Data Structures and Algorithms

1
Data Structures and Algorithms

• Week 2
• Dr. Ken Cosh

2
Week 1 Review

• Introduction to Data Structures and Algorithms
• Background
• Computer Programming in C
• Mathematical Background

3
Week 2 Topics

• Complexity Analysis
• Computational and Asymptotic Complexity
• Big-O Notation
• Properties of Big-O Notation
• Amortized Complexity
• NP-Completeness

4
Computational Complexity

• The same problem can be solved using many
  different algorithms
• Factorials can be calculated iteratively or
  recursively
• Sorting can be done using shellsort, heapsort,
  quicksort etc.
• So how do we know what the best algorithm is?
  And why do we need to know?

5
Why do we need to know?

• If searching for a value amongst 10 values, as
  with many of the exercises we have encountered
  while learning computer programming, the
  efficiency of the program is maybe not as
  significant as getting the job done.
• However, if we are looking for a value amongst
  several trillion values, as only one step in a
  longer algorithm establishing the most efficient
  searching algorithm is very significant.

6
How do we find the most efficient algorithm?

• To compare the efficiency of algorithms,
  computational complexity can be used.
• Computational Complexity is a measure of how much
  effort is needed to apply an algorithm, or how
  much it costs.
• An algorithms cost can be considered in
  different ways, but for our means Time and Space
  are critical. Time being the most significant.

7
Computational Complexity Considerations

• Computational Complexity is both platform /
  system and language dependent
• An algorithm will run faster on my PC at home
  than the PCs in the lab.
• A precompiled program written in C is likely to
  be much faster than the same program written in
  Basic.
• Therefore to compare algorithms all should be run
  on the same machine.

8
Computational Complexity Considerations II

• When comparing algorithm efficiencies, real-time
  units such as nanoseconds need not be used.
• Instead logical units representing the
  relationship between n the size of a file, and
  t the time taken to process the data should be
  used.

9
Time / Size relationships

• Linear
• If tcn, then an increase in the size of data
  increases the execution time by the same factor
• Logarithmic
• If tlog2n then doubling the size n increases
  t by one time unit.

10
Asymptotic Complexity

• Functions representing n and t are normally
  much more complex, but calculating such a
  function is only important when considering large
  bodies of data, large n.
• Ergo, any terms which dont significantly affect
  the outcome of the function can be eliminated,
  producing a function which approximates the
  functions efficiency. This is called Asymptotic
  Complexity.

11
Example I

• Consider this example
• F(n) n2 100n log10n 1000
• For small values of n, the final term is the most
  significant.
• However as n grows, the first term becomes most
  significant. Hence for large n it isnt worth
  considering the final term how about the
  penultimate term?

12
Example II
13
Big-O Notation

• Given 2 positively-valued functions (f() and
  g())
• f(n) is O(g(n)) if (cgt0 and Ngt0) exist such that
  f(n) cg(n) for all n N.
• (in other words) f is big-O of g if there is a
  positive number c such that f is not larger than
  cg for sufficiently large ns (all ns larger than
  some number N).
• The relationship between f and g is that g(n) is
  an upper bound of f(n), or that in the long run f
  grows at most as fast as g.

14
Big-O Notation problems

• The problem with the definition is that while c
  and N must exist, no help is given towards
  calculating them
• No restrictions are given for these values.
• No guidance for choosing values when more than
  one exist.
• The choice for g() is infinite! (so when dealing
  Big-O the smallest g() is chosen).

15
Example I

• Consider
• f(n) 2n2 3n 1 O(n2)
• When g(n) n2, candidates for c and N can be
  calculated using the following inequality
• 2n2 3n 1 cn2
• 2 (3/n) 1/n2 c
• If n 1, c 6. If n 2, c 3.75. If n 3,
  c 3.111, If n 4, c 2.8125.

16
Example II

• So what pair of c N?
• Choose the best pair by determining when a term
  in f becomes the largest and stays the largest.
  In our equation on 2n2 and 3n are candidates.
  Comparing them, 2n2 gt 3n holds true for n gt 1,
  hence N 2 can be chosen.
• But whats the practical significance of c and N?
• For any g an infinite number of pairs of c N
  can be calculated.
• g is almost always greater than or equal to f
  when multiplied by a constant. Almost always
  means when n is greater than N. The constant
  then depends on the value of N chosen.

17
Big-O

• Big-O is used to give an asymptotic upper bound
  for a function, i.e. an approximation of the
  upper bound of a function which is difficult to
  formulate.
• Just as there is an upper bound, there is a lower
  bound (Big-O), well come on to that shortly
• But first, some useful properties of Big-O.

18
Fact 1 - Transitivity

• If f(n) is O(g(n)) and g(n) is O(h(n)), then f(n)
  is O(h)n)) or O(O(g(n))) is O(g(n)).
• Proof
• c1 and N1 exist so that f(n)c1g(n) for all nN1.
• c2 and N2 exist so that g(n)c2h(n) for all nN2.
• c1g(n)c1c2h(n) for all nN, when N the larger
  of N1 and N2
• Hence if c c1c2, f(n)c1h(n) for all nN.
• f(n) is O(h)n))

19
Fact 2

• If f(n) is O(h(n)) and g(n) is O(h(n)), then f(n)
  g(n) is O(h(n)).
• Proof
• After c c1c2, f(n)g(n)ch(n).

20
Fact 3

• The function ank is O(nk)
• Proof
• For the inequality ankcnk to hold, ca is
  necessary.

21
Fact 4

• The function nk is O(nkj) for any positive j.
• Proof
• This is true if cN1.
• From this, it is clear that every polynomial is
  big-O of n raised to the largest power
• f(n) aknk ak-1nk-1 a1n a0 is O(nk)

22
Big-O and Logarithms

• First lets state that if the complexity of an
  algorithm is on the order of a logarithmic
  function, it is very good! (Check out slide 12).
• Second lets state that despite that, there are an
  infinite number of better functions, however very
  few are useful O(lg lg n) or O(1).
• Therefore, it is important to understand big-O
  when it comes to Logarithms.

23
Fact 5 - Logarithms

• The function logan is O(logbn) for any positive a
  and b ? 1.
• This means that regardless of their bases all
  logarithmic functions are big-O of each other
  i.e. all have the same rate of growth.
• Proof
• logan x, logbn y, i.e. axn, byn
• ln of both sides gives, x ln a ln n and x ln b
  ln n
• x ln a y ln b
• ln a logan ln b logbn
• logan (ln b / ln a) logbn c logbn
• Hence logan and logbn are multiples of each
  other.

24
Fact 5 (cont.)

• Because the base of a logarithm is irrelevant in
  terms of big-O we can use just one base
• Logan is O(lg n) for any positive a?1, where lg n
  log2n

25
Big-O

• Big-O refers to the upper bound of functions.
  The opposite of this is a definition for the
  lower bound of functions, known as big-O (big
  omega)
• f(n) is O(g(n)) if (cgt0 and Ngt0) exist such that
  f(n) cg(n) for all n N.
• (in other words) f is big- O of g if there is a
  positive number c such that f is at least equal
  to cg for almost all ns (all ns larger than some
  number N).
• The relationship between f and g is that g(n) is
  an lower bound of f(n), or that in the long run f
  grows at least as fast as g.

26
Big-O example

• Consider
• f(n) 2n2 3n 1 O(n2)
• When g(n) n2, candidates for c and N can be
  calculated using the following inequality
• 2n2 3n 1 cn2
• 2 (3/n) 1/n2 c
• As we saw before, in this equation c tends
  towards 2 as n grows, hence the proposal is true
  for all c2.

27
Big-O

• f(n) is O(g(n)) iff g(n) is O(f(n))
• There is a clear relationship between big- O and
  big-O, and the same (in reverse) problems and
  facts hold true for in both cases
• There are still infinite numbers of big-O
  equations.
• Therefore we can explore the relationship between
  big-O and big-O further by introducing big-T
  (theta), which restricts the sets of possible
  upper and lower bounds.

28
Big-T

• f(n) is T(g(n)) if c1,c2,N gt 0 exist such that
  c1g(n) f(n) c2g(n) for all nN.
• From this f(n) is Tg(n) if both functions grow at
  the same rate in the long run.

29
O, O T

• For the function
• f(n) 2n2 3n 1
• Options for big-O include
• g(n) n2, g(n) n3, g(n) n4 etc.
• Options for big-O include
• g(n) n2, g(n) n, g(n) n½
• Options for big-T include
• g(n) n2, g(n) 2n2, g(n) 3n2
• Therefore, while there are still an infinite
  number of equations to choose from, it is obvious
  which equation should be chosen.

30
Possible problems with Big-O

• Given the rules of Big-O an equation g(n) can be
  chosen such that f(n)cg(n) assuming the constant
  c is large enough.
• As c grows, the number of exceptions (essentially
  n) is reduced.
• If c108, g(n) might not be very useful for
  approximating f(n), as our algorithm may never
  need to perform 108 operations.
• This may lead to algorithms being rejected
  unnecessarily.
• If c is too large for practical significance g(n)
  is said to be OO of f(n) (double-O), however too
  large depends upon the application.

31
Why Complexity Analysis?

• Todays computers can perform millions of
  operations per second at relatively low cost, so
  why complexity analysis?
• With a PC that can perform 1 million operations
  per second and 1 million items to be processed.
• A quadratic equation O(n2) would take 11.6 days.
• A cubic equation O(n3) would take 31,709 years.
• An exponential equation O(2n) is not worth
  thinking about.

32
Why Complexity Analysis

• Even a 1,000 times improvement in processing
  power (consider Moores Law).
• The cubic equation would take over 31 years.
• The quadratic would still be over 16 minutes.
• To make scalable programs algorithm complexity
  does need to be analysed.

33
Complexity Classes

• 1 operation per µsec (microsecond), 10
  operations to be completed.
• Constant O(1) 1 µsec
• Logarithmic O(lg n) 3 µsec
• Linear O(n) 10 µsec
• O(n lg n) 33.2 µsec
• Quadratic O(n2) 100 µsec
• Cubic O(n3) 1msec
• Exponential O(2n) 10msec

34
Complexity Classes

• 1 operation per µsec (microsecond), 102
  operations to be completed.
• Constant O(1) 1 µsec
• Logarithmic O(lg n) 7 µsec
• Linear O(n) 100 µsec
• O(n lg n) 664 µsec
• Quadratic O(n2) 10 msec
• Cubic O(n3) 1 sec
• Exponential O(2n) 3.171017 yrs

35
Complexity Classes

• 1 operation per µsec (microsecond), 103
  operations to be completed.
• Constant O(1) 1 µsec
• Logarithmic O(lg n) 10 µsec
• Linear O(n) 1 msec
• O(n lg n) 10 msec
• Quadratic O(n2) 1 sec
• Cubic O(n3) 16.7min
• Exponential O(2n)

36
Complexity Classes

• 1 operation per µsec (microsecond), 104
  operations to be completed.
• Constant O(1) 1 µsec
• Logarithmic O(lg n) 13 µsec
• Linear O(n) 10 msec
• O(n lg n) 133 msec
• Quadratic O(n2) 1.7 min
• Cubic O(n3) 11.6 days

37
Complexity Classes

• 1 operation per µsec (microsecond), 105
  operations to be completed.
• Constant O(1) 1 µsec
• Logarithmic O(lg n) 17 µsec
• Linear O(n) 0.1 sec
• O(n lg n) 1.6 sec
• Quadratic O(n2) 16.7 min
• Cubic O(n3) 31.7 years

38
Complexity Classes

• 1 operation per µsec (microsecond), 106
  operations to be completed.
• Constant O(1) 1 µsec
• Logarithmic O(lg n) 20 µsec
• Linear O(n) 1 sec
• O(n lg n) 20 sec
• Quadratic O(n2) 11.6 days
• Cubic O(n3) 31,709 years

39
Asymptotic Complexity Example

• Consider this simple code
• for (i sum 0 i lt n i)
• sum ai
• First 2 variables are initialised.
• The loop executes n times, with 2 assignments
  each time (one updates sum and one updates i)
• Thus there are 22n assignments for this code
  and so an Asymptotic Complexity of O(n).

40
Asymptotic Complexity Example 2

• Consider this code
• for (i 0 i lt n i)
• for (j 1, sum a0 j lt i j) sum
  aj
• coutltltsum for subarray 0 through ltlt i ltlt
  is ltltsumltltendl
• Before loop starts there is 1 initialisation (i)
• The outer loop executes n times, each time
  calling the inner loop and making 3 assignments
  (sum, i and j)
• The inner loop executes i times for each
  i?1,,n-1 (the elements in i) with 2
  assignments in each case (sum and j)

41
Asymptotic Complexity Example 2 (cont.)

• Therefore there are
• 13nn(n-1) or O(n2)
• assignments before the program completes.

42
Asymptotic Complexity 3

• Consider this refinement
• for (i 4 i lt n i)
• for (j i - 3, sum ai-4 j lt i j) sum
  aj
• coutltltsum for subarray ltlti-4 ltlt through
  ltlt i ltlt is ltltsumltltendl
• How would you calculate the asymptotic complexity
  of this code?

43
The Number Game

• Ive picked a number between 1 and 10 can you
  guess what it is?
• Take a guess, and Ill tell you if its higher or
  lower than your guess.

44
The Number Game

• There are several approaches you could take
• Guess 1, if wrong guess 2, if wrong guess 3, etc.
• Alternatively, guess the midpoint 5. If lower
  guess halfway between 1 and 5, maybe 3 etc.
• Which is more better?
• It depends on what the number was! But, in each
  option there is a best, worst and average case.

45
Average Case Complexity

• Best Case
• Number of steps is smallest
• Worst Case
• Number of steps is maximum
• Average Case
• Somewhere in between.
• Could calculate as the sum of the number of steps
  for each input divided by the number of inputs.
  But this assumes each input has equal
  probability.
• So we weight calculation with the probability of
  each input.

46
Method 1

• Choose 1, if wrong choose 2 , if wrong choose 3
• Probability of success for 1st try 1/n
• Probability of success for 2nd try 1/n
• Probability of success for nth try 1/n
• Average 12n / n (n1)/2

47
Method 2

• Picking midpoints
• Method 2 is actually like searching a binary
  tree, so we will leave a full calculation until
  week 6, as right now the maths could get
  complicated.
• But for n10, you should be able to calculate the
  average case try it! (When n10 I make is 1.9
  times as efficient)

48
Average Case Complexity

• Calculating Average Case Complexity can be
  difficult, even if the probabilities are equal,
  so calculating approximations in the form of
  big-O, big-O and big-T can simplify the task.

49
Amortized Complexity

• Thus far we have considered simple algorithms
  independently from any others, however its more
  likely these algorithms are part of a larger
  problem.
• To calculate the best, worst and average case for
  the whole sequence, we could simply add the best,
  worst and average cases for each algorithm in the
  sequence
• Cworst(op1, op2, op3, ) Cworst(op1)Cworst(op2)
  Cworst(op3)

50
Grades Case

• Suppose I create an array in which to store
  student grades. I then enter the midterm grades
  and sort the array best to worst. Next I enter
  the coursework grades, and then sort the array
  best to worst. Finally I enter the final exam
  grades and sort the array best to worst.
• This is a sequence of algorithms
• Input Values
• Sort Array
• Input Values
• Sort Array
• Input Values
• Sort Array

51
Grades Case

• However, is it fair to calculate the worst case
  for this program by adding the worst cases for
  each step?
• Is it fair to use the worst case Sort Array
  cost for sorting the array every time, even after
  it has only changed slightly?
• Is it likely that the array will need a complete
  rearrangement after the coursework grade has been
  added? i.e. is it likely that the student who
  receives the lowest mid term grade then has the
  highest score after midterm and coursework are
  included?

52
Grades Case

• In reality it is unlikely that the worst case
  scenario will ever be run for the 2nd and 3rd
  array sorts, so how do we approximate an accurate
  worst case when combining a sequence of
  operations?
• Steal from the rich, and give to the poor.
• Add a little to the quick operations and take a
  little from the expensive operations.
• Overcharge cheap operations, undercharge
  expensive ones.

53
Bangkok

• I want to drive to Bangkok how long will it
  take?
• Average Case?
• Best Case?
• Worst Case?
• How do you come to your answer?

54
ltVectorgt

• ltVectorgt is a library we first encountered during
  computer programming 1. It defines a data
  structure remember how it worked?
• Add elements to the vector when there is space
  through push_back.
• When capacity is reached add to capacity through
  reserve.
• Suppose each time the capacity is full, we double
  the size of the vector how can we estimate an
  amortized cost of filling the vector?

55
ltVectorgt

• Case of adding an element to a vector with space
• Copy new values into first available cell.
• O(1)
• Case of adding an element to a full vector
• Copy existing values to new space
• Add new value
• O(size(vector)1)
• i.e. if the vector capacity and size is 4, the
  cost of adding an element would be 41.

56
Amortized cost 2
57
Amortized cost 3
58
Amortized Cost

• From the previous 2 tables it can be seen that an
  amortized cost of 2 is not enough.
• With an Amortized cost of 3, there are sufficient
  units left over to cover expensive operations.
• Finding an acceptable amortized cost is however
  not always that easy.

59
Difficult Problems

• It would be ideal if problems were of class
  constant, linear or logarithmic.
• However, many problems we will look at are
  polynomial class problems (quadratic / cubic or
  worse) - P
• Unfortunately, there are many important problems
  whose best algorithms are very complex, sometimes
  taking exponential time (and in fact sometimes
  worse!)
• As well as EXPTIME problems there is another
  class of problem call NP-Complete, which is bad
  news, evidence that some problems just cant be
  solved easily.

60
NP-Complete

• Why worry about it?
• Knowing that some problems are NP-Complete saves
  you blindly trying to find a solution to them.

61
NP-Complete

• Background
• P refers to the class of problems which can be
  solved in polynomial time.
• NP stands for Non-deterministic Polynomial Time
• Essentially here, we can test whether a proposed
  solution is correct fairly quickly, but finding a
  solution is difficult. There is no problem with
  an NP problem if we could only guess the right
  solution!

62
NP Examples

• Long Simple Path
• Finding a path through a graph from A to B
  traveling over ever vertex once and only once is
  very difficult, but if I tell you a solution path
  it is relatively simple for you to check it. The
  Traveling Salesman Problem is a long ongoing
  problem, with huge financial rewards for a
  successful solution!
• Cracking Cryptography
• Its difficult to break encryption, but if I give
  you a solution, it is easy to test it works.
• Infinite Loop Checking
• Ever wondered why your compiler doesnt tell you
  youve got an infinite loop? This problem is
  actually much harder than NP a class of
  complexity known as undecidable

63
P vs NP

• Arguably one of the most famous current
  theoretical science debates concerns whether
  PNP, with many theoreticians divided.
• While all P problems are NP, is the reverse true?
• If it is always easy to check a solution, should
  it also be easy to find the solution? Can you
  prove either way?
• This leads us to a complexity framework where we
  cant prove that a problem isnt P, but known to
  be NP, and this is where NP-Complete fits in.

64
NP-Complete

• NP-Complete problems are the hardest problems
  within NP, which are not known to have solutions
  in polynomial time.
• We are still left with the problem of identifying
  NP-Complete problems.
• How can we prove that a problem is not known to
  have a solution in polynomial time?
• (Rather than just a problem we havent solved?)

65
Reduction

• We can often reduce problems
• Problem A, can be solved by an algorithm
  involving a number of calls to Algorithm B.
• The number of calls could 1, a constant or
  polynomial.
• If Algorithm B is P, then this demonstrates that
  Algorithm A is also P.
• The same theory applies to NP-Complete problems.

• If Problem is NP-Complete if it is NP, and all
  other NP problems are polynomially reduced to it.
• The astute will realise that to prove a problem
  is NP-Complete it takes a problem which has
  already been proved to be NP-Complete. A kind of
  Chicken and Egg scenario, where fortunately
  Cooks satisfiability problem came first.
• We will encounter more NP-Complete problems when
  dealing with graphs later in the course.
