BMI Systems Group

1
Barcode RFID Scanning Systems Designed to
interface with Windsor Management
Groups Infinite Visions Fixed Asset Module
Integrating Mobile Scanning Technology To Help
Your Organization Be More Productive
2
Why Use Barcode RF Technology?

• Error Rate Barcode scan - 1 in 3,000,000
• Keyboard input - 1 in 300
• Data Can Be Exchanged Between Various Software
  Packages and Platforms
• Database Integrity Tag Must be Scanned
• Update/Cleanup Data Easily During Scanning
• Saves Time On Future Inventories

3
BMI Scanning Systems
BMI Systems Group offers (3) scanning systems
that automate the inventory process for Infinite
Visions

• AssetTrak Basic
• with Pocket PC Scanner
• Basic Pocket PC Barcode RFID Reporting
  System for Fixed Assets
• (Version 2.x Enterprise Edition )
• AssetTrak PPC
• with Pocket PC Scanner
• Advanced Barcode RFID ready Data Management
  System for Fixed Assets
• (Enterprise Edition Only )

• ScanIT
• with HT-630 Scanner
• Basic Barcode Inventory System for Fixed
  Assets
• (Enterprise Edition Only )

4
ScanIT is BMIs entry level barcode scanning
system that is designed to interface with the
your Infinite Visions (Enterprise Edition) fixed
asset module. Using an HT-630 scanner that is
loaded with valid Asset Tag s makes taking an
inventory easy. BMIs ScanIT allows you to scan
only bar-coded asset tags with the scanner. The
updated asset file with the current location code
and inventory date is exported from ScanIT. The
file is now available for importing and posting
to your fixed asset module utilizing the Infinite
Visions (Enterprise Edition) Interface.
5
ScanIT Data Collection
Basic Fixed Asset Scanning System for Fixed
Assets

6
Following is a Short Preview of our Easy-to-Use
ScanIT System. It allows you to

• Import Asset Tag s from IVEE for tag validation
• Take Inventory with a portable barcode scanner.
• Upload scanned assets to your desktop PC
• Export an asset data file from ScanIT
• Import Post the updated asset information to
  IVEE
• Note ScanIT requires the IVEE Fixed asset
  interface

7
BMI ScanIT Data Collection
Infinite Visions Enterprise Edition Fixed Asset
Module
Import Post Your Scanned Inventory File
Export Your Infinite Visions Master Asset File
Valid Tag s
Scanned File
Text File on PC
8
Export Master File to ScanIT
Export Master File from IVEE
9
Upload Valid Tag s into Scanner
Beginner Data Collection System for
Fixed Assets (Enterprise Edition)

Click on the Import Button to load valid
Infinite Visions Tag s into the Scanner
10
Unitech HT-630 Scanner
Basic Data Collection System for
Fixed Assets (Enterprise Edition)

You can scan the Location Code Scan the
current Asset Tag
11
Download Scanned Data to PC
Basic Data Collection System for
Fixed Assets (Enterprise Edition)

Click on the Export Button to Upload the
Scanned Asset file to the Desktop PC
12
Import Post Scanned File
13
Process Scanned File in IVEE
14

• ScanIT Product Summary
• ScanIT is designed for the client that wants to
  use a barcode scanner to automate their fixed
  asset inventory process. ScanIT requires that all
  of your assets are bar-coded. A Missing asset
  report has to be created or available in Infinite
  Visions (Enterprise Edition) . ScanIT is
  recommended for entry level clients who have
  accurate data and want to stop using a manual
  check-off inventory process.

15
Main Menu
16
AssetTrak Basic is BMIs entry level Pocket PC
barcode scanning system designed to interface
with the Infinite Visions Enterprise Edition or
Version 2.x fixed asset module. A physical
inventory using a Pocket PC scanner is synced
with the AssetTrak Basic Database. AssetTrak
Basic allows you to view, edit report on the
assets scanned. The updated asset file is
exported from AssetTrak Basic. The file is now
available for importing and posting to your
Infinite Visions Enterprise Edition or Version
2.x fixed asset module. View the BMI Product
Comparison Matrix at the end of this presentation
for more details.
17
Following is a Short Preview of our Easy-to-Use
AssetTrak Basic System. It allows you to
Scan your assets with a BMI programmed Pocket PC
Upload scanned data to AssetTrak Basic on your
Desktop Review, edit data print reports from
your Desktop Export an scanned asset data file
to your Desktop Import Post the updated asset
information to Infinite Visions Enterprise
Edition or Version 2.x scan file processing
utility
18
AssetTrak Basic
Infinite Visions Fixed Asset Module
Export Your Infinite Visions Location Codes
Import Post Your Scanned Asset File
Pocket PC
Location File
Scanned File
Reports
19
Main Menu
20
Import Location Codes
21
Supported Scanning Devices for AssetTrak Basic
PA 600 Portable Terminal BDF 9000 (RFID
Scanner) CSL-CS101 RFID Terminal
22
BMI TrakSync Program
Use BMIs TrakSync application to sync the
Location Codes from AssetTrak Basic on the
desktop computer to the Pocket PC
23
Pocket PC Screen
Scan Program
Scan the Location Code Scan the current Asset
Tag . You can also update the Serial if
required
24
Pocket PC Screens
Main Menu
Data Lookup
Scanned Lookup
25
BMI TrakSync Program
Use BMIs TrakSync application to send the
scanned data from the Pocket PC to AssetTrak
Basic on the desktop computer
26
Main Menu
27
View Edit Scanned Data
28
Main Menu
29
Scanned Data Reports
30
Export Scanned Data
31
Import Post Scanned File
32
Import Post Scanned File
33
Process Scanned File
34
AssetTrak Basic Product Summary AssetTrak Basic
is designed for the client that wants to use a
Pocket PC scanner to automate their fixed asset
inventory process. AssetTrak Basic requires that
all of your assets currently have a bar-coded or
RFID asset tag. AssetTrak Basic includes
reporting on scanned data. You can also view and
edit scanned asset records before uploading and
posting to Infinite Visions. Missing asset
reports need to be created in Infinite Visions.
AssetTrak Basic is recommended for entry level
clients who want the advanced features of a
Pocket PC scanner and want the option to upgrade
to the more advanced AssetTrak PPC at a later
date. View BMI Product Comparison Matrix for more
details.
35
AssetTrak PPC - Main Menu
Advanced Data Management System for Infinite
Visions (Enterprise Edition)
36
AssetTrak PPC is BMIs most advanced barcode
scanning and data management system, designed to
interface with the your fixed asset module.
Exporting the Infinite Visions (Enterprise
Edition) master file and importing it into
AssetTrak PPC allows for automated barcode
scanning and reporting. AssetTrak PPC compares
scanned asset data with your current data and
automatically updates the changes. The updated
asset file is exported from AssetTrak PPC and
can be imported to your Infinite Visions
(Enterprise Edition) fixed asset module.
AssetTrak PPC also allows for easy conversion to
bar-coded or RFID Tags if required.
37
AssetTrak PPC allows the user to

• Import current fixed asset data from IVEE
• Inventory and clean up data with barcode scanner
• Compare the scanned data to the IVEE file
• Produce a variety of post inventory reports
• Reconcile inventory
• Export data to the IVEE Fixed Asset Module

38
AssetTrak PPC
Infinite Visions Enterprise Edition Fixed Asset
Module
Import Post Your Corrected Asset File
Export Your Infinite Visions Master Asset
Location Codes
Pocket PC
Master Loc Files
Reports
Scanned File
39
Download master file into AssetTrak and Sync with
the Pocket PC
Infinite Visions Enterprise Edition Fixed Asset
Module
Pocket PC
Download a copy of your Master Assets
Master Files
Scanned Files
40
Export Master File to AssetTrak PPC
41
Import Infinite Visions Master Asset File for
Inventory
42
Import Infinite Visions Master Asset File for
Inventory
43
View Infinite Visions Master Asset File - Prior
to Scanning
No Status
44
Pocket PC TrakSync Program
Use BMIs TrakSync application to sync the
Infinite Visions fixed asset data on the desktop
computer to the Pocket PC
45
Supported Scanning Devices for AssetTrak PPC
PA 600 Portable Terminal BDF 9000 (RFID
Scanner) CSL-CS101 RFID Terminal
46
Barcode vs. RFID Scanning Systems from BMI
Barcode RFID Scanning
RFID scanning does NOT require Line of Sight.
The scanning distance ranges from 1 to 10 feet,
depending on the scanner, tag size, tag type
scanner used
BMI offers a Bluetooth RFID scanner (BDF-9000)
that works with the PA 600. This system is
recommended when a majority of your tags are
barcodes. The CSL-CS101 is recommended when a
majority of your tags are RFID tags. The scanning
range for the CS-101 is 2 to 10 feet
47
Pocket PC Screens
Main Menu
Data Lookup Menu
48
Pocket PC Lookup Screens
New Asset Lookup Missing
Lookup Master/SN Lookup
49
Data Collection Screens
Scan Program
Convert Program
50
Pocket PC Lookup Screens
View / Add / Update
Program
Scan the Location Code, Scan the Asset Tag,
Convert the Tag (if required), View the Site,
Bldg Room you are in. View Edit data in the
Desc, Serial , Make Model fields in
Infinite Visions ( Enterprise Edition)
51
Pocket PC TrakSync Program
Use BMIs TrakSync application to send the
scanned data on the Pocket PC to the Desktop PC
52

View/Edit Scanned Asset Data
53
View/Edit Scanned Asset Data
54
View/Edit Reconciled Data
Click on this button to reconcile
Note Status Update
55
AssetTrak PPC Reports
Infinite Visions Enterprise Edition Fixed Asset
Module
Pre-reconciled Assets Reports
56
AssetTrak PPC Reports
57
Sample Missing Asset Report
58
Automatically post changes to your fixed assets
by importing posting the New corrected data
from ATPPC into your Infinite Visions fixed asset
module
Infinite Visions Enterprise Edition Fixed Asset
Module
Import Post Your Updated Scanned Asset File
59
Export to upload your corrected asset file into
Infinite Visions Requires the FA Interface
program from Infinite Visions
60
Export Reconciled File
61
Import Post Scan File
62
Process Scanned File in IVEE
63

• AssetTrak PPC Product Summary
• AssetTrak PPC is designed for the client that
  requires features of our most advanced fixed
  asset scanning system. Converting to barcode or
  RFID tags is easy. Missing and New Asset
  listings on the Pocket PC and the Master Asset
  Serial lookup on the scanner increase
  productivity. You can scan an asset using the
  View/Add/Update program to view the Description,
  Make, Model and Serial and edit asset records
  easily. Also, a series of exception reports are
  available to help you reconcile and manage your
  physical inventory before you upload to Infinite
  Visions (Enterprise Edition). View the next BMI
  Product Matrix Comparison slide for more details.


64
Additional Scanning Systems from BMI
AssetTrak Pro TransTrak PPC
AssetTrak PRO Database for Departmental
Inventory that works with a Pocket PC scanner
Import data from a Spreadsheet
TransTrak and AssetTrak Pro are two more tools
that can make fixed asset management easier.
Contact BMI Systems Group for more details
65
BMI Product Matrix
66
When Choosing a Barcode Solutions Provider Check
us out
Serving the Private and Public Sector for over 24
Years with over 20 years experience in Asset
Management Integration
67

• Phone [phone]
• 800.264.9949
• Fax [phone]
• E-Mail bmisales_at_bmisys.com
• Website www.bmisys.com
