MARMOT MPI Analysis and Checking Tool

1
MARMOT- MPI Analysis and Checking Tool
Bettina Krammer, Matthias Müller krammer_at_hlrs.de
, mueller_at_hlrs.de HLRS High Performance
Computing Center Stuttgart Allmandring 30 D-70550
Stuttgart http//www.hlrs.de

2
Overview

• General Problems of MPI Programming
• Related Work
• New Approach MARMOT
• Results within CrossGrid
• Outlook

3
Problems of MPI Programming

• All problems of serial programming
• Additional problems
• Increased difficulty to verify correctness of
  program
• Increased difficulty to debug N parallel
  processes
• Portability issues between different MPI
  implementations and platforms, e.g. with mpich on
  the Crossgrid testbed
• WARNING MPI_Recv tag 36003 gt 32767 ! MPI only
  guarantees tags up to this.
• THIS implementation allows tags up to 137654536
• versions of LAM-MPI lt v 7.0 only guarantee tags
  up to 32767
• New problems such as race conditions and deadlocks

4
Related Work

• Parallel Debuggers, e.g. totalview, DDT, p2d2
• Debug version of MPI Library
• Post-mortem analysis of trace files
• Special verification tools for runtime analysis
• MPI-CHECK
• Limited to Fortran
• Umpire
• First version limited to shared memory platforms
• Distributed memory version in preparation
• Not publicly available
• MARMOT

5
What is MARMOT?

• Tool for the development of MPI applications
• Automatic runtime analysis of the application
• Detect incorrect use of MPI
• Detect non-portable constructs
• Detect possible race conditions and deadlocks
• MARMOT does not require source code
  modifications, just relinking
• C and Fortran binding of MPI -1.2 is supported

6
Design of MARMOT
7
Basics of MARMOT

• Library written in C that will be linked to the
  application in addition to the underlying MPI
  library.
• This library consists of the debug server and the
  debug clients.
• No source code modification of the application is
  required.
• Additional process working as debug server, i.e.
  the application will have to be run with n1
  instead of n processes.

8
Basics of MARMOT (contd)

• Main interface MPI profiling interface
  according to MPI standard 1.2
• Implementation of C language binding of MPI
• Implementation of Fortran language binding as a
  wrapper to the C interface
• Environment variables for tool behaviour and
  output (report of errors, warnings and/or
  remarks, trace-back, etc.).
• MARMOT produces a human readable logfile.

9
Examples of Client Checks verification on the
local nodes

• Verification of proper construction and usage of
  MPI resources such as communicators, groups,
  datatypes etc., for example
• Verification of MPI_Request usage
• invalid recycling of active request
• invalid use of unregistered request
• warning if number of requests is zero
• warning if all requests are MPI_REQUEST_NULL
• Check for pending messages and active requests in
  MPI_Finalize
• Verification of all other arguments such as
  ranks, tags, etc.

10
Examples of Server Checks verification between
the nodes, control of program

• Everything that requires a global view
• Control the execution flow, trace the MPI calls
  on each node throughout the whole application
• Signal conditions, e.g. deadlocks (with traceback
  on each node.)
• Check matching send/receive pairs for consistency
• Check collective calls for consistency
• Output of human readable log file

11
MARMOT within CrossGrid
12
CrossGrid Application Tasks
13
CrossGrid Application WP 1.4 Air pollution
modelling (STEM-II)

• Air pollution modeling with STEM-II model
• Transport equation solved with Petrov-Crank-Nikols
  on-Galerkin method
• Chemistry and Mass transfer are integrated using
  semi-implicit Euler and pseudo-analytical methods
• 15500 lines of Fortran code
• 12 different MPI calls
• MPI_Init, MPI_Comm_size, MPI_Comm_rank,
  MPI_Type_extent, MPI_Type_struct,
  MPI_Type_commit, MPI_Type_hvector, MPI_Bcast,
  MPI_Scatterv, MPI_Barrier, MPI_Gatherv,
  MPI_Finalize.

14
STEM application on an IA32 cluster with Myrinet
15
CrossGrid Application WP 1.3 High Energy Physics

• Filtering of real-time data with neural networks
  (ANN application)
• 11500 lines of C code
• 11 different MPI calls
• MPI_Init, MPI_Comm_size, MPI_Comm_rank,
  MPI_Get_processor_name, MPI_Barrier, MPI_Gather,
  MPI_Recv, MPI_Send, MPI_Bcast, MPI_Reduce,
  MPI_Finalize.

16
HEP application on an IA32 cluster with Myrinet
17
CrossGrid Application WP 1.1 Medical Application

• Calculation of blood flow with Lattice-Boltzmann
  method
• Stripped down application with 6500 lines of C
  code
• 14 different MPI calls
• MPI_Init, MPI_Comm_rank, MPI_Comm_size, MPI_Pack,
  MPI_Bcast, MPI_Unpack, MPI_Cart_create,
  MPI_Cart_shift, MPI_Send, MPI_Recv, MPI_Barrier,
  MPI_Reduce, MPI_Sendrecv, MPI_Finalize

18
Medical application on an IA32 cluster with
Myrinet
19
Message statistics with native MPI
20
Message statistics with MARMOT
21
Medical application on an IA32 cluster with
Myrinet without barrier
22
Barrier with native MPI
23
Barrier with MARMOT
24
Conclusion

• MARMOT supports MPI 1.2 for C and Fortran binding
• Tested with several applications and benchmarks
• Tested on different platforms, using different
  compilers and MPI implementations, e.g.
• IA32/IA64 clusters (Intel, g compiler) with
  mpich (CrossGrid testbed, )
• IBM Regatta
• NEC SX5, SX6
• Hitachi SR8000, Cray T3e

25
Impact and Exploitation

• MARMOT is mentioned in the U.S. DoD High
  Performance Computing Modernization Program
  (HPCMP) Programming Environment and Training
  (PET) project as one of two freely available
  tools (MPI-Check and MARMOT) for the development
  of portable MPI programs.
• Contact with tool developers of the other 2 known
  verification tools like MARMOT (MPI-Check,
  umpire)
• Contact with users outside CrossGrid
• MARMOT has been presented at various conferences
  and publications
• http//www.hlrs.de/organization/tsc/projects/marmo
  t/pubs.html

26
Future Work

• Scalability and general performance improvements
• Better user interface to present problems and
  warnings
• Extended functionality
• more tests to verify collective calls
• MPI-2
• Hybrid programming

27
Thanks for your attentionAdditional information
and downloadhttp//www.hlrs.de/organization/tsc/
projects/marmot
Thanks to all CrossGrid partnershttp//www.eu-cro
ssgrid.org/
28
Back Up
29
Impact and Exploitation

• MARMOT is mentioned in the U.S. DoD High
  Performance Computing Modernization Program
  (HPCMP) Programming Environment and Training
  (PET) project as one of two freely available
  tools (MPI-Check and MARMOT) for the development
  of portable MPI programs.
• Contact with tool developers of the other 2 known
  verification tools like MARMOT (MPI-Check,
  umpire)
• MARMOT has been presented at various conferences
  and publications
• http//www.hlrs.de/organization/tsc/projects/marmo
  t/pubs.html

30
Impact and Exploitation contd

• Tescico proposal
• (Technical and Scientific Computing)
• French/German consortium
• Bull, CAPS Entreprise, Université Versailles,
• T-Systems, Intel Germany, GNS, Universität
  Dresden, HLRS
• ITEA-labelled
• French authorities agreed to give funding
• German authorities did not

31
Impact and Exploitation contd

• MARMOT is integrated in the HLRS training classes
• Deployment in GermanyMARMOT is in use in two of
  the 3 National High Performance Computing
  Centers
• HLRS at Stuttgart (IA32, IA64, NEC SX)
• NIC at Jülich (IBM Regatta)
• Just replaced their Cray T3E with a IBM Regatta
• spent a lot of time finding a problem that would
  have been detected automatically by MARMOT

32
Feedback of Crossgrid Applications

• Task 1.1 (biomedical)
• C application
• Identified issues
• Possible race conditions due to use of
  MPI_ANY_SOURCE
• deadlock
• Task 1.2 (flood)
• Fortran application
• Identified issues
• Tags outside of valid range
• Possible race conditions due to use of
  MPI_ANY_SOURCE
• Task 1.3 (hep)
• ANN (C application)
• no issues found by MARMOT
• Task 1.4 (meteo)
• STEMII (Fortran)
• MARMOT detected holes in self-defined datatypes
  used in MPI_Scatterv, MPI_Gatherv. These holes
  were removed, which helped to improve the
  performance of the communication.

33
Examples of Log File

• 54 rank 1 performs MPI_Cart_shift
• 55 rank 2 performs MPI_Cart_shift
• 56 rank 0 performs MPI_Send
• 57 rank 1 performs MPI_Recv
• WARNING MPI_Recv Use of MPI_ANY_SOURCE may
  cause race conditions!
• 58 rank 2 performs MPI_Recv
• WARNING MPI_Recv Use of MPI_ANY_SOURCE may
  cause race conditions!
• 59 rank 0 performs MPI_Send
• 60 rank 1 performs MPI_Recv
• WARNING MPI_Recv Use of MPI_ANY_SOURCE may
  cause race conditions!
• 61 rank 0 performs MPI_Send
• 62 rank 1 performs MPI_Bcast
• 63 rank 2 performs MPI_Recv
• WARNING MPI_Recv Use of MPI_ANY_SOURCE may
  cause race conditions!
• 64 rank 0 performs MPI_Pack
• 65 rank 2 performs MPI_Bcast
• 66 rank 0 performs MPI_Pack

34
Examples of Log File (continued)

• 7883 rank 2 performs MPI_Barrier
• 7884 rank 0 performs MPI_Sendrecv
• 7885 rank 1 performs MPI_Sendrecv
• 7886 rank 2 performs MPI_Sendrecv
• 7887 rank 0 performs MPI_Sendrecv
• 7888 rank 1 performs MPI_Sendrecv
• 7889 rank 2 performs MPI_Sendrecv
• 7890 rank 0 performs MPI_Barrier
• 7891 rank 1 performs MPI_Barrier
• 7892 rank 2 performs MPI_Barrier
• 7893 rank 0 performs MPI_Sendrecv
• 7894 rank 1 performs MPI_Sendrecv

35
Examples of Log File (Deadlock)

• 9310 rank 1 performs MPI_Sendrecv
• 9311 rank 2 performs MPI_Sendrecv
• 9312 rank 0 performs MPI_Barrier
• 9313 rank 1 performs MPI_Barrier
• 9314 rank 2 performs MPI_Barrier
• 9315 rank 1 performs MPI_Sendrecv
• 9316 rank 2 performs MPI_Sendrecv
• 9317 rank 0 performs MPI_Sendrecv
• 9318 rank 1 performs MPI_Sendrecv
• 9319 rank 0 performs MPI_Sendrecv
• 9320 rank 2 performs MPI_Sendrecv
• 9321 rank 0 performs MPI_Barrier
• 9322 rank 1 performs MPI_Barrier
• 9323 rank 2 performs MPI_Barrier
• 9324 rank 1 performs MPI_Comm_rank
• 9325 rank 1 performs MPI_Bcast
• 9326 rank 2 performs MPI_Comm_rank
• 9327 rank 2 performs MPI_Bcast
• 9328 rank 0 performs MPI_Sendrecv

36
Examples of Log File (Deadlock traceback on 0)

• timestamp 9298 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9300 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 1, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 2, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9304 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9307 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9309 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 1, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 2, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9312 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9317 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9319 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 1, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 2, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9321 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9328 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)

37
Examples of Log File (Deadlock traceback on 1)

• timestamp 9301 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 0, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9302 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9306 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 0, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 2, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9310 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 0, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9313 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9315 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 0, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 2, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9318 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 2, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 0, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9322 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9324 MPI_Comm_rank(comm
  MPI_COMM_WORLD, rank)
• timestamp 9325 MPI_Bcast(buffer, count 3,
  datatype MPI_DOUBLE, root 0, comm
  MPI_COMM_WORLD)

38
Examples of Log File (Deadlock traceback on 2)

• timestamp 9303 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 0, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9305 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9308 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 1, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 0, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9311 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 0, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9314 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9316 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 1, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 0, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9320 MPI_Sendrecv(sendbuf, sendcount
  7220, sendtype MPI_DOUBLE, dest 0, sendtag
  1, recvbuf, recvcount 7220, recvtype
  MPI_DOUBLE, source 1, recvtag 1, comm
  self-defined communicator, status)
• timestamp 9323 MPI_Barrier(comm
  MPI_COMM_WORLD)
• timestamp 9326 MPI_Comm_rank(comm
  MPI_COMM_WORLD, rank)
• timestamp 9327 MPI_Bcast(buffer, count 3,
  datatype MPI_DOUBLE, root 0, comm
  MPI_COMM_WORLD)

39
Classical Solutions I Parallel Debugger

• Examples totalview, DDT, p2d2
• Advantages
• Same approach and tool as in serial case
• Disadvantages
• Can only fix problems after and if they occur
• Scalability How can you debug programs that
  crash after 3 hours on 512 nodes?
• Reproducibility How to debug a program that
  crashes only every fifth time?
• It does not help to improve portability

40
Classical Solutions II Debug version of MPI
Library

• Examples
• catches some incorrect usage e.g. node count in
  MPI_CART_CREATE (mpich)
• deadlock detection (NEC mpi)
• Advantages
• good scalability
• better debugging in combination with totalview
• Disadvantages
• Portability only helps to use this
  implementation of MPI
• Trade-of between performance and safety
• Reproducibility Does not help to debug
  irreproducible programs

41
Comparison with related projects
42
Comparison with related projects
43
Examples
44
Example 1 request-reuse (source code)

• /
• Here we re-use a request we didn't free before
• /
• include ltstdio.hgt
• include ltassert.hgt
• include "mpi.h"
• int main( int argc, char argv )
• int size -1
• int rank -1
• int value -1
• int value2 -1
• MPI_Status send_status, recv_status
• MPI_Request send_request, recv_request
• printf( "We call Irecv and Isend with non-freed
  requests.\n" )
• MPI_Init( argc, argv )
• MPI_Comm_size( MPI_COMM_WORLD, size )

45
Example 1 request-reuse (source code continued)

• if( rank 0 )
• / this is just to get the request used
  /
• MPI_Irecv( value, 1, MPI_INT, 1, 18,
  MPI_COMM_WORLD, recv_request )
• / going to receive the message and reuse a
  non-freed request /
• MPI_Irecv( value, 1, MPI_INT, 1, 17,
  MPI_COMM_WORLD, recv_request )
• MPI_Wait( recv_request, recv_status )
• assert( value 19 )
• if( rank 1 )
• value2 19
• / this is just to use the request /
• MPI_Isend( value, 1, MPI_INT, 0, 18,
  MPI_COMM_WORLD, send_request )
• / going to send the message /
• MPI_Isend( value2, 1, MPI_INT, 0, 17,
  MPI_COMM_WORLD, send_request )
• MPI_Wait( send_request, send_status )
• MPI_Finalize()
• return 0

46
Example 1 request-reuse (output log)

• We call Irecv and Isend with non-freed
  requests.
• 1 rank 0 performs MPI_Init
• 2 rank 1 performs MPI_Init
• 3 rank 0 performs MPI_Comm_size
• 4 rank 1 performs MPI_Comm_size
• 5 rank 0 performs MPI_Comm_rank
• 6 rank 1 performs MPI_Comm_rank
• I am rank 0 of 2 PEs
• 7 rank 0 performs MPI_Irecv
• I am rank 1 of 2 PEs
• 8 rank 1 performs MPI_Isend
• 9 rank 0 performs MPI_Irecv
• 10 rank 1 performs MPI_Isend
• ERROR MPI_Irecv Request is still in use !!
• 11 rank 0 performs MPI_Wait
• ERROR MPI_Isend Request is still in use !!
• 12 rank 1 performs MPI_Wait
• 13 rank 0 performs MPI_Finalize
• 14 rank 1 performs MPI_Finalize

47
Example 2 deadlock (source code)

• / This program produces a deadlock.
• At least 2 nodes are required to run the
  program.
• Rank 0 recv a message from Rank 1.
• Rank 1 recv a message from Rank 0.
• AFTERWARDS
• Rank 0 sends a message to Rank 1.
• Rank 1 sends a message to Rank 0.
• /
• include ltstdio.hgt
• include "mpi.h"
• int main( int argc, char argv )
• int rank 0
• int size 0
• int dummy 0
• MPI_Status status

48
Example 2 deadlock (source code continued)

• MPI_Init( argc, argv )
• MPI_Comm_rank( MPI_COMM_WORLD, rank )
• MPI_Comm_size( MPI_COMM_WORLD, size )
• if( size lt 2 )
• fprintf( stderr," This program needs at least
  2 PEs!\n" )
• else
• if ( rank 0 )
• MPI_Recv( dummy, 1, MPI_INT, 1, 17,
  MPI_COMM_WORLD, status )
• MPI_Send( dummy, 1, MPI_INT, 1, 18,
  MPI_COMM_WORLD )
• if( rank 1 )
• MPI_Recv( dummy, 1, MPI_INT, 0, 18,
  MPI_COMM_WORLD, status )
• MPI_Send( dummy, 1, MPI_INT, 0, 17,
  MPI_COMM_WORLD )
• MPI_Finalize()

49
Example 2 deadlock (output log)

• mpirun -np 3 deadlock1
• 1 rank 0 performs MPI_Init
• 2 rank 1 performs MPI_Init
• 3 rank 0 performs MPI_Comm_rank
• 4 rank 1 performs MPI_Comm_rank
• 5 rank 0 performs MPI_Comm_size
• 6 rank 1 performs MPI_Comm_size
• 7 rank 0 performs MPI_Recv
• 8 rank 1 performs MPI_Recv
• 8 Rank 0 is pending!
• 8 Rank 1 is pending!
• WARNING deadlock detected, all clients are
  pending

50
Example 2 deadlock (output log continued)

• Last calls (max. 10) on node 0
• timestamp 1 MPI_Init( argc, argv )
• timestamp 3 MPI_Comm_rank( comm, rank )
• timestamp 5 MPI_Comm_size( comm, size )
• timestamp 7 MPI_Recv( buf, count -1,
  datatype non-predefined datatype, source -1,
  tag -1, comm, status)
• Last calls (max. 10) on node 1
• timestamp 2 MPI_Init( argc, argv )
• timestamp 4 MPI_Comm_rank( comm, rank )
• timestamp 6 MPI_Comm_size( comm, size )
• timestamp 8 MPI_Recv( buf, count -1,
  datatype non-predefined datatype, source -1,
  tag -1, comm, status )

51
Bandwidth on a IA64 cluster with Myrinet
52
Latency on an IA64 cluster with Myrinet
53
cg.B on an IA32 cluster with Myrinet
54
is.B on an IA32 cluster with Myrinet
55
is.A
