Patrick Nussbaum

1
Data-management in Switzerland
2
Family doctor
3
Emergency Service
4
(University-) Hospital
5
Patient
6
Time
7
Consequences
8
Aim
9
System

• Completely tablet pc with applications
• Smartphone with application and sender- and
  documentations-possibility (limited)
• Defibrillator with 12 Lead and integrated
  Bluetooth (M- or E-series)
• Corscience on transmitter side (family doctor,
  hospital emergency)
• Web-server (only with version tablet pc)
• Data-server (with both systems)
• If needed smartphone on receivers side, not
  compellingly

10
Data-management family doctor
.
EKG can be done with accessory equipment
(corscience). With the smartphone you can make
the data visible or you can send / transmit. On
the pc you can have a look at the EKG, you can
make an interpretation and it can be saved with a
special patient-programme. If needed it can be
printed out and filed.
11
DM Emergency Version A
Cardiology
Doctor
HKL
EKG will be done and printed out. Afterwards
transmission via Bluetooth and smartphone,
(programmed). Data will be sent from smartphone
to server. There they will be converted.
Afterwards they can be filedor forwarded.
XY with web-connection
Smartphone
12
DM Emergency Version B
Cardiology
Doctor
HKL
EKG will be done and printed out. Afterwards
transmission via Bluetooth to Panther Data
will be sent to the server. There they will be
converted. Afterwards they can be filed or
forwarded..
XY with web-connection
Smartphone
13
Advantages Version B
The particular advantages are the extended
possibilities. In addition the possibility of
electronic patient minutes exists. EKG as well as
vital-data can be called up, web-based. The
system is open and dynamic. It can be sent by
application on EKG and vital-data-servers.
14
Examples of EKG / vitalweb-DB
15
DM (university) Hospital Version A
Data will be sent by sender via smartphone to the
smartphone of the receiver. Via DB data are
available and can be printed out. Afterwards data
can be saved in a sema (patient) data bank
16
DM (university) Hospital Version B
Data will be sent by sender via smarphone or
panther to the smartphone of the receiver. Via DB
data are available and can be printed out.
Additional there is the opportunity to see
emergency service data on an EKG and vital DB. As
well data can be saved in a sema (patient) data
bank.
17
Advantages entirely

• One system for the heart emergency
• saving of time - improves chances of survival for
  the patient
• on users co-ordinated product
• Financially attractive product
• Possibility for the rework
• Error reduction (minutes/record)
• Documentation possibilitie
• Simply, fast, innovatively

18

• Requirements

19
Corscince

• The corscience is small (approx. 10x6 cm)
  equipment, Bluetooth able of 12 derivative. It
  has the necessary extremity- as well as
  breast-wall derivatives. The electrode
  connections can be selected (tie-clip, clips,
  pushbuttons). The corscience has no monitor. The
  smartphone is used as a monitor.
• On the smartphone the EKG can be also measured
  and increased, with the software installed on it.

• With a simple tip on the touch screen the EKG can
  be transmitted and the emergency service or a
  cardiologist can be alarmed.
• At present the Qtek S100 is used as smartphone.
  In addition, also htc works satisfactorily.
  Compellingly is the program Windows Mobile 5,0
  and higher.
• For the application a software licence exists.
  You get these with the purchase. For the license
  price is valid.

20
ZOLL M-Serie or E-Serie Version A

• Defibrillator must be rigged on 12-Lead as well
  as on integrated Bluetooth.
• With a simple tip on the touch screen the EKG can
  be transmitted and the cardiologist can be called
• At present as samrtphone the Qtek S100 is used.
  In addition, also htc works satisfactorily.
  Compellingly is the program Windows Mobile 5,0
  and higher
• For the application a software licence exists.
  You get these with the purchase. For the license
  price is valid.

21
ZOLL M-Serie or E-Serie Version B

• Defibrillator must be rigged on 12-Lead as well
  as on integrated Bluetooth
• A smartphone is not used compellingly
• Server, panther and application is co-ordinated
  on the user /customer. Thats why the prices can
  be different
• The exact expenditure and a cost framework can be
  provided only after a need clarification and a
  discussion with the customer.

22
Result
only with an optimally, entirely, and good
working (data) emergency management the chance of
survival in case of a heart attack can be
increased. For the sake for the patient and his
heart.
23

• thank you very much!
• Patrick Nussbaum
• Productmanager 12-Lead
• März 2008
