Motivation

1
Skippy Enabling Long-Lived Snapshots of the Long-Lived Past Skippy Enabling Long-Lived Snapshots of the Long-Lived Past Skippy Enabling Long-Lived Snapshots of the Long-Lived Past
Ross Shaullrshaull_at_cs.brandeis.edu Liuba Shriraliuba_at_cs.brandeis.edu Hao Xuhxu_at_cs.brandeis.edu
Lab for Experimental Software SystemsBrandeis University Lab for Experimental Software SystemsBrandeis University Lab for Experimental Software SystemsBrandeis University
Analysis

• Expected cost to build SPT
• Calculate expected cost of building SPT by
  factoring in
• acceleration
• cost to read sequentially at each level
• cost of disk seeks between each level
• Plot shows time to build SPT versus the number of
  Skippy levels for various skews

Motivation
Cost of Scan
Experimental Evaluation

• An old problem Time travel in databases
• Retaining past state at logical record level
  (ImmortalDB, Postgres) changes arrangement of
  current state
• File system-level approaches block transactions
  to get consistency (VSS)
• A new solution Split Snapshots
• Integrates with page cache and transaction
  manager to provide disk page-level snapshots
• Application declares transactionally-consistent
  snapshots at any time with any frequency
• Snapshots are retained incrementally using
  copy-on-write (COW), without reorganizing
  database
• All applications and access methods run
  unmodified on persistent, on-line snapshots
• Achieve good performance in same manner as the
  database leverage db recovery to defer snapshot
  writes
• A new problem How to index copy-on-write split
  snapshots?

1. Let overwrite cycle length L be the number of
   page updates required to overwrite entire
   database
2. Overwrite cycle length determines the number of
   mappings that must be scanned to construct SPT
3. Let N be the number of pages in the database
4. For a uniformly random workload, L N ln N (by
   the coupon collectors waiting time problem)
5. Skew in the update workload lengthens overwrite
   cycle by introducing many more repeated mappings
6. For example, skew of 80/20 (80 of updates to 20
   of pages) increases L by a factor of 4

Implementation

• Skippy-based Snapshot System Implemented in
  Berkeley DB (BDB)
• Page-level snapshots created using COW
• Page cache is augmented to intercept requests for
  pages
• Pages which are write locked get COWd on the
  first request after declaration of a snapshot
• Pages are flushed periodically from a background
  thread to a second disk
• Snapshot metadata is created in-memory at
  transaction commit
• Metadata (and any unflushed pages COWd before
  the checkpoint) are written to disk during
  checkpoint
• Recovery of snapshot pages and metadata can be
  done in one log pass

!
Skew hurts
Results Cost of Scanning to Construct SPT
Indexing Split Snapshots
Combat Skew with Skippy

• Setup
• 100M database
• 50K node (holds 2560 mappings, which is 1/10th
  the number of database pages)
• 10,000rpm disk
• Conclusions
• Skippy could counteract 80/20 skew in 3 levels
• 99/1 has hot section much smaller than node size,
  so one level is enough

Skew Skippy Levels Time to Build SPT (s)
50/50 0 13.8
80/20 0 19.0
80/20 1 15.8
80/20 2 14.7
80/20 3 13.9
99/1 0 33.3
99/1 1 6.69

• Each snapshot needs its own page table (an SPT)
  which points to current-state and COWd pages

Key Idea
For faster scan, create higher-level logs of FEMs
with fewer repeated mappings

• Order of Events
• Snapshot 1 declared
• Page 1 modified
• Snapshot 2 declared
• Page 1 modified again
• Page 2 modified

P1
P1
P2
Database
Snapshot pages
P1
P3
P2

• Divide Maplog into equal-sized chunks called
  nodes
• Copy each FEM in a Maplog node into Skippy Level
  1
• At the end of each node record an up-link that
  points to the next position in Skippy Level 1
  where a mapping will be stored
• To construct Skippy Level N, recursively apply
  the same procedure to the previous Skippy Level
• When scanning, follow up-links to Skippy Levels
  (a Skippy scan)

P1
SPT1
P1
P2
P1
P2
P1
P3
P3
Skippy Level 1
P2
P3

• P2 is shared by SPT1 and SPT2
• P3 has not been modified so SPT1 and SPT2 point
  to P3 into the database

Impact of Taking Snapshots
P1
SPT2
P1
P1
P2
P1
P1
P1
P2
P1
P3
P3
Maplog
P2

• Can we create split snapshots with a Skippy index
  efficiently?
• Plot shows time to complete a single-threaded
  updating workload of 100,000 transactions in a
  66M database with each of 50/50, 80/20, and 99/1
  skews
• We can retain a snapshot after every transaction
  for a 68 penalty

P3
Snap 1
Snap 2
Snap 3
Snap 4
Snap 5
Snap 6
Start
Solid arrows denote pointers Dotted arrows
indicate copying
Updating SPTs on disk would be costly, since one
COW may change the pointers in multiple SPTs
Accessing Snapshots with Maplog

• Instead of maintaining many SPTs, append mappings
  to snapshot pages into a log, the maplog
• Ordering invariant
• All mappings retained for snapshot X are written
  into maplog before mappings retained for snapshot
  X1
• Construct SPT for snapshot X by scanning for
  first-encountered mappings (FEMs)
• Any page for which a mapping is not found in
  maplog is still in the database (i.e., has not
  been COWd yet)

A Skippy scan that begins at Start(X) constructs
the same SPTX as a maplog scan
More Stuff
Acceleration of Scan

• Across-Time Execution (ATE)
• Skippy can be used to cheaply construct SPTs for
  a window of snapshots for across-time analysis
• Garbage collection
• Collecting old records from a log is simple, just
  chop off the tail
• Skippy enables cheap generational garbage
  collection of snapshots according to
  priorities(Thresher, Shrira and Xu, USENIX 06)

P1
SPT1

• Skippy acceleration is the ratio of number of
  mappings in top Skippy level to maplog
• Acceleration depends on
• Node size (repeated mappings are only eliminated
  if they appear in the same node)
• Workload (likelihood of repetitions)

P2
P3
Snap 1
Snap 2
P1
P1
P2
References
Maplog
Start

• Shaull, R., Shrira, L., and Xu, H. Skippy
  Enabling Long-Lived Snapshots of the Long-Lived
  Past. ICDE 2008.
• Shrira, L., van Ingen, C., and Shaull, R. Time
  Travel in the Virtualized Past. SYSTOR 2007.
• Shrira L., and Xu, H. Snap Efficient Snapshots
  for Back-In-Time Execution. ICDE 2005.
