XML and Databases

1
XML and Databases

• Justin Hong
• Suhasini Ranganathan
• Michael Suwandi

2
Outline

• XML / Relational Model
• XML in Relational Databases
• Native XML Databases
• References

3
XML / Relational Model

• Suhasini Ranganathan

4
XML in One Slide

• Hierarchical document format for information
  exchange in WWW
• Self describing data (tags)
• Nested element structure having a root
• Element data can have
• Attributes
• Sub-elements

5
XML and Databases

• With a large amount of data represented as XML
  documents, it becomes necessary to store and
  query these XML documents.
• Exciting database opportunity
• Unlike HTML, tags are not only for presentation
• Can capture semantics
• Can query the web if we can query XML!!!
• Two approaches to storing XML data
• Using relational databases
• Using native XML stores.

6
Why relational databases to store XML?

• Can harness the sophisticated storage and query
  capability already provided by existing
  relational database systems.
• No need to build native systems from scratch.
• users can query seamlessly across XML documents
  and other data stored in relational database
  systems.

7
Storing XML Documents in a Relational Database
System
Automatic Translation Layer
Commercial RDBMS (DB2)
8
Issues

• The main issues that must be addressed include
• dealing with the complexity of DTD element
  specifications
• resolving the conflict between the two-level
  nature of relational schemas (table and
  attribute) vs. the arbitrary nesting of XML DTD
  schemas
• dealing with set-valued attributes and recursion.

9
Example DTD (will be used in further slides)

• lt!ELEMENT book(booktitle,author)
• lt!ELEMENT article(title,author,contactauthor)gt
• lt!ELEMENT contactauthor EMPTYgt
• lt!ATTLIST contactauthor authorID IDREF IMPLIEDgt
• lt!ELEMENT monograph(title,author,editor)gt
• lt!ELEMENT editor(monograph)gt
• lt!ATTLIST editor name CDATA REQUIREDgt
• lt!ELEMENT author(name, address)gt
• lt!ATTLIST author id ID REQUIREDgt
• lt!ELEMENT name(firstname?,lastname)gt
• lt!ELEMENT firstname(PCDATA)gt
• lt!ELEMENT lastname(PCDATA)gt
• lt!ELEMENT address(ANY)gt

10
DTD Graph
11
Simplifying DTDs

• DTDs can be complex and generating relational
• schemas that capture this complexity would be
• unwieldy
• Use set of transformations that can be used to
• simplify any arbitrary DTD without undermining
• the effectiveness of queries over documents
• conforming to that DTD.

12
Transformation of DTDs

• The transformations are of three types
• flattening transformations which convert a
  nested
• definition into flat representation (eg
  (e1,e2)e1,e2)
• simplification transformations, which reduce many
  unary
• operators to a single unary operator(ege1e1)

• grouping transformations that group sub-elements
• having the same name(eg a,.,a.. .a..
• For example, applying these transformations can
• transform an element such as
• lt!ELEMENT a ((bce)?,(e?(f?,(b,b))))gt to
• lt!ELEMENT a (b, c?, e, f)

13
DTD to Relational Schema

• Naïve Approach
• Each Element gt Relation
• Each Attribute of Element gt Column of Relation
• Connect elements using foreign keys
• Problem?
• Fragmentation!

14
Fragmentation Example
lt!ELEMENT author (name, address)gt lt!ATTLIST
author id ID REQUIREDgt lt!ELEMENT name
(firstname?, lastname)gt lt!ELEMENT firstname
(PCDATA)gt lt!ELEMENT lastname (PCDATA)gt lt!ELEME
NT address ANYgt
author (authorID integer, id string) name
(nameID integer, authorID integer) firstname
(firstnameID integer, nameID integer, value
string) lastname (lastnameID integer, nameID
integer, value string) address (addressID
integer, authorID integer, value string)

• Results in 5 relations
• Just retrieving first and last names of an author
  requires three joins!

15
The Basic Inlining Technique

• solves the fragmentation problem by inlining as
  many descendants of an element as possible into a
  single relation.
• Basic creates relations for every element because
  an XML document can be rooted at any element in a
  DTD.
• create a graph structure called the element graph

16
Example Element Graph
article

?
title

contactauthor
author
authorid
name
authorid
address
?
firstname
lastname
17
Basic Inlining Technique (contd)

• book (bookID integer, book.booktitle string,
  book.author.name.firstname string,
  book.author.name.lastname string,
• book.author.address string, author.authorid
  string)
• booktitle (booktitleID integer, booktitle
  string)
• article (articleID integer, article.contactauthor
  .authorid string, article.title string)
• article.author (article.authorID integer,
  article.author.parentID integer,
  article.author.name.firstname string,
• article.author.name.lastname string,
  article.author.address string,
  article.author.authorid string)
• contactauthor (contactauthorID integer,
  contactauthor.authorid string)
• title (titleID integer, title string)
• monograph (monographID integer,
  monograph.parentID integer, monograph.title
  string, monograph.editor.name string,
• monograph.author.name.firstname string,
  monograph.author.name.lastname string,
• monograph.author.address string,
  monograph.author.authorid string)
• editor (editorID integer, editor.parentID
  integer, editor.name string)
• editor.monograph (editor.monographID integer,
  editor.monograph.parentID integer,
  editor.monograph.title string,
• editor.monograph.author.name.firstname string,
  editor.monograph.author.name.lastname string,
• editor.monograph.author.address string,
  editor.monograph.author.authorid string)
• author (authorID integer, author.name.firstname
  string, author.name.lastname string,
  author.address string,
• author.authorid string)
• name (nameID integer, name.firstname string,
  name.lastname string)
• firstname (firstnameID integer, firstname
  string)

18
Shared Inlining Technique

• Intuition
• Inline as many sub-elements as possible
• Do not inline only if it is a shared, recursive
  or set sub-element.
• Technique
• Relations are created for all elements in the
  DTD graph whose nodes have an in-degree greater
  than one / in-degree equal to zero.
• Nodes with an in-degree of one are inlined.

19
Shared Relational Schema

• book (bookID integer, book.booktitle.isroot
  boolean, book.booktitle string)
• article (articleID integer, article.contactauthor
  .isroot boolean,
• article.contactauthor.authorid
  string)
• monograph (monographID integer,
  monograph.parentID integer,
• monograph.parentCODE integer, monograph.editor.is
  root boolean, monograph.editor.name string)
• title (titleID integer, title.parentID integer,
  title.parentCODE integer, title string)
• author (authorID integer, author.parentID
  integer, author.parentCODE integer,
  author.name.isroot boolean, author.name.firstname
  .isroot boolean,author.name.firstname string,
  author.name.lastname.isroot boolean,
  author.name.lastname string, author.address.isroo
  t boolean, author.address string,
  author.authorid string)

20
Semi-structured Queries to SQL Queries

• Semi-structured queries have a lot more
  flexibility than SQL
• Allow path expressions with various operators and
  wild cards
• Discussion based on Shared approach

21
Queries with Simple Path Expressions Example

• WHERE ltbookgt
• ltbooktitlegt The Selfish
  Gene lt/booktitlegt
• ltauthorgt
• ltnamegt
• ltfirstnamegt f
  lt/firstnamegt
• ltlastnamegt l lt/lastnamegt
• lt/namegt
• lt/authorgt
• lt/bookgt IN CONFORMING TO
  pubs.dtd
• CONSTRUCT ltresultgt f l lt/resultgt

22
Queries with Simple Path Expressions Translation
Select A.author.name.firstname,
A.author.name.lastname From author A, book
B Where B.bookID A.parentID AND
A.parentCODE 0 AND
B.book.booktitle The Selfish Gene
23
XML in Relational Databases

• Michael Suwandi

24
Motivation

• Need to support new breed of applications
• Financial applications
• Web services (SOAP and XML-RPC messages)
• Web feed formats (RSS and Atom)
• Want to combine SQL and XML
• Preserve the long term investments in established
  relational databases
• SQL and Relational Databases are reliable,
  dependable, understood, proven, tested, and
  familiar
• Introduce the power and flexibility of XML and
  its related technologies
• XML, XPath and XQuery are new, flexible, powerful
  and intuitive
• Somehow need to fuse XML content into SQL
  databases

25
Solutions

• Possible solution
• Turn the XML elements into tables, columns and
  rows in databases
• Advantages minimal changes, only add
  pre-processing
• Disadvantages cannot handle unstructured data,
  cannot handle data with evolving schemas, cannot
  handle recursive structures
• Proposed solution
• Just insert the XML document
• Add a new column type (XML blob)
• Add a new index type (XPath fragment)
• Combine query language SQL DML XQuery
• Advantages XML data is stored as is (do not care
  if the data is structured or not, if the schema
  is static or changing, if structure is
  recursive), no pre-processing, XQuery processing
  is integrated with the query optimizer, etc.
• Disadvantages dual type systems, new technology
  (less studied and understood), new pitfalls and
  gotchas (optimizing storage and queries)

26
SQL Table vs. XML Document

• ltblogsgt
• ltblog date12/2/06 userJakegt
• ltentrygtI got accepted to UTlt/entrygt
• ltkeywordsgtltkeywordgtschoollt/keywordgtltkeywordgtU
  Tlt/keywordgtlt/keywordsgt
• lt/bloggt
• ltblog date12/5/06 userCindygt
• ltentrygtI won lotterylt/entrygt
• ltmoodsgtltmoodgtecstaticlt/moodgtltmoodgthappylt/mood
  gtlt/moodsgt
• lt/bloggt
• lt/blogsgt

27
SQL Table XML Document
CREATE TABLE blogs (date DATE, user VARCHAR, blog
XML)

• Entire XML documents or fragments are stored
  inside a column to preserve the structure,
  whitespaces, etc
• Notice that blog column contents do not match in
  structure

28
SQL Indexing vs. XPath Indexing

• SQL Indexing
• Builds B tree on the entire value of each cell
  values cannot efficiently process large VARCHAR
  nor BLOB (Binary Large OBject) columns
• Most commercial databases add full text indexing
  for efficiently processing LIKE operator
• XPath indexing
• Needs to evaluate both the explicit and implicit
  paths for the XML nodes
• Needs to preserve ordering between nodes
  important to process XPath axis functions e.g.
  last(), first(), following-sibling()
• Needs to preserve node identities important to
  support attribute id uniqueness

29
SQL Indexing XPath Indexing

• Index for all the user names
• CREATE INDEX blog_user ON blogs(user)
• Index for all the blog keywords
• CREATE INDEX blog_keyword ON blogs(blog)
• USING XMLPATTERN '//keyword' AS VARCHAR
• Index for all the blog moods
• CREATE INDEX blog_mood ON blogs(blog)
• USING XMLPATTERN '//mood' AS VARCHAR
• Notice as VARCHAR clause at the end

30
SQL DML vs. XQuery

• Notice the differences in clauses

• SELECT ltprojected columnsgt
• FROM lttables and/or viewsgt
• WHERE ltpredicatesgt
• GROUP BY ltgrouping columnsgt
• ORDER BY ltsorting columnsgt
• SELECT clause always produces tables (even if it
  is only one row/one column)
• Allow nesting in WHERE clause

• for ltitems in XPath sequencegt
• let ltvariable definitionsgt
• where ltXPath conditionsgt
• order by ltXPath expressiongt
• return ltsequence of itemsgt
• return clause produces sequences of XML documents
• Allow nesting in for, let, where, and return
  clauses
• XPath usage for selecting, enumerating,
  filtering, evaluating XML element and attributes

31
SQL DML XQuery

• Return all of cindys happy entries
• SELECT b.date,
• XMLQuery('blog//entry passing b.blog
  as blog")
• as VARCHAR
• FROM blog b
• WHERE b.user cindy AND
• XMLExists('blog//keywordtext() eq
  happy
• passing b.blog as blog)
• Notice the use of XMLQuery() and XMLExists()
  functions as well as the clause as VARCHAR

32
Differences in Type Systems

• SQL data types date, varchar, blob, double, etc.
• XML data types XML nodes (elements and
  attributes) and text
• Need some way to bridge the two
• Hint!! Look at XMLExists(), XMLQuery() functions
  and as VARCHAR clause in previous examples
• Problems (like trying to convert one to a
  double) are silenced by inserting empty nodes or
  empty sequences.
• Warning!! This behavior is generally correct
  except in the presence of negation.

33
Commercial Implementations

• IBM DB2 Viper
• Microsoft SQL Server 2005

34
IBM DB2 Viper

• Native XML column storage
• Truly hierarchical XML storage
• Flexible schema support
• Schema assignment is per document not per column
• Documents are allowed not to have schemas
• Multiple query systems
• Plain old SQL
• Stand-alone XQuery
• Use db2-fnxmlcolumn() to fetch XML documents
  from the columns in tables
• XQuery in SQL
• Use xmlquery(), xmlexists(), xmltable() and
  xmlcast() to convert from XML elements to SQL
  native data types
• SQL in XQuery XML in SQL
• Use xmlelement() to construct column data to XML
  documents

35
IBM DB2 Viper (continued)

• Path specific XML indexing
• Because indexing all nodes is prohibitive
• Path can only contain navigation specifications
• Implemented as B tree
• Building the index
• Perform XPath evaluation of the indexed column
  if the evaluation succeeded, the node is added to
  the index.
• Tolerant behaviour if the node passes the XPath
  evaluation but failed the coversion to the
  desired data type that node is not added to the
  index this is important to support evolving
  schema definition
• Using the index
• Can be used to filter based on structural
  restrictions
• Can be used to locate specific nodes in specific
  rows
• Mainly used to perform context filtering on the
  entire table this is to done to support the
  millions of moderately sized documents workload
• Algorithm to determine eligibility of indexes as
  well as effectiveness in terms of processing the
  queries

36
Microsoft SQL Server 2005

• Native column type for XML storage
• Binary XML to represent XML documents and
  fragments
• Flexible schema support
• XML documents are either typed (associated with a
  schema) or un-typed (not associated with any
  schema)
• Single query system
• Support augmented SQL with XQuery
• Support most (but not all) of the XQuery
  functions
• Tries to map as many operations from XPath and
  XQuery to the relational model for faster
  execution
• Optimization of execution plan uses the costing
  functions and histogram of data distributions
  (same as the relational model) together the SQL
  and the XML parts for the query are optimized as
  a whole using rule based query tree rewrites

37
Microsoft SQL Server 2005 (cont.)

• XML indexing
• Primary XML indexes
• Contains the data model content of the XML nodes
• Secondary XML indexes
• PATH indexes for path-based queries
• PROPERTY indexes for property bag scenarios
• VALUE indexes for value-based queries
• Building the index
• Implemented as B tree on the data model content
  of the nodes
• Also contains the reversed encoded path for each
  node to the XML root
• Also contains the OrdPath column for each node to
  capture relative ordering of the nodes
• Statistics are created for the key column of the
  primary and secondary indexes
• Using the index
• Use the cost based selection for the secondary
  indexes

38
Microsoft SQL Server 2005 (cont.)

• XQuery processing diagram
• (tries to map XQuery expression to Relational
  query processor)

Example Relational operator tree for XDOC.query
(/BOOK_at_id123)
39
Conclusion

• XML is here to stay. Need to integrate it into
  the established framework (i.e. relational
  databases)
• Enhancing the type system, the index type, and
  the query language allow for easier transition
  and faster adoption of XML related technology
• Commercial support for XML in relational
  databases are available from IBM, MS, and Oracle
• The level of XML support are different in each
  offerings
• Need to understand the impact of these additional
  features to the storage and performance
  requirements of existing applications

40
Native XML Databases

• Justin Hong

41
Motivation

• Advantages of XML
• Interoperability
• Ease of use
• Extensibility
• Integration of XML into existing DBMSs
• Most DBMSs use tables as basic storage element
• Hierarchical structure of XML needs to be mapped
  into and out of tables when querying
• High number of joins to recreate XML structure

42
Motivation (Continued)

• Typical queries on XML documents are queries on
  the hierarchical structure (relationships between
  nodes)
• Types of relationships
• parent-child
• ancestor-descendant
• sibling (previous and following)
• Processing these types of queries without native
  XML data store support is costly

43
Native XML Data Stores

• Provides a logical model for storing and
  retrieving XML documents efficiently
• XML interface for accessing XML data (e.g. XPath,
  XQuery)
• Advantages
• Scalability
• Data-access speed
• Reliability

44
Native XML Database

• Definition (XMLDB Initiative
  www.xmldb-org/sourceforge.net)
• XML document is the fundamental unit of logical
  storage
• Uses a logical model for the XML document itself
• Requires a particular underlying physical storage
  model

45
Abstract View of Components

• Native XML Interface
• Most popular choices are XQuery and XPath
• Storage Manager
• Performs any necessary transformations to
  store/retrieve XML data

6
46
Storage Trees Collections

• XML documents are trees, so storing them as trees
  is beneficial for navigation-oriented
  applications
• Collection-based implementations are beneficial
  for applications that query a collection of XML
  documents

47
eXist

• An Open Source Native XML Database

48
XML Indexing (Motivation)

• Example find all the figures in a collection of
  books
• Access all the nodes under the book elements and
  check if they are figure elements
• Implies that a lot of non-figure elements are
  accessed
• Need index structures to efficiently perform
  queries on large, unconstrained collections of
  XML documents

49
XML Index by Numbering

• A numbering scheme assigns a unique identifier to
  each node in an XML document
• Depending on the scheme, certain relationships
  can be determined immediately

50
Base Numbering Scheme in eXist

• XML document is modeled as a complete k-ary tree
• Unique identifier assigned to each node by
  traversing tree document in level-order

4
51
Base Scheme (Continued)

• A nodes parent identifier can be computed with
• parent7 (7-2) / 2 1 3.5 3

4
4
52
Base Scheme Disadvantage

• Typical documents have a small number of top
  level elements (e.g. chapters of a book), whereas
  the deeper elements contain many more children
  (e.g. paragraphs in a chapter)
• Spare identifiers need to be inserted at the top
  level elements (to be complete)
• Assigned identifiers grows extremely fast even in
  small documents

53
eXists Alternating Scheme

• The maximum number of children (k) for an element
  is a per-level attribute k(d) where d is the
  depth of the node with respect to the root node
• How to calculate parent identifier?
• Not obvious and not presented in the paper, but
  authors claim that it is still doable

54
Index Files

• collections.dbx manages collection hierarchy
• dom.dbx stores nodes in a paged file
  associates them with their identifiers
• elements.dbx indexes elements attributes

55
dom.dbx

• Index is a multi-root B-Tree

4
56
elements.dbx

• Indexed by ltcollection-id, name-idgt pairs
• Value is ordered list of ltdocument-id, node-idgt
  pairs, which are the nodes whose name matches the
  key entry

57
Limitations

• eXist is good for relatively static documents
• Inserting a child element under a node that
  already has the max number of children involves
  re-assigning identifiers to all elements in the
  level and subsequent levels

58
References

• A. Balmin, K. S. Beyer, F. Özcan and M. Nicola.
  On the Path to Efficient XML Queries. In
  Proceedings of the 32nd international Conference
  on Very Large Data Bases, Seoul, Korea, September
  12 - 15, 2006.
• A. Halverson, V. Josifovski, G. M. Lohman, H.
  Pirahesh and M. Mörschel. ROX Relational Over
  XML. In Proceedings of the Thirtieth
  International Conference on Very Large Data
  Bases, Toronto, Canada, August 31 September 3,
  2004.
• R. Krishnamurthy, R. Kaushi and J. F. Naughton.
  Efficient XML-to-SQL Query Translation Where to
  Add the Intelligence? In Proceedings of the
  Thirtieth International Conference on Very Large
  Data Bases, Toronto, Canada, August 31
  September 3, 2004.

59
References

• W. Meier. eXist An Open Source Native XML
  Database. In Erhard Rahm B. Chaudri, Mario Jeckle
  and Rainer Unland, editors, Web, Web-Services,
  and Database Systems, 2593, Erfurt, Germany,
  2002. Springer LNCS Series.
• S. Pal, I. Cseri, O. Seeliger, M. Rys, G.
  Schaller, W. Yu, D. Tomic, A. Baras, B. Berg, D.
  Churin and E. Kogan. XQuery Implementation in a
  Relational Database System. In Proceedings of the
  31st international Conference on Very Large Data
  Bases, Trondheim, Norway, August 30 - September
  02, 2005.
• A. Vakali, B. Catania and A. Maddalena. XML Data
  Stores Emerging Practices. In IEEE Internet
  Computing Journal, Vol. 9 Issue 2, pages 62-69,
  March-April 2005.

60
Questions?
