Today: whats up with soil

1
Today whats up with soil?
2
Today whats up with soil?

• Human uses of soil
• food, medicine, beer, wine, livestock
• biotechnology - antibiotics
• culture - art, shelter, archaeology
• your nose? The smell of rain is from spores
• Soil in my yard
• gardening, grass, compost bin

3
Earths environmental spheres
REVIEW

• Atmosphere gaseous envelope surrounding Earth
  (e.g., nitrogen, oxygen, argon, water vapor)
• Hydrosphere all forms of water (oceans, ice,
  fresh)
• Lithosphere inorganic solid rocks minerals
• Biosphere where living organisms reside (at/near
  surface)

Atmosphere? Hydrosphere? Lithosphere? Biosphere
?
Where are they?
4
Soil

• The area between the atmosphere and bedrock is
  called the REGOLITH
• regolith includes an unconsolidated mix of
  soil, sediments, and weathered rock

5
Soil

• Soil is born from the physical and chemical
  disintegration of rock, or the WEATHERING of rock

6
Soil
7
Soil

• weathering vs. erosion

8
Soil

• The surface of the lithosphere is usually, but
  not always, covered with soil

9
no soil
Soil
no soil
no soil
10
Soil

• How does soil form?
• Five factors
• Geology
• Climate
• Topography
• Biology
• Time

11
Soil forming factor 1 Geology
12
Soil forming factor 2 Climate

• Chemical and biological processes are accelerated
  in warm, moist climates and slowed in cold, dry
  climates.
• Surface water and water in soil carries chemicals
  in solution and tiny particles in suspension.

13
Soil forming factor 3 Topography

• Slope and
• drainage
• influence
• soil character-
• istics. Generally,
• deeper soils on
• flatter surfaces.

N
N
N
S
S
S
N
S
N
S
N
S
N
north to left
S
14
Soil forming factor 4 Biology

• Living and dead plants and animals
• Roots, worms, ants, prairie dogs, termites,
  grubs,
• In some places, worms deposit 25 tons of casts
  per acre.
• ¾ of soils metabolic activity is generated by
  microorganisms (microbes). Microbes release
  nutrients from dead organisms.

http//www.urbanext.uiuc.edu/worms/live/
15
Soil forming factor 5 Time

• We are talking geologic slowness here!
• Older soils generally display more horizons (or
  layers).

SUPER OLD
OLDER
YOUNGER
16
Soil components

• Inorganics (minerals)
• Air
• Water
• Organics

17
Soil components

• Inorganics (50 of volume)
• sand and silt from weathered rock
• mostly quartz (SiO2)
• some feldspars and micas
• clay
• smaller than sand/silt
• colloidal in size (too small to see)
• form plateletes or sheets
• water moves freely through clay
• negatively charged, attract cations
• many plant nutrients are cations!

feldspars in granite weather into clay
18
Soil components

• Air (25 of volume)
• generally found in voids lined with water
• saturated (100 humidity)
• rich in carbon dioxide (CO2), poor in oxygen
• plant roots remove the O and respire the CO2.
• CO2 slowly seeps into atmosphere

19
Soil components

• Water (25 of volume)
• from rainfall, snowmelt
• water moves down AND up AND laterally
• envelops soil particles

20
Soil components

• Water (25 of volume)
• Four forms of soil moisture
• Gravitational water (stays only a short time)
• performs eluviation and illuviation
• helps keep top layers open and coarse and bottom
  layers compact and dense
• Capillary water (plants use this)
• sticks around from surface tension (ST)
• ST is a force stronger than the downward pull of
  gravity

21
Soil components

• Water (25 of volume)
• Four forms of soil moisture
• Hygroscopic Water (unavailable to plants)
• a microscopically thin film of water
• bound very tightly to all soil particles
• Combined water (entirely unavailable)
• held in combination to minerals
• freed only if chemicals are altered

22
eluvial zone (eluviation) water carrying fine
particles down
illuvial zone (illuviation) the deposition of
these fine particles
23
Soil components

• Review of all four forms of soil moisture

from your book, pg. 361
24
Soil components

• Soil-water budget (balance)
• water added (precipitation)
• water removed (evaporation)
• when there is SUPPLUS water, the soil is at field
  capacity. When moisture is DEPLTED, soil reaches
  wilting point.

determined by temp. and humidity
25
Soil properties
(field capacity)
(field capacity)
time --gt
26
Soil horizons

• O horizon live and decaying organic matter
  litter from dead plants/animals common in
  forests uncommon in grasslands some soils do
  not have an O horizon

27
Soil horizons

• A horizon the topsoil layer a blend of
  minerals and organics sometimes at surface
  coarse due to eluviation horizon in which seeds
  germinate.

28
Soil horizons

• E horizon normally lighter in color an eluvial
  layer from which clay, iron, and aluminum have
  been removed a concentration of sand and silt.

29
Soil horizons

• B horizon the subsoil layer a mineral horizon
  of illuviation where most minerals from above are
  deposited a collection zone for clay, iron, and
  aluminum very dense and clay rich.

30
Soil horizons

• C horizon loose regolith roots cant quite make
  it down this far very little if any organics
  mostly fractured bedrock.

31
Soil horizons

• R horizon mostly unweathered, solid bedrock.
