Arduino UNO Board



• By Robomart

2
Introduction of Arduino UNO Board

• Arduino board and accessories is easily
  accessible to all users whether online or
  directly.
• In this modern technology, users can easily
  prepare kits at home.
• In terms of boards arduino UNO is the perfect
  board to work on.
• Its been described as an open source phase for
  electronics projects. It comprises of a
  microcontroller board that can be easily
  accessible interfacing using an analog to digital
  adapter or using a power supply.
• Its configuration describes its reliability and
  compatibility with other devices.
• Students can grab the latest version and
  information by just clicking our website.
• Online purchasing is also available with ease for
  students.

3
Pin out of Arduino UNO
Pin Out of Arduino UNO Board
4
Features of Arduino UNO

• Microcontroller ATmega328P
• Operating Voltage 5V
• Input Voltage (recommended) 7-12V
• Digital I/O Pins 14 (of which 6 provide PWM
  output)
• Analog Input Pins 6
• DC Current per I/O Pin 40 mA
• DC Current for 3.3V Pin 50 mA
• Flash Memory 32 KB
• SRAM 2 KB
• EEPROM 1 KB
• Clock Speed 16 MHz
• Weight 25g

5
Applications of Arduino UNO Board

• First is a robot that simply walks and
  demonstrates a tiny breadboard, wires and a UNO
  board making robot run and dance.
• Second include SMS alarm system in which
  resistors, sensors and alarm is used to detect
  visibility of persons at your door.
• Third is the robot boat that sense and detect to
  move the pen on the surface to draw shapes.
• Fourth is the robotic arm that helps in the
  movement of environmental circumstances. It
  calculates six servomotors, Lexan polycarbonate
  parts with ultrasonic sensor which help in
  judging the movement in air.
•  Finally a traffic light controller that helps in
  communicating the vehicles in aligned manner with
  simple coding done.
