Coastal Zone Module

1
Coastal Zone Module

• Tiffany L. Hepner
• Bureau of Economic Geology
• John A. and Katherine Jackson School of
  Geosciences
• The University of Texas at Austin
• Development of this module has been funded by
  National Science Foundation Geoscience Education
  GEO-0224501

2
Texas High School Coastal Monitoring Program

• Funding for THSCMP is provided by the Texas
  Coastal Coordination Council, Conoco, the Exxon
  Foundation, and the Wray Family Trust.

3
Texas High School Coastal Monitoring Program

• Provide high school students with an
  inquiry-based learning experience.
• Increase public awareness and understanding of
  coastal processes and hazards.
• Obtain a better understanding of the relationship
  between coastal processes, beach morphology, and
  shoreline change, and make data and findings
  available for solving coastal management
  problems.
• http//txcoast.beg.utexas.edu/thscmp/

4
Study Area
5
Student Orientation
6
Beach Measurements

• Topographic transect oriented perpendicular to
  the shoreline. For comparison through time,
  profiles are measured from the same starting
  point landward of the beach and oriented in the
  same direction.
• Purpose
• Provide quantitative morphological data and
  shoreline and vegetation line positions
• Method
• Measure relative changes in beach topography
  using Emery rods and tape measure
• Equipment
• Emery rods Tape measure (at least 5m)
• Hand sighting level Survey flags
• Sighting compass Data forms and clipboard

7
Topographic Profile
Determine vertical change between front and back
Emory rods using siting level or horizon
Measure horizontal distance between Emory rods
8
(No Transcript)
9
Processes measurements

• Estimates of processes acting on the beach wind
  direction and speed wave breaker type surf zone
  width wave direction, height, and period number
  of apparent longshore bars longshore current
• Purpose
• Explore relationship between processes and beach
  changes. Over time these data may be used to
  calibrate, for a specific beach location, data
  acquired by weather and wave stations in the
  area. Encourage students to systematically
  observe processes that surround them
• Method
• Visual observations averaged among three
  observers. Float and stopwatch for longshore
  current. Hand-held wind gauge
• Equipment
• Tape measure Sighting compass
• wind gauge 3 floats
• Data forms and clipboard

10
Beach Observations
Observation of waves
Observation of wind
Orientation of Dunes and Shoreline
Measuring Speed and Direction of Current
11
(No Transcript)
12
Shoreline Measurements

• Horizontal (no elevation) survey of the
  vegetation line and shoreline. Shoreline and
  foredune trends. Measurement of beach cusps
• Purpose
• Provide quantitative data on the position and
  trend of the shoreline and the longshore spacing
  and relief of beach cusps
• Method
• Differential Global Positioning System walking
  survey
• Equipment
• Differential Global Positioning System (GPS)
  receiver
• Emery rods Digital camera
• Sighting level Sighting Compass
• Tape measure Data forms and clipboard

13
Mapping Shoreline and Vegetation Line with GPS
14
(No Transcript)
15
2002-2003 Student Participants
16
Beach Features
17
Barrier Island System
18
Barrier Island Cross-Section
19
(No Transcript)
20
Tropical Storm Frances
21
Tropical Storm Frances

• September 7-13, 1998
• Extensive beach and dune erosion and damage to
  structures.
• Storm surge peaked at 1.4 meters above mean sea
  level.
• Peak wave height 4.09 meters
• Extreme water levels (gt0.78 meters) lasted 64
  hours and extreme wave heights (gt2.3 meters)
  lasted 73 hours.

22
Ball High School Monitoring Sites
23
BEG02 Pre-Tropical Storm Frances
24
BEG02 Post-Tropical Storm Frances
25
Coastal Processes
26
Waves

• There are 3 forces that form waves wind,
  earthquakes, and gravitational attractions
  between Earth, Sun, and Moon.
• Ocean waves are typically formed by the wind
  (friction between the wind and the waters
  surface).
• The size of a wave depends upon the wind speed,
  length of time wind blows in the same direction,
  and the fetch (distance over which the wind
  blows).
• Wind waves will continue as long as the wind is
  blowing. Once the wind stops the waves will
  continue until all of their energy is dissipated.

27
Wave Diagram
Wave Period time it takes 2 successive crests
(or troughs) to pass a fixed point Frequency
number of waves per second (1/period)
28
Wave Motion

• Water particles in waves move in a nearly
  stationary circular motion.
• At the surface, the orbit is equal to the wave
  height. The orbits decreases in size downward
  through water column to a depth of L/2.
• Breaking occurs when crest angle is less than
  120º or a steepness (H/L) greater than 1/7.

29
Breaker Types

• Spilling Breaker-gentle beach slope, waves break
  far from shore and surf gently rolls over the
  front of the wave
• Plunging Breaker-moderately steep beach slope,
  less steep wave, slightly longer period, wave
  curls over forming a tunnel until wave breaks
• Surging Breaker-steep beach slope, low wave of
  long period, doesnt actually break-wave rolls
  onto beach

30
Tides

• Tides are actually waves. They are caused by the
  gravitational forces of the Earth, Moon, and Sun.
• Tides are caused by a relationship between mass
  of the above celestial objects as well as their
  distance from Earth.
• The moon orbits the Earth once every 27 days and
  8 hours. Therefore, the tides move up 50 minutes
  every day.
• High tide is generated by the pull of the moon
  upon global waters. There is an equal pull on the
  opposite side of the Earth from the moon.
• Spring tides occur when the Earth, sun, and moon
  line up (new and full moon-2x during the lunar
  month). Spring tides have the largest tidal
  ranges.
• Neap tides occur when the moon is in the first
  and third quarter (tidal range smallest).

31
Galveston Pleasure Pier
Neap
Spring
Neap
Spring
32
Galveston Pleasure Pier-June 2003
33
Hurricane Claudette Water Levels Corpus Christi
July 10-20, 2003
