grommet
  • Easier to untie under tension and more permanent
    than a clove hitch

28
Round Turn with 2 Half Hitches
  • To tie a line permanently to a piling

29
Anchor or Fishermans Bend
30
The Bowline
  • To make a temporary loop
  • The rabbit comes up through the hole
  • Around the tree
  • Then back down
  • into the hole

31
The Bowline
  • The King of Knots
  • Easy to untie
  • Tie Jib sheets to Clew of Jib
  • Tie lines to fittings
  • Tie lines of equal or unequal size together
  • Tie a rode to an anchor

32
Bowline
33
Timber Hitch
34
Rolling Hitch
Around again, cross over first turn passing
between the first turn and the standing part of
its own line
Tie a half hitch
Around once
35
Cleats and Chocks
36
Mooring Cleat
37
Belaying to a Cleat
38
Jam Cleat
Working End
Standing Part
39
Larks Head
40
Cam Cleat
41
Chock
  • Used to protect boat and line

42
Securing Cleats
  • Use through bolts and backing block

Deck
Backing Block
43
Securing Lines
Bow Bitts
Samson Post
44
Dipping the Eye
  • Other boats eye on piling
  • Your eye can be removed or put on without
    disturbing the other boats line

45
Turnbuckle
46
Blocks
  • On a vessel, pulleys are called blocks

47
Double Sheave Block
48
Thimble
49
Special Lines
  • Lead Line
  • Measures Depth of Water
  • Weighted with a lead weight
  • (Hollow end for bottom sample)

50
Dock Lines
  • Stern line
  • Bow line
  • Breast line
  • Spring line

51
Dock Lines
  • Spring line
  • Bow/Stern lines

52
Fenders
53
Summary
  • Natural fiber vs. Synthetic line
  • Laid vs. Braided line
  • Coiling, Faking, Flemishing
  • Knots, Bends, Hitches
  • Splices
  • Securing lines
  • Dipping the Line
