Pressure System Proportional Control Design, Modeling

1
-Pressure
System- Proportional Control Design, Modeling
Experiments

• Cory Richardson
• Dennis To
• Jamison Linden
• 11/15/2009, UTC, ENGR-329

2
Contents

• Background, Schematics
• Previous work
• SSOC, Step Response
• Sine Response, Bode graphs,
• Root Locus
• Proportional Only Controller
• Proportional Integral Controller
• Root Locust Model
• Experimental
• Conclusions and Recommendations

3
Background - System



                             Figure 1. Schematic
diagram of the Dunlap Plant Spray-Paint Booths
4
Background - Block Diagram



Figure 2. Block diagram of paint booth system

5
Background - SSOC
Operating Range for Output
Operating Range for Input
6
Transfer Function
m(s) Input
c(s) Output
Transfer Function
7
Feedback Control
8
Background Step Response
9
Background Step Response Results

• Experimental results
• K 0.1 0.3 (cm-H2O/)
• t0 0.5 s
• t 1.7 s
• Model results
• K 0.1 0.3 (cm-H2O/)
• t0 0.48 s
• t 1.75 s

10
Frequency Response - Example
T (25.3)
Dc (1.45)
Dm (15)
t (-1.8)
11
Modeling Approach Bode Plots
12
Modeling Approach Bode Plots
13
System

• 2nd order system
• fu 0.85 Hz
• From the model
• K 0.1 0.35 (cm-H2O/)
• t0 0.85 s
• t 1.7 s
• Kcu 18.2 55.6 (/cm-H2O)

14
Kc Locations 45-60
15
Kc for Different Operating Ranges-based on the
model-
all units are /cm H2O
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Determination of P-only Kcu, fu

• 45-60
• Bode 180 /cm-H2O, 0.8 Hz
• Experimental 180 /cm-H2O, 0.33 Hz
• 60-75
• Bode 67 /cm-H2O, 0.8 Hz
• Experimental 67 /cm-H2O, 0.4 Hz
• 75-90
• Bode 42 /cm-H2O, 0.8 Hz
• Experimental 42 /cm-H2O, 0.42 Hz

29
Dampers were closed for 25 seconds, then opened.
30
Dampers were closed for 25 seconds, then opened.
31
Dampers were closed for 25 seconds, then opened.
32
P-Only Conclusions

• 45 60 operating range
• The model ceases to match the system at a Kc
  value of approximately 20.
• 60 - 75 operating range
• The model ceases to match the system at a Kc
  value of approximately 14.

33
P-only Conclusions

• 75 90 operating range
• The model ceases to match the system at a Kc
  value of approximately 8.

34
System Recommendations (P-only)
35
PI Controller Design Parameter

• FOPDT Parameter
• t1.7 sec.
• To0.8 sec
• K 0.1-.035 (cm-H20/
• 2nd Order system
• FOPDT Parameter to Find
• Kc
• ti

36
Root Locus Plots
37
Root Locus
38
Root Locus
39
(No Transcript)
40
PI Controller

• Direct Substitution Results
• Routh Method Results

41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
Disturbance Response 45-60
Damper closed for 30 seconds then opened for
remainder of experiment
47
Reset Wind-up 45-60 input
48
Conclusion

• Final FOPDT Parameter
• Taui3 sec.
• Kc 8
• These values will give stable operation
  throughout all ranges
