Extracting Symbolic Knowledge From The Web

1
Extracting Symbolic Knowledge From The Web

• Ofer Neiman

2
The Problem

• The WWW contains information which is easily
  understandable to humans , but less
  understandable to computers
• Web Pages contain mostly text , images and
  sounds. These can be immediately processed by
  humans, but the information is not necessarily
  arranged in the optimal manner for automatic
  problem solving by computers.

3
The Web-gtKB Projects Long Range Goal

• Create a computer understandable knowledge base
  whose content mirrors that of the WWW.
• This Knowledge Base would consist of
  assertions in symbolic form.


4
Web-gtKB Goal (ctd.)

• At the minimum, the KB would allow more
  sophisticated queries than keyword-based search
  engines.

5
The 1st Step A Machine Learning Approach

• Develop a TRAINABLE system , that can be
  taught to extract information.
• The inputs to the system 1)
  An Ontology specifying classes in
  hierarchical tree form and relations between
  these classes. Class Examples
  Student , Person, Research.Project
  Relation Examples Advisor.Of(Instructor,Stud
  ent) , Projects.Led.By(Project,Researcher).



6
A Machine Learning Approach (ctd.)

• 2) (2nd input) Training Examples
  that represent instances of the classes and
  relations. Given the ontology and
  training examples, the system is expected to
  extract from the web NEW instances of classes
  and relations.

7
(No Transcript)
8
Some Simplifying Assumptions

• 1) Instances of ontology classes are represented
  by single web pages (home pages).
• 2) Instances of relations R(A,B) are
  represented in one of 3 ways
  - a segment
  of text connecting the segment representing A
  to the segment representing B .
  - a contiguous segment of text representing
  A that contains a segment representing B .

9
Assumptions (ctd.)

• Example Jims home page contains the words
  Intro To AI , so courses.taught.by(Jim,Intro2AI
  ) holds
• - The segment representing A is related to B
  because it fits some pattern .
  Example Jims page contains words typical of AI
  researchers , so the relation Research.Of (Jim,
  AI) holds.

10
The Goal In More Specific Terms

• 1. Recognizing class instances by classifying
  segments of hypertext
• 2. Recognizing relation instances, mostly by
  classifying hyperlinks

11
A KB for CS Departments

• 2 sets of pages from CS departments were drawn,
  each one with more than 4000 pages .
• The 1st set was drawn from four departments, and
  the 2nd from many departments.
• The classes and relation instances were hand
  labeled.
• The idea is to learn instances from one
  department using the data from other departments
  as training input.

12
1st Method For Recognizing Class Instances- A
Statistical Model

• From the labeled data, each class A is assigned
  a vector of probabilities W(A) W(A)(
  W1,.Wvocabulary ) Wi the frequency
  of word i in a page representing class A.
• The working vocabulary size is finite (2000
  key words)

13
Recognizing Class Instances- A Statistical
Model (ctd.)

• A new page P is assigned to the class which
  is most probable given the distribution of
  words in P (The class with minimal distance ).
• The calculation is done using a variant of the
  KL divergence, which measures the distance
  between distributions
  D(PQ) Sigma x P(x) log (P(x)/q(x))

14
A Statistical Model (ctd.)

• Evaluating the results, according to two
  criteria 1) Coverage - The
  percentage of pages from a given class that are
  correctly classified as belonging to that class
  2) Accuracy - The percentage of pages
  classified to a class that are actually members
  of that class
• Theres a natural trade-off between the two.
• We can raise or lower coverage (accuracy) by
  setting a confidence threshold Page P will be
  classified to class A only if the distribution
  in P is sufficiently similar to the
  distribution in A .

15
A Statistical Model (ctd.)

• Mistaken Classifications Since the
  ontology is hierarchical (Person -gt Faculty
  Or Staff Or Student), a classification of an
  instance into a more general ancestor class
  can still be useful.


16
Some Experimental Results

• The Student Class


• Coverage 20 , Accuracy 67 Coverage80
  , Accuracy45
• The Course Class
• Coverage 20 , Accuracy 55
• Coverage80 , Accuracy30

17
2nd Method For Recognizing Class Instances
Learning First Order Rules

• Instead of looking just at the word pattern on a
  given page, we look at the word pattern in
  neighboring pages as well.
• Example A page is a course home page if it
  contains the words textbook and TA, and is
  linked to a page that contains the word
  assignment.

18
Recognizing Class Instances Learning First
Order Rules ( ctd .)

• We need an algorithm to infer rules in
  predicate form, where the arguments are pages.
• The rule defines a target class , using
  basic (atomic) predicates of 2 kinds
• has_word(Page) - a finite family of
  predicates where word can be any word, indicating
  that the page contains the word.
• link_to(Page1,Page2) - there is a hyperlink
  from page 1 to page 2.

19
Recognizing Class Instances Learning First
Order Rules (ctd.)

• The input positive instances of basic
  predicates and positive and negative instances
  of the target class.
• The output rules are in terms of the basic
  predicates (previous slide).
• The algorithm (FOIL) uses a greedy method
  At each stage , add to the current
  definition a basic predicate that excludes
  from the instances still unaccounted for as many
  negative examples as possible, while including
  as many positive examples as possible.

20
Recognizing Class Instances Learning First
Order Rules (ctd.)

• Example The Algorithm found the following
  definition for the class faculty
  faculty(A) has_professor(A),
  has_ph(A), link_to(B,A), has_faculty(B)
• MeaningA page belongs to a faculty member if it
  contains the words professor and ph (prefix
  of phd) , and there is a link to it from a
  page containing the word faculty.

21
More Experimental Results (for first order
rules)

• The student class Coverage 20 ,
  Accuracy 90
  Coverage 80 , Accuracy 70

• Tends to be more accurate than
  statistical classification, but the coverage is
  not as good (hard to come up with rules that
  will make all instances of the class classified
  as belonging to the class) .

22
Recognizing Relation Instances

• - The main issue to consider is hyperlink
  connection.
• - The algorithm is similar to the algorithm for
  learning 1st order class rules.
• - The underlying assumption a relation between
  pages is expressed in terms of a hyperlink or
  a chain of hyperlinks. Therefore , we need
  predicates whose arguments are pages and
  hyperlinks.
• - The algorithm is applied assuming class
  instances have already been extracted.
• Tjhe studying 1st order r ru
  rulerules. T


23
Recognizing Relation Instances (ctd.)

• The basic predicates
• class(Page)
• link_to(Hyperlink,Page,Page)
• Has_word(Hyperlink)
• all_words_capitalized(Hyperlink)
• has_alphanumeric_word(Hyperlink)
• has_neighborhood_word(Hyperlink)
• Tjhe studying 1st order r ru
  rulerules. T


24
Recognizing Relation Instances (ctd.)

• An Example Learned Rule
• members.of.project(A,B)
• research_project(A) , person(B) , link_to(C,A,D),
  link_to(E,D,B)
• Meaning The projects home page A points to an
  intermediate page D which points to a personal
  home page B.
• Tjhe studying 1st order r ru
  rulerules. T


25
Recognizing Relation Instances (ctd.)

• Another Rule
• department.of.person(A,B)
• person(A) , department(B),link_to(C,D,A),
  link_to(E,F,D),link_to(G,B,F),
• has_neighborhood_graduate(E)
• Meaning A 3 hyperlink path from a department
  to a person, requiring that the word graduate
  occur near the 2nd hyperlink.
• Tjhe studying 1st order r ru
  rulerules. T


26
Recognizing Relation Instances (ctd.)

• Better results than for 1st order class learning
  rules The coverage was not perfect but the
  accuracy was close to 100.
• Tjhe studying 1st order r ru
  rulerules. T


27
Future Research

• 1) Relaxation of restrictions, e.g a class may
  be represented by more than one page.
  2) Exploiting HTML structure there are
  different kinds of text fields in a page .

28
References

• 1) M. Craven et al. , Learning to Extract
  Symbolic Knowledge from the World Wide Web,
  AAAI-98.
• 2) More Articles The Machine Learning Group at
  CMU
• www.cs.cmu.edu/Groups/TextLearning/
