CS1104 Computer Organization

1
CS1104 Computer Organization

• PART 2 Computer Architecture
• Lecture 2
• Performance Evaluation Benchmarking

2
Issues in Performance Evaluation

• Response time time between start and completion
  time of an event (execution time)
• Throughput total amount of work (or number of
  jobs) done in a given time
• Ex Replace a processor with a faster processor
  or add multiple slower processors? How is
  throughput and response time effected? How does
  this depend on job arrival rate?
• Notion of performance TIME - user perceived
  time, CPU time (user CPU time system CPU time),


3
Benchmarks Choosing Programs to Evaluate
Performance

• Measure the performance of a machine using a
  set of programs which will hopefully emulate the
  workload generated by the users programs.
  Benchmarks programs designed to measure
  performance

Disadvantages
Advantages

• overly specific
• non-portable
• difficult to run
• hard to identify source

• representative

Actual Target Workload

• portable
• widely used
• improvements useful in reality

• less representativethan above

Full Application Benchmarks
Small Kernel Benchmarks

• easy to use early in design cycle

• easy to fool

• peak may be far way from real application
  performance

Microbenchmarks

• identify peak capability and potential
  bottlenecks

4
Summarizing Performance
Average execution time
Weighted execution time
where the sum of the weights is equal to 1
5
SPEC Benchmarks

• Normalized execution times (divide execution time
  on a Sun SPARCstation by the execution time on
  the measured machine M) SPEC ratio
• Performance of a new program on M performance
  of the program on reference machine x SPEC ratio
• Average normalized execution times of multiple
  benchmarks can be expressed as either an
  arithmetic or a geometric mean

Geometric mean of normalized execution times
6
Design Principle
Make the common case fast Amdahls Law
Execution time of entire task without enhancement
Speedup
Execution time of entire task with enhancement
Execution time of entire task without enhancement

eold x (1-fracenhanced) enew x fracenhanced

• Fraction of the execution time that can benefit
  from the enhancement
• How much faster does the enhanced part run?

7
Examples

• Suppose we enhance a machine making all
  floating-point instructions run five times
  faster. If the execution time of some benchmark
  before the floating-point enhancement is 10
  seconds, what will the speedup be if half of the
  10 seconds is spent executing floating-point
  instructions?
• Time 5 non fl-pt. 5 fl-pt. / 5 6 sec.
• Speedup 10 / 6 1.33
• We are looking for a benchmark to show off the
  new floating-point unit described above, and want
  the overall benchmark to show a speedup of 3.
  One benchmark we are considering runs for 100
  seconds with the old floating-point hardware.
  How much of the execution time would
  floating-point instructions have to account for
  in this program in order to yield our desired
  speedup on this benchmark?
• Speedup 3 100 / (tfl / 5 100 - tfl) ? tfl
  83.33sec.

8
The CPU Performance Equation

• Instead of reporting execution time in seconds,
  we often use the number of clock cycles spent in
  executing a program
• Any instructions always starts at the beginning
  of a clock cycle
• Clock cycle time time between two ticks (in
  seconds)
• Clock rate (frequency) cycles per second (1
  Hz. 1 cycle/sec)A 200 Mhz. clock has a
  cycle time

Cycle time
9
The CPU Performance Equation
How many clock cycles are required to execute a
program?
if different instructions require different
number of clock cycles (which is mostly the case)
CPU time (instrA x cyclesA instrB x
cyclesB ) x cycle time
instrA, instrB, are the different possible
instructions
10
The CPU Performance Equation

• Instruction Count (IC) Total number of
  instructions executed for a program
• Average number of Clock Cycles Per Instruction
  (CPI) Total Clock Cycles/IC
• Total CPU time IC x CPI x Clock Cycle Time
• Therefore, CPU performance depends on
• Clock Cycle Time Hardware technology
  Organization
• CPI Organization Instruction Set Architecture
• IC Instruction Set Architecture (ISA) Compiler

These are dependent on each other, but at times
one can be changed with small and predictable
impacts on the other two
11
IC
CPI
Clock Cycle Time

• instr count ave. CPI clock rate
• Program X (X)
• Compiler X X
• ISA X X
• Organization X X
• Technology X

12

• Be careful of the following concepts
• Machine ? ISA and hardware organization
• Machine ? Cycle time
• ISA hardware organization
• ? cycles for any instruction (this is not
  CPI)
• ISA Compiler Program ? instructions
  executed
• Therefore, ISA Compiler Program hardware
  organization Cycle time ? Total CPU time

13
Summary

• What is Performance?
• How to determine performance? Use benchmarks
• How to summarize performance results
• Amdahls Law Make the common case faster
• CPU performance equation
• What determines CPU time (running time) of a
  program? -instructions, cycles per instruction,
  cycle time
• How do each of these depend on the ISA,
  organization, compiler, hardware technology

14
?
?
?
?
?
Questions!
