Learning to Rank (part 1)

1
Learning to Rank (part 1)

• NESCAI 2008 Tutorial
• Yisong Yue
• Cornell University

2
Booming Search Industry
3
Goals for this Tutorial

• Basics of information retrieval
• What machine learning contributes
• New challenges to address
• New insights on developing ML algorithms

4
(Soft) Prerequisites

• Basic knowledge of ML algorithms
• Support Vector Machines
• Neural Nets
• Decision Trees
• Boosting
• Etc
• Will introduce IR concepts as needed

5
Outline (Part 1)

• Conventional IR Methods (no learning)
• 1970s to 1990s
• Ordinal Regression
• 1994 onwards
• Optimizing Rank-Based Measures
• 2005 to present

6
Outline (Part 2)

• Effectively collecting training data
• E.g., interpreting clickthrough data
• Beyond independent relevance
• E.g., diversity
• Summary Discussion

7
Disclaimer

• This talk is very ML-centric
• Use IR methods to generate features
• Learn good ranking functions on feature space
• Focus on optimizing cleanly formulated objectives
• Outperform traditional IR methods

8
Disclaimer

• This talk is very ML-centric
• Use IR methods to generate features
• Learn good ranking functions on feature space
• Focus on optimizing cleanly formulated objectives
• Outperform traditional IR methods
• Information Retrieval
• Broader than the scope of this talk
• Deals with more sophisticated modeling questions
• Will see more interplay between IR and ML in Part
  2

9
Brief Overview of IR

• Predated the internet
• As We May Think by Vannevar Bush (1945)
• Active research topic by the 1960s
• Vector Space Model (1970s)
• Probabilistic Models (1980s)
• Introduction to Information Retrieval (2008)
• C. Manning, P. Raghavan H. Schütze

10
Basic Approach to IR

• Given query q and set of docs d1, dn
• Find documents relevant to q
• Typically expressed as a ranking on d1, dn

11
Basic Approach to IR

• Given query q and set of docs d1, dn
• Find documents relevant to q
• Typically expressed as a ranking on d1, dn
• Similarity measure sim(a,b)!R
• Sort by sim(q,di)
• Optimal if relevance of documents are
  independent. Robertson, 1977

12
Vector Space Model

• Represent documents as vectors
• One dimension for each word
• Queries as short documents
• Similarity Measures
• Cosine similarity normalized dot product

13
Cosine Similarity Example
14
Other Methods

• TF-IDF
• Salton Buckley, 1988
• Okapi BM25
• Robertson et al., 1995
• Language Models
• Ponte Croft, 1998
• Zhai Lafferty, 2001

15
Machine Learning

• IR uses fixed models to define similarity scores
• Many opportunities to learn models
• Appropriate training data
• Appropriate learning formulation
• Will mostly use SVM formulations as examples
• General insights are applicable to other
  techniques.

16
Training Data

• Supervised learning problem
• Document/query pairs
• Embedded in high dimensional feature space
• Labeled by relevance of doc to query
• Traditionally 0/1
• Recently ordinal classes of relevance (0,1,2,3,)

17
Feature Space

• Use to learn a similarity/compatibility function
• Based off existing IR methods
• Can use raw values
• Or transformations of raw values
• Based off raw words
• Capture co-occurrence of words

18
Training Instances
19
Learning Problem

• Given training instances
• (xq,d, yq,d) for q 1..N, d 1 .. Nq
• Learn a ranking function
• f(xq,1, xq,Nq ) ! Ranking
• Typically decomposed into per doc scores
• f(x) ! R (doc/query compatibility)
• Sort by scores for all instances of a given q

20
How to Train?

• Classification Regression
• Learn f(x) ! R in conventional ways
• Sort by f(x) for all docs for a query
• Typically does not work well
• 2 Major Problems
• Labels have ordering
• Additional structure compared to multiclass
  problems
• Severe class imbalance
• Most documents are not relevant

21
Somewhat Relevant
Very Relevant
Not Relevant
Conventional multiclass learning does not
incorporate ordinal structure of class labels
22
Somewhat Relevant
Very Relevant
Not Relevant
Conventional multiclass learning does not
incorporate ordinal structure of class labels
23
Ordinal Regression

• Assume class labels are ordered
• True since class labels indicate level of
  relevance
• Learn hypothesis function f(x) ! R
• Such that the ordering of f(x) agrees with label
  ordering
• Ex given instances (x, 1), (y, 1), (z, 2)
• f(x) lt f(z)
• f(y) lt f(z)
• Dont care about f(x) vs f(y)

24
Ordinal Regression

• Compare with classification
• Similar to multiclass prediction
• But classes have ordinal structure
• Compare with regression
• Doesnt necessarily care about value of f(x)
• Only care that ordering is preserved

25
Ordinal Regression Approaches

• Learn multiple thresholds
• Learn multiple classifiers
• Optimize pairwise preferences

26
Option 1 Multiple Thresholds

• Maintain T thresholds (b1, bT)
• b1 lt b2 lt lt bT
• Learn model parameters (b1, , bT)
• Goal
• Model predicts a score on input example
• Minimize threshold violation of predictions

27
Ordinal SVM Example
Chu Keerthi, 2005
28
Ordinal SVM Formulation
Such that for j 0..T
And also
Chu Keerthi, 2005
29
Learning Multiple Thresholds

• Gaussian Processes
• Chu Ghahramani, 2005
• Decision Trees
• Kramer et al., 2001
• Neural Nets
• RankProp Caruana et al., 1996
• SVMs Perceptrons
• PRank Crammer Singer, 2001
• Chu Keerthi, 2005

30
Option 2 Voting Classifiers

• Use T different training sets
• Classifier 1 predicts 0 vs 1,2,T
• Classifier 2 predicts 0,1 vs 2,3,T
• Classifier T predicts 0,1,,T-1 vs T
• Final prediction is combination
• E.g., sum of predictions
• Recent work
• McRank Li et al., 2007
• Qin et al., 2007

31

• Severe class imbalance
• Near perfect performance by always predicting 0

32
Option 3 Pairwise Preferences

• Most popular approach for IR applications
• Learn model to minimize pairwise disagreements
• (Pairwise Agreements) ROC-Area

33

• 2 pairwise disagreements

34
Optimizing Pairwise Preferences

• Consider instances (x1,y1) and (x2,y2)
• Label order has y1 gt y2

35
Optimizing Pairwise Preferences

• Consider instances (x1,y1) and (x2,y2)
• Label order has y1 gt y2
• Create new training instance
• (x, 1) where x (x1 x2)
• Repeat for all instance pairs with label order
  preference

36
Optimizing Pairwise Preferences

• Result new training set!
• Often represented implicitly
• Has only positive examples
• Mispredicting means that a lower ordered instance
  received higher score than higher order instance.

37
Pairwise SVM Formulation
Such that
Herbrich et al., 1999
Can be reduced to time
Joachims, 2005.
38
Optimizing Pairwise Preferences

• Neural Nets
• RankNet Burges et al., 2005
• Boosting Hedge-Style Methods
• Cohen et al., 1998
• RankBoost Freund et al., 2003
• Long Servidio, 2007
• SVMs
• Herbrich et al., 1999
• SVM-perf Joachims, 2005
• Cao et al., 2006

39
Rank-Based Measures

• Pairwise Preferences not quite right
• Assigns equal penalty for errors no matter where
  in the ranking
• People (mostly) care about top of ranking
• IR community use rank-based measures which
  capture this property.

40
Rank-Based Measures

• Binary relevance
• Precision_at_K (P_at_K)
• Mean Average Precision (MAP)
• Mean Reciprocal Rank (MRR)
• Multiple levels of relevance
• Normalized Discounted Cumulative Gain (NDCG)

41
Precision_at_K

• Set a rank threshold K
• Compute relevant in top K
• Ignores documents ranked lower than K
• Ex
• Prec_at_3 of 2/3
• Prec_at_4 of 2/4
• Prec_at_5 of 3/5

42
Mean Average Precision

• Consider rank position of each relevance doc
• K1, K2, KR
• Compute Precision_at_K for each K1, K2, KR
• Average precision average of P_at_K
• Ex has AvgPrec of
• MAP is Average Precision across multiple
  queries/rankings

43
Mean Reciprocal Rank

• Consider rank position, K, of first relevance doc
• Reciprocal Rank score
• MRR is the mean RR across multiple queries

44
NDCG

• Normalized Discounted Cumulative Gain
• Multiple Levels of Relevance
• DCG
• contribution of ith rank position
• Ex has DCG score of
• NDCG is normalized DCG
• best possible ranking as score NDCG 1

45
Optimizing Rank-Based Measures

• Lets directly optimize these measures
• As opposed to some proxy (pairwise prefs)
• But
• Objective function no longer decomposes
• Pairwise prefs decomposed into each pair
• Objective function flat or discontinuous

46
Discontinuity Example
D1 D2 D3
Retrieval Score 0.9 0.6 0.3
Rank 1 2 3
Relevance 0 1 0

• NDCG 0.63

47
Discontinuity Example

• NDCG computed using rank positions
• Ranking via retrieval scores

D1 D2 D3
Retrieval Score 0.9 0.6 0.3
Rank 1 2 3
48
Discontinuity Example

• NDCG computed using rank positions
• Ranking via retrieval scores
• Slight changes to model parameters
• Slight changes to retrieval scores
• No change to ranking
• No change to NDCG

D1 D2 D3
Retrieval Score 0.9 0.6 0.3
Rank 1 2 3
49
Discontinuity Example

• NDCG computed using rank positions
• Ranking via retrieval scores
• Slight changes to model parameters
• Slight changes to retrieval scores
• No change to ranking
• No change to NDCG

NDCG discontinuous w.r.t model parameters!
D1 D2 D3
Retrieval Score 0.9 0.6 0.3
Rank 1 2 3
50
Yue Burges, 2007
51
Optimizing Rank-Based Measures

• Relaxed Upper Bound
• Structural SVMs for hinge loss relaxation
• SVM-map Yue et al., 2007
• Chapelle et al., 2007
• Boosting for exponential loss relaxation
• Zheng et al., 2007
• AdaRank Xu et al., 2007
• Smooth Approximations for Gradient Descent
• LambdaRank Burges et al., 2006
• SoftRank GP Snelson Guiver, 2007

52
Structural SVMs

• Let x denote the set of documents/query examples
  for a query
• Let y denote a (weak) ranking
• Same objective function
• Constraints are defined for each incorrect
  labeling y over the set of documents x.
• After learning w, a prediction is made by
  sorting on wTxi

Tsochantaridis et al., 2007
53
Structural SVMs for MAP

• Maximize
• subject to
• where
  ( yij -1, 1 )

• and
• Sum of slacks upper bound MAP loss.

Yue et al., 2007
54
Too Many Constraints!

• For Average Precision, the true labeling is a
  ranking where the relevant documents are all
  ranked in the front, e.g.,
• An incorrect labeling would be any other ranking,
  e.g.,
• This ranking has Average Precision of about 0.8
  with ?(y,y) ¼ 0.2
• Intractable number of rankings, thus an
  intractable number of constraints!

55
Structural SVM Training

• STEP 1 Solve the SVM objective function using
  only the current working set of constraints.
• STEP 2 Using the model learned in STEP 1, find
  the most violated constraint from the exponential
  set of constraints.
• STEP 3 If the constraint returned in STEP 2 is
  more violated than the most violated constraint
  the working set by some small constant, add that
  constraint to the working set.
• Repeat STEP 1-3 until no additional constraints
  are added. Return the most recent model that was
  trained in STEP 1.

STEP 1-3 is guaranteed to loop for at most a
polynomial number of iterations. Tsochantaridis
et al., 2005
56
Illustrative Example

• Structural SVM Approach
• Repeatedly finds the next most violated
  constraint
• until set of constraints is a good
  approximation.

• Original SVM Problem
• Exponential constraints
• Most are dominated by a small set of important
  constraints

57
Illustrative Example

• Structural SVM Approach
• Repeatedly finds the next most violated
  constraint
• until set of constraints is a good
  approximation.

• Original SVM Problem
• Exponential constraints
• Most are dominated by a small set of important
  constraints

58
Illustrative Example

• Structural SVM Approach
• Repeatedly finds the next most violated
  constraint
• until set of constraints is a good
  approximation.

• Original SVM Problem
• Exponential constraints
• Most are dominated by a small set of important
  constraints

59
Illustrative Example

• Structural SVM Approach
• Repeatedly finds the next most violated
  constraint
• until set of constraints is a good
  approximation.

• Original SVM Problem
• Exponential constraints
• Most are dominated by a small set of important
  constraints

60
Finding Most Violated Constraint

• Required for structural SVM training
• Depends on structure of loss function
• Depends on structure of joint discriminant
• Efficient algorithms exist despite intractable
  number of constraints.
• More than one approach
• Yue et al., 2007
• Chapelle et al., 2007

61
Gradient Descent

• Objective function is discontinuous
• Difficult to define a smooth global approximation
• Upper-bound relaxations (e.g., SVMs, Boosting)
  sometimes too loose.
• We only need the gradient!
• But objective is discontinuous
• so gradient is undefined
• Solution smooth approximation of the gradient
• Local approximation

62
LambdaRank

• Assume implicit objective function C
• Goal compute dC/dsi
• si f(xi) denotes score of document xi
• Given gradient on document scores
• Use chain rule to compute gradient on model
  parameters (of f)

Burges et al., 2006
63
Burges, 2007

• Intuition
• Rank-based measures emphasize top of ranking
• Higher ranked docs should have larger derivatives
• (Red Arrows)
• Optimizing pairwise preferences emphasize bottom
• of ranking (Black Arrows)

64
LambdaRank for NDCG

• The pairwise derivative of pair i,j is
• Total derivative of output si is

65
Properties of LambdaRank

• 1There exists a cost function C if
• Amounts to the Hessian of C being symmetric
• If Hessian also positive semi-definite, then C is
  convex.

1Subject to additional assumptions see Burges
et al., 2006
66
Summary (Part 1)

• Machine learning is a powerful tool for designing
  information retrieval models
• Requires clean formulation of objective
• Advances
• Ordinal regression
• Dealing with severe class imbalances
• Optimizing rank-based measures via relaxations
• Gradient descent on non-smooth objective functions
