Diagnostic Imaging Considerations for Wildlife

1
Diagnostic Imaging Considerations for Wildlife

• Mark A. Mitchell DVM, MS, PhD
• University of Illinois
• College of Veterinary Medicine

2
Diagnostic imaging

• Non-invasive
• Radiography
• Ultrasonography
• Advanced imaging (CT, MRI)
• Semi-invasive/Invasive
• Endoscopy

3
Introduction

• Diagnostic imaging
• Underutilized
• Thorough diagnostic work-up
• Getting started
• learn anatomy
• restraint and anesthesia
• positioning techniques
• Practice, practice, pratice

4
Radiographic Equipment

• Machine should be capable of
• short exposure time 1/60 or faster
• high mA- capacity (gt300) better detail
• KvP range 40-100
• bone less radiopaque than mammals
• 2 kVp incremental change

5
Radiographic equipment

• Dental radiographs

6
Radiographic equipment

• Digital radiography

7
(No Transcript)
8
Radiographic Equipment

• Film and screens
• High-detail, rare-earth
• Kodak Ektascan EM-1
• gray film
• single emulsion
• slow speed
• more detail
• Kodak T-Mat TML
• black film
• double emulsion
• fast speed
• less detail
• use appropriate size

9
Restraint and Immobilization

• Manual vs. Chemical Restraint
• Manual restraint
• physical restraint
• increases stress
• restraint devices
• tubes
• blinders

10
Chemical restraint
11
Positioning-Birds and Mammals

• Standard
• Dorsoventral or Ventrodorsal
• Lateral

12
Positioning-Reptiles

• Chelonians
• dorsoventral
• tortoise in prone position
• measure thickest point between carapace and
  plastron

13
Positioning-Reptiles

• Chelonians
• Lateral
• Horizontal beam
• place tortoise on sponge
• cassette in vertical position
• Vertical beam
• fasten tortoise to cassette and position animal
  in vertical position

14
Positioning-Reptiles

• Chelonians
• Craniocaudal
• Horizontal beam
• tortoise on sponge
• cassette placed vertically and behind tortoise
• Vertical
• fasten tortoise to cassette

15
Avian Radiographic Anatomy

• Respiratory System
• Trachea
• Syrinx
• Lungs
• Air Sacs
• Interclavicular, thoracic, and abdominal air sacs

16
Avian Radiographic Anatomy

• Cardiovascular System
• Heart
• right-sided aortic arch
• ascending aorta
• pulmonary arteries
• caudal vena cava

17
Avian Radiographic Anatomy

• Gastrointestinal tract
• Crop
• Esophagus
• Proventriculus
• Ventriculus
• Small intestine
• duodenum
• Cloaca

18
Avian Radiographic Anatomy

• Viscera
• Liver
• hour-glass
• Spleen
• Kidneys
• Gonads
• obvious during breeding periods

19
Avian Radiographic Anatomy

• Skeletal
• Clavicles
• Coracoids
• Appendages
• Normal anatomy

20
Avian Radiographs

• Contrast radiographs
• deliver suspension into crop
• Iohexal (25-30 mg/kg)
• 2x as fast as barium
• every 15 minutes
• radiograph over 2-3 hour period

21
Radiographic Abnormalities
22
Radiographic Abnormalities
23
Radiographic Abnormalities
24
Radiographic Abnormalities
25
Radiographic Abnormalities
26
Chelonian Radiographic Anatomy

27
Chelonian Radiographic Anatomy
28
Chelonian Radiographic Anatomy
29
Radiographic Abnormalities
30
Radiographic Abnormalities
31
Radiographic Abnormalities
32
Radiographic Abnormalities
33
Radiographic Abnormalities
34
Radiographic Abnormalities
35
Radiographic Abnormalities
36
Radiographic Anatomy
37
Radiographic Anatomy
38
Radiographic Anatomy
39
Radiographic Anatomy
40
Mammal Radiographic Anatomy

• Heart
• Point of elbow
• Mustelids
• Caudal to elbow
• Globoid
• Gastrointestinal tract
• Splenomegaly
• Kidneys
• 2 lumbar vertebrae
• adrenal glands
• Urinary system
• Barium 15 ml/kg, 20 solution

41
Radiographic Abnormality
42
Radiographic Abnormality
43
Radiographic Abnormality
44
Rodent and Rabbit Radiographic Anatomy

• Teeth
• Tympanic bullae
• Respiratory tract
• reduced size
• Gastrointestinal tract
• prominent cecum
• Urogenital system
• Skeleton

45
Ultrasonography

• Value?
• Anatomic size
• Location
• Architecture
• Organs
• Heart
• Liver
• Reproductive
• Bladders
• Kidneys
• GI
• Post-radiographs
• Overall sensitivity?

46
Ultrasound
47
(No Transcript)
48
Pre-follicular
49
Endoscopy

• Diagnostic imaging?
• Additional benefits beyond imaging
• Biopsies
• More invasive
• General anesthesia

50
Endoscopy

• Rigid endoscopes
• Sizes
• Procedures
• Coelioscopy
• Cloacoscopy
• Upper respiratory
• Oral
• Aural

51
Endoscopic sexing
52
Endoscopic sexing
53
Endoscopy

• Flexible endoscopes
• Sizes variable
• Respiratory tract
• Gastrointestinal tract
• Upper
• Foreign body removal
• Biopsies
• Lower
• Cloacoscopy
• Examine dystocia
• Cystoscopy

54
