Generic Programming and Formal Methods

1
Generic Programmingand Formal Methods

• David R. Musser
• Rensselaer Polytechnic Institute

2
Minimal requirements works with maximal family
of types
A
Generic algorithm
m
Lift
. . .
Remove an unneeded requirement on the type
Lift
Less specialized works with more than one type
A
1
Lift
A
Start here
Concrete algorithm requires specific data type
0
3

A Concrete Algorithm
float max_element(float a, int
N) if (N 0) throw MaxElementEmptyArra
yError int first 0 float max a0
while (first lt N) if (max lt afirst)
max afirst return max
4

A More Useful Interface
int max_element(float a, int
first, int last) if (first last)
return first int result first while
(first ! last) if (aresult lt afirst)
result first return result
5

A Linked-List Counterpart
float_list_node max_element(float_list_node
first, float_list_node last) if
(first last) return first
float_list_node result first while
(first-gtnext ! last) if (result-gtdata lt
first-gtdata) result first return
result
6

Back to the Array Version
int max_element(float a, int
first, int last) if (first last)
return first int result first while
(first ! last) if (aresult lt afirst)
result first return result
7

Generalize the Element Type
template lttypename Egtint max_element(E a,
int first, int last) if (first
last) return first int result first
while (first ! last) if (aresult lt
afirst) result first return result
8

From Arrays to Pointers
template lttypename TgtTmax_element(T first,
T last) if (first last)
return first T result first while
(first ! last) if (result lt first)
result first return result
9

Generalize from Pointers to Iterators
template lttypename ForwardIteratorgtForwardIterat
or max_element(ForwardIterator first,
ForwardIterator last) if (first last)
return first ForwardIterator result
first while (first ! last) if (result
lt first) result first return result
10

Use with any Container with appropriate iterators
int a 6, 3, 7, 5int ai
max_element(a, a4)vectorltintgt v(a,
a4)vectorltintgtiterator vi
max_element(v.begin(), v.end())listltintgt x(a,
a4) listltintgtiterator li
max_element(x.begin(), x.end()). . .
11
Generic algorithm on
max_element
i
Forward Container Concept
i
ij
k jj 3k 7
j
k
j
k
7
3
3
7
max_element
max_element
12
Container
Part of the STL Container Concept Taxonomy
Forward Container

Sequence
Reversible Container
Front InsertionSequence
Back InsertionSequence
Random Access Container
Vector
Slist
Deque
List
13
Output Iterator
Input Iterator
Forward Iterator
Ostream iterator
Istream iterator
Bidirectional Iterator
Slist iterator
Random Access Iterator
The STL Iterator Concept Taxonomy
List iterator
Vector iterator
Deque iterator
14
Algorithms, Concepts, and Challenges
Generic algorithms
Concept Taxonomy
Making Concepts First Class Constructs
C requires . . . template lttypename T
models Cgt. . . assert T models C
A
m
Lift
. .
Lift
. . . for formal checking of syntactic and
semantic properties and using them in software
engineering
A
1
Lift
A
0



Concrete algorithms

Useful Data and Algorithm Abstractions a
Generic Library
15
A Dilemma

• STL and other concept-based generic libraries are
  based on mathematical principles, so it should be
  easier to apply formal methods to them than to
  average software
• But they rest on a language substrate, C, whose
  formal analysis is viewed by many to be
  intractable
• Solving this completely will require much work at
  lower levels of implementation
• Im concentrating on developing formal deduction
  support for the key ideas and methodology of
  generic programming in a somewhat idealized
  setting.

16
An Observation

• Understanding of how to prove something about a
  new generic component under development often
  depends heavily on thorough understanding of
  proofs about similar existing components
• especially when studying how to make it even more
  general without losing correctness or efficiency
• This means the goal of fully-automated proofs
  becomes much less important than it is for other
  applications of formal proof

17
What kind of proof system is most suitable?

• Resolution provers fail on the readability
  requirement
• So do tactics-based provers (although
  Isabelle-Isar overcomes this problem to an
  extent)
• My own earlier work on interactive proof systems
  (Affirm, Affirm-2, Tecton) fell short
• A relatively recent development Denotational
  Proof Languages, and the Athena proof checking
  system
• Due to Konstantine Arkoudas (MIT PhD
  Dissertation, 2000)

18
Athena Proof-Checker (K. Arkoudas)

• Supports proofs that are both human-readable and
  machine checkable
• Supports generalization and specialization
  through methods, which are deductive counterpart
  of (higher-order) functions
• Using only its built-in and library-defined
  capabilities, often requires writing proofs in
  excessive detail
• But also allows skipping over details via calls
  of external full-automation provers (originally
  Otter, currently SPASS and Vampire)
• Also connects with a model checker (Paradox) so
  that one can easily look for counterexamples
  before investing effort in developing a proof

19
On the C Language Issue

• C is the language in which most generic library
  development has been done
• due to better support than most other languages
  templates, template partial specialization,
  operator overloading, function-inlining
• resulting in essentially no abstraction penalty
  at runtime
• Is a formal semantics for C possible?
• For unrestricted programming it would be very
  complex since there are few language-imposed
  restrictions on low-level features like pointers
• But generic programming principles impose a
  simplifying discipline, enforced by well-designed
  concept requirements
• Will require collaboration with those who can
  influence the future evolution of the language
• a recent promising development the C Standard
  Committee is considering proposals to add
  concepts as a first class feature of the language

20
