Allen D. Malony, Aroon Nataraj

1
TAU Meets Dyninst and MRNetA Long-term and
Short-term Affair

• Allen D. Malony, Aroon Nataraj
• malony,anataraj_at_cs.uoregon.edu
• http//www.cs.uoregon.edu/research/tau
• Department of Computer and Information Science
• Performance Research Laboratory
• University of Oregon

2
Performance Research Lab

• Dr. Sameer Shende, Senior scientist
• Alan Morris, Senior software engineer
• Wyatt Spear, Software engineer
• Scott Biersdorff, Software engineer
• Li Li, Ph.D. student
• Model-based Automatic Performance Diagnosis
• Ph.D. thesis, January 2007
• Kevin Huck, Ph.D. student
• Aroon Nataraj, Ph.D. student
• Integrated kernel / application performance
  analysis
• Scalable performance monitoring

3
Outline

• What is TAU?
• Observation methodology
• Instrumentation, measurement, analysis tools
• Our affair with Dyninst
• Perspective
• MPI applications
• Integrated instrumentation
• Courting MRNet
• Initial results
• Future work

4
TAU Performance System

• Tuning and Analysis Utilities (14 year project
  effort)
• Performance system framework for HPC systems
• Integrated, scalable, flexible, and parallel
• Multiple parallel programming paradigms
• Parallel performance mapping methodology
• Portable (open source) parallel performance
  system
• Instrumentation, measurement, analysis, and
  visualization
• Portable performance profiling and tracing
  facility
• Performance data management and data mining
• Scalable (very large) parallel performance
  analysis
• Partners
• Research Center Jülich, LLNL, ANL, LANL, UTK

5
TAU Performance Observation Methodology

• Advocate event-based, direct performance
  observation
• Observe execution events
• Types control flow, state-based, user-defined
• Modes atomic, interval (enter/exit)
• Instrument program code directly (defines events)
• Modify program code at points of event occurrence
• Different code forms (source, library, object,
  binary, VM)
• Measurement code inserted (instantiates events)
• Make events visible
• Measures performance related to event occurrence
• Contrast with event-based sampling

6
TAU Performance System Architecture
7
TAU Performance System Architecture
8
Multi-Level Instrumentation and Mapping

• Multiple interfaces
• Information sharing
• Between interfaces
• Event selection
• Within levels
• Between levels
• Mapping
• Performance data is associated with high-level
  semantic abstractions

source code
instrumentation
instrumentation
preprocessor
source code
instrumentation
compiler
instrumentation
object code
libraries
executable
instrumentation
instrumentation
runtime image
instrumentation
instrumentation
VM
performancedata
run
9
TAU Instrumentation Approach

• Support for standard program events
• Routines, classes and templates
• Statement-level blocks and loops
• Support for user-defined events
• Begin/End events (user-defined timers)
• Atomic events (e.g., size of memory
  allocated/freed)
• Selection of event statistics
• Support definition of semantic entities for
  mapping
• Support for event groups (aggregation, selection)
• Instrumentation selection and optimization
• Instrumentation enabling/disabling and runtime
  throttling

10
TAU Instrumentation Mechanisms

• Source code
• Manual (TAU API, TAU component API)
• Automatic (robust)
• C, C, F77/90/95 (Program Database Toolkit
  (PDT))
• OpenMP (directive rewriting (Opari), POMP2 spec)
• Object code
• Pre-instrumented libraries (e.g., MPI using PMPI)
• Statically-linked and dynamically-linked
• Executable code
• Dynamic instrumentation (pre-execution)
  (DyninstAPI)
• Virtual machine instrumentation (e.g., Java using
  JVMPI)
• TAU_COMPILER to automate instrumentation process

11
TAU Measurement Approach

• Portable and scalable parallel profiling solution
• Multiple profiling types and options
• Event selection and control (enabling/disabling,
  throttling)
• Online profile access and sampling
• Online performance profile overhead compensation
• Portable and scalable parallel tracing solution
• Trace translation to EPILOG, VTF3, and OTF
• Trace streams (OTF) and hierarchical trace
  merging
• Robust timing and hardware performance support
• Multiple counters (hardware, user-defined,
  system)
• Measurement specification separate from
  instrumentation

12
TAU Measurement Mechanisms

• Parallel profiling
• Function-level, block-level, statement-level
• Supports user-defined events and mapping events
• TAU parallel profile stored (dumped) during
  execution
• Support for flat, callgraph/callpath, phase
  profiling
• Support for memory profiling (headroom, leaks)
• Tracing
• All profile-level events
• Inter-process communication events
• Inclusion of multiple counter data in traced
  events
• Compile-time and runtime measurement selection

13
Performance Analysis and Visualization

• Analysis of parallel profile and trace
  measurement
• Parallel profile analysis
• ParaProf parallel profile analysis and
  presentation
• ParaVis parallel performance visualization
  package
• Profile generation from trace data (tau2pprof)
• Performance data management framework (PerfDMF)
• Parallel trace analysis
• Translation to VTF (V3.0), EPILOG, OTF formats
• Integration with VNG (Technical University of
  Dresden)
• Online parallel analysis and visualization
• Integration with CUBE browser (KOJAK, UTK, FZJ)

14
TAU and DyninstAPI

• TAU has had a long-term affair Dyninst technology
• Dyninst offered a binary-level instrumentation
  tool
• Could help in cases when the source code is
  unavailable
• Could allow instrumentation without recompilation
• TAU requirements
• Instrument HPC applications with TAU measurements
• Multiple paradigms, languages, compilers,
  platforms
• Portability
• Tested Dyninst features as they were released
• Issues
• MPI, threading, availability, binary rewriting
• It been on/off open relationship

15
Using DyninstAPI

• TAU uses DyninstAPI for binary code patching
• Pre-execution
• versus at any point during execution
• Methods
• runtime before the application begins
• binary rewriting
• tau_run (mutator)
• Loads TAU measurement library
• Uses DyninstAPI to instrument mutatee
• Can apply instrumentation selection

16
Using DyninstAPI with TAU
Configure TAU with Dyninst and build
lttaudirgt/ltarchgt/bin/tau_run configure
dyninst/usr/local/dyninstAPI-5.0.1 make
clean make install tau_run command tau_run
lt-o outfilegt -Xrunltlibnamegt-f
ltselect_inst_filegt -v
ltinfilegt Instrument all events with TAU
measurement library and execute tau_run
klargest Instrument all events with TAUPAPI
measurements (libTAUsh-papi.so) and execute
tau_run -XrunTAUsh-papi a.out Instruments only
events specified in select.tau instrumentation
specification file and execute tau_run -f
select.tau a.out Binary rewriting tau_run o
a.inst.out a.out
17
Runtime Instrumentation with DyninstAPI

• tau_run loads TAUs shared object in the address
  space
• Selects routines to be instrumented
• Calls DyninstAPI OneTimeCode
• Register a startup routine
• Pass a string of routine (event) names
• main foo bar
• IDs assigned to events
• TAUs hooks for entry/exit used for
  instrumentation
• Invoked during execution

18
Using DyninstAPI with MPI

• One mutator per mutatee
• Each mutator instruments mutatee prior to
  execution
• No central control
• Each mutatee writes its own performance data to
  disk

mpirun -np 4 ./run.sh cat run.sh
!/bin/sh /usr/local/tau-2.x/x86_64/bin/tau_ru
n ltpathgt/a.out
19
Binary Rewriting with TAU

• Rewrite binary (Save the world) before executing
• No central control
• No need to re-instrument the code on all backend
  nodes
• Each mutatee writes its own performance data to
  disk

tau_run -o a.inst.out a.out cd
_dyninstsaved0 mpirun -np 4 ./a.inst.out
20
Example

• EK-SIMPLE benchmark
• CFD benchmark
• Andy Shaw, Kofi Fynn
• Adapted by Brad Chamberlain
• Experimentation
• Run on 4 cpus
• Runtime instrumentation using DyninstAPI and
  tau_run
• Measure wallclock time and CPU time experiments
• Profiling and tracing modes of measurement
• Look at performance data with Paraprof and Vampir

21
ParaProf - Main Window (4 cpus)
22
ParaProf - Indivdual Profile (n,c,t 0,0,0)
23
ParaProf - Statistics Table (Mean)
24
ParaProf - net_recv (MPI rank 1)
25
Integrated Instrumentation (Source Dyninst)

• Use source instrumentation for some events
• Use Dyninst for other events
• Access same TAU measurement infrastructure
• Demonstrate on matrix multiplication example
• Compare regular versus strip-mining versions

Source instrumented
Source binary instrumented
26
TAU-over-MRNET (ToM) Project

• MRNET
• as a
• Transport Substrate
• in
• TAU
• (Reporting early work done in the last week.)

27
TAU Transport Substrate - Motivations

• Transport Substrate
• Enables movement of measurement-related data
• TAU, in the past, has relied on shared
  file-system
• Some Modes of Performance Observation
• Offline / Post-mortem observation and analysis
• least requirements for a specialized transport
• Online observation
• long running applications, especially at scale
• dumping to file-system can be suboptimal
• Online observation with feedback into application
• in addition, requires that the transport is
  bi-directional
• Performance observation problems and requirements
  are a function of the mode

28
Requirements

• Improve performance of transport
• NFS can be slow and variable
• Specialization and remoting of FS-operations to
  front-end
• Data Reduction
• At scale, cost of moving data too high
• Sample in different domain (node-wise,
  event-wise)
• Control
• Selection of events, measurement technique,
  target nodes
• What data to output, how often and in what form?
• Feedback into the measurement system, feedback
  into application
• Online, distributed processing of generated
  performance data
• Use compute resource of transport nodes
• Global performance analyses within the topology
• Distribute statistical analyses
• easy (mean, variance, histogram), challenging
  (clustering)

29
Approach and First Prototype

• Measurement and measured data transport are
  separate
• No such distinction in TAU
• Created abstraction to separate and hide
  transport
• TauOutput
• Did not create a custom transport for TAU
• Use existing monitoring/transport capabilities
• Supermon (Sottile and Minnich, LANL)
• Piggy-backed TAU performance data on Supermon
  channels
• Correlate system-level metrics from Supermon with
  TAU application performance data

30
Rationale

• Moved away from NFS
• Separation of concerns
• Scalability, portability, robustness
• Addressed independent of TAU
• Re-use existing technologies where appropriate
• Multiple bindings
• Use different solutions best suited to particular
  platform
• Implementation speed
• Easy, fast to create adapter that binds to
  existing transport
• MRNET support was added in about a week
• Says a lot about usability of MRNET

31
ToM Architecture

• TAU Components
• Front-End (FE)
• Filters
• Back-End (BE)
• Over MRNet API
• No-Backend-Instantiationmode
• Push-Pull model of dataretrieval
• No daemon
• Instrumented application contains TAU and
  Back-End
• Two channels (streams)
• Data (BE to FE)
• Control (FE to BE)

32
ToM Architecture

• Applicaton calls into TAU
• Per-Iteration explicit call to output routine
• Periodic calls using alarm
• TauOutput object invoked
• Configuration specificcompile or runtime
• One per thread
• TauOutput mimics subset of FS-style operations
• Avoids changes to TAU code
• If required rest of TAU can be made aware of
  output type
• Non-blocking recv for control
• Back-end pushes
• Sink pulls

33
Simple Example (NPB LU - A, Per-5 iterations)
Exclusive time
34
Simple Example (NPB LU - A, Per-5 iterations)
Number of calls
35
Comparing ToM with NFS

• TAUoverNFS versus TAUoverMRNET
• 250 ssor iterations
• 251 TAU_DB_DUMP operations
• Significant advantages with specialized transport
  substrate
• Similar when using Supermon as the substrate
• Remoting of expensive FS meta-data operations to
  Front-End

36
Playing with Filters

• Downstream (FE to BE) multicast path
• Even without filters, is very useful for control
• Data Reduction Filters are integral to Upstream
  path (BE to FE)
• W/O filters loss-less data reproduced D-1 times
• Unnecessary large cost to network
• Filter 1 Random Sampling Filter
• Very simplistic data reduction by node-wise
  sampling
• Accepts or Rejects packets probabilistically
• TAU Front-End can control probability P(accept)
• P(accept)K/N (N leafs, K is user constant)
• Bounds number of packets per-round to K

37
Filter 1 in Action (Ring application)

• Compare different P(accept) values
• 1, 1/4, 1/16
• Front-End unable to keep up
• Queuing delay propagated back

38
Other Filters

• Statistics filter
• Reduce raw performance data to smaller set of
  statistics
• Distribute these statistical analyses from
  Front-End to the filters
• Simple measures - mean, std.dev, histograms
• More sophisticated measures - distributed
  clustering
• Controlling filters
• No direct way to control Upstream-filters
• not on control path
• Recommended solution
• place upstream filters that work in concert with
  downstream filters to share control information
• requires synchronization of state between
  upstream and downstream filters
• Our Echo hack
• Back-Ends transparently echo Filter-Control
  packets back upstream
• this is then interpreted by the filters
• easier to implement
• control response time may be greater

39
Feedback / Suggestions

• Easy to integrate with MRNET
• Good examples documentation, readable source code
• Setup phase
• Make MRNET intermediate nodes listen on
  pre-specified port
• Allow arbitrary mrnet-ranks to connect and then
  set the Ids in the topology
• Relaxing strict apriori-ranks can make setup
  easier
• Setup in Job-Q environments difficult
• Packetization API can be more flexible
• Current API is usable and simple (var-arg printf
  style)
• Composing a packet over a series of staggered
  stages difficult
• Allow control over how buffering is performed
• Important in a push-pull model as data injection
  points (rates) independent of data retrieval
• Is not a problem in a purely pull model

40
TAUoverMRNET - Contrast TAUoverSupermon

• Supermon (cluster-monitor) vs. MRNet
  (reduction-network)
• Both light-weight transport substrates
• Data format
• Supermon ascii s-expressions
• MRNET packets with packed (binary?) data
• Supermon Setup
• Loose topology
• No support/help in setting up intermediate nodes
• Assume Supermon is part of the environment
• MRNET Setup
• Strict topology
• Better support for starting intermediate nodes
• With/Without Back-End instantiation (TAU uses
  latter)
• Multiple Front-Ends (or sinks) possible with
  Supermon
• MRNET, front-end needs to program this
  functionality
• No exisiting pluggable filter support in
  Supermon
• Performing aggregation is more difficult with
  Supermon.
• Supermons allows buffer-policy specification,
  MRNET does not

41
Future Work

• Dyninst
• Tighter integration of source and binary
  instrumentation
• Conveying of source information to binary level
• Enabling use of TAUs advanced measurement
  features
• Leveraging TAUs performance mapping support
• Want robust and portable binary rewriting tool
• MRNet
• Development of more performance filters
• Evaluation of MRNet performance for different
  scenarios
• Testing at large scale
• Use in applications
