Outline

• Hardware
• CPU / GPU / Cache
• Memory / Storage / Extras
• Operating System
• Overview / OS X / Darwin
• XNU / Mach
• IPC / Thread Management
• Differences w/ iPhone
• Development
• SDK / Tools / Objective-C / Examples

3
Hardware (3G)
4
Motherboard (top)
5
Motherboard (bottom)
6
Samsung S5L8900 (SoC)
S3C6400
7
CPU / GPU Specs

• ARM1176JZ(F)-S
• 412 MHz (620 MHz)
• 103MHz FS Bus
• 32-bit RISC
• 32KB L1 (16x2 I/D)
• ARM TrustZone
• ARM Thumb

• PowerVR MBX Lite
• 133 MHz (233 MHz)
• 130m pix/s fillrate
• 1.7m tri/s fill rate
• Anti-Aliasing
• Texture Compression
• OpenGL ES / D3D M

8
Memory (PoP)

• DDR-SDRAM
• 1Gb (128MB)
• (16MB reserved for GPU)
• 8K blocks
• 4 banks
• Speed 7.5ns_at_CL3
• 1.8V core - 1.8V I/O

9
Storage

• K9MCG08U5M
• TH58NVG6D1D (3G)
• NAND Flash Memory
• 4GB / 8GB / 16GB
• 2 GB dies (x2 / x4 / x8)
• ---------------------------------------
• NOR faster non-contiguous reads, slow erase/write
  (read only)
• NAND faster erase/write, slow non-contiguous
  reads (serial)NAND prone to single-bit errors
  error detection correction

10
Touch Screen

• Broadcom BCM5974 Controller
• Multi-touch
• No stylus or non-conductive gloves

11
iPhone OS (?)

• Remember that OS X on a Mac features a lot of
  applications that we dont have to ship on the
  iPhone.
• Greg Joswiak
• Macworld Expo (01/2007)
• The entire Mac OS is gigs, a lot is data. Take
  out the data -- every desktop pattern, sound
  sample -- if you look at Safari it's not that
  big. It's REAL Safari, REAL OS X. We put a
  different user interface on it to work with a
  multi-touch screen...
• Steve Jobs
• Wall Street Journal D Conference (05/30/2007)

12
OS X Lineage
13
NeXTSTEP

• ... we at id Software developed DOOM and Quake
  on the NeXTSTEP 3.3 OS running on a variety of
  hardware for about 4 years. I still remember the
  wonderful time I had coding DoomEd and QuakeEd in
  Objective-C there was nothing like it before and
  there still is no environment quite like it even
  today.
• John Romero
• http//rome.ro
• I wrote the program using a NeXT computer. This
  had the advantage that there were some great
  tools available -it was a great computing
  environment in general. In fact, I could do in a
  couple of months what would take more like a year
  on other platforms, because on the NeXT, a lot of
  it was done for me already.
• Tim Berners-Lee
• http//www.w3.org/People/Berners-Lee/WorldWideWeb

http//www.youtube.com/watch?vj02b8Fuz73A
14
NeXTSTEP -gt OPENSTEP -gt Rhapsody -gt Darwin -gt OS X
http//www.roughlydrafted.com/RD/RDM.Tech.Q1.07/4B
800F78-0F75-455A-9681-F186A4365805.html
Apple using System Software 1984 - 1999 Apple
talks w/ Microsoft, Be, Sun, NeXT. Apple acquires
NeXT (1996) Apple initially pushes OPENSTEP (epic
fail) Rhapsody OPENSTEP, BSD, etc. Apple
rushes OS X Server v1.0 (1999) Apple forks
Rhapsody as Darwin (2000) Apple releases OS X
v10.0 (2001)
15
Darwin OS X
16
Darwin Source
17
Mac OS X Kernel XNU
Layered modular simplicity / debugging -
layers add overhead - layer order complexity
(catch-22 scenarios)
Microkernel ease of extending hardware
portability reusable w/ OS layers -
performance decrease due to extensive IPC
Hybrid / Modular benefits of layered
dynamic-loaded extensions IPC unnecessary
between extensions - too many kernel
extensions becomes -gt monolithic
...about 70 percent of operating systems consist
of device drivers, which have error rates three
to seven times higher than ordinary code... 22
18
XNU
I/O Kit
FreeBSD

• process model
• user ids, permissions, basic security policies
• POSIX API, BSD style system calls
• TCP/IP stack, BSD sockets, firewall
• VFS, HFS and other file systems
• System V IPC
• cryptographic framework
• various synchronization mechanisms

• dynamic matching / loading of drivers / kext
• numerous device families (usb, pci, ata, etc.)
• i/o registry
• object oriented abstractions of devices
• power management
• an extensive API
• plug-and-play and hot-plugging
• driver stacking

Mach

• preemptive multitasking, kernel threads
• protected memory
• virtual memory management (FIFO w/ second
  chance)
• inter-process communication
• interrupt management
• kernel debugging support
• console I/O

19
Mach

• Simplified kernel structure, easier to extend
  modify
• BSD compatible Heterogeneous system support
  Mach-O binary format
• Support diverse architectures mutliprocessors
  (UMA, NUMA, NORMA)
• Network transparency Distributed operation
  internally externally
• Fix UNIX design of everything-as-a-file
  Generalize pipes to ports

Machs design philosophy is to have a simple,
extensible kernel, concentrating on communication
facilities. For instance, all requests to the
kernel, and all data movement among processes,
are handled through one communication mechanism.
Mach is therefore able to provide system-wide
protection to its users by protecting the
communications mechanism. Optimizing this one
communications path can result in significant
performance gains, and it is simpler than trying
to optimize several paths. 21
20
Mach System Components

• TaskContains virtual address space, threads,
  protected access to system resources via ports.
• ThreadBasic unit of execution shares parent
  tasks resources.
• PortKernel-protected communication channel with
  access rights.Tasks must have proper rights to
  use the ports.Implemented as a protected,
  bounded queue within kernel.
• Port SetGroup of ports sharing a common message
  queue.
• MessageBasic method of communication between
  threads collection of typed data or pointers.
• Memory ObjectAny source of memory where
  memory-mapped access makes senseTasks access it
  by mapping portions into their address spaces.

21
XCode Interface Builder
22
IB Connecting Components
23
Shark
24
Objective-C
Simula
C
Small Talk
Developed 1985 interchangeable software
components Licensed by NeXT 1988 Used by Apple
(Cocoa API)
C
Obj-C

• Message Handlers vs. Methods
• Dynamic Typing (use types according to runtime
  data)
• Categories (method blocks bound _at_ runtime)
• Properties (public instance variables generate
  methods)
• Protocols Interfaces
