UNIXs grand illusion

1
UNIXs grand illusion

• How Linux makes a hardware device appear to be a
  file

2
Basic char-driver components
Device-driver LKM layout
modules payload is a collection of
callback-functions having prescribed
prototypes
function
function
function
AND a package of
function-pointers
fops
. . .
init
the usual pair of module-administration
functions
registers the fops
exit
unregisters the fops
3
Background

• To appreciate the considerations that have
  motivated the over-all Linux drivers design
  requires an understanding of how normal
  application-programs get their access to services
  that the operating system offers
• This access is indirect through specially
  protected interfaces (i.e., system calls)
  usually implemented as library functions

4
Standard File-I/O functions

• int open( char pathname, int flags, )
• int read( int fd, void buf, size_t count )
• int write( int fd, void buf, size_t count )
• int lseek( int fd, loff_t offset, int whence )
• int close( int fd )
• (and other less-often-used file-I/O functions)

5
Our elfcheck.cpp example
include ltfcntl.hgt for open() include
ltstdio.hgt for perror(), printf() include
ltunistd.hgt for read(), close() include
ltstring.hgt for strncpy() char buf4 int
main( int argc, char argv ) if ( argc 1
) return -1 // command-line argument is
required int fd open( argv1, O_RDONLY ) //
open specified file if ( fd lt 0 ) perror(
argv1 ) return -1 // quit if open
failed int nbytes read( fd, buf, 4 ) // read
first 4 bytes if ( nbytes lt 0 ) perror(
argv1 ) return -1 // quit if read failed if
( strncmp( buf, \177ELF, 4 ) 0 ) // check
for ELF id printf( File \s\ has ELF
signature \n, argv1 ) else printf( File
\s\ is not an ELF file \n, argv1 ) close(
fd ) // close the file
6
Special device files

• UNIX systems treat hardware-devices as special
  files, so that familiar functions can be used by
  application programmers to access devices (e.g.,
  open, read, close)
• But a System Administrator has to create these
  device-files (in the /dev directory)
• Or alternatively (as weve seen), an LKM could
  create these necessary device-files

7
UNIX man pages

• A convenient online guide to prototypes and
  semantics of the C library functions
• Example of usage
• man 2 open

8
The open function

• include ltfcntl.hgt
• int open( char pathname, int flags, )
• Converts a pathname to a file-descriptor
• File-descriptor is a nonnegative integer
• Used as a file-ID in subsequent functions
• flags is a symbolic constant
• O_RDONLY, O_WRONLY, O_RDWR

9
The close function

• include ltunistd.hgt
• int close( int fd )
• Breaks link between file and file-descriptor
• Returns 0 on success, or -1 if an error

10
The write function

• include ltunistd.hgt
• int write( int fd, void buf, size_t count )
• Attempts to write up to count bytes
• Bytes are taken from buf memory-buffer
• Returns the number of bytes written
• Or returns -1 if some error occurred
• Return-value 0 means no data was written

11
The read function

• include ltunistd.hgt
• int read( int fd, void buf, size_t count )
• Attempts to read up to count bytes
• Bytes are placed in buf memory-buffer
• Returns the number of bytes read
• Or returns -1 if some error occurred
• Return-value 0 means end-of-file

12
Notes on read() and write()

• These functions have (as a side-effect) the
  advancement of a file-pointer variable
• They return a negative function-value of -1 if an
  error occurs, indicating that no actual data
  could be transferred otherwise, they return the
  number of bytes read or written
• The read() function normally does not return 0,
  unless end-of-file is reached

13
The lseek function

• include ltunistd.hgt
• off_t lseek( int fd, off_t offset, int whence )
• Modifies the file-pointer variable, based on the
  value of whence
• enum SEEK_SET, SEEK_CUR, SEEK_END
• Returns the new value of the file-pointer (or
  returns -1 if any error occurred)

14
Getting the size of a file

• For normal files, your application can find out
  how many bytes belong to a file using the
  lseek() function
• int filesize lseek( fd, 0, SEEK_END )
• But afterward you need to rewind the file if
  you want to read its data
• lseek( fd, 0, SEEK_SET )

15
Device knowledge

• Before you can write a device-driver, you must
  understand how the hardware works
• Usually this means you need to obtain the
  programmer manual (from manufacturer)
• Nowdays this can often be an obstacle
• But some equipment is standardized, or is well
  understood (because of its simplicity)

16
Our RTC example

• We previously learned how the Real-Time Clock
  device can be accessed by module code, using the
  inb() and outb() macros
• So we can create a simple char driver that lets
  application-programs treat the RTCs memory as if
  it were in an ordinary file

outb( addr, 0x70 ) outb( data, 0x71 )
outb( addr, 0x70 ) data inb( 0x71 )
17
How device-access works
Application program
user space (unprivileged)
call
int 0x80
ret
Standard runtime library
int 0x80
iret
iret
Operating system (software)
call
supervisor space (privileged)
ret
Device-driver module (software)
out
in
Physical peripheral device (hardware)
18
Our cmosram.c driver

• We implement three callback functions
• llseek // sets file-pointers position
• read // inputs a byte from CMOS
• write // outputs a byte to CMOS
• We omit other callback functions, such as
• open // we leave this function-pointer NULL
• release // we leave this function-pointer NULL
• The kernel has its own default implementation
  for any function with NULL as its pointer-value

19
The fops syntax

• The GNU C-compiler supports a syntax for struct
  field-initializations that lets you give your
  field-values in any convenient order

struct file_operations my_fops
llseek my_llseek, write my_write,
read my_read,
20
init and exit

• The modules initialization function has to take
  care of registering the drivers fops
• register_chrdev( major, devname, fops )
• Then the modules cleanup function must make sure
  to unregister the drivers fops
• unregister_chrdev( major, devname )
• (These are prototyped in ltlinux/fs.hgt)

21
Our dump.cpp utility

• We have written an application that lets users
  display the contents of any file in both
  hexadecimal and ascii formats
• It also works on device files!
• With our driver-module installed, you can use it
  to view the CMOS memory-values
• ./dump /dev/cmos

22
Now for a useful char-driver

• We can create a character-mode driver for the
  processors physical memory (i.e. ram)
• (Our machines have 2-GB of physical ram)
• But another device-file is named /dev/ram so
  ours will be /dev/dram (dynamic ram)
• Weve picked 85 as its major ID-number
• Our SysAdmin setup a device-node using root
  mknod /dev/dram c 85 0

23
2-GB RAM has zones
ZONE_HIGH
1024128-MB
2048-MB ( 2GB)
ZONE_NORMAL
896-MB
16-MB
ZONE_LOW
Installed physical memory
24
Legacy DMA

• Various older devices rely on the PC/ATs DMA
  controller to perform data-transfers
• This chip could only use 24-bit addresses
• Only the lowest 16-megabytes of physical memory
  are visible to these devices
• 224 0x01000000 (16-megabytes)
• Linux tries to conserve its use of memory from
  this ZONE_LOW region (so devices will find free
  DMA memory if its needed)

25
Normal memory zone

• This zone extends from 16MB to 896MB
• Linux uses the lower portion of this zone for an
  important data-structure that tracks how all the
  physical memory is being used
• Its an array of records mem_map
• (We will soon be studying this structure)
• The remainder of ZONE_NORMAL is free for
  dynamic allocations by the OS kernel

26
HIGH memory

• Linux traditionally tried to map as much
  physical memory as possible into virtual
  addresses allocated to the kernel-space
• Before the days when systems had 1-GB or more of
  installed memory, Linux could linearly map ALL of
  the physical memory into the 1-GB virtual
  kernel-region
• 0xC0000000 0xFFFFFFFF
• But with 2-GB theres not enough room!

27
The 896-MB limit
HIGH MEMORY
temporary mappings using kmap()
Installed ram (2-GB)
HIGH ADDRESSES
Kernel space (1-GB)
896-MB
896-MB
always mapped
application programs code and data goes here
Physical address-space
User space (3-GB)
A special pair of kernel-functions named
kmap() and kunmap() can be called by
device-drivers to temporarily map vacant areas
in the kernels high address-space to pages of
actual physical memory
Virtual address-space
28
dram.c module-structure

• We will need three kernel header-files
• include ltlinux/module.hgt
• // for printk(), register_chrdev(),
  unregister_chrdev()
• include ltlinux/highmem.hgt
• // for kmap(), kunmap(), and num_physpages
• include ltasm/uaccess.hgt
• // for copy_to_user()

29
Our dram_size global

• Our init_module() function will compute the
  size of the installed physical memory
• It will be stored in a global variable, so it can
  be accessed by our driver methods
• It is computed from a kernel global using the
  PAGE_SIZE constant (4096 for x86)
• dram_size num_physpages PAGE_SIZE

30
major ID-number

• Our major device ID-number is needed when we
  register our device-driver with the kernel
  (during initialization) and later when we
  unregister our device-driver (during the
  cleanup procedure)
• int my_major 85 // static ID-assignment

31
Our file_operations

• Our dram device-driver does not need to
  implement special methods for doing the
  open(), write(), or release() operations
  (the kernel default operations will suffice)
• But we DO need to implement read() and
  llseek() methods
• Our llseek() code here is very standard
• But read() is specially crafted for DRAM

32
Using our driver

• We have provided a development tool on the class
  website (named fileview.cpp) which can be used
  to display the contents of arbitrary files --
  including device-files!
• The data is shown in hex and ascii formats
• The arrow-keys can be used for navigation
• The enter-key allows an offset to be typed
• Keys b, w, d and q adjust data-widths

33
In-class exercise 1

• Install the dram.ko device-driver module then
  use fileview to browse the contents of the
  processors physical memory
• ./fileview /dev/dram
• Be sure to try the b, w, d, q, ltENTERgt
  and ltESCAPEgt keys
• Also try ./fileview /dev/cmos

34
In-class exercise 2

• The read() and write() callback functions in our
  cmosram.c device-driver only transfer a single
  byte of data for each time called, so it takes
  128 system-calls to read all of the RTC
  storage-locations!
• Can you improve this drivers efficiency, by
  modifying its read() and write() functions, so
  theyll transfer as many valid bytes as the
  supplied buffers space could hold?
