RTLinux Lab Introduction Cpre 558

1
RTLinux Lab IntroductionCpre 558

• Anil
• anil_at_iastate.edu

2
Contents

• Real-Time Operating System (RTOS) Vs. General
  Purpose OS (GPOS)
• Can Linux provide real-time guarantees?
• Commercial RTOSs
• RTLinux Vs. Linux Architectural comparison
• RTLinux Vs. Linux Code perspective
• Get the RTLinux setup ready
• Things to Issue and Handling the hard disk
• Lab 1 Detailed discussion

3
RTOS Vs. GPOS

• RTOS
• needs deterministic timing behavior
• Works under worst case assumptions
• GPOS
• high throughput and fairness
• Optimizes for the average case
• Hence, the design objectives of the OSs are
  different

4
Can Linux provide real-time guarantees?-- No!!

• Linux
• non-preemptible kernel
• A system call might take long time to complete
• Coarse timer resolution
• Tasks can be released only with 10ms precision
• Virtual memory
• Introduces unpredictable amount of delays
• Variable priority
• Each task is assigned a priority which varies
  over the time this is to achieve fairness

5
Can Linux provide real-time guarantees?-- No!!
(contd..)

• Linux
• Linux will batch several operations for efficient
  use of H/W delaying all tasks
• Linux also reorders requests from multiple
  processes for H/W efficiency
• Linux does not preempt low priority task in a
  system call, instead queues the high priority
  task
• Linux makes high priority tasks to wait for low
  priority tasks to release resources
• Therefore, Linux cannot provide real-time
  guarantees

6
Commercial RTOS

• RTLinux Monolithic kernel with loadable modules
• QNX Microkernel approach
• VxWorks Monolithic kernel
• LynxOS Microkernel
• ARTS, Spring, KURT, RTAI, etc.

7
RTLinux Overview

• Open source Linux project
• Supports x86, PowerPC, Alpha
• Available as a patch to the regular Linux kernel
• Provides an RT API for developers
• Runs Linux kernel as lowest priority process

8
Linux Kernel
User Processes
System libraries
Linux kernel
Device drivers
I/O
Hardware Interrupts
Hardware
9
RTLinux Kernel
Linux is executed in the background
User Processes
Real Time Tasks
System libraries
Linux kernel
Device drivers
I/O
Software Interrupts
Direct h/w access
RTLinux Plug-in
RT-Scheduler
I/O
Hardware Interrupts
Hardware
10
Linux Kernel code perspective
THE controller
User Process
Kernel Loadable Modules
Module M2 service (system call)
M1
M2
M2
Linux Monolithic kernel core
M3
M4
RAM
DISK
11
RTLinux Kernel code perspective
THE controller
RT Load command
RT core
Kernel Loadable Modules
Load RT core
RTM2
RTM3
Linux Monolithic kernel core
M1
M2
RT-Core Module
M3
RAM
DISK
12
Getting RTLinux ready

• Configure and compile a fresh Linux kernel
  (2.4.29)
• Download the kernel from
• http//www.kernel.org/pub/linux/kernel/v2.4/linux-
  2.4.29.tar.gz
• Patch the RTLinux to the Linux kernel
• Recompile the kernel and reboot the system into
  the new kernel
• Configure the RTLinux kernel and compile it

13
So, How do we run a RT-application program ?

• Step 1 Write the RT-application program as a
  kernel module
• (You are still in Linux)
• Step 2 Compile the module and check for errors
• (You are still in Linux)
• Step 3 Load the RT-Core (or RT Scheduler, etc..)
  and the RT-application program module
• (After this we will be in RTLinux)
• Step 4 Now you are in RTLinux!!!!

14
Homework

• Submission 1
• Give a ten line write-up comparing RTLinux with
  Linux with at least five differences along with
  the references.
• Submission 2
• Give a ten line write-up comparing RTLinux with
  two other commercial RTOSs with at least five
  differences for each of them along with the
  references.

15
Lab Policies

• Six assignments in total
• First three assignments are mandatory
• One of the last three assignments is mandatory
• You will be working with a removable hard disk
  which can be issued from CSG

16
Things to Issue

• Issue the following from the CSG
• Hard disk (one per group)
• Key (one per group)
• RHEL WS3 installation DVD (one per group)
• You need to download the lab01 tar file
  (lab01.tgz) from the course website.
• The RTLinux lab is in Coover - 1331C

17
Handling the hard disk (1)

• Shutdown the PC
• After the power is off, unlock the existing hard
  disk and take it out
• Insert the hard disk given to you and lock it
• Restart the comp
• Follow the manual you have downloaded from the
  course website

18
Handling the hard disk (2)

• After you are done with the lab
• Shutdown the PC
• After the power is off, unlock the hard disk and
  remove it
• Insert the original hard disk and lock it
• Leave the Lab

19
RTLinux Lab 1Cpre 558

• Anil
• anil_at_iastate.edu

20
Lab 1 Objectives

• Part 1
• Getting the RTLinux lab setup ready
• Part 2
• Run a few simple hello-world modules

21
Part 1

• Install the RHEL-WS3 using the DVD given to you
• Go for the auto-partitioning option
• Rest everything is straightforward
• Configure and compile fresh Linux kernel (2.4.29)
• Patch the RTLinux to the Linux kernel
• Recompile the kernel and reboot the system into
  the new kernel
• Load RT-modules
• Instructions are provided in the Lab manual

22
Part 2

• Boot into the RTLinux kernel compiled in part-1
• The objectives of the part 2 are
• Understanding a simple RTLinux kernel module
• With one thread (hello-1) and two threads
  (hello-2)
• Printing from a RTLinux module
• rtl_printf (hello-3)
• Using rtf_put (RT-FIFO) (hello-4)

23
A kernel module Vs. Program

• All RT-Tasks are kernel modules. Therefore, we
  write kernel modules in this lab.
• A user program runs in user space and the kernel
  module runs in the kernel space
• A user program starts running at its main
  function
• A kernel module starts running at the
  init_module function and exits via
  cleanup_module function
• Therefore, for a kernel module init_module and
  cleanup_module are as necessary as main is
  necessary for a C program

24
A typical kernel module
Init_module() . Perform your module
initiation stuff etc.. Cleanup_module() . P
erform cleanup stuff like destroying the threads,
freeing memory, etc..
25
Hello world Module

• Go through the hello world module
• Realize the importance of init_module and
  cleanup_module
• Notice the way the thread is created and how it
  is made periodic
• Understand the pthread_make_periodic and
  pthread_wait and other interfacing functions

26
A typical RTLinux module
This function tells the scheduler that I am a
periodic task with period p
Init_module() For each thread Choose the
priority function //pthread_set_priority(..) Ass
ign the task_function to the thread Create the
thread //pthread_create(.., task_function,..)
Task_function() Pthread_make_periodic_np(p)
while(1) Pthread_wait_np() //perform
the task function //for this instance
Cleanup_module() . Delete the
thread //pthread_delete_np(..)
This function tells the scheduler that I am done
for this instance and schedule me after p units
of time
27
Hello World 2

• This module creates two threads using a nice
  thread_struct structure to make the
  initialization easy and compact.
• Once again go through the interfacing funcitons
• This time put more rtl_printf statements and
  open /var/log/messages file to find your output

28
RTL_PRINTF how does it work?
Might overflow!!
printk
Rtl_printf
Printk buffer
Kernel ring buffer
Log file
Might overflow!!
syslodg
console
29
Other ways of printing RTL-FIFO

• RTLinux FIFO provides communication mechanisms
  between RTL threads and Linux task.
• A linux process creates the RTL-FIFO buffer which
  the RTL threads access and write and read from
  them

30
RTL-FIFO

• Creating and destroying FIFOS
• Using functions rtf_create and rtf_destroy
• These functions are called from linux process
  open(), read(), write()
• Accessing FIFOs from RTL threads
• using functions rtf_put and rtf_get

31
Using RTL_FIFO
Linux Task my_read task
RT Task my_put task
rtf_create()
open()
rtf_put()
Time
read()
rtf_destroy()
RTL FIFO
32
Submissions

• Submission 1
• Submit a five line write-up explaining the
  working of the two RTL interfacing functions
  including
• Pthread_make_periodic_np
• Pthread_wait_np
• Rtf_create,rtf_destroy, rtf_put, rtf_get
• Submission 2
• Submit a five line write-up giving at least five
  differences between a kernel module and a user
  program.

33
Thank You!!
