Information Visualization

1
Information Visualization

• Kathryn Summers
• 2005

2
Perceptual processing

• Stage 1pre-attentive processing (20 of cortical
  neurons)
• Parallel processing (fast)
• Data-driven
• Color, motion, elements of form, contour,
  orientation, texture
• Short-term memory
• Stage 2
• Visual field segmented into regions and
  two-dimensional patterns

3
Stage 3 perceptual processing

• Sequential processing (slow)
• Action-oriented processing
• Semiotic processing
• Goal-driven
• Involves working and long-term memory

4
Physical characteristics of the eye

• 100 million rods (night vision)
• Input data pooled over large areas (thousands of
  rods contributing to signal in a single optic
  nerve)
• So sensitive they are overloaded and shut down
  during the day
• 6 million cones (daytime/color)
• Densely packed in fovea, or center of eye (a
  two-degree field, but most detail in ½ degree)
• Thumbnail at arms length is about 1 degree

5
Implications for monitors

• Typical computer monitor only stimulates 5-10 of
  the visual field, but it is likely to stimulate
  more than 50 of the visual processing mechanisms
  in the brain
• Flat screen of monitor doesnt provide depth of
  focus information

6
Opponent process color theory

• Luminance is based on input from all three cones
• Red-green is based on the difference between
  long- and middle-wavelength cones (color
  blindness can come from lack of long or medium
  cones)
• Yellow-blue is based on the difference between
  short wave-length cones and the sum of the other
  two

Long (red)
luminance
R-G
Medium (green)
Y-B
Short (blue)
7
Properties of color channels

• Luminance, or black-white channel, carries the
  most detail
• Stereo perception, and perceived speed of motion,
  and even shape are based mostly on luminance
• The R-G and Y-B channels only carry 1/3 as much
  detail (use for coding of objects)
• We adapt to colored lightso that the neutral
  point for white shifts (for example, indoor
  light is yellow, but we still perceive white as
  white)

8
Color and focus

• Different wavelengths of light are focused at
  different distances within the eye
• On a monitor, blue peaks at 480 nm, red peaks at
  650 nm
• If the eye focuses on a red patch, any
  neighboring blue patch will be out of focus, and
  the red will look closer
• If unavoidable, add a small amount of red or
  green to blue in order to provide luminance edges
  that will clarify boundaries

9
Color in interface design

• Some colors seem to be cross-cultural black,
  white, red, yellow, green, blue are the most
  standard brown, pink, purple, orange, and gray
  are the next most common
• Most people can reliably identify pure yellow
• There seem to be two pure greens, one at 514 nm
  and one at 525 nm (about 1/3 of people)
• Appearance of colors will change in context

10
Color in interface design

• Use high-saturation colors to code small objects
• Use low-saturation colors for large areas
• Add a white or black border to reduce contrast
  effects
• Yellow-blue contrast less vulnerable to color
  blindness
• Limit the number of color codes to 5-10

11
Data visualization

• How to design attention-grabbing features
• How to code data so that patterns become
  perceptible

12
Data visualizationwhy do it?

• Facilitates comprehension of large amounts of
  data
• Allows perception of unanticipated properties
  (patterns)
• May expose problems with the data, contributing
  to quality control
• Facilitates understanding large and small scale
  features of the data
• Support hypothesis formation

13
Stages of data visualization

• Collecting and storing the data
• Preprocessing data to transform it into something
  understandable
• Display hardware and software (graphics
  algorithms) to produce visualization
• Reception by human perceptual and cognitive system

14
Pre-attentively processed characteristics

• Form
• Color
• Motion
• Spatial position
• (See pg 151-52, figure 5.5)

• Pre-attentive processing takes 10 msec or less
  per item (time increases with variety)
• Non-pre-attentive processing takes 40 msec or
  more per item

15
Eye movements

• Saccadic movements
• movement takes 20-100msec, dwell period
  200-600msec
• Ballisticcant be interrupted
• Saccadic suppressionmay not see events during
  saccade
• Smooth pursuit movements
• Convergent movements
• eyes converge if object moving closer, diverge if
  moving away
• Accommodation200 msec to refocus after movement

16
Field of view

• Varies
• Larger if low density environment
• Smaller if high density environment
• Narrows as cognitive load increases
• Tunnel vision in emergencies

17
Specialized vision cells

• Specialized cells for detecting
• Orientation and size, with luminance
• Color (two types of signal)
• Stereoscopic depth
• Motion
• Gabor receptive fields
• Orientation
• Scale
• Contrast
• Hue (added to Gabors model)

18
Human visionsharpening

• Brain is most sensitive to
• patterns of differences
• Changes over time
• Brain uses the ways in which groups of cells fire
  to increase resolution of differences
• Retinal ganglion cells respond differently to
  on-center and off-center stimulation
• On-center stimulation?more neuron pulses
• Off-center stimulation?depressed pulses
• The result is heightened perceived contrast
• pg 73-75

19
Image-based research

• Subjects shown 2560 pictures, one every 10
  seconds, for seven hours spread over four days
  (Standing et al. 1970)
• Could identify ones they saw from ones not seen
  with 90 accuracy
• Research shows that searching through an image
  store may be faster if images presented in a
  quick series displayed in the same spot than if
  particpant must scan through a matrix of
  thumbnails.

20
More image research

• Subjects shown images too briefly to identify,
  then a random pattern (to remove stimulus from
  iconic store) (Bar and Biederman 1998)
• Tests showed no recall of image
• 15 minutes later, recognition tested, and was
  higher than random
• Image primed the visual system
• Priming effect reduced if the image was rotated a
  few degrees.

21
Conjunctionssome are pre-attentive, most are not

• Space and color
• Space and shape
• Depth and color
• Depth and movement

• Convexity and color
• Motion and shape

22
Integral and separable dimensions (figure 5.25)

• Integral dimensions cause interference, but can
  speed processing with redundant coding
• Separable dimensions dont cause interference,
  but dont speed processing with redundant coding

23
Vision and computer monitors

• Center of monitor at typical distance stimulates
  gt50 of the visual processing mechanisms in the
  brain
• Resolution about 40 pixels/cm human visual
  acuity (for lines) accurate to about 1/10 pixel
• Monitor cannot provide depth of focus info may
  confuse human spatial processing systems
• Red and blue phosphors resolve at different
  distances, so monitor blue is usually out of
  focus (solution add some red green)

24
Human interrupt signals

• Warnings, routine change of status, patterns of
  events
• Channels for informationdisplay windows, dials,
  speakers
• Eventssignals on channels
• Expected costcost of missing an event

25
Characteristics of human interrupts

• Should be easily perceived even outside locus of
  attention
• Should continue to remind user even if ignored
• Should not be annoying
• Should reflect appropriate (varying) levels of
  urgency

26
Channel monitoring behavior

• Growth of uncertainty about state of channel
• Cost of sampling
• Proximity of channels
• Frequency of events (channels with infrequent
  events may get oversampled or forgotten)
• Learned scan patterns (habit)

27
Implications for interrupt design

• Events can be missed during a saccade
• Peripheral vision is color blind
• Too rapid motion is so hard to ignore its likely
  to be annoying
• Motion is already overused (banner pop-up
  blindness)
• Use smooth motion, or repeated appearance/disappea
  rance of object, or even auditory cues

28
Next Week

• Motion, patterns, and data objects

29
Spatial contrasts

• Spatial frequency
• Orientation
• Contrast
• Phase angle (lateral displacement of pattern)
• Area covered by the pattern

30
Semiotics and perception

• Symbols and their meanings
• Pictures
• Realism vs. convention
• Words
• Sensory vs. arbitrary
• Sensoryno need to learn, rapidly processed, not
  culture-specific
• Arbitraryhard to learn, easy to forget,
  culture-specific, can change quickly, but are
  formally powerful
