Title: Pattern recognition system


1
??? ???? ??
  • ????? ?????? ????
  • ? ? ?

2
?? ??
  • ?? ? ?? ? 0900 1200, ????????? ?? 1?
  • ?1???
  • Required textbook Pattern classification, 2nd
    edition, R. O. Duda, P. E. Hart, D. G. Stork
  • References
  • Pattern recognition, statistical, structural and
    neural approaches, R. Schalkoff, Wilely
  • Statistical digital signal processing and
    modeling, M. H. Hayes, Wiley
  • Wavelet transform Introduction to theory and
    application, R. M. Rao, A. S. Bophardica, Wiley
  • Selected papers on invasive brain-computer
    interface (BCI) and neural spike sorting (to be
    announced, 5 10 papers)
  • Contents
  • Fundamentals of statistical pattern recognition
    (Ch. 1, 2, 3, 5, 6, 10 of Duda and Hart)
  • Preprocessing of biomedical signal for pattern
    recognition
  • Application of pattern recognition system to
    neural spike sorting for the analysis of nervous
    system, brain-computer interface (for neural
    prosthesis)

3
Ch. 1. Introduction
4
Machine perception
  • Objective to design and build machines that can
    recognize patterns
  • Example
  • Speech recognition
  • Fingerprint identification
  • Character recognition
  • DNA sequence identification
  • ECG abnormal beat detection

5
Pattern recognition system
A priori information
Sensor
Modeling
Feature extractor
Measurement vector
Feature vector
Sensor
Classifier
Feature extractor
Input data
Decision
6
Ex. Bass or Salmon
7
Ex. Bass or Salmon
No single threshold value of the length will
serve to unambiguously discriminate between the
two categories using length alone, we will have
some errors.
8
Patterns and features
  • Objects represented by set of measurements
  • Measurement image, waveform
  • Pattern
  • a set of measurements
  • represented by a vector in an n-dimensional space
    (multi-dimensional space, hyperspace)
  • represented as a point in hyperspace.
  • Feature vector
  • Derived from the pattern vector
  • Smaller dimension (compared to pattern vector
    dimension)

9
Feature vectors in hyperspace
10
Bass or salmon? using 2-D feature vector
Overall classification error on the data shown is
lower than if we use only one feature as in Fig.
1.3, but there will still be some errors.
11
Decision boundary and generalization
  • Overly complex models complicated decision
    boundaries
  • Perfect classification of our training samples,
    but poor performance on future patterns.

12
Decision boundary and generalization
  • The decision boundary shown might represent the
    optimal tradeoff between performance on the
    training set and simplicity of classifier,
    thereby giving the highest accuracy on new
    patterns.

13
Typical structure of pattern recognition system
  • Sensor inputs -gt signal data
  • Segmentor isolates sensed object from the
    background
  • Feature extractor ????? ??? ??? ??
  • Classifier sensed object? ?? class? ??
  • Post-processor ?? ?????? (context, cost of
    errors )? ???? ??? action? ??

14
Sensing
  • Input to a pattern recognition system is often
    some kind of a transducer (ex. Camera, microphone
    )
  • Problem characteristics and limitation of the
    transducer
  • ( bandwidth, resolution, sensitivity,
    signal-to-noise ratio )

15
Segmentation and grouping
  • Isolate each fish from others on the conveyor
    belt
  • In practice, the fish would be abutting or
    overlapping
  • Difficult process in practice particularly in
    speech recognition system

16
Feature extraction
  • Feature ??? ??? ??? ??? ??? ??? ?? ???? feature
    ???? ?? trivial? ???? ?? (vice versa)
  • Traditional goal of the feature extractor to
    characterize an object to be recognized by
    measurements whose values are
  • very similar for objects in the same category
  • very different for the objects in different
    categories
  • Seeking distinguishing features
  • In the fish example size of the fish may not be
    important

17
Classification
  • Classifier uses feature vector to assign the
    abject to a category
  • Abstraction provided by the feature-vector
    representation of the input data ?
  • enables the development of domain-independent
    theory of classification
  • The degree of difficulty in the classification
    problem
  • within-cluster variability vs. between-cluster
    variability
  • Variability 1. Problem complexity. 2. Noise

18
Post-processing
  • Pattern classifier generally is to be used to
    recommend actions
  • put this fish in bucket A, put that fish in
    bucket B
  • Post-processor uses the classifier output to
    decide the action
  • Measure of classifier performance classification
    error rate, total expected cost (risk)
  • Post-processor may be able to exploit context
    T-( )-e, c-( )-t
  • Combination of classifier

19
Design of pattern recognition system
  • Data collection for the training and testing of
    the system
  • Feature selection using domain knowledge and
    experience
  • Choose model pattern
  • Training determine system parameters
  • The results of evaluation may call for
    repetition of various steps in this process in
    order to obtain satisfactory results.

20
Learning and adaptation (Training)
  • Learning (training) training data? ???? pattern
    ???? parameter? ??? ??
  • Supervised training a teacher provides a
    category label or cost for each pattern in a
    training set
  • Unsupervised no explicit teacher, and the system
    forms clusters or natural groupings of input
    patterns

21
Pattern recognition system
A priori information
Sensor
Modeling
Feature extractor
Measurement vector
Feature vector
Sensor
Classifier
Feature extractor
Input data
Decision
22
A good reference paper
  • Statistical pattern recognition a reviewJain,
    A.K. Duin, R.P.W. Jianchang MaoIEEE
    Transactions on Pattern Analysis and Machine
    Intelligence,, Volume 22 , Issue 1 , pp.
    4-37,Jan. 2000
