observational evidences of CR acceleration at shocks

1
observational evidences of CR acceleration at
shocks

• chung-ming ko
• institute of astronomy and
• department of physics, national central
  university, taiwan

KAW4, KASI, Daejeon, Korea, 2006.05.17
2
shocks, shocks everywhere

• from interplanetary shocks to stellar wind
  termination shocks to supernova remnant shocks to
  merger shocks to

3
what I want to talk

• SNR shocks has been discussed by Peter and Aya
• DSA has been discussed by Hyesung
• those are the things I know better than what I am
  going to discuss, so bear with me if I say
  something trivial or stupid
• I will concentrate on heliospheric shocks
• the particles are low energy (low energy
  energetic particles?), in MeV or even sub-MeV
  range

4
interplanetary or heliospheric shocks
(collisionless)

• CME driven shocks
• planetary and cometary bow shocks
• CIR and MIR
• termination shock

• in situ measurements
• energy spectrum
• composition
• temporal variation
• magnetic field
• Waves
• plasma properties
• seed

5
Voyager 1 has crossed the solar termination shock
6
Voyager 1 2 (Voyager Interstellar Mission,VIM)
7
voyage to the edge of heliosphere
counterclockwise from top right Frisch et al.
APOD20020624 Fisk (2005) Decker et al. (2005)
APOD20020624
8
heliosphere is just one more bubble in the sky
but smaller
bow shock near young star
wind bubble from hot star
planetary nebula
9
how do we know Voyager 1 have crossed the
termination shock?

• magnetic field strength and its fluctuations
• 3 times increase in magnitude right across the
  shock
• field in heliosheath is 2.4 times the average
  upstream field
• larger fluctuations after shock crossing

Burlaga et al. 2005
10
together with

• abrupt increase in low-energy particle intensity
• electron plasma oscillations
• detected upstream and not detectable downstream
• inferred solar wind speed
• reduce solar wind speed

Fisk 2005 Stone et al. 2005 Decker et al. 2005
Gurnett Kurth 2005 Burlaga et al. 2005
termination shock (TS) is a reverse
quasi-perpendicular pickup ion-dominated
shock now it is at 94 AU and is moving inward (gt
90 km s-1?) compression ratio between 2.4 and 3.0
11
how about energetic particles?

• besides SEPs, ACRs, GCRs there are TSPs recently
• TSPs are energetic termination shock particles
  (e.g., protons at several MeV)
• strongly affected by heliospheric disturbances
  such as MIRs

Stone et al. 2005
12
TSPs

• mysterious streaming outward along B field
  upstream of TS
• source located several AU closer to the sun and
  closer to the pole than Voyager 1
• TS distorted by LISM B field or interstellar wind

Decker et al. 2005
13
TSPs before and after TS

• upstream
• field-align beaming
• large intensity variation
• large spectral slope variation (-1 to -2)
• heliosheath
• reduced anisotropy
• less intensity variation
• less spectral slope variation (-1.26 to -1.56)
• spectral break varies very little ( 3.5 MeV)
• same source for upstream and heliosheath (steady
  source from TS)
• reason of break unknown (cf., spectral break in
  ACR comes from adiabatic deceleration)

14
ACRs

• anomalous CRs are
• interstellar neutrals ionized by UVpickup by
  solar wind at around 1 KeV/nucleonthen
  accelerated by TS to gt 10 MeV/nucleon
• ACRs are substantially modulated in the
  heliosheath
• source is somewhere beyond (may still be TS but
  at a distance from the region where Voyager 1
  crossed)

Stone et al. 2005
15
ACR spectrum

• diffusive shock acceleration is alright
• however, 0.0420 MeV can also be explained by
  solar wind ram pressure heating at TS(Gloecker
  et al. 2005)

Decker et al. 2005
16
ACR acceleration
further into heliosheath

• not quite what is expected
• the spectrum does not change and the intensity
  does not increase cross the shock
• low energy ions (lt 3 MeV per nucleon) are rapidly
  accelerated, while high energy ions are not
  affected by shock
• TS is a shock but not an efficient accelerator
• new physics is needed?some say yes and some say
  no, of course!

immediate downstream
Stone et al. 2005
immediate upstream
17
TSPs and ACRs

• both ACRs and TSPs are accelerated pickup ions
  (e.g., both are deficient in carbon ions)
• two stagess acceleration first accelerate TSPs,
  then accelerate ACRs later (but further
  fractionation of H is needed in the second stage
  as H/He ratios are different)

Stone et al. 2005
18
interplanetaryshocks
19
connection to earth
magnetic field
energized particles
adapted from Lee 1983
20
typical IP shock
ACE measurements 2000.06.202000.06.26

• most interplanetary shocks are CME driven shocks
• in situ measurements by ACE, SOHO, WIND, Ulysess,
  Voyagers, IMP8, ISEE3, Goes, etc.
• particles are energized, but
• seed population?
• location?
• self-excited waves?
• modified-shock?

Desai et al. 2003
21
SEPs (solar energetic particles)
two types gradual and impulsivedifferent
isotopic compositions
associated with CMEs?
associated with flares?
Reames 1999
22
spectrum from solar wind to CR energies
seed? high energy tail of solar wind? or
pre-accelerated suprathermal ions?
Mewaldt et al. 2001
23
seed population

• solar wind ions or suprathermal ions?
• observation of IP shocks at 1 AU indicates seeds
  come from suprathermal ions pre-accelerated by
  solar flares or other IP shocks
• 3He rich events associated with solar flares

Desai et al. 2003
24
acceleration sites for SEPs

• solar flares or CME driven shocks
• common view (but not all) is CME driven shocks
• how do we know
• timing
• spectrum and intensity of anisotropic
  ground-level events (GLEs)
• GLE-associated with CMEs
• solar gamma ray line flares has little
  correlation with SEPs

25
self-excited waves

• the idea is waves excited upstream of the shock
  by energetic particles trap the particles for
  further acceleration
• the breaks in these spectra may be an indication
  of proton-excited Alfven waves (e.g., due to
  saturation)

Mewaldt et al. 2005
26
direct measurement

• Bastille 2000 event (2000.07.15)
• self-excited Alfven waves by protons
• weakly super-Alfvenic ions generates ion whistler
  waves
• ions are trapped by these waves near shock and
  thus increasing the efficiency of shock
  acceleration

27
2000.07.15 event (Bastile day event)
Terasawa et al. 2006
ACE news 91, 2005.08.30 (Kallenbach Bamert)
28
modified shock?

• at strong shock, when accelerated particles gain
  enough energy, backreaction will take place
• SEPs suck up 10 of CMEs energy (dissipation of
  CME, modified shock?)

Mewaldt et al. 2005
29
1994.02.21 event
2003.10.29 event (Halloween event)
Terasawa et al. 2006
shock precursor?
30
complications

• both 3He and 4He intensities are increased at CME
  magnetic compression region (C) and CME fast
  forward shock (S)
• 3He/4He enhancement with respect to solar wind
• ion intensities at (C) is larger than at (S)
  indicates shocks are not the only acceleration
  mechanism in interplanetary space

ACE news 44, 2000.04.25 (Desai et al.)
31
complications

• 2005.01.20 event pushes the shock model to its
  extreme parameters regime
• because of the fast rise time and intensity

Ryan et al. 2005
32
factors affecting IP shock acc

• shock strength, velocity, size and curvature,
  lifetime, etc.
• quasi-parallel and quasi-perpendicular
• seed populations
• solar wind suprathermal
• solar flare suprathermal
• CMEs may or may not have associated shocks
• direction of CMEs propagation and connectivity
• a lot of things needs to be disentangled

33
complicated business
Mason 2001
34
some statistics
354 shocks

• how does energetic particle relate to shock
  parameter?
• no apparent trend from shock angle and speed
  (except maybe shock speed has to be large enough
  for large increase in intensity)

Cohen et al. 2005
35
162 fast forward IP shocks (CME related)
ACE news 44, 2000.04.25 (Lario et al.)

• shock parameters may not govern the associated
  energetic particle event
• maybe the energetic particle event is a history
  of injections and accelerations (by other shocks
  or accelerators), while the shock is measured
  locally
• about half of the shocks do not affect
  pre-existing particle intensities, i.e., no shock
  acceleration (even for a few strong shocks)

36
its goodstill lots of things to do
are you hungry for some?
to be contd
37
the end
