Title: Remediation%20is%20Enhanced%20Oil%20Recovery:%20Know%20Your%20Source


1
Remediation is Enhanced Oil Recovery Know Your
Source
  • G.D. Beckett, R.G., C.HG.
  • AQUI-VER, INC. SDSU
  • g.d.beckett_at_aquiver.com
  • gbeckett_at_geology.sdsu.edu

2
Which Scenario Works Best?
Oil
Oil
3
Its Sort Of Obvious..
  • EP expends effort knowing oil distribution
  • Aim for the oil
  • Missing the oil misses revenues
  • Environmental restoration has a more spotty
    record
  • Sampling difficulty below water tables
  • Some misnomers misconceptions about NAPL
  • Thickness exaggeration
  • Sorption vs. residual
  • Dissolved-phase thinking
  • Hydrologic time bias in most environmental data
    sets

4
Talk Outline
  • A few source principles observations
  • Chemistry will not be discussed
  • Focus is source location relative to cleanup
    mechanisms
  • Site examples where the source zone was missed
  • Site example where source zone was pegged
  • Conclusions

5
NAPL is the Source of Risk
Gasoline LNAPL Mass
Equivalent Volumes
Water, Vapor Sorbed Mass
6
Schematic of LNAPL Source Distribution
I
II
III
I
II
III
IV
V
IV
V
7
Equilibrium LNAPL Saturation(uniform dune sand)
3
2
Z above oil/water interface (ft)
1
LNAPL
Predicted Saturations
Measured Saturations
0
0.00
0.05
0.10
0.15
0.20
0.25
0.30
Hydrocarbon Saturation
8
LNAPL Saturation in Heterogeneous
Soil(interbedded silty sands and sand)

250
200
150
100

Z Above Oil/Water Interface (cm)
LNAPL
50
M
e
a
s
u
r
e
d

P
r
e
d
i
c
t
e
d

0
O
2
H
-50
0.0
0.1
0.2
0.3
0.4
0.5
0.6
Hydrocarbon Saturation
after Huntley et al., 1997
9
PHOTOGRAPH OF NAPL GANGLIA
Courtesy of Daugherty Peuron Orange County
Health Care Agency
10
A Peak Into the Pore Domain (brine to oil
mobility spectrum)
Courtesy of Terra Tek, Salt Lake City, UT
11
The SitesTwo Misses One Hit
  • Site 1 Service station adjacent to tidal stream
  • Tidal influence affects product distribution
    cleanup
  • Several years of cleanup have not changed gw
    impacts
  • Site 2 Service station with deep vadose zone
  • Rise in gw table strands product
  • 5 years of cleanup with no meaningful gw benefit
  • Site 3 Former fuel terminal with effective
    targeting
  • Dewatering with enhanced airflow delivery
  • Source zone characterization was key to success

12
SITE 1
  • Gasoline LNAPL Adjacent to Tidal Stream

13
Site Plan Plume Map
gw flow
14
LNAPL Source Geologic Distribution(after the
fact)
CB-1
CB-3
CB-4
CB-7
CB-6
CB-10
-
5
.
0
-
1
0
.
0
-
1
5
.
0
-
2
0
.
0
0
2
0
4
0
6
0
8
0
1
0
0
1
2
0
S
e
c
t
i
o
n
D
i
s
t
a
n
c
e
(
f
t
)
L
I
F
I
n
t
e
n
s
i
t
y
C
o
n
t
o
u
r
15
Remediation Actions
  • Horizontal IAS, 18 fbg, uncontrolled flow
    responses
  • Airflow in creek
  • No direct capture by SVE
  • SVE from available wells, pulling upper zone
  • Groundwater pumping skimming
  • Combined SVE groundwater recovery

16
Remediation Results after 7 years
  • Free product thickness decrease in wells
  • Product still present at low water stands
  • No statistical reduction in gw concentrations
  • Product discharges to adjacent creek
  • Despite hydraulic containment in water phase
  • System upsizing to pump more water
  • Increase drawdown into deeper impact zone
  • Force airflow into dewatered zone

17
SITE 2
  • Stranded LNAPL from Groundwater Rise
  • No gw benefit from SVE Pumping

18
Site Plan Initial Plume Distribution
19
Schematic Cross-Section
SVE Pumping Well
Dispensers
UST
Sandstone
F.P. Zone
Shale
20
Site Groundwater Elevation Hydrograph
21
SVE/PT System Summary 1991-1996
  • Low flow gw pumping planned (lt 2 gpm)
  • Never really ran much, head loss issues
  • No effective dewatering
  • Water level rise over period of cleanup
  • SVE from multilevel screens
  • Packers not maintained by new contractor
  • SVE from full interval
  • gt 10,000 ppmv TPH initial to 500 ppmv final
  • However, discrete well sampling 9,600 ppmv
    final

22
Chemical Hydrograph, Sentry Well MW-8
23
Site Plan Post SVE/Pumping Plume
24
Site Plan Initial Plume Distribution
25
Site 2 Wrap Up
  • Water table rose
  • No effective dewatering of smear zone
  • SVE did not access full smear zone
  • Ran to asymptotic
  • Lower zone pneumatically inefficient
  • Dissolved concentrations unchanged at key points
  • Despite this, no risk site obtained NFA status

26
Fuel Terminal Operations Site
  • LNAPL Smear Found Targeted
  • Highly Effective Remediation Response

27
General Site Conditions
  • AST terminal operation sources
  • Heterogeneous, interbedded fine materials
  • Water table approx. 15 feet below grade (fbg)
  • Observed free product gasoline in 12 wells
  • Widespread dissolved phase impacts
  • Initial TPHg max 500,000 ug/L
  • Initial Benzene max 58,000 ug/L
  • Initial MTBE max 24,000 ug/L

28
Site Plan Plume Width ? 600 ft
29
Original Lithology Source Understanding
30
Updated Source Lithologic Setting
75
70
65
60
55
Elevation (ft msl)
50
45
LNAPL zones
40
35
30
0
25
50
75
100
125
Section Distance (ft)
Sands
Clays/silts
Silty Sands
31
Changes in Thinking
  • LNAPL stranded below, not at the water table
  • Original design unable to access impacted zones
  • Went to dewatering, enhanced airflow strategy
  • Specific target smear zone
  • Large improvement in subsurface cleanup
    efficiency
  • Large improvement in mass per unit time per cost

32
Estimated Cleanup Improvement Factor(multiphase
calculations)
14
13
12
11
10
Stratigraphic Elevation (m)
9
8
7
6
Area 1
Area 2
5
4
0.0
20
40
60
80
100
Mass Recovery Improvement Factor
33
MTBE Through Remediation
34
Benzene Through Remediation
35
Recovery to Date
  • Full hydraulic capture
  • 400,000 lbs TPH recovered over 6 months
  • 18,000 as free phase 2,000 in water phase
    15,000 in biodecay 365,000 in vapor phase
  • Free product no longer observed in cleanup area
  • 80-day removal, multiphase estimate was 2-3
    months
  • Orders of magnitude reduction in MTBE benzene
  • On average and against pre-cleanup maximums
  • Mole fraction changes consistent with principles

36
Conclusions
  • Targeting depends first on knowing smear zone
  • Common limitations to characterization efforts
  • Like EP, no oil, no production
  • Efficient designs directly access smear zone
  • Geologic efficiency is order of magnitude
  • Tracking of success is fairly straightforward
  • Chemical milestones, molar otherwise
  • Physical relationships between fluid zones
  • No matter what, you cannot have it all
  • Some soil zones wont produce in any phase
  • Always uncertainty in geologic distributions
