Title: CS 112 Introduction to Programming


1
CS 112 Introduction to Programming
  • Lecture 15
  • Defining Classes
  • Http//zoo.cs.yale.edu/classes/cs112/

2
Outline
  • Admin. and review
  • Classes and objects
  • Defining classes
  • Basic syntax
  • Examples

3
Admin.
  • Assignment 3
  • Due Oct. 13
  • Two problems
  • Problem 1 Control structure and method reuse
  • Problem 2 Method decomposition

4
Review Program Development Process
5
Design
year GetYearFromUser()
month GetMonthFromUser()
month ? 0
t
f
PrintMonth(month, year)
PrintYear(year)
6
Design PrintMonth( month, year )
Print month header
GetFirstWeekday (month, year)
IndentInitialWeekdays
GetMonthDays(month, year)
Print each day
7
Methods To Be Implemented and an Order to
Implement them
  • static string GetMonthName( int month )
  • // The English word for a specific month
  • static bool IsLeapYear( int month, int year )
  • // Check if a year is a leap year
  • static int GetMonthDays( int month, int year )
  • // Calculate the number of days for a specific
    month of a specific year
  • static int GetFirstWeekday( int month, int year
    )
  • // Calculate the weekday of the first day of a
    month (in a specific year)
  • static void IndentInitialWeekdays( int weekday )
  • // Indent the first line so that the first
    day appears in the correct position
  • static void PrintMonth( int month, int year )
  • static void PrintYear( int month, int year )
  • static void GievInstructions( int month, int year
    )
  • static void GetYearFromUser( int month, int year
    )
  • static void GetMonthFromUser( int month, int year
    )
  • static void Main( string args )

8
Example Implementing GetMonthName
  • static string GetMonthName(int month)
  • switch (month)
  • case 1 return ("January")
  • case 2 return ("February")
  • case 3 return ("March")
  • case 4 return ("April")
  • case 5 return ("May")
  • case 6 return ("June")
  • case 7 return ("July")
  • case 8 return ("August")
  • case 9 return ("September")
  • case 10 return ("October")
  • case 11 return ("November")
  • case 12 return ("December")
  • default return ("Illegal month")
  • // end of method GetMonthName

static void Main( string args )
Console.WriteLine( GetMonthName( 1 ) ) //
end of method Main
Test
9
Example Implementing IsLeapYear
  • static bool IsLeapYear(int year)
  • return ( (year 4 0) (year 100 ! 0)
    )
  • ( year 400 0)
  • // end of method IsLeapYear

static void Main( string args )
Console.WriteLine( IsLeapYear( 2000 ) )
Console.WriteLine( IsLeapYear( 1900 ) )
Console.WriteLine( IsLeapYear( 2003 ) ) // end
of method Main
10
Example Implementing GetMonthDays
  • static int GetMonthDays(int month, int year)
  • switch ( month )
  • case 2
  • return IsLeapYear( year ) ? 29 28
  • case 4 case 6 case 9 case 11
  • return (30)
  • default
  • return (31)
  • // end of switch
  • // end of method GetMonthDays

static void Main( string args )
Console.WriteLine( GetMonthDays( 2, 2000 ) )
Console.WriteLine( GetMonthDays( 2, 1900 ) )
Console.WriteLine( GetMonthDays( 6, 2003 )
) // end of method Main
11
Summary Method Control Flow
PrintMonth
GetMonthDays


GetMonthDays()



12
Summary
  • Design
  • Top-down stepwise refinement
  • Implementation and testing
  • Bottom-up
  • Write the simple functions first
  • Write a piece and test a piece
  • Test a method
  • using some dummy method calls, e.g.
  • Call the method in Main() with some typical
    test cases
  • using Visual Studio Immediate window

13
Outline
  • Admin. and review
  • Classes and objects
  • Defining a class
  • Basic syntax
  • Examples

14
Object-Oriented Design
  • The focus of methods is on doing things roughly
    speaking, we can say that methods focus on the
    verbs.
  • In object-oriented design, we focus on the nouns
  • In object-oriented design, we tend to group
    methods together according to the nouns
  • Important for large, complex programs

15
C Classes
  • A C class plays dual roles
  • Program module containing a list of (static)
    method declarations and (static) data fields
  • Blueprint for generating objects
  • It is the model or pattern from which objects are
    created
  • Supports two techniques which are essence of
    object-oriented programming
  • data encapsulation (for abstraction)
  • inheritance (for code reuse)

16
User-Defined Class
  • A user-defined class is also called a
    user-defined type
  • class written by a programmer
  • A class encapsulates (wrap together) data and
    methods
  • data members (member variables or instance
    variables)
  • methods that manipulate data members

17
Objects
  • An object has
  • state - descriptive characteristics
  • behaviors - what it can do (or be done to it)
  • For example, consider a coin in a computer game
  • The state of the coin is its current face (head
    or tail)
  • The behavior of the coin is that it can be
    flipped
  • Note the interactions between state and behaviors
  • the behavior of an object might change its state
  • the behavior of an object might depend on its
    state

18
Outline
  • Admin. and review
  • Classes and objects
  • Defining a class
  • Basic syntax
  • Examples

19
Defining Classes
  • Use Project lt Add Class to add a new class to
    your project
  • A class contains data declarations and method
    declarations

Data declarations
Method declarations
Member (data/method) Access Modifiers public
member is accessible outside the class private
member is accessible only inside the class
definition
20
Data Declarations
  • You can define two types of variables in a class
    but not in any method (called class variables)
  • static class variables
  • nonstatic variables are called instance variables
    (fields) because each instance (object) of the
    class has its own copy
  • class variables can be accessed in all methods of
    the class
  • Comparison Local variables
  • Variables declared within a method or within a
    block statement
  • Variables declared as local variables can only be
    accessed in the method or the block where they
    are declared

21
Method Declarations
  • A class can define many types of methods, e.g.,
  • Access methods read or display data
  • Predicate methods test the truth of conditions
  • Constructors
  • initialize objects of the class
  • they have the same name as the class
  • There may be more then one constructor per class
    (overloaded constructors)
  • can take arguments
  • they do not return any value
  • it has no return type, not even void

22
Outline
  • Admin. and review
  • Classes and objects
  • Defining a class
  • Basic syntax
  • Examples

23
Example Time1 class
  • We define the Time1 class to represent time
    midnight to 115959
  • The state of a time object can be represented by
  • hour, minute, second integers representing time
  • We might define the following methods
  • a Time1 constructor, to set up the object
  • a SetTime method, to set time
  • a ToUniversalString method, to convert the
    internal representation to a string representing
    the time in 24 hour format
  • a ToStandardString method, to convert the
    internal representation to a string representing
    the time in 12 hour format

24
Time1.cs
  • 1 // Fig. 8.1 Time1.cs
  • 2 // Class Time1 maintains time in 24-hour
    format.
  • 3
  • 4 using System
  • 5
  • 6 // Time1 class definition
  • 7 public class Time1
  • 8
  • 9 private int hour // 0-23
  • 10 private int minute // 0-59
  • 11 private int second // 0-59
  • 12
  • 13 // Time1 constructor initializes instance
    variables to
  • 14 // zero to set default time to midnight
  • 15 public Time1()
  • 16
  • 17 SetTime( 0, 0, 0 )
  • 18
  • 19

25
Time1.cs
  • 33 // convert time to universal-time (24
    hour) format string
  • 34 public string ToUniversalString()
  • 35
  • 36 return String.Format(
  • 37 "0D21D22D2", hour,
    minute, second )
  • 38
  • 39
  • 40 // convert time to standard-time (12
    hour) format string
  • 41 public string ToStandardString()
  • 42
  • 43 return String.Format(
    "01D22D2 3",
  • 44 ( ( hour 12 hour 0 ) ? 12
    hour 12 ),
  • 45 minute, second, ( hour lt 12 ? "AM"
    "PM" ) )
  • 46
  • 47
  • 48 // end class Time1

26
TimeTest1.cs
  • 1 // Fig. 8.2 TimeTest1.cs
  • 2 // Demonstrating class Time1.
  • 3
  • 4 using System
  • 5 using System.Windows.Forms
  • 6
  • 7 // TimeTest1 uses creates and uses a Time1
    object
  • 8 class TimeTest1
  • 9
  • 10 // main entry point for application
  • 11 static void Main( string args )
  • 12
  • 13 Time1 timeObj1 new Time1() //
    calls Time1 constructor
  • 14 string output
  • 15
  • 16 // assign string representation of
    time to output
  • 17 output "Initial universal time is "
  • 18 timeObj1.ToUniversalString()
  • 19 "\nInitial standard time is
    "

27
TimeTest1.cs Program Output
  • 34 output "\n\nAfter attempting
    invalid settings "
  • 35 "\nUniversal time "
    time.ToUniversalString()
  • 36 "\nStandard time "
    time.ToStandardString()
  • 37
  • 38 MessageBox.Show( output, "Testing
    Class Time1" )
  • 39
  • 40 // end method Main
  • 41
  • 42 // end class TimeTest1

28
Class View and Object Browser
  • Class View and Object Browser are features of
    Visual Studio that facilitate the design of
    object-oriented applications
  • Class View
  • Displays variables and methods for all classes in
    a project
  • Displays as treeview hierarchical structure
  • at nodes allows nodes to be expanded
  • - at nodes allows nodes to be collapsed
  • Can be seen by selecting View lt Class View

29
Class View Example
Fig. 8.20 Class View of class Time1 (Fig. 8.1)
and class TimeTest1 (Fig. 8.2).
30
Object Browser
  • Object Browser
  • Lists all classes in a library
  • Helps developers learn about the functionality of
    a specific class
  • To view the Object Browser select any .NET FCL
    method, right click, and select Go To Definition

31
Object Browser Example
Fig. 8.21 Object Browser when user selects
MessageBox from TimesTest1.cs.
32
Example 2 The Coin Class
  • We define a Coin class to model a coin in a game
  • In our Coin class we could define the following
    data
  • face, an integer that represents the current face
  • HEADS and TAILS, integer constants that represent
    the two possible states
  • We might also define the following methods
  • a Coin constructor, to set up the object
  • a Flip method, to flip the coin
  • a GetFace method, to return the current face
  • a StateToString method, to return a string
    description of the current state
  • See Coin.cs, CountFlips.cs, FlipRace.cs
  • To compile CountFlips csc CountFlips.cs
    Coin.cs
  • To compile FlipRace csc FlipRace.cs Coin.cs

33
Instance Data The Two Coins in FlipRace
34
Backup Slides
35
Summary Data Scope
  • Variables declared in a larger scope can be
    accessed in an enclosed scope, e.g.
  • Variables declared in a class can be accessed by
    the methods in the class
  • Variables declared in a method can only be
    accessed in the method
  • Variables declared in a block can only be
    accessed in the block
Write a Comment
User Comments (0)
About PowerShow.com
