Visual Sensation

1
Visual Sensation Perception

• How do we see?

2
Structure of the eye
3
The Retina
4
(No Transcript)
5
Visual Receptors

• Rods
• Slowly adapting
• Black White vision
• 120 million None in fovea
• Cones
• Rapidly adapting
• Color vision
• 6 million 50,000 in fovea

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
Chemistry of the photoreceptor

• Light-sensitive protein retinal (a pigment)
  absorbs a photon, causing the retinal to change
  shape.
• Through a series of enzyme-based chemical
  reactions, this causes a closing of the Na
  channels in the receptor.
• This has the effect of hyperpolarizing the cell,
  since sodium can no longer enter.
• This inhibits the latent activity of the cell,
  releasing less glutamate into the next layer of
  the retina - the bipolar cells.
• This causes one set of bipolar cells to be
  hyperpolarized (those that had excitatory
  connections with the receptor) and one set to be
  depolarized (those that had inhibitory
  connections).

10
Retinal Ganglion cells

• Gather information from many rods and cones
  across an area of the retina.
• How many rods and cones depends on the size of
  the ganglion cells receptive field
• The closer to the fovea, the smaller the
  receptive field.
• Project out of the eye through the optic nerve,
  creating a blind spot.
• 1 million retinal ganglion cells (receiving
  signals from 125 million receptors).

11
(No Transcript)
12
Receptive fields of retinal ganglion cells

• Center-surround
• Most are excitatory center, inhibitory surround.
• Some are the opposite

13
Out of the retina

• Signals from the two eyes cross over to the
  opposite brain hemisphere at the optic chiasm.
• Not all signals from an eye go to contra-lateral
  hemisphere.
• Which hemisphere the signal goes to is based on
  which visual hemifield the ganglion cell receives
  information from.

14
(No Transcript)
15
Into the brain

• Ganglion cells synapse in the lateral geniculate
  nucleus (LGN) of the thalamus.
• For comparison, the auditory nerve synapses in
  the medial geniculate nucleus.
• The LGN divides the signals into layers depending
  on which eye they come from, and whether they
  come from the fovea or not.
• 1, 4, 6 from the contralateral eye 2, 3, and 5
  from the ipsilateral eye.
• 1 and 2 (magnocellular levels) from the fovea.
• Other layers (parvocellular) from extra-foveal
  regions.
• 400,000 cells leave the LGN

16
(No Transcript)
17
V1

• From the LGN, the signals are sent to area V1 in
  the very back of the occipital lobe.
• Signals are organized into a retinotopic map
  based on where on the retina they come from, and
  which eye they come from.
• All cells project to layer IV of striate cortex,
  but M and P cells project to slightly different
  parts.
• Furthermore, P cells project from layer IV into
  layers II and III, creating blob and interblob
  areas.

18
(No Transcript)
19
Feature detectors in V1

• The retinotopic map is not simply a light/dark
  detector. Signals are beginning to be combined
  into simple feature detectors that can detect
  lines at various orientations.
• All of the feature detectors for a particular
  area of the retina are anatomically organized
  into a column.
• A hypercolumn is two columns from corresponding
  parts of both retinas.

20
(No Transcript)
21
Beyond V1

• From V1, signals go to area V2 where the combine
  into more complex features (corners and simple
  shapes).
• After V2, the signal splits into two streams of
  information.
• The what stream passes through V3 (which does
  color detection) into the temporal lobe.
• The where stream passes through V4 (which aids
  with motion detection) into the parietal lobe.

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
