Business Driven SOA

1

• Business Driven SOA

Edwin Schumacher Director of Product
Management edwin.schumacher_at_compuware.com
2
Development strategiesBuilding dynamic,
business-driven applications faster

• Faster increase productivity dramatically
• Model-Driven Architecture (MDA) based Development
• Dynamic ability to change, agility
• Service Oriented Architecture (SOA)
• Business-driven applications close the gap
  between business and IT
• Business Process Automation (BPA)

3
Faster DevelopmentThrough a Model-Driven
Architecture based approach
4
Productivity Analysis Comparing MDA-based to
Code-Centric Development

• Conducted by The Middleware Company
• Compared two development paradigms
• MDA environment against a traditional
  code-centric IDE
• Two teams
• Each had 1 architect 2 developers
• Architected and produced the same J2EE
  application one using MDA, the other using a
  code-centric, enterprise-caliber IDE
• Report available on http//www.omg.org/mda/presen
  tations.htm Title MDA Productivity
  Study, June 2003

5
Study ResultsThe Middleware Company

• MDA team delivered an error-free application in
  330 hours versus 507 hours with the IDE tool,
  which equates to 35 productivity increase
• One of the programmers expected that the MDA team
  would have been 10-20 faster were it not for the
  fact that this was their first project using the
  tool
• The quality of the code of an application built
  with an MDA tool is comparable if not better than
  applications that are built with traditional
  techniques

6
EDS StudyDriving Business Agility with MDA-based
development

• Background
• Conducted by a SUN Certified J2EE
  Architect/Developer from EDS
• Compared two development paradigms
• MDA environment against a traditional
  code-centric IDE
• Approach taken
• Pet Store specification used
• Compared lines of handcrafted code
• Migration from EJB 1.1 to 2.0
• Report available on http//www.eds.com/thought/th
  ought_leadership_agility_model_arch.pdf

7
Study ResultsEDS

• Lines of handcrafted code
• J2EE Pet Store using MDA development tool 610
• J2EE Pet Store 14,273
• On average the developer wrote only one to four
  lines of Java code manually for each 200 lines
  generated automatically
• Upgrading to EJB 2.0
• Took less than 30 minutes to upgrade. This would
  typically be a manual process, taking several
  months
• Bottom line
• Significant productivity gains achieved with MDA
  tool during application development and
  maintenance
• Clearly demonstrates how MDA protects existing
  investments

8
Model-Driven Architecture based Development
9
Ability to ChangeThrough a Business Driven
Service Oriented Architecture
10
Business ModelStep One

• Expressed in UML
• Structure and behaviour
• Class Model and Service Model
• Develop at a high abstraction level
• Business centric
• Undistorted by technical details
• Focus on application functionality
• Enrich with business rules
• Constraints
• Expressions
• Automated reuse of model definitions and business
  rules
• Change applications rapidly in the model

11
Architecture ModelStep Two
Business Model

• Automatic transformation from Business Model to
  Architecture Model
• Consistency and quality
• Logically layered components
• Presentation Model
• Data schemas, Web components etc.
• Business Logic Model
• Data schemas, key classes, entity components,
  session components etc.
• Data Model
• Relational data schema
• Tables, columns, keys etc.

Design Patterns
Architecture Model
Code Model
12
Code ModelStep Three

• Automatic transformation from Architecture Model
  to Code
• Productivity, quality and consistency
• J2EE Core Patterns
• Presentation Tier
• MVC framework (Struts)
• Java Server Pages, Servlets
• Business Logic Tier
• Bean class, home/remote and primary key classes
  etc.
• According to EJB specification
• Data Access Tier
• SQL scripts for target database
• Application deployment descriptors
• For target application server

Transformation Patterns
Business Model
Technology Patterns
Architecture Model
Code Patterns
Code Model
13
Service EnablementCoherent Migration to a
Service Oriented Architecture

• SOA is more than just Web services
• Integration Model
• Import WSDL, IDL, COBOL Copybooks (CICS and
  IMS/TM),Java/EJB signatures, SAP business
  objects, DBMS,etc.
• Automatic re-design to business model
  throughre-design patterns enabling
  participation of legacy applications in a SOA
• Reduce complexity through adapter approach

Business Model
Architecture Model
Code Model
14
A Service Oriented ArchitectureIncreases the
ability to change - flexibility

• Web-based
• Java Server Pages

Presentation Logic
Application

• Contains business logic
• Integration layer
• Exposable as Web Service

Business Logic

• Automatically generated
• Distributed
• Manage persistency

Data Logic
Data

• Create new database
• Upload existing database

Data Storage
15
Closing the Gap between Business and ITBusiness
Process Automation leveraging SOA
16
The Evolution of Enterprise Application
Development
Development paradigm
Business IT alignment
17
Business Process Automation The next step after
SOA

• Organisational model
• Actors and Roles
• Process model

Process
Enter Order
Business Process
Ship Order
Check Customer
Send Message

• Web-based
• Client-Server
• Wireless

Presentation Services
Application
Business Logic Services

• Contain business logic
• Manage the transaction
• Integration layer

Data Access Services

• Generated
• Distributed
• Manage data integrity

Data

• Create new database
• Upload existing database

Databases
18
Business Process Management

• Process focus
• Goals-driven
• Customer orientation

task
customer
customer
Shipping
Production
Sales
19
Conclusion

• Model-Driven Architecture based development (MDA)
• Focus on automating the translations from
  Business Model to Architecture to Code as they
  are the main source of errors Model Driven
  Architecture
• Service Oriented Architecture (SOA)
• Make sure Application Services relate to Business
  Operations
• Web Services are just one implementation of a SOA
• Take an evolutionary approach to SOA
  implementation
• Business Process Automation (BPA)
• A Service Oriented Architecture is the foundation
  for Business Process Automation
• Integrate BPA into your application development
  paradigm process-oriented application
  development
