AQUATIC ANIMAL PRODUCTION INDUSTRY EFFLUENT GUIDELINES

1
AQUATIC ANIMAL PRODUCTION INDUSTRY EFFLUENT
GUIDELINES

• January 27, 2002

2
Possible Rulemaking Outcomes

• No Regulation or Regulation
• Entire Industry Category
• Certain Subcategories
• Certain Size Facilities of a Given
  Subcategory(ies)
• For No Regulation, options include
• EPA issues guidance - BMPs (e.g. voluntary
  approaches, incentive programs)
• EPA does not issue guidance

3
Possible Rulemaking Outcomes (Continued)

• For regulation, options include
• EPA establishes numeric limitations
• EPA develops BMPs
• EPA develops combination of numeric limitations
  and BMPs
• Different levels of stringency by industry
  subcategories
• levels of stringency are based on a number of
  factors (e.g., economic impacts, size, production
  systems, discharge levels, performance of control
  technology/practices) and can vary for each
  subcategory. For example
• Subcategory A no regulation
• Subcategory B least stringent option considered
• Subcategory C more stringent option considered

4
Major Milestones

• SBREFA
• Management Selects Options Winter 2001/2002
• Interagency Review Spring 2002
• Proposed Rule June 2002
• Notice of Data Availability Summer 2003
• Interagency Review (Final Rule) Spring 2004
• Final Rule June 2004

5
SBREFA

• Outreach to Small Entity Representatives
  December 2001
• Small Business Panel Convenes January 2002
• Small Business Panel Concludes
• March 2002

6
Proposed Rule

• Administrator Signs Proposal June 30, 2002
• Proposal Published in Federal Register July
  2002
• Comment Period - Probably 60 days

7
Current Activities

• Data Collection Activities
• Subcategorization
• Options under consideration
• Pollutants
• Costs and Loadings
• Economic Impact Analyses

8
Screener Survey Results to Date

• Summary of Response Rate
• 5989 surveys have been mailed
• 4856 surveys have been received
• 130 Duplicates
• 80 Returned blank
• 500 Returned unopened
• Re-mailings will be made to incorrect addresses
• Follow-up actions for non-responses enforcement
  letter

9
Subcategorization Analysis Factors Being
Assessed

• System type and water management strategy
• Species
• Facility age
• Facility location
• Facility size
• Feed type and feeding rate
• Non-water quality environmental impacts
• Disproportionate economic impacts

10
Model Facility Approach

• Facility-specific
• Detailed process information for specific
  facilities
• Model Facility
• Reasonable representation of the industry
• Reflect the different characteristics of the
  industry

11
Model Facility Approach Sources of Data

• Site visits and sampling
• Information from industry members and
  associations
• Screener and detailed survey
• Aquaculture census
• Published information

12
Loadings Approach
Food
Oxygen
Water In
Biomass

• Mass Balance on annual basis
• Predict Effluent Quality
• Determine relationship of feed input to effluent
  quality

13
Pollutants Of Interest

• Total Suspended Solids
• Nutrients
• Nitrogen
• Phosphorus
• BOD
• Microbiologicals
• Drugs and Chemicals

14
Cost Methodology

• Identify Candidate BMPs and Treatment
  Technologies Regulatory Options
• Develop Cost Equations BMPs and Treatment
  Technologies
• Develop Computer Models Compliance Costs and
  Loadings
• Estimate Total Annualized Costs and Economic
  Impacts

15
Cost Methodology (continued)

• Cost and financial estimates for each model
  facility
• Industry-level costs calculated
• Number of facilities
• x
• Model facility cost

16
Estimating the Number of Facilities

• USDA Aquaculture Census
• Screener Survey

17
Costs

• Capital costs
• Land Equipment
• One-time non capital costs
• Consulting Services
• Annual operation and maintenance costs
• Labor
• Equipment

18
Frequency Factors

• Used to adjust for BMPs and Treatment Technology
  options that already exist in the industry

19
Example of Frequency Factor Use

• Catfish Farms practice water level management
  100 (based on information from site visits and
  JSA)
• Therefore, no costs included for water level
  management

20
Options Being Considered

• System Specific Options
• Best Management Practices
• Treatment Technologies
• Risk Minimization Strategies

21
Status of Revisions

• As we discuss the different aspects of the rule,
  we will indicate the changes that have occurred.
• Changes have been made to reflect input from
  various sources and refinement of the options

22
Treatment Technologies and Best Management
Practices

• Baseline- practices and technologies existing at
  most facilities and primary feature is solids
  removal
• Option 1 considers the development of a BMP Plan
  (HACCP-like approach) to control conventional and
  nutrient pollutants also to address escapes,
  fish pathogens, and drugs and chemicals

23
Treatment Technologies and Best Management
Practices

• Baseline- practices and technologies existing at
  most facilities and primary feature is solids
  removal
• Option 1 considers the development of a BMP Plan
  (HACCP-like approach) to control conventional and
  nutrient pollutants also to address escapes,
  fish pathogens, and drugs and chemicals

24
Treatment Technologies and Best Management
Practices

• Option 2 considers additional solids removal and
  establishes a numeric limit for TSS
• Option 3 considers additional treatment for
  specific pollutants such as disinfection to
  control microorganisms and establish limits for
  total coliform

25
Treatment Technologies and Best Management
Practices

• Option 2 considers additional solids removal and
  establishes a numeric limit for TSS
• Option 3 considers additional treatment for
  specific pollutants such as disinfection to
  control microorganisms and establish limits for
  total coliform

26
Pond Systems
27
Pond Systems
28
Treatment Technologies and Best Management
Practices

• Baseline
• Ponds - Feed management, In-pond treatment, Water
  Management, Discharge Management
• Flow through - Feed Management, Quiescent Zones,
  Sedimentation Basins
• Recirculating- Feed Management, Sedimentation
  basins
• Net Pens Feed Management

29
Treatment Technologies and Best Management
Practices

• Option 1 - BMP Plan (referred to as PACCP)
• Identifies ways to minimize or control aquatic
  animal pathogens, nonnative species, drug and
  chemical usage.
• The BMP plan consists of same approach for all
  production systems

30
Treatment Technologies and Best Management
Practices

• Option 2 Additional treatment of TSS
• Ponds- Vegetated ditches, in-pond
  settling(holding water), settling basins
• Flow through microscreen filters
• Recirculating microscreen filters
• Net Pens active monitoring

31
Treatment Technologies and Best Management
Practices

• Option 3 Additional Treatment for Specific
  Pollutants
• Ponds Constructed Wetlands (nutrients)
• Flow-through Disinfection (bacteria associated
  with manure storage)
• Recirculating Systems Disinfection (bacteria
  associated with manure storage)

32
NPDES Concentrated Aquatic Animal Production
Facility Definition

• EPA considering revising the National Pollutant
  Discharge Elimination System (NPDES) definition
  of a Concentrated Aquatic Animal Production
  Facility (CAAPF).

33
NPDES Concentrated Aquatic Animal Production
Facility Definition

• As part of the effluent guidelines rulemaking
  development, EPA is evaluating aquatic animal
  facilities as a whole to determine the
  applicability of the effluent guidelines.

34
NPDES Concentrated Aquatic Animal Production
Facility Definition

• Should EPA determine that the effluent guidelines
  apply to facilities that are excluded from the
  current NPDES CAAPF definition, EPA may decide to
  change the NPDES definition.

35
Additional Considerations

• For Land Application of Manure (similar to CAFOs)
• Determine N P content
• Record keeping requirements
• Amount of manure disposed
• Frequency of disposal
• Person/entity receiving manure

36
Additional information

• To obtain additional information on the
  development or progress of the aquaculture
  guidelines
• http//www.epa.gov/OST/guide/aquaculture
• http//ag.ansc.purdue.edu/aquanic/jsa/effluents/in
  dex.html

37
Additional information

• For technical information
• Marta Jordan [phone]
• Jan Goodwin [phone]
• For economic technical information
• Kristen Strellec [phone]

38
Types of Systems VisitedTotal 74
39
Regional Distribution of Facilities
40
Species
41
Sampling Events
42
Sampling Analytes

• Solids TSS, TDS, SS, TVS
• Nitrogen NH3, NO2/NO3, TKN
• Phosphorus TP, Dissolved P, Ortho P
• Oil grease
• BOD, TOC, COD
• Metals
• Organic compounds (volatile and semivolatile
  compounds)
• Microbiologicals
