Solutions to Mass Storage in Banking Surveillances

1
Solutions to Mass Storage in Banking Surveillances
Sales Marketing Department Surveon
Technology 2013
2
2
Solutions Overview
3
Banking Surveillances in Key Areas
Control Center in Banks
Bank Vaults
ATM
Business Halls
Public Areas
Administrative Areas
Data Center
4
Challenges in Banking Surveillances Massive Data
4
Challenges in HD real-time performance and
stability
Integration problems in different independent
systems
Network monitoring and the project scalability
High resolutions bring the capacity and data
protection issues
Scalability in all aspects including numbers of
channels, storages, and networks functionality.
Capacity, data protection, storage problems
Recording system, alarm system, intercom system,
access control system and so on
Recording in real-time at 30FPS and storing for
60 days
5
Surveon Banking Surveillance Solution Architecture
Centralized Video Storage
Sub-branch Control Center
Branch Control Center
Monitoring (CCTV)
Video Analysis
Alarm System
Intercom System
Access Control Sys.
Cameras
Video Mgt. Software
Interphone
Emergency Buttons
Finger Scanner
RAID NVR
External Storage System
Infrared Rays
Intercom Terminal
Digital Lock
6
Surveon Banking Surveillance System Architecture
Local Client
The Security Department Local Client
The Safety Security Department TV Matrix
SCC Mgt. Center
Access Control Server
Intelligent Building Server
I/O Integration
Recording Storage
NVR
Integrated Subsystems
Intelligent Analysis
Fire Alarm Sys.
Intelligent Building Mgt.
CCTV Cameras
Monitoring Areas
Service Points
ATM
Bank Vaults
Office Building
Data Center
7
7
SCC Functions Overview
8
Surveon Enterprise Surveillance Management-
Advantage 1
8
Enhanced Recording Sys.
High Scalability Distributed Architecture
Enterprise Video Mgt.
Enterprise video management software with
functions that meet what a professional security
surveillance needs such as the E-Map and Virtual
Matrix.
Built with RAID or enterprise Storage, providing
a highest mega pixel Recording performance.
Surveon offers high scalability distributed
architecture unlimited numbers of cameras,
clients, storages can be added. This is
applicable for banking surveillances In
sub-branches, branches and data centers of the
head offices.
Execution
360 Fisheye
Time
9
Surveon Enterprise Surveillance Management-
Advantage 2
9
Real Time Video Analytics
Control Center Matrix Wall
Intuitive Monitoring
Handles all tasks in one unified inter- face
operations in monitoring , playback, advanced
settings and managements remotely, locally or
central.
More than 10 advanced real time VI Analytics in
response to the professional surveillance
requirements.
Supports 1000 channels,300 NVRs,360 days
recording and high-end multiple monitors-in-one
and so on.
Unified UI in remote / local client, and central
management.
Virtual Wall
Access Control
Log in via the browser on the computer remotely.
Log in via IOS and Android smart phones.
Matrix Wall Alarm
Traffic Direction Control
10
Surveon Enterprise Surveillance Management-
Advantage 3
10
Integrations in Alarm and Sub-systems
Complete Controls Managements Remotely
2-way Audio Detection
From any client point to assign accounts to
arrange system managements including alarm
setups, parameter configurations, storage
management, data import export.
The banking system can improve their performance
and services via observing the integrated videos
and audios files.
Via I/O Box integrations to create various
sub-systems and to setup rules to manage
proactively.
Access Control
Intrusion Detection Sys.
CAM1320 Compact Indoor Dome
11
Surveon Enterprise Surveillance Management-
Advantage 4
Seamless Recording
360Panoramic View
People Count
Equipped with the SD slot, automatically store
the videos to the SD card during downtime, even
when the network Connection is down.
CAM7511 5M Fish Eye Camera
Use the people count data to arrange the display
in the stores.

• - Count the people flow daily, weekly and
  monthly
• Discover the hot product by analyzing the people
  flow
• people count during openings, lunch breaks and
  discount period

12
12
Surveon Clustered Video Storage Solutions
13
Main challenge for megapixel surveillance is the
storage
13
Its required for banking surveillance to record
in real-time HD for long hours. But it also
burdens the system performance, storage and under
high risk of data loss.
Number of IP Cameras Storage I/O Requirement 30Days Recording 3TB RAID NVR 60Days Recording 3TB RAID NVR Others Surveon
32 128 15 32 YES YES
40 160 18 37 NO YES
50 200 23 47 NO YES
64 512 29 60 NO YES
80 320 37 69 NO YES
100 400 47 95 NO YES
128 1024 60 121 NO YES

• Standard Embedded or PCVMS system dont have
  the above performance.
• Surveons solution is in-house design and
  production with the same quality as other big
  brands .

14
Surveon Clustered Video Storage Architecture
14
15
Limitations of other NVR Storage Solutions
15
Surveon Clustered Video Storage Other NVR Storage Pros and Cons
Storage Method Clustered Storage Built in hard disk Reduce total number of HDD
System Architecture RAID Subsystem PC Built in When PC is down, so is the storage.
Overall Design Cableless, whole module designed, anti-vibration and advanced thermal design Cables, dusts, vibration and thermal issues HDD are prone to failure
Performance Enterprise RAID Subsystem RAID Card or software RAID High performance and high stability
Maintenance Hot swappable hard disks, central management None or Difficult Lower maintenance cost and risk
Scalability Yes None More costs on expansion
Occupied space Less than 2/3 Standard Save space
Power Low power required Standard Save electricity
IPVX Research points out the initial costs and
maintenance for a 128 CH project can be reduced
up to 600,000 when using the clustering storage
solutions
16
Advantages of Surveon Clustered Video Storage
16
Surveon Clustered Video Storage Other NVR Storage Surveon Advantages
Storage Space Save 30 storage space Standard Save costs
System Space Save 20 system space Standard Save space and electricity
Recording Performance High Low No frame Lost
Storage Expansion Unlimited expansions None Camera numbers can be increased and the recording days can be prolonged.
Design Cable-less, module designed Standard Easy installation
Heat and Vibration Optimized Design None High stability
Central Management Yes None Lower maintenance costs
Fault-tolerant Disk Enterprise RAID RAID 0, 1, 3, 5, 6, 10, 50, 60 None or low-level RAID 0, 1, 5 Data Integrity
Data Protection Hard disk snapshots and remote backup None Data Integrity
17
Industry-leading, 5 levels advanced data services
17
Problems Impacts Surveon Storage Solutions Others
Recording Performance Stability , frame dropping Enterprise RAID ensures stability and no frame dropping. Low performance
Hard disk Failure Unrecoverable videos Hardware RAID protection None or under high risk
Files being deleted deliberately Critical evidence missing Local HD snapshot and recovery None
Whole System Crashed (Natural Disasters) System dead Remote Replication None
Long term recording (ex60 days record) Unable to retrieve old data Remote backup / Archive.. None
For financial industry, the loss of important
image impacts more than the costs of investment
in a good storage solution.
18
I/O Performance and Hard Drive Failure Protection
18
Enterprise storage subsystem, cableless, module
design, easy maintenance, anti- vibration and
advanced thermal designed.
Ensure no frame dropping, increase overall
system stability, hard drive failure protection
and automatic recovery
Ensure the maximum stability under high
rpm, lower the HDD failure rate with extra RAID
protection
19
HDD Damages from Embezzlements / Theft Local
Hardware Snapshots
19
Even if the recording is deleted deliberately,
Surveon hardware snapshot and automatic recovery
functionalities can be used to avoid huge loss
from employee embezzlements and thefts.
20
Overall System Failure Protection Remote Backup
20
Surveon remote backup mechanism lowers the risk
of video loss whether its caused by natural
disasters or man-made damages, critical
recordings can still be preserved.
21
Powerful System and Data Management
21
Allocated system management
Advanced RAID Configuration and Data Management
Active monitoring disk performance and status
Backup and schedule management settings
22
22
3Megapixel 30 FPS HDR Cameras
23
3M Real-time Performance
23
Surveon 3M real-time camera can monitor 1.5 times
larger than a 2M camera.
3M Camera _at_ 30FPS
2M Camera _at_ 30FPS
A project with 18 sets of 2M cameras can be
replaced by 12 sets of 3M cameras. Lower the
cost of installation and maintenance by 40.
24
More Details in Real-time
24
For banking surveillance , 30FPS in real-time is
required. Surveon 3M real-time cameras show more
details.
3 Mega
2 Mega
25
High Resolution Surveillance Solution full
ranges of industrial-grade HD cameras
25
??????
Complete Product Lines
The Lowest Bitrate
- 1 M, 2M, 3M, 5M Camera Lines -Industrial-grade
design 3-year warranty -Industry leading 3M
real time HDR cameras
-Offers the lowest bitrate in market -Outstanding
low light sensitivity
HDR Range
-True HDR - 2M _at_ 50FPS, 3M _at_ 30FPS
26
3M Real-time HD in Banking Surveillance
Applications
26
Monitor and manage key areas of the building such
as main entrances, exits, stairways, stair
halves, elevator halls, shelter areas, main way
in the park lots, garage entrances, and outdoor
parking lots.
Surroundings of the Financial Institutes
Office Buildings Business Halls
Surveon DayNight cameras are vandal proof
designed and built with IP66 the cameras are
sure to be secured, suitable for parking lots,
operation areas, warehouses and so on.
With the HDR function, 3M HD Cameras produce
clear images all day long, and is perfect for
outdoor surveillance , key areas, main roads and
so on.
Install HD Dome Cameras in the hallways or
stairway, the interior design will remain
intact.
27
27
Surveon Control Center - Solutions to Integration
28
Surveon Control Center Intergraded Solutions
Overview
28

• Intergrades and manages all kinds of videos,
  alarms, events, and data
• Executes and manages the surveillance system in
  one unified platform
• Video analytics and real time alarms

Surveon Control Center Solutions
Applications ATM, bank vaults, data centers,
and office buildings
Alarms
Collecting data from different alarm systems such
as HTML, I/O, etc to SCC.
Controls
Alarms
Surveion SCC Solution
3rd Parties Surveillance System
Controls
HD Surveillance
Video Analytics
Access Control
I/O Controls
29
Active Video Intelligent Alarm System

• Supports VI notifications to ensure rapid and
  accurate decisions

Tailgating Detection
Virtual Fence
Access Control
Supports real time VI notification and labels
Real Time Event Notifications
?When an event is triggered, the monitors will
switch to display its surrounding images.
?Triggered event popups the videos
30
Integration - Videos Link to Access Control Sys.
30
Through access control and video surveillance
management, access management and protections on
people and facilities are strengthened.
Through integrated monitoring, real-time video
surveillance and event popups , the security
guard can be notified instantly.

IP Network
HTML integrated with the monitoring system
Triggered Events Popups
When an alarm is triggered, the video will popup
to notify the security guard.
Integrated with Access Control, the videos and
the times of coming ins and outs can provide
more information when needed.
SAMS Pro Integrated monitoring Pop-up windows for
alarm events
SAMS Pro Integrated Monitoring
31
Active Intelligent Analysis Applications
Virtual Wall
Access Detection

• Residential Areas
• Surroundings of Hotels, Campus, Factories
• Important Buildings

• Hotel Reception Areas
• Entrances of Hospitals, Residential Areas,
  Initiations

Virtual Fence
Restricted Zone

• ?

• High Value Products
• Important Facilities / Properties
• Public Objects

• No Parking Areas
• Entrances of Warehouse
• Important Facilities

Count
Tailgating Detection

• ATM
• Garages / Parking Lots
• Access Controls

• People Flows in Stores
• Business VI Integrations
• Warehouses, Department Stores

32
32
Recommended Camera Series
33
Professional 3M HD IP Camera Series
33
CAM3471M/V 3M IP66 Bullet
CAM2441 3M Box
CAM4471M/V 3M Vandal Proof Dome
CAM7511 5M Fish Eye Cameras
CAM3571M 5M IP66 Bullet
CAM2511 5M Box
CAM4571M 5M Vandal Proof Dome
M Moto Lens V Vari-Focal Lens
34
Professional 2M IP Camera Series
34
CAM3371M/CAM3361 2M IP66 Bullet
CAM2331/CAM4361 2M Box
CAM4371/CAM4361 2M Vandal Proof Dome
CAM4311 5M Fish Eye Cameras
CAM3351 5M IP66 Bullet
CAM1320 5M Box
CAM4321 5M Vandal Proof Dome
M Moto Lens V Vari-Focal Lens
35
Enterprise-Grade NVR Central Storage Solutions
35

• Supports megapixel quality videos and enhances
  HD videos quality
• Supports DAS and iSCSI SAN clustered video
  storages
• Expandable to maximum 420TB storage
• Enterprise hardware RAID, advanced recording
  data protection
• Built with professional video management
  software, controls over streams,
• video images and so on

36
Surveon SCC Platform Solutions
36

• Enterprise proactive surveillance management
  platform
• Central management, integrating all accounts,
  cameras and storages
• Supports network and high scalability to
  thousands of channels
• Intelligent decoding matrix wall applicable for
  professional control centers
• Integrated videos, alarms, events, and data
  management
• Advanced VI analysis and real-time alarms

37
37
Q A
