Title: Title: Arial 28pt'


1
PWB501 HTMLBridge - Moving a Client Server
Application to the Web
Franck Fasolin Application Development Division
Manager Fasolin_at_utac.com August 15-19, 2004
2
UTAC
  • private laboratory, 250 staff, 30M revenue
  • customers governement agencies, manufacturers,
    related industries
  • skills
  • agreement of road vehicles and equipment
  • engine pollution efficiency
  • noise, vibrations, electromagnetic emissions
  • active and passive security
  • others fluids, standards, certification

3
UTACs application farm
  • Local network
  • PowerBuilder Client/server applications
  • Client/server C ERP applications
  • HTML Intranet applications using ASP, ASP.NET,
    HTMLBridge
  • Laptop
  • Not connected PowerBuilder Client/server
    applications with database synchro
  • Internet connected HTML Intranet applications
    using HTMLBridge.
  • Extranet
  • JSP/J2EE applications with SAS Software data
    mining solutions
  • HTML applications using HTMLBridge
  • www.utac.com
  • HTML dynamic Web site using ASP

4
Franck Fasolin
  • Been using PowerBuilder for 12 years
  • Created many partner tools for PowerBuilder
    (commercial framework, security tool, translation
    tool, makeup tool)
  • Created HTMLBridge 7 years ago

5
Creating a Web application
  • Employees management Process
  • 1- Search for employees
  • 2- Display the resulting employee List
  • 3- Display the employee Form

1
2
3
6
Creating a Web application
  • The asp/jsp approach

Employee_search_srv
Employee_Query.xsp
Of_get_html_for_query_page() Of_search_for_employe
e(criterias) Of_get_html_for_employee_list()
Employee_list.xsp
Employee_form.xsp
Employee
Of_get_html_for_master_page(employee_data) Of_get_
html_for_detail_form() Of_get_html_for_tab_1_page(
) Of_get_html_for_tab_2_page() Of_save_employee()
Employee_save.xsp
7
Creating a Web application
  • The Client/server approach

Employee_List_window
Employee_form_window
Dw_employee_list Search button Query button
Dw_employee_master Tab_employee Dw_tabpage_1 Dw_ta
bpage_2 Save button
Clicked for search button Clicked for query
button DoubleClicked for dw_employee_list
Clicked for search button Clicked for query
button DoubleClicked for dw_employee_list
8
Creating a Web application
  • The HTMLBridge / ASP.Net / JSF approach
  • Nearly the same that the client/server approach
  • Introducting  Web windows  (web forms for
    ASP.net, faces for JSF)
  • Instroducing  Web controls
  • Intruducing  Server events

Employee_List_Web_window
Employee_form_web_window
Dw_employee_list Search button Query button
Dw_employee_master Tab_employee Dw_tabpage_1 Dw_ta
bpage_2 Save button
Clicked for search button Clicked for query
button Hyperlinkclicked for dw_employee_list Of_Ge
tHTML()
Clicked for search button Clicked for query
button DoubleClicked for dw_employee_list Of_get_H
TML()
9
Web windows
  • Each single process becomes a Web window (same as
    the client server approach)
  • Each Web window inherits from an ancestor class
    that is a NVO
  • The web window ancestor class has a of_get_html
    () method that generates the needed code to
    display what the user should see depending on his
    actions
  • Each Web window holds Web controls
  • A Web window is displayed as a HTML page in the
    Web Browser.
  • Specific to HTMLBridge Each HTML page
    displaying a Web window is made of frames in
    order to refresh only the part that has changed
    when the user made an action that needs the GUI
    to be refreshed.

10
Web controls
  • Each Web window includes Web controls
  • Each Web controls inherits from a specific
    ancestor class that is a NVO.
  • Each Web control ancestor class holds its own
    attributes declared as instance variables (.text,
    .x, .y, .width, .height, .dataobject)
  • Each ancestor of a Web control has a
    of_get_html() method that generated the needed
    code to display the control.

11
Server events
  • Each Web controls reacts to events depending on
    its ancestor class).
  • Those events can be triggerred by the end user
    from the graphical interface or by the
    application on the server
  • Example clicked, constructor, retrieveend
    ,open, any userevent defined by a developper

12
Creating the components
  • Create all ancestor NVOs (Web window ancestor,
    Web controls). They should have the same methods
    and instance variables than the PowerBuilder
    ones, plus a of_get_html() method that returns
    the needed HTML code to display the object.
  • Create a component that centralize all calls made
    by the Web browser from ASP or JSP pages and that
    instanciates all the needed objects (this would
    be the equivalent of the PowerBuilder application
    object and the PowerBuilder open() method).
  • Edit all your PowerBuilder windows source code
    and replace all Powerbuilder graphical ancestor
    classes (window,datawindow, command button) by
    your new NVO ancestor classes.
  • Rebuild your application.
  • You now have a Web application based on the Web
    window technology similar to ASP.NET Web forms.

13
Use HTMLBridge
  • Step 1 Describe your application logic by
    building a classic client-server application with
    PowerBuilder.

14
Use HTMLBridge
  • Step 2 Describe how it should look in a Web
    browser with HTMLBridges theme painter and
    Webzard Painter

15
  • Step 3 Ask HTMLBridge to generate non visual
    components that include all your application
    logic and that generate the needed HTML code for
    your application GUI.

16
Use HTMLBridge
  • Step 4 Deploy the generated components on your
    target web http server and your target
    application server. Access your application from
    any Web browser.

17
HTMLBridge coding restrictions
  • Only use datawindows or treeviews/listviews for
    data input, data display or reporting, avoid
    standard controls.
  • Do not use response windows with a
    closewithreturn statement.
  • Only one datawindow per tabpage (no other
    control).
  • Use command buttons for user actions (not only
    popmenus, menus or drag and drop).
  • Don 't display messageboxes that have more than
    one button.
  • Don 't overlay graphical objects.
  • Do not open more than one window at a time.
  • Only use datawindow controls for printing.
  • Don 't use custom graphical userobjects.
  • Do not refresh the screen display too often.
  • Dont use the PowerBuilder getfocus() function.
  • Prefer single menu MDI applications.
  • No edit mask for data input.
  • All input fields must be specified as "empty
    string is null".

18
HTMLbridge Supported features
  • All PowerBuilder object oriented features
    (inheritance, polymorphism, encapsulation)
  • Event driven applications (userevents)
  • PowerScript
  • Global variables, global functions
  • Main PowerBuilder datawindow features
  • PowerBuilders HTML Datawindow features
  • Data retrieval / update / sort / filter / XML
    support
  • Reporting, n-up, composite, Rich text mailing
    features, OLE support
  • Dropdown datawindows
  • Master/details datawindows
  • Sharedata datawindows
  • Treeviews, listviews, tabs, menus
  • Windows programming (DLL access, OLE Access to
    Microsoft office)
  • Corba Component server access (EAServer, Web
    sphere, Web logic)
  • COM component server access (Microsoft MTS)
  • Web services access

19
Benefits
  • Productivity (.powerbuilder)
  • Same source code for windows GUI and Web GUI
  • Ultra thin client (no javascript files
    downloaded, no activeX, no java applets).
    Applications can be accessed using a modem.
  • Web looking and behaving client
  • Customizable GUI (Set your own Web standards)
  • Clean Reporting (PDF files)
  • Ready for the future (Target GUI could be Windows
    longhorns XAML)
  • Microsoft world and Suns world (ASP or JSP)
  • Average learning time One day
  • Development process up to 1000 faster than other
    web technologies (for complex applications)
  • Average migration process time for existing
    PowerBuilder applications 10 to 20 of
    original development time
  • And much more
