Title: VEHICLE STRUT EXPLOSIONS


1
County of Los Angeles FIRE DEPARTMENT
VEHICLE STRUT EXPLOSIONS
Injury to Firefighters
2
Wichita - Kansas Fire Department
  • Fire Fighter Severely Injured During
    Extinguishment Of An Automobile Fire

3
Wichita - Kansas Incident
  • January 17, 1995
  • A Lieutenant was opening the hood of an
    automobile fire
  • On a 1993 Oldsmobile, Achieva
  • Major fire involvement in the engine compartment
  • Gas spring (Strut) in the hood area exploded

4
Wichita - Kansas Incident
  • The housing from the gas spring (strut) propelled
    the tube out the front headlight
  • The housing from the gas spring (strut) impaled
    into the Lieutenants hand
  • The second gas spring (strut) located under the
    hood exploded
  • Rocketed out the front headlight

5
Investigation Of The Wichita Incident
  • National Center for Automobile Safety
  • U.S. Department of Transportation Auto Safety Hot
    Line
  • U.S. Department of Transportation National
    Highway Traffic Safety Administration
  • National Consumer Product Safety Commission

6
Investigation Of The Wichita Incident
  • U.S. Department of Labor (OSHA)
  • General Motors Corporation, Consumer Division
  • Legal and Liability concerns
  • Would not provide any data or make
    recommendations
  • Ford Motors Corporation, Customer Hotline (same
    results as G.M.)

7
Fire Departments Nation Wide
  • Do they recognize that small diameter gas springs
    (struts) are an explosion / rocket hazard when
    exposed to high temperature conditions during
    automotive fires?

8
Fire Departments Nation Wide
  • Have they experienced fire fighter injuries from
    exploding / rocketing small diameter gas springs
    (struts) during automobile extinguishment
    operations?

9
Gas Spring Struts
  • Gas springs come in a variety of lengths and
    diameters
  • On all 1992 - 1998 G.M. vehicle hoods , lift
    gates, etc.
  • Simple in construction
  • Sealed cylinder consisting of only a few basic
    components rod, tube, piston, seals and end
    attachments

10
(No Transcript)
11
Gas Spring Struts
  • They contain pressurized inert gas (nitrogen) and
    a small amount of oil
  • The increase in force on compression is between
    5 and 50 from the point where the rod is almost
    fully extended to the point where it is fully
    compressed

12
Gas Spring Struts
  • The cylinders are generally constructed of 1040
    mild steel and are coated with a baked matte
    black epoxy power paint
  • The rod is also made of 1040 mild steel, and is
    chrome plated
  • Both finishes are resistant to corrosion

13
Temperature Affects Performance
  • Gas springs (struts) are designed to operate at
    temperatures ranging from minus 40 degrees F to
    284 degrees F
  • No manufacturer could provide any evidence that
    any testing at temperatures above 284 degrees F
    had ever been conducted

14
Temperature Affects Performance
  • Additionally, no manufacturer could provide any
    data on the temperature at which the entire gas
    spring or any portion of the unit (cylinder,
    seals, or fittings to which it attaches) fails.

15
Vehicle Fire Hazards
  • Energy Absorbing Bumpers
  • Vehicle Suspension Systems
  • Safety Restraint System
  • Hatchback and Hood Gas Springs (Struts)
  • Fuel Systems

16
Vehicle Fire Hazards
  • Vehicle Drive Shafts
  • Split Rims
  • Batteries

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Strut Explosion - 1998 Chevy Blazer
  • L.A. County Fire - 8/9/98 - 0052 Hrs.
  • Vehicle fire in the passenger area
  • Well involved with fire
  • Rear glass window hatch open
  • Both gas spring (struts) exploded
  • One strut traveled at a right angle about 50 to
    75 feet from vehicle
  • No Fire Fighter injuries

34
Kansas City, Kansas Incident
  • March 1997, gas spring strut
  • 1993 Chevrolet Caprice police cruiser
  • Exploded during an engine compartment fire
  • Launching a metal shard into the right flank of a
    fire fighter

35
Kansas City, Kansas Incident
  • Causing serious soft tissue injury
  • The fire fighter was assisting another fire
    fighter in opening the hood of the involved
    vehicle

36
County of Los Angeles Fire Department
  • Fire Fighter Severely Injured During
    Extinguishment Of An Automobile Fire

37
L.A. County Incident
  • July 26, 1998 - 0220 Hours
  • Fire Fighter prying open the hood of an
    automobile fire
  • On a 1992 Oldsmobile, Achieva
  • Major fire involvement in the engine compartment
    area
  • Gas spring (strut) exploded in the hood area

38
Wichita - Kansas Incident
  • January 17, 1995
  • A Lieutenant was opening the hood of an
    automobile fire
  • On a 1993 Oldsmobile, Achieva
  • Major fire involvement in the engine compartment
  • Gas spring (Strut) in the hood area exploded

39
L.A. County Incident
  • The housing from the gas spring (strut) propelled
    out of the front part of the vehicle where it
    appeared to glance off the asphalt
  • Impaling into the right lower leg of the Fire
    Fighter as he was trying to pry open the hood
    latch

38
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
L.A. County Incident
  • The second gas spring (strut) located under the
    hood appeared to explode
  • Propelled forward 56 6 into the front of a gas
    station

58
L.A. County Incident
  • Striking the gas station at a five foot high
    level
  • Making a 3 indentation into the aluminum fascia
  • Then ricocheting another 33 feet where it finally
    came to rest on the asphalt

59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
Tactics Strategy
  • Clear citizens in, near and around the vehicle
  • Appropriate hose line, minimum 1 3/4
  • Foam capabilities
  • Proper positioning of your apparatus
  • Approach the vehicle at a 90 angle and never
    from the ends

72
Tactics Strategy
  • Avoid approaching directly in front of or in the
    rear of the automobile
  • Pry open the hood along one of its sides just
    enough to direct a fog stream into the engine
    compartment
  • After knock down, personnel should return to a
    safe location, allowing gas struts to cool

73
Fire Fighter Safety
  • High risk / Low frequency
  • Can you afford a career ending injury
  • The fire damaged vehicle goes to the junk yard
  • I did not anticipate or expect that to happen
