Michael Factor IBM IL

1
Optimistic Concurrency for Clustersvia
Speculative Locking

• Michael Factor (IBM IL)
• Assaf Schuster (Technion)
• Konstantin Shagin (IBM IL)
• Tal Zamir (Technion)

2
Motivation

• Locks are commonly used in distributed systems
• Protect access to shared data
• Coarse-grained/fine-grained locking
• Blocking lock acquisition operations are
  expensive
• Require cooperation with remote machines
• Obtain ownership, memory consistency operations,
  checkpointing
• On the applications critical path
• Reduce concurrency
• Hence, removal of blocking lock acquisitions has
  potential to boost performance

3
Speculative locking

• Speculative Locking (SL) suggests that the
  application should continue its execution without
  waiting for a lock acquisition to be completed
• Such execution may cause data consistency
  violations
• A thread may access invalid data
• Consistency violations are detected by the system
  and a rollback is performed if such a violation
  is detected
• Thus, speculative locking
• Removes the lock acquisition from the critical
  path
• Allows concurrent execution of critical sections
  protected by the same lock
• In a number of cases speculative locking is
  especially advantageous
• Little data contention
• Threads access different data
• Threads rarely perform write operations
• Little lock contention
• Conservative thread-safe libraries using
  coarse-grained locks

4
Blocking lock acquisition vs. speculative
B
A
A
B
spec. acq (L)
acq(L)
spec. acq(L)
write(Y)
write(Y)
request(L)
request(L)
executing in speculative mode
blocked
rel (L)
rel (L)
read(X)
ownership(L)
ownership(L)
conflict check
read(X)
blocking
speculative
5
Speculative locking for a general-purpose
distributed runtime

• We suggest employment of SL in a general-purpose
  distributed runtime system
• Since rollback capability is required, it is best
  suited for fault-tolerant systems
• We implement and evaluate SL in JavaSplit, a
  fault-tolerant distributed runtime system for
  Java
• The protocol consists of three main components
• Acquire operation logic
• Data conflict detection
• Checkpoint management
• Although we demonstrate distributed speculative
  locking in a specific system, the approach is
  generic enough to be applied to any other
  distributed runtime with rollback capabilities.

6
JavaSplit overview

• Executes standard multithreaded Java programs
• Each application thread runs in a separate JVM
• The shared objects are managed by a distributed
  shared memory protocol
• The memory model is Lazy Release Consistency
• The protocol is object-based
• Can tolerate multiple concurrent node failures
• Thread checkpoints and shared objects are
  replicated
• Employs bytecode instrumentation to distribute
  threads, preserve memory consistency and enable
  checkpointing. Hence it is
• Transparent the programmer is not aware of the
  system
• Portable executes on a collection of JVMs

7
Blocking Lock Acquisition in JavaSplit

• The requester sends a lock acquisition request to
  the current lock owner and waits for a reply
• When the owner releases the lock, it takes a
  checkpoint of its state and transfers the lock
• A checkpoint is required to support JavaSplits
  fault-tolerance scheme
• Along with the lock, write notices are
  transferred, invalidating objects whose
  modifications should be observed by the acquirer
  (to maintain LRC)

8
Speculative Lock Acquisition in JavaSplit

• The requester sends a lock acquisition request to
  the current lock owner and continues execution
• Until lock ownership is received, the requester
  is in speculative mode
• While in speculative mode, object read accesses
  are logged (using Java bytecode instrumentation)
• When lock ownership is received, write notices
  are examined to detect a data conflict
• Upon data conflict detection, the thread rolls
  back
• A thread can speculatively acquire a number of
  locks

9
Blocking lock acquisition vs. speculative
blocking
speculative
10
Managing consistent checkpoints (theory)

• Requirement 1 Must ensure a thread can rollback
  to a state preceding any potentially conflicting
  access
• Since a conflicting access can be may occur only
  in speculative mode, it is sufficient to
  guarantee there is a valid checkpoint taken
  before speculating
• In a fault-tolerant system, each thread has at
  least one valid checkpoint preceding speculation
• It remains to ensure this checkpoint is not made
  invalid by checkpoints taken while in speculation
  mode
• Requirement 2 Must prevent the speculating
  thread from affecting other threads or monitor
  such dependencies
• If a speculating thread affects another thread,
  then the latter must be rolled back along with
  the former in the case of a data conflict

11
Managing consistent checkpoints (practice)

• In JavaSplit, a thread can rollback only to the
  most recent checkpoint
• In addition, a thread has to checkpoint (only)
  before transferring lock ownership to another
  thread
• Consequently, in order to ensure a speculating
  thread can rollback to a state preceding
  speculation we prevent threads from transferring
  lock ownership while in speculative mode
• This satisfies the requirement 1
• The transfer of lock ownership is postponed until
  the thread leaves the speculative mode
• Coincidentally, this also satisfies the
  requirement 2, because in JavaSplit, a thread
  may affect other threads only when transferring
  lock ownership
• Thus, a speculating thread cannot affect other
  threads

12
Speculative Deadlocks
A
B

• Two threads concurrently acquire locks from each
  other
• The threads enter speculative mode and therefore
  cannot transfer lock ownership
• No application deadlock
• A number of threads can be involved in such a
  dependency loop
• Deadlock detection and recovery are required

13
Speculative Deadlocks (2)

• Deadlock Avoidance
• Limiting the number of speculations per session
• Returning lock ownership to passive home nodes on
  release
• Deadlock Detection
• Timeout-based approach
• Simple but inaccurate
• Message-based approach
• Similar to Chandy-Misra-Haas edge-chasing
  algorithm
• Can be used to automatically detect a more
  accurate timeout value
• Deadlock Recovery
• Thread rolls back to its latest checkpoint
• Before continuing execution, all pending lock
  requests are served
• Heuristic next few lock acquisitions are
  non-speculative

14
Speculation Preclusion

• The protocol allows to acquire lock speculatively
  or the old fashioned blocking way
• Threads can decide at run time whether to apply
  speculation in each particular instance
• This enables run time heuristic logic that
• Detects acquire ops. that are likely to result in
  a rollback, and
• Prevents speculative acquisitions
• For a time period
• In a number of next acquire operations
• The speculation preclusion algorithm should be as
  lightweight as possible because it is invoked on
  each lock acquisition
• Static analysis can also be employed to detect
  cases in which rollback is likely to occur

15
Transactional Memory

• Transactional memory is another form of
  optimistic concurrency control akin to
  speculative locking
• The basic principle is the same
• optimistically execute a critical code segment
• determine whether there have been data conflicts
• roll back in case validation fails
• However, the programming paradigm and the
  implementation details differ significantly

16
Distributed Transactional Memory

• Non-scalable/somewhat inefficient implementations
  (drawn from the classic hardware/software
  transactional memory protocols)
• Broadcast based
• Centralized
• Require global cooperation
• Less optimistic than distributed speculative
  locking
• Try to ensure validity of one transaction before
  executing another, hence
• Fail to overlap communication with computation
• Can be classified to blocking-open and
  blocking-commit schemes
• Blocking-open schemes that often induce a remote
  blocking open operation when accessing an object
  for the first time within a transaction
• Blocking-commit schemes that require a blocking
  remote request prior to committing
• Question Is SL a suitable alternative for TM in
  a distributed setting?
• It is surely more optimistic, but speculative
  deadlock and other factors may hinder this
  advantage
• We only scratch the surface of this question

17
(No Transcript)
18
Performance Evaluation

• Test bed
• Cluster of 15 commodity workstations
• Workstation parameters
• Windows XP SP2
• Intel Pentium Xeon dual-core 1.6 GHz processor
• 2GB RAM
• 1 Gbit Ethernet
• Each station executes two JavaSplit threads
• Standard Sun JRE 1.6

19
Traveling Salesman Problem

• Single lock application
• Lock protects the globally known minimal path
• Non-speculative system has scalability issues due
  to lock acquisition operations
• Speculative system does not need to wait for lock
  acquisitions, but has a slight overhead due to
  speculation failures (data conflicts)
• With a single thread, the read access monitoring
  overhead results in a slowdown

20
SPECjbb (low acquisition frequency)

• Business server middleware application
• Workers process incoming client requests, each
  requiring exclusive access to specific stock
  objects
• Fine-grained locking
• Job processing time is non-negligible (low lock
  acquisition frequency)
• Non-SL system does not have a scalability issue
• SL removes the lock acquisition overhead
• No speculative deadlocks
• No data conflicts

21
SPECjbb (high acquisition frequency)

• Job processing time minimized to simulate
  extremely high lock acquisition frequency
• In the non-SL system, the lock acquisition
  overhead is high
• SL has to set a quota on the number of
  speculations per speculative session, to avoid
  speculative deadlocks
• SL reduces the lock acquisition overhead, but
  does not eliminate it here

22
HashtableDB

• Naive benchmark demonstrating an optimal scenario
  for SL
• A single lock protects a hash table object
• Coarse-grained locking
• Processing is performed while holding the lock
• Non-speculative system does not scale, only one
  thread can perform computation at any given
  moment
• SL system has near full linear scalability

23
Checkpointing Frequency

• The underlying fault-tolerant system performs
  checkpoints at a given frequency
• This graph demonstrates the effect of
  checkpointing frequency on the performance of
  SPECjbb
• A high checkpointing frequency results in higher
  checkpointing overhead, but smaller speculation
  failure recovery penalty
• This tradeoff is balanced by an ideal frequency
  (per execution)

24
Speculative Deadlocks

• In the presence of speculative deadlocks, setting
  a quota on the number of speculations per session
  is required
• The probability of speculative deadlocks is a
  complex function of multiple factors, also
  effected by this quota
• The higher the quota, the more time can be spent
  in speculative mode, increasing deadlock
  probability

25
Speculative Deadlocks (2)

• However, a higher speculation quota allows the
  application to continue execution (without
  blocking) for longer periods of time
• Thus, per execution, an optimal value of
  speculation quota exists

26
Questions?
The end
