Todays Menu

• Advanced Pipelining
• Brief overview of the Pentium 4

3
Instruction Level Parallelism

• Pipelining exploits the potential parallelism
  among instructions. There are two main methods to
  increase the potential amount of parallelism
• Increase the depth of the pipeline to overlap
  more instructions
• Replicate the internal components of the
  computer so that it can launch multiple
  instructions in every pipeline stage

4
Washer-Dryer Example

• Suppose that the washer cycle is longer than the
  other cycles. We can divide our washer into three
  machines that perform the wash, rinse, and spin
  steps of a traditional washer.
• (Move from a four to six pipeline stages)
• A multiple issue laundry would replace our
  household washer and dryer with, say, three
  washers and three dryers.

5
Multiple-Issue Processors

• We have two different approaches to
  multiple-issue processors
• The approach to decide at compile time which
  instructions should be issued is called static
  multiple issue
• The approach to decide at execution time which
  instructions should be issued is called dynamic
  multiple issue

6
Multiple Issues with Multiple-Issue

• Package instructions into issue slots How does
  the processor determine how many instructions and
  which instructions can be issued in a given clock
  cycle?
• Dealing with data and control hazards In static
  issue processors, some or all consequences of
  these hazards are handled statically by the
  compiler. Dynamic issue processors attempt to
  alleviate at least some classes of hazards using
  hardware techniques

7
Speculation

• The most important method to exploit more ILP is
  speculation. The compiler or the processor guess
  about the properties of an instruction, to enable
  execution of instructions that depend on the
  current instruction.
• For example, a compiler can use speculation to
  reorder instructions and move instructions beyond
  a branch.

8
Recovery from wrong Speculations

• Speculation in software the compiler inserts
  additional instructions to that check the
  accuracy of a speculation and provide a fix-up
  routine when the speculation was incorrect.
• Speculation in hardware The processor usually
  buffers the results until it knows that they are
  no longer speculative. If the speculation was
  correct, then the instructions are completed by
  allowing the contents to be written to registers
  or memory otherwise the buffers are flushed and
  the correct instruction sequence is re-executed.

9
Register Renaming

• A compiler can get more performance from loops by
  so-called loop unrolling this is a technique
  where multiple copies of the loop are made gt
  more ILP by overlapping instructions from
  different iterations
• In the loop unrolling, the compiler will usually
  introduce additional registers to eliminate
  dependencies that are not true data dependencies
  (just name dependence). The process is called
  register renaming.

10
Pentium 4
11
Intels History
Intel Pentium Processor with MMX technology
Intel Pentium II Xeon Processor
Intel386 Processor
Intel Pentium III And Xeon Processors
Intel Pentium II Processor
Intel Pentium Pro Processor
8086 Microprocessor
Intel Celeron Processor
Intel Pentium Processor
Pentium 4 Processor
Intel Founded
Intel286 Processor
Intel486 Processor
First Microprocessor 4004
1999
2000
2001
2002
1968
1970
1971
1978
1982
1985
1986
1989
1991
1992
1993
1995
1994
1997
1998
Flash Memory Intro
DRAM Exit
100 Mbit E-Net Card
1 Gbit E-Net Card
First EPROM
Internet Exchange Architecture
First Intel Motherboard
First DRAM
Intel Inside Launch
1st Pb-Free Devices
ProShare Introduced
First Intel Inside Brand TV Ad
Slide courtesy of Intel
12
The Pentium4 Architecture
Graphic courtesy of Toms hardware guide
13
A Glance at a Pentium 4 Chip
Picture courtesy of Toms hardware guide
14
Pentium4

• The Pentium 4 was first released in 2000. Some of
  its features are
• fast system bus
• advanced transfer cache
• advanced dynamic execution (execution trace cache
  and enhanced branch prediction)
• hyper pipeline technology
• rapid execution engine
• enhanced floating point and multimedia (SSE2)

15
Some Features

• The processor uses micro-operations/operands
• simple instructions of unified length
• easier sequencing than variable length x86 instr.
• understood by the execution units
• the length is not exactly small

16
System Bus

• The system bus is clocked at 100 MHz, 64 bits
  wide, quad-pumped, meaning that is can transfer

• 8 bytes 100 million/s4 3,200 MB/s
• (this is about 3 times the speed of the system
  bus of the Pentium 3)
• Intel introduced the 850 chipset to sustain high
  data exchange rates between processor and system

17
Data Caches

• Data passes a level 2 cache (256 KB),
• (8-way associative, 128 byte cache lines that
  are divided into 64 byte blocks that are read in
  one burst, read latency is 7 clock cycles we
  come back later to such issues)
• Data passes a small level 1 cache (8 KB)
• Hardware pre-fetch unit
• (allows the processor to guess and fetch some
  that that is presumably used next good for
  streaming video applications).

18
Execution Pipeline The Trace Cache

• The Pentium 4 does not use an L1 instruction
  cache, but rather an execution trace cache.
• Note that the decoding of x86 instructions is
  much more complex than on MIPS
• The execution trace cache is basically an
  instruction cache after the decoding unit (which
  generates the micro-operations), so that decoding
  does not have to be repeated.
• Supplies next pipeline stage with 6
  micro-operations every 2 clock cycles.

19
The Trace Cache
Actual program instructions
Trace cache can contain instructions of both
branches
20
The Pipeline
The branch prediction aids the execution trace
cache it has a fairly large branch target buffer

• The 20 stage hyper pipeline
• The pipeline can keep up to 126 instructions

21
The Pipeline
Trace cache
22
Rapid Execution Engine

• The rapid execution engine consists of two ALUs
  and two AGUs that run at twice the clock speed.
• Not every instruction can be processed by the
  rapid execution engine those instructions need
  to use e.g. the slower ALU
• AGU address generation unit to load or store
  at the correct address (used whenever you have
  indirect addressing ai).

23
Streaming SIMD Extensions SSE2

• The Pentium 4 can operate on 128 bit data as
• 4 single precision FP values (SSE)
• 2 double precision FP values (SSE2)
• 16 byte values (SSE2)
• 8 word values (SSE2)
• 4 double word values (SSE2)
• 2 quad word values
• 1 128 bit values
• single instruction multiple data instructions

24
Pentium 4 Pipeline

• Trace cache access, predictor 5 clock cycles
• Microoperation queue
• Reorder buffer allocation, register renaming 4
  clock cycles
• functional unit queues
• Scheduling and dispatch unit 5 clock cycles
• Register file access 2 clock cycles
• Execution 1 clock cycle
• reorder buffer
• Commit 3 clock cycles (total 20 clock cycles)

25
Pentium 4 Generations

• Willamette
• Northwood (smaller transistors, later
  hyper-threading)
• Extreme Edition (added 2MB level 3 cache)
• Prescott (90 nm process, new micro architecture)
• Irwindale (as Prescott, but with doubled L2
  cache)
• Dual Core

26
Hyper-Threading

• A typical thread of code of the IA-32
  architecture uses about 35 of the
  microarchitecture execution resources.
• Intel added a little bit of hardware to schedule
  and control two threads.
• The operating system sees two logical processors

27
To Probe Further

• Read Chapter 6
• Hennessy and Patterson, Computer Architecture A
  Quantitative Approach
• Intel website
• AMD websiter
