OSPF Monitor Architecture, Design and Deployment Experience

1
OSPF Monitor Architecture, Design and Deployment
Experience

• Aman Shaikh
• Albert Greenberg
• ATT Labs - Research
• NSDI 2004

2
Objectives for OSPF Monitor

• Real-time analysis of OSPF behavior
• Trouble-shooting, alerting, validation of
  maintenance
• Real-time snapshots of OSPF network topology
• Off-line analysis
• Post-mortem analysis of recurring problems
• Generate statistics and reports about network
  performance
• Identify anomaly signatures
• Facilitate tuning of configurable parameters
• Improve maintenance procedures
• Analyze OSPF behavior in commercial networks

3
OSPF Monitor in a Nutshell

• Collect OSPF LSAs (Link State Advertisements)
  passively from network
• Every router describes its local connectivity in
  an LSA
• Router originates an LSA due to...
• Change in network topology
• Periodic soft-state refresh
• LSA is flooded to other routers in the domain
• Flooding is reliable and hop-by-hop
• Flooding leads to duplicate copies of LSAs being
  received
• Every router stores LSAs (self-originated
  received) in link-state database ( topology
  graph)
• Real-time analysis of LSA streams
• Archive LSAs for off-line analysis

4
Components

• Data collection LSA Reflector (LSAR)
• Passively collects OSPF LSAs from network
• Reflects streams of LSAs to LSAG
• Archives LSAs for analysis by OSPFScan
• Real-time analysis LSA aGgregator (LSAG)
• Monitors network for topology changes, LSA
  storms, node flaps and anomalies
• Off-line analysis OSPFScan
• Supports queries on LSA archives
• Allows playback and modeling of topology changes
• Allows emulation of OSPF routing

5
Example
LSAs
LSAs
TCP Connection
LSAs
LSAR 1
LSAR 2
Reflect LSA
Reflect LSA
replicate
LSAs
LSAs
LSAs
OSPF Network
Area 0
Area 2
Area 1
6
How LSAR attaches to Network

• Host mode
• Join multicast group
• Adv completely passive
• Disadv not reliable, delayed initialization of
  LSDB
• Full adjacency mode
• Form full adjacency ( peering session) with a
  router
• Adv reliable, immediate initialization of LSDB
• Disadv LSARs instability can impact entire
  network
• Partial adjacency mode
• Keep adjacency in a state that allows LSAR to
  receive LSAs, but does not allow data forwarding
  over link
• Adv reliable, LSARs instability does not impact
  entire network, immediate initialization of LSDB
• Disadv can raise alarms on the router

7
Partial Adjacency for LSAR
I need LSA L from LSAR
Partial state

• Router R does not advertise a link to LSAR

• LSAR does not originate any LSAs

• Routers (except R) not aware of LSARs presence
• Does not trigger routing calculations in network
• LSARs going up/down does not impact network

• LSAR?R link is not used for data forwarding

8
LSA aGregator (LSAG)

• Analyzes reflected LSAs from LSARs in real-time
• Generates console messages
• Change in OSPF network topology
• ADJACENY COST CHANGE rtr 10.0.0.1 (intf
  10.0.0.2) ? rtr 10.0.0.5 old_cost 1000 new_cost
  50000 area 0.0.0.0
• Node flaps
• RTR FLAP rtr 10.0.0.12 no_flaps 7 flap_window
  570 sec
• LSA storms
• LSA STORM lstype 3 lsid 10.1.0.0 advrt 10.0.0.3
  area 0.0.0.0 no_lsas 7 storm_window 470 sec
• Anomalous behavior
• TYPE-3 ROUTE FROM NON-BORDER RTR ntw 10.3.0.0/24
  rtr 10.0.0.6 area 0.0.0.0
• Dumps snapshots of network topology

9
OSPFScan

• Tools for off-line analysis of LSA archives
• Parse, select (based on queries), and analyze
• Functionality supported by OSPFScan
• Classification of LSA traffic
• Change LSAs, refresh LSAs, duplicate LSAs
• Emulation of OSPF Routing
• How OSPF routing tables evolved in response to
  network changes
• How end-to-end path within OSPF domain looked
  like at any instance
• Modeling of topology changes
• Vertex addition/deletion and link
  addition/deletion/change_cost
• Playback of topology change events
• Statistics and report generation

10
Performance Evaluation

• Performance of LSAR and LSAG through lab
  experiments
• LSAR and LSAG are key to real-time monitoring
• How performance scales with LSA-rate and network
  size

11
Experimental Setup
PC
SUT
LSAG
TCP connection
OSPF adjacency
Zebra
LSAR
TCP connection
12
Methodology

• Send a burst of LSAs from Zebra to LSAR
• Vary number of LSAs (l) in a burst of 1 sec
  duration
• Use of fully connected graph as the emulated
  topology
• Vary number of nodes (n) in the topology
• Performance measurements
• LSAR performance LSA pass-through time
• Zebra measures time difference between sending
  and receiving an LSA from LSAR
• LSAG performance LSA processing time
• Instrumentation of LSAG code

13
LSAR Performance
14
LSAG Performance
15
Deployment

• Tier-1 ISP network
• Area 0, 100 routers point-to-point links
• Deployed since January, 2003
• LSA archive size 8 MB/day
• LSAR connection partial adjacency mode
• Enterprise network
• 15 areas, 500 routers Ethernet-based LANs
• Deployed since February, 2002
• LSA archive size 10 MB/day
• LSAR connection host mode

16
LSAG in Day-to-day Operations

• Generation of alarms by feeding messages into
  higher layer network management systems
• Grouping of messages to reduce the number of
  alarms
• Prioritization of messages
• Validation of maintenance steps and monitoring
  the impact of these steps on network-wide OSPF
  behavior
• Example
• Network operators use cost-out/cost-in of links
  to carry out maintenance
• A link-audit web-page allows operators to keep
  track of link costs in real-time

17
Problems Caught by LSAG

• Equipment problem
• Detected internal problems in a crucial router in
  enterprise network
• Problem manifested as episodes of OSPF adjacency
  flapping
• Configuration problem
• Identified assignment of same router-id to two
  routers in enterprise network
• OSPF implementation bug
• Caught a bug in type-3 LSA generation code of a
  router vendor in ISP network
• Faster refresh of LSAs than standards-mandated
  rate

18
Long Term Analysis by OSPFScan

• LSA traffic analysis
• Identified excessive duplicate LSA traffic in
  some areas of Enterprise Network
• Led to root-cause analysis and preventative steps
• Statistics generation
• Inter-arrival time of change LSAs in ISP network
• Fine-tuning configurable timers related to route
  calculation ( SPF calculation)
• Mean down-time and up-time for links and routers
  in ISP network
• Assessment of reliability and availability

19
Lessons Learned through Deployment

• New tools reveal new failure modes
• Real-time alerting and off-line analysis are
  complementary
• Distributed architecture helped a lot
• OSPF exhibits significant activity in real
  networks
• Maintenance and genuine problems
• Add functionality incrementally and through
  interaction with users
• Archive all LSAs
• LSA volume is manageable
• Dont throw away refresh and duplicate LSAs

20
Conclusion

• Three component architecture
• LSAR data collection
• LSAG real-time analysis
• OSPFScan off-line analysis
• Performance analysis
• LSAR and LSAG scale well as LSA-rate and network
  size increases
• Deployment
• Deployed in Tier-1 ISP and Enterprise network
• Has proved to be an extremely valuable tool for
  network management
• OSPF Monitor was a Lifesaver
• VP of Networking, Enterprise network?

21
Future Work

• Real-time analysis
• Correlation with other fault and performance data
  for more meaningful alerting
• Prioritization of alerts
• Off-line analysis
• Correlation with other data sources
• Work already underway BGP, fault, performance
• Identification of problem signatures and feeding
  them into real-time component for problem
  prediction

22
Backup Slides
23
Overview of OSPF

• OSPF is a link-state protocol
• Every router learns entire network topology
• Topology is represented as graph
• Routers are vertices, links are edges
• Every link is assigned weight through
  configuration
• Every router uses Dijkstras single source
  shortest path algorithm to build its forwarding
  table
• Router builds Shortest Path Tree (SPT) with
  itself as root
• Shortest Path Calculation (SPF)
• Packets are forwarded along shortest paths
  defined by link weights

24
Areas in OSPF

• OSPF allows domain to be divided into areas for
  scalability
• Areas are numbered 0, 1, 2
• Hub-and-spoke with area 0 as hub
• Every link is assigned to exactly one area
• Routers with links in multiple areas are called
  border routers

25
Summarization with Areas

• Each router learns
• Entire topology of its attached areas
• Information about subnets in remote areas and
  their distance from the border routers
• Distance sum of link costs from border router
  to subnet

26
Link State Advertisements (LSAs)

• Every router describes its local connectivity in
  Link State Advertisements (LSAs)
• Router originates an LSA due to
• Change in network topology
• Example link goes down or comes up
• Periodic soft-state refresh
• Recommended value of interval is 30 minutes
• LSA is flooded to other routers in the domain
• Flooding is reliable and hop-by-hop
• Includes change and refresh LSAs
• Flooding leads to duplicate copies of LSAs being
  received
• Every router stores LSAs (self-originated
  received) in link-state database ( topology
  graph)

27
Adjacency

• Neighbor routers (i.e., routers connected by a
  physical link) form an adjacency
• The purpose is to make sure
• Link is operational and routers can communicate
  with each other
• Neighbor routers have consistent view of network
  topology
• To avoid loops and black holes
• Link gets used for data forwarding only after
  adjacency is established
• Use of periodic Hellos to monitor the status of
  link and adjacency

28
Equipment Problem at Enterprise Network

• Internal errors in a router in area 0
• Episodes where router would drop adjacencies with
  other routers
• Problem manifested in LSAG as ADJ UP and ADJ
  DOWN messages
• Not visible in other network management systems
• Led to proactive maintenance

29
LSA Traffic in Enterprise Network
Refresh LSAs
Change LSAs
Duplicate LSAs
30
Overhead Duplicate LSAs
Days

• Why do some areas witness substantial duplicate
  LSA traffic, while other areas do not witness
  any?
• OSPF flooding over LANs leads to control plane
  asymmetries and to imbalances in duplicate LSA
  traffic
