Abhinav Engineering

1
Abhinav EngineeringJ.B.Associates

• INTRODUCTION

2
Mission Statement

• Abhinav Engineering with M/s. J.B. Associates
  committed to build an organisation to help in
  development of Process simplification, Ease in
  material handling, Automation, Mechanisation
  Pokka yoke

3
The Team

• This is fast growing organization with
  combination of New energetic young technical
  staff Highly experienced technical engineers.

4
Industries Requirements

• In past industries were production oriented since
  they have monopoly in the market and it was a
  sellers market.
• After globalisation lot of Multi National's and
  competitors arrived in the industries market.
  With the introduction of ISO, TQM, TPM, TS, etc
  the thinking of industries has take a shift from
  production to Quality system orientation, Which
  gives lot of boost to Process simplification,
  Ease in material handling, Automation,
  Mechanisation Pokka yoke etc.

5
Opportunities

• Opportunities
• The shift in the thinking from production to
  Quality System gives an opportunities for
  Automation, Mechanisation, etc for improvement
  consistency in product quality as well as human
  fatigue.

6
Our Concept

• We ( Abhinav Engineering J. B. Associates) have
  started working on the same concept of Low cost
  Automations, Mechanization, Material handling,
  Fool proofing, etc to help the different kind of
  industries since doing these concepts in house
  becomes difficult for different reasons for all
  industries.

7
Competition

• A healthy competition in small industries like us
  is there to give the best idea and the product at
  best price to serve the purpose of the big
  industries.
• Abhinav Engineering J.B. Associates have lot of
  advantages over their competitors like,
• New energetic young technical staff.
• Highly experienced technical engineers.
• Well equipped work shop.
• High quality products.

8
2 DIFFERENT MODEL TILTING UNIT FOR HEAVY HOUSING.

• Tilting unit for changing the location of
  the face.
• Equipment can be used for two different models
  with selector switch.
• Fully automatic with single push button start.
• Complete safety for antifouling sensors for
  different models.

9
1
2
1 Manipulator for lifting of Hood of
Tractor
2 lifting of Hood moving near Tractor
3 Fitting of Hood of on the Tractor
3
4
4 Next hood ready for next tractor
10
Elimination of Hammering Operation
1 Split dowel inserted manually.
B E F O R E
2 Dowel was use to hammered in the lever.
1
2
3 Split dowel is to inserted at the slot
provided in fixture.
A F T E R
3
4 The dowel is being safely pressed by
Hydraulic force.
4
11

• A complete pneumatically controlled system
  is developed.
• Hoist eliminated
• No need of tightening of bolts.
• No need of handling
• No Fatigue to operator
• Cycle time reduced

• Previous method
• Lifting of sealing plate by hoist
• Tightening of 18 Nos of bolts
• manually.
• Cycle time too high
• Bulky in handling
• Fatigue for operator

12
ELEMINATION OF MANUAL SPRING PRESSING FIXTURE
1
2
1 New modified fully Pneumatic operated equipment
2 Slider pressing Unit at back position
3
4
3 Slider at forward Position ready for Pressing
the spring
4 Spring pressed Ready for insertion Locking
pin.
13
SLIDING MECHANISM FOR BIG CASTINGS.
1

• SLIDING MECHANISM TO MOVE
• THE CASTING FROM
• CONVEYOR TO MACHINE.

2
2) SLIDING MECHANISM TO TAKE
BACK THE CASTING BACK TO
CONVEYOR TO KEEP THE AILE CLEAR
FOR MOVEMENT.
14
Oil seal Missing orientation wrong.
Before Status
1) Pneumatic ram was operating with out oil
seal. 2) Wrong orientation of oil seal was
possible with old mandrill. 3) Rework Cost was
more.
No arrangement to ensure the oil seal
1) Proxy Switch on Mandrill Sense the Presence of
oil Seal on mandrill passes signal to
Pneumatic System for Operation of Ram. 2)
Missing Wrong Orientation of oil Seal will
Not Operate the Proxy Switch which stop the
operation of ram. 3) Stopper is Provided
interlock with the Pneumatic Ram Operation.
1) Avoid oil seal Missing Wrong orientation. 2)
Cost of Rework saved.
Proxy Ensure the oil seal Presence.
After Status
15

• TOOLS AND TACKLES AS PER THE REQUIREMENT
• ROLLER CONVEYORS FOR MATERIAL MOVEMENT
• JIB CRANES
• DOLLYS FOR ASSAMBLY LINES
• HYDRAULIC POWER PACKS, PRESSES EQUIPMENTS
• INDUSTRIAL FABRICATION

We also design Manufactures
16
Thank you
17

• We will never rest in our endeavours to exceed
  your expections.
• As your patronage breathes life into our
  entwrprise Satisfaction is the key to our
  success
