Principles for HPLC Methods Development

1
Principles for HPLC Methods Development

• Bioanalytical Chemistry
• Lecture Topic 4

2
Five Stages

• Define problem
• Experiment with key variables
• Evaluate
• Optimize
• Troubleshoot

3
Define

• What is the purpose?
• Analytical
• Preparative
• What are the molecular characteristics of the
  analyte and sample?
• CHASM

4
CHASM

• Charge
• Positive/negative
• Hydrophobicity
• Affinity
• lock and key sites
• Solubility stability
• pH, ionic strength, organic solvents
• Molecular weight

5
Analytical vs. Preparative

• Analytical Requirements
• Linearity
• Precision
• Accuracy
• Sensitivity
• Assay reproducibility
• Robustness

6
Analytical vs. Preparative

• Preparative Requirements
• Recovery
• Product purity
• Capacity
• Costs
• Scale up
• Process throughput
• Speed

7
Methods Development

• Select the mode
• pH map
• Optimize gradient/elution
• gradient slope
• eluent concentration
• Loading study
• overload peak width and shape

8
Common Modes

• Reverse phase (RPC)
• Stationary phase hydrophobic and mobile phase
  hydrophilic
• column silica, polystyrene covalently modified
  with alkyl chain 3-18 Cs
• EX octadecylsilane (ODS) - C18
• mobile phase buffered water organic solvent
  (propanol CH3CN, CH3OH)
• gradient elution

9
Reverse Phase
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
CH3CN
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
CH2CH2CH2CH2CH2CH2CH2CH3
CH3CN
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
H2O
CH2CH2CH2CH2CH2CH2CH2CH3
10
Reverse Phase
C6H6
Polarity?
CH3OH
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
CH2CH2CH2CH2CH2CH2CH2CH3
C6H6
CH3OH
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
H2O
CH2CH2CH2CH2CH2CH2CH2CH3
C6H6
polar
Non-polar
11
Reverse Phase 50/50?
Mobile phase More/less polar?
C6H6
CH3OH
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
CH2CH2CH2CH2CH2CH2CH2CH3
C6H6
CH3OH
CH2CH2CH2CH2CH2CH2CH2CH3
H2O
H2O
CH2CH2CH2CH2CH2CH2CH2CH3
C6H6
polar
Non-polar
12
Common Modes

• Ion-Exchange (IEC)
• Ion exchange interactions between cationic or
  anionic analyte and stationary phase bearing
  opposite charge
• stationary phase polystyrene, silica modified
  with functional groups such as quaternary amines
• mobile phase buffer containing increasing
  concentration of salt (NaCl, MgCl2, K3PO4,
  NH4SO4)
• gradient elution

13
Evaluation

• Resolution
• degree of separation between analyte and other
  species present in mixture
• bandspreading
• selectivity
• Recovery
• mass recovery
• activity recovery
• Capacity

14
Developing Your Application

• Proteins
• Antibodies
• Peptides
• Nucleic acids

15
Proteins

• All modes can potentially be used
• Ion exchange common first step
• mobile phase less denaturing
• Antibodies
• Affinity

16
Peptides

• amino acid chain lt 30 residues (5000 MW)
• reverse phase most commonly used
• historical
• ion exchange can be equally effective

17
Nucleic Acids

• gel electrophoresis commonly used
• anion exchange predominant chromatographic method

18
Ion Exchange

• Sample must be ionized in order to be retained on
  column significantly
• Anion exchange (anionic acidic proteins)X-
  RCl- X-R Cl-
• Cation exchange (protonated basic proteins)X
  R-K XR- K

19
Column Type

• 4 types strong/weak cation/anion
• Strong - ionization of ionic group does not
  change over usual pH range
• better starting point
• Weak - lose charge and sample retention for
  certain pH ranges

20
Cation Exchangers

• Strong cation exchanger (SCX)
• sulfonic acid, SO3-
• Weak cation exchanger (WCX)
• carboxylic acid, COO-

21
Anion Exchangers

• Strong anion exchanger (SAX)
• quaternary ammonium, e.g., N(CH3)4
• Weak anion exchanger (WAX)
• diethylaminoethyl (DEAE)

22
pH Effects

• Anion exchange
• RCOOH RCOO- H
• INcrease in pH leads to greater sample ionization
  and retention
• Cation exchange
• RNH3 RNH2 H
• DEcrease in pH leads to greater sample ionization
  and retention

23
Salt/Buffer Effect

• Mobile phase cations/anions can displace analyte
  on column
• All salts are NOT equal
• Anions
• F- lt OH- lt Cl- lt NO3- lt citrate3- (strong)
• Cations
• Li lt H lt NH4 lt K lt Mg2 lt Ca2 (strong)
• Polyvalent ions held more strongly by ion
  exchange column than monovalent ions

24
Salt/Buffer Effect

• Need to select appropriate pH
• Anion exchange, pH gt 6 used
• start pH 8.5
• protein stable?
• extreme end of pH range
• binding should be tightest
• Cation exchange, pH lt 6 used (pH 4.0)

25
Salt/Buffer Effect

• Select Salt
• 0.5 - 1.0 M
• Gradient
• 0 - 100 gradient - to determine relative
  retention of sample
• long, shallow to start
• 0 - 1 M NaCl, 50 - 100 CVs

26
Organic Solvent Effect

• Addition of organic solvents decreases retention
• Be careful! Can denature biomolecules
• Can be used to create changes in selectivity
• EXS methanol or acetonitrile
• water miscible

27
Cytochrome c

• Function Redox protein involved in cell
  apoptosis and respiration
• Structure heme protein
• FW 12,384 (horse)
• Basic protein

3CYT Takano, T., Dickerson, R. E. Redox
conformation changes in refined tuna cytochrome
c. Proc. Natl. Acad. Sci. USA 77 pp. 6371 (1980)
28
What mode should we use?
29
Cyt c
COO-
K
K
COO-
K
K
COO-
K
K
K
COO-
K
30
Cyt c
COO-
K
NH3
NH3
NH3
COO-
Cyt c
K
NH3
NH3
COO-
K
NH3
NH3
COO-
K
31
NH3
NH3
NH3
COO-
Cyt c
NH3
COO-
NH3
NH3
NH3
COO-
K
K
K
COO-
K
K
32
NH3
NH3
NH3
Na
COO-
Cyt c
NH3
COO-
Na
NH3
NH3
NH3
COO-
Na
Na
Na
Na
Na
COO-
Na
33
Effect of pH

• What Does Cyt c look like at low pH?

34
NH3
NH3
NH3
Na
COO-
Cyt c
NH3
COO-
Na
NH3
NH3
NH3
COO-
Na
Na
Na
Na
Na
COO-
Na
35
Effect of pH

• What Does Cyt c look like at high pH?

36
NH2
NH2
NH2
Na
COO-
Cyt c
NH2
COO-
Na
NH2
NH2
NH2
COO-
Na
Na
Na
Na
Na
COO-
Na
37
Effect of pH

• So low pH more effective for cation exchange than
  high pH

38
Useful References

• The Busy Researchers Guide to Biomolecular
  Chromatography, Perspective Biosystems,
  publication date unknown.
• Snyder, L.R. Kirkland, J.J. Glajch, J.L.
  Practical HPLC Method Development, 2nd ed.
  John Wiley Son New York, 1997.
