Statistical Analysis I' Basic HypothesisDriven Analyses

1
Statistical Analysis I. Basic Hypothesis-Driven
Analyses

• fMRI Graduate Course
• November 13, 2002

2
When do we not need statistical analysis?
Inter-ocular Trauma Test (Lockhead, personal
communication)
3
Why use statistical analyses?

• Replaces simple subtractive methods
• Signal highly corrupted by noise
• Typical SNRs 0.2 0.5
• Sources of noise
• Thermal variation (unstructured)
• Physiological variability (structured)
• Assesses quality of data
• How reliable is an effect?
• Allows distinction of weak, true effects from
  strong, noisy effects

4
Statistical Parametric Maps

• 1. Brain maps of statistical quality of
  measurement
• Examples correlation, regression approaches
• Displays likelihood that the effect observed is
  due to chance factors
• Typically expressed in probability (e.g., p lt
  0.001)
• 2. Effect size
• Determined by comparing task-related variability
  and non-task-related variability
• Signal change divided by noise (SNR)
• Typically expressed as t or z statistics

5
Why use effect size measures?

• Dissociate size of signal change from reliability
  of signal change
• Understanding reliability of change allows
  quantification of error probabilities
• Types of Errors
• Type I Rejecting null hypothesis when it is true
• Calling active voxels that really have no
  activity
• To minimize false positives, adopt a high
  threshold for significance
• Type II Accepting null hypothesis when it is
  false
• Calling inactive voxels that are really
  associated with the task
• To minimize incorrect rejections, adopt a low
  threshold for significance

6
Simple Statistical Analyses

• Common
• t-test across conditions
• Fourier
• t-test at time points
• Correlation
• General Linear Model
• Other tests
• Kolmogorov-Smirnov
• Iterative Connectivity Mapping

7
T Tests across Conditions

• Compares difference between means to population
  variability
• Uses t distribution
• Defined as the likely distribution due to chance
  between samples drawn from a single population
• Commonly used across conditions in blocked
  designs
• Potential problem Multiple Comparisons

8
Drift Artifact and T-Test
9
Fourier Analysis

• Fourier transform converts information in time
  domain to frequency domain
• Used to change a raw time course to a power
  spectrum
• Hypothesis any repetitive/blocked task should
  have power at the task frequency
• BIAC function FFTMR
• Calculates frequency and phase plots for time
  series data.
• Equivalent to correlation in frequency domain
• At short durations, like a sine wave (single
  frequency)
• At long durations, like a trapezoid (multiple
  frequencies)
• Subset of multiple regression
• Same as if used sine and cosine as regressors

10
Power
12s on, 12s off
Frequency (Hz)
11
(No Transcript)
12
(No Transcript)
13
T/Z Tests across Time Points

• Determines whether a single data point in an
  epoch is significantly different from baseline
• BIAC Tool tstatprofile
• Creates
• Avg_V.img
• StdDev_V.img
• ZScore_V.img

14
Correlation

• Special case of General Linear Model
• Blocked t-test is equivalent to correlation with
  square wave function
• Allows use of any reference waveform
• Correlation coefficient describes match between
  observation and expectation
• Ranges from -1 to 1
• Amplitude of response does not affect correlation
  directly
• BIAC tool tstatprofile

15
Problems with Correlation Approaches

• Limited by choice of HDR
• Poorly chosen HDR can significantly impair power
• Examples from previous weeks
• May require different correlations across
  subjects
• Assume random variation around HDR
• Do not model variability contributing to noise
  (e.g., scanner drift)
• Such variability is usually removed in
  preprocessing steps
• Do not model interactions between successive
  events

16
Kolmogorov Smirnov (KS) Test

• Statistical evaluation of differences in
  cumulative density function
• Cf. t-test evaluates differences in mean

p lt 10-30
ns
p lt 10-30
17
Iterative Connectivity Mapping

• Acquire two data sets
• 1 Defines regions of interest and hypothetical
  connections
• 2 Evaluates connectivity based on low frequency
  correlations
• Use of Continuous Data Sets
• Null Data
• Task Data
• Can see connections between functional areas
  (e.g., between Brocas and Wernickes Areas)

Hampson et al., Hum. Brain. Map., 2002
18
Use of Continuous Tasks to Evaluate Functional
Connectivity
Hampson et al., Hum. Brain. Map., 2002
19
The General Linear Model
20
Basic Concepts of the GLM

• GLM treats the data as a linear combination of
  model functions plus noise
• Model functions have known shapes
• Amplitude of functions are unknown
• Assumes linearity of HDR nonlinearities can be
  modeled explicitly
• GLM analysis determines set of amplitude values
  that best account for data
• Usual cost function least-squares deviance of
  residual after modeling (noise)

21
Signal, noise, and the General Linear Model
Amplitude (solve for)
Measured Data
Noise
Design Model
Cf. Boynton et al., 1996
22
Form of the GLM
Model Functions
Model Functions
Model

Amplitudes


Data
Noise
N Time Points
N Time Points
23
Implementation of GLM in SPM
24
The Problem of Multiple Comparisons
25
The Problem of Multiple Comparisons
P lt 0.001 (32 voxels)
P lt 0.01 (364 voxels)
P lt 0.05 (1682 voxels)
26
Options for Multiple Comparisons

• Statistical Correction (e.g., Bonferroni)
• Gaussian Field Theory
• Cluster Analyses
• ROI Approaches

27
Statistical Corrections

• If more than one test is made, then the
  collective alpha value is greater than the
  single-test alpha
• That is, overall Type I error increases
• One option is to adjust the alpha value of the
  individual tests to maintain an overall alpha
  value at an acceptable level
• This procedure controls for overall Type I error
• Known as Bonferroni Correction

28
(No Transcript)
29
Bonferroni Correction

• Very severe correction
• Results in very strict significance values for
  even medium data sets
• Typical brain may have about 15,000-20,000
  functional voxels
• PType1 1.0 Corrected alpha 0.000003
• Greatly increases Type II error rate
• Is not appropriate for correlated data
• If data set contains correlated data points, then
  the effective number of statistical tests may be
  greatly reduced
• Most fMRI data has significant correlation

30
Gaussian Field Theory

• Approach developed by Worsley and colleagues to
  account for multiple comparisons
• Forms basis for much of SPM
• Provides false positive rate for fMRI data based
  upon the smoothness of the data
• If data are very smooth, then the chance of noise
  points passing threshold is reduced

31
Figures from http//www.irsl.org/fet/Presentation
s/wavestatfield/wavestatfield.html
32
Cluster Analyses

• Assumptions
• Assumption I Areas of true fMRI activity will
  typically extend over multiple voxels
• Assumption II The probability of observing an
  activation of a given voxel extent can be
  calculated
• Cluster size thresholds can be used to reject
  false positive activity
• Forman et al., Mag. Res. Med. (1995)
• Xiong et al., Hum. Brain Map. (1995)

33
How many foci of activation?
Data from motor/visual event-related task (used
in laboratory)
34
How large should clusters be?

• At typical alpha values, even small cluster sizes
  provide good correction
• Spatially Uncorrelated Voxels
• At alpha 0.001, cluster size 3 reduces Type 1
  rate to ltlt 0.00001 per voxel
• Highly correlated Voxels
• Smoothing (FW 0.5 voxels) increases needed
  cluster size to 7 or more voxels
• Efficacy of cluster analysis depends upon shape
  and size of fMRI activity
• Not as effective for non-convex regions
• Power drops off rapidly if cluster size gt
  activation size

Data from Forman et al., 1995
35
ROI Comparisons

• Changes basis of statistical tests
• Voxels 16,000
• ROIs 1 100
• Each ROI can be thought of as a very large volume
  element (e.g., voxel)
• Anatomically-based ROIs do not introduce bias
• Potential problems with using functional ROIs
• Functional ROIs result from statistical tests
• Therefore, they cannot be used (in themselves) to
  reduce the number of comparisons

36
Are there differences between voxel-wise and ROI
analyses?
37
Summary of Multiple Comparison Correction

• Basic statistical corrections are often too
  severe for fMRI data
• What are the relative consequences of different
  error types?
• Correction decreases Type I rate false positives
• Correction increases Type II rate misses
• Alternate approaches may be more appropriate for
  fMRI
• Cluster analyses
• Region of interest approaches
• Smoothing and Gaussian Field Theory

38
Fixed and Random Effects Comparisons
39
How do we compare across subjects?

• Fixed-effects Model
• Uses data from all subjects to construct
  statistical test
• Examples
• Averaging across subjects before a t-test
• Taking all subjects data and then doing an ANOVA
• Allows inference to subject sample
• Random-effects Model
• Accounts for inter-subject variance in analyses
• Allows inferences to population from which
  subjects are drawn
• Especially important for group comparisons
• Beginning to be required by reviewers/journals

40
How are random-effects models run?

• Assumes that activation parameters may vary
  across subjects
• Since subjects are randomly chosen, activation
  parameters may vary within group
• Fixed-effects models assume that parameters are
  constant across individuals
• Calculates descriptive statistic for each subject

• i.e., t-test for each subject based on
  correlation
• Uses all subjects statistics in a one-sample
  t-test
• i.e., another t-test based only on significance
  maps

41
Summary of Hypothesis Tests

• Simple experimental designs
• Blocked t-test, Fourier analysis
• Event-related correlation, t-test at time points
• Complex experimental designs
• Regression approaches (GLM)
• Critical problem Minimization of Type I Error
• Strict Bonferroni correction is too severe
• Cluster analyses improve
• Accounting for smoothness of data also helps
• Use random-effects analyses to allow
  generalization to the population
