Buy an Arduino board by Robomart

1
Arduino
2
Arduino UNO Board
Uno" means one in Italian and was chosen to mark
the release of Arduino Software (IDE) 1.0. The
Uno board and version 1.0 of Arduino Software
(IDE) were the reference versions of Arduino, now
evolved to newer releases. The Uno board is the
first in a series of USB Arduino boards, and the
reference model for the Arduino platform
The Uno is a microcontroller board based on
the ATmega328P. It has 14 digital input/output
pins (of which 6 can be used as PWM outputs), 6
analog inputs, a 16 MHz quartz crystal, a USB
connection, a power jack, an ICSP header and a
reset button.
The Uno is open-source hardware!
Product Code RM0058
3
Features of Arduino UNO

• Microcontroller ATmeg328.
• Operating Voltage 5V.
• Input Voltage 7-12V.
• Digital I/O Pins 14 (of which 6 provide PWM
  output).
• Analog Input Pins 6.
• DC Current 40 mA.
• DC Current 50 mA.
• Flash Memory 32 KB.
• SRAM 2 KB.
• EEPROM 1 KB.
• Clock Speed 16 MHz.

4
Applications of Arduino UNO

• DIY project prototyping.
• Developing varied varieties of projects that
  require a code based control.
• Automation System development.
• Learning AVR programming.
• Entry level circuit designing.

Product Code RM0058
5
Description of Arduino Board
6
Description of Arduino Board
7
RELATED PRODUCTS
Arduino LCD Shield with Arduino UNO Board
Robomart ARDUINO Board (ATMEGA 8)
8
CONTACT US
B5, C Block Sector 31, Above Indian Overseas
Bank Noida Uttar Pradesh 201301 India
Mob. [phone] Tel. [phone]
Email ID admin_at_robomart.com Web.
https//www.robomart.com
9
THANK YOU
