2Direct3D Retained Mode
- Colin McCartney
- Development Manager
- Microsoft Corporation
3Agenda
- New features
- Interpolator Interfaces
- Support of true alpha
- Progressive Meshes
- Tips and tricks
4New Features - Interpolators
- Allows animation of applicable APIs
- APIs such as
- SetGroupColorRGB()
- SetVerticies()
- SetOrientation()
- SetPosition()
- Check out morph sample
5New Features - Interpolators
- Used by creating an Interpolator object and
calling QueryInterface() for the interface you
wish to animate - Attach interpolator object to the target object
for animation
6New Features - Interpolators
- Example
- First create a mesh with some vertices and faces
LPDIRECT3DRMMESH pMesh D3DRMGROUPINDEX
dwGID DWORD pFaceData D3DRMVERTEX
pVData pD3DRM-CreateMesh(pMesh) pMe
sh-AddGroup(3, 1, 3, pFaceData,
dwGID) pMesh-SetVertices(dwGID, 0, 3, pVData)
7New Features - Interpolators
- Now create an interpolator object to animate the
color of vertices
LPDIRECT3DRMINTERPOLATOR pInterp LPDIRECT3DRMMESH
pMeshProxy pD3DRM-CreateObject(CLSIID_CDirect3
DRMMeshInterpolator, NULL,
IID_IDirect3DRMInterpolator,
(LPVOID)pInterp) // pMeshProxy provides
interpolants pInterp-QueryInterface(IID_IDirect3
DRMMesh, (LPVOID)pMeshProxy) // Hook
the interpolator to the real mesh pInterp-AddObje
ct(pMesh)
8New Features - Interpolators
// pInterp and pMeshProxy and interfaces to the
same // Interpolator object pInterp-SetIndex(D3DV
AL(0.0)) pMeshProxy-SetGroupColorRGB(D3DVAL(0.0)
, D3DVAL(0.0), D3DVAL(0.0)) pInterp-SetInd
ex(D3DVAL(25.0)) pMeshProxy-SetGroupColorRGB(D3D
VAL(0.3), D3DVAL(0.3), D3DVAL(0.3)) pInterp
-SetIndex(D3DVAL(50.0)) pMeshProxy-SetGroupColo
rRGB(D3DVAL(1.0), D3DVAL(1.0),
D3DVAL(1.0)) pInterp-SetIndex(D3DVAL(75.0)) pMe
shProxy-Release() // Dont need it anymore
9New Features - Interpolators
- Now just add the mesh to the scene and vary the
index over time - E.g. in a move callback
VOID CDECL interpolateFunc(LPDIRECT3DRMFRAME
pFrame, LPVOID pvArg, D3DVALUE
dvDelta) static D3DVALUE dvVal
D3DVAL(0.0) LPDIRECT3DRMINTERPOLATOR pInterp
(LPDIRECT3DRMINTERPOLATOR)pvArg
dvVal dvDelta pInterp-Interpolate(dvVal,
NULL, D3DRMINTERPOLATION_CLOSED
D3DRMINTERPOLATION_LINEAR)
10New Features - Interpolators
11New Features - True Alpha
- Alpha channel in texture
- In order to support compatibility texture must be
created from IDirect3DRM2 interface - Or use CLSIID_CDirect3DRMTexture2
- Alpha value in vertex
- Used to only provide stippled alpha
- Now provides true alpha
12New Features - True Alpha
- Shadows use true alpha if available
- How to use it?
- Device must have an IDirect3DDevice2 available
- Create device using IDirect3DRM2
- Possibly need to use DrawPrimitive
13New Features - True Alpha
- Must also set IDirect3DRMDevice2SetRenderMode()
- D3DRMRENDERMODE_BLENDEDTRANSPARENCY
- Uses True Alpha instead of stippled alpha IF
supported - D3DRMRENDERMODE_SORTEDTRANSPARENCY
- Use only if really needed - overhead of sorting
- Uses DrawPrimitive
- Demo...
14New Features - I/O
- New load support
- Asynchronous
- Progressive Mesh only
- From a URL
- All objects (Frame, Mesh, PMesh)
15New Features - Others
- Mostly on IDirect3DRMFrame2
- Bounding box support
- Modify origin axis
- Crease angle
- Ray picking
- Misc
- Right-handed support
- MIP map generation
16New Features - Progressive Mesh
- Provide real time, continuous level of detail
support - no popping as in traditional LOD
- Mesh stored as a base mesh and series of vertex
splits - Mesh is renderable after the base mesh has been
loaded
17New Features - Progressive Mesh
- Base mesh contains
- all face and vertex information for the lowest
level of detail - information about materials and textures
- Vertex splits introduce a new vertex and 1 or 2
new faces
18New Features - Progressive Mesh
- Vertex splits are invertible
- edge collapse
- Highest level of detail is geometrically
identical to source mesh - lossless representation
19New Features - Progressive Mesh
Vertex Split
vt
vl
vr
vs
vs
Edge collapse
20New Features - Progressive Mesh
21New Features - Direct3DRM and Progressive Mesh
- New visual object and interface
- IDirect3DRMProgressiveMesh
- Same behavior as other visuals
- added to frames in the hierarchy
- adhere to overrides
- Can create a normal mesh object from any level of
detail
22New Features - Direct3DRM and Progressive Mesh
- Concise representation in DirectX Files
- Feature set of the interface
- Flexibility in choosing LOD to fine-tune frame
rate - Incremental changes LOD reduce snapping / popping
artifacts - Face, vertex or normalized basis
23New Features - Direct3DRM and Progressive Mesh
- Feature set of the interface
- Asynchronous loading with new load flag
- D3DRMLOAD_ASYNCHRONOUS
- can be progressively rendered as it is loaded
- can be combined with D3DRMLOAD_FROMURL
24New Features - Direct3DRM and Progressive Mesh
Conversion tool Preserve appearance geometric
shape scalar fields (e.g. color,
normals) discontinuity curves
25New Features -Progressive Mesh Recap
- LOD selection at install time of a title
- profile platform, decide LOD for content
- Real time LOD simplification
- based on frame rate or Z distance
- Progressive download of 3D over the net
- Polygon reduction in an authoring tool
26New Features -Progressive Mesh Recap
- More information
- Siggraph 96 proceedings
- http//www.research.microsoft.com/hoppe
- http//www.microsoft.com/directx
- Demo Havent you seen it yet???
27Tips And Tricks
- Debugging
- Use the debug DLLs
- win.ini section
- Please dont profile using the debug dlls...
Direct3DRM debug3 dumpformats1 nopal40 nopal8
1 norgb80 norgb160
28Tips And Tricks
- Various things can be done to speed up your
application - Many of them not specific to Retained Mode
- scale the application
29Tips And Tricks
- Culling
- Retained Mode culls on a mesh basis
- bounding box/sphere
- Z visibility - 200 triangles
- Dont have one huge mesh
- caveat - dont have one polygon meshes
30Tips And Tricks
- Mesh Usage
- MeshBuilders are convenient
- file access, face paradigm
- have overhead
- MeshBuilders built on top of Meshes
- changing the MeshBuilder requires reconstruction
of underlying Mesh - if you dont need the MeshBuilder again, throw it
away
31Tips And Tricks
- Mesh Usage
- Meshes are fast
- built directly on ExecuteBuffers
- changing the Meshes modifies ExecuteBuffer
directly
32Tips And Tricks
- Textures
- Check which texture formats are directly
supported - currently via ImmediateMode
- if you dont use a directly supported format,
Direct3DRM will convert - Call TextureChanged() if you change the surface
or palette
33Tips And Tricks
- Textures
- Use system memory textures to enable texture
caching - To enable alpha, use IDirect3DRM2
- Use IDirect3DTexture2 to get BMPs the right way
up Ooops
34Tips And Tricks
- Palettized Displays
- You can lock down the palette
- Create device via
- CreateDeviceFromSurface()
- CreateDeviceFromD3D()
- Set texture shades to 1
35Tips And Tricks
- Screen update
- Dont update what you dont need to
- Either
- let Retained Mode handle the update (in
CreateFromClipper case) - use an update callback
- Pay attention to region information
- Always call IDirect3DRMDeviceUpdate()
36Tips And Tricks
- Scale the application
- Applicable to any application
- Keep a track of the frame rate
- Keep motion steady using
- IDirect3DRMFrameMove(dvDelta)
- If you can, use Progressive Mesh
- if you cant provide geometry at various levels
of detail - Profile the application on start-up
- hardware may change on you
37Questions ?
?
?
?
?
?
?
?
?
?
?
?
