Software Design CS 406 Software Engineering I Fall 2001

1
Software DesignCS 406 Software Engineering
IFall 2001

• Aditya P. Mathur

Last update October 2, 2001
2
Organization

• Part I Design principles and process
• Part II OO Design
• Part III Design Patterns
• Part IV Special topics

3
Learning Objectives

• To learn notations for representing a design.

• To understand and be able to apply the basic
  principles of software design. (GRASP patterns).

• To learn techniques and tools for
  Object- Oriented Design.

• Interaction diagrams

• Class diagrams

• State diagrams

4
Models during the Design Phase
Static structure diagrams
Interaction Diagrams Collaboration
diagrams Sequence diagrams
Contracts for methods and operations
State diagrams for classes
5
A collaboration diagram
classAinstance
classBinstance
message1() is sent to an instance of class
A. message2() and message3() are sent, in
that order, by an instance of class A to an
instance of class B. One diagram for each
system event.
6
A sequence diagram
May be used for multiple events.
7
Collaboration diagram makepayment()
Payment
Note Post is Register in the second edition of
Larman.
8
Making collaboration diagrams

• One diagram for each system operation in the
  current development cycle, e.g. for
  makepayment().

• If the diagram gets complex, split into smaller
  diagrams.

• Design a system of interacting objects to fulfill
  the tasks....this is the tough part of design!

9
Classes and Objects
10
Links
Sale
Post
Link illustrates client/server relationship.
11
Messages
12
Parameters
13
Return values
1 tottotal() int
14
Messages to self or this
msg1()
Post
1 clear()
15
Iteration
iteration, no recurrence values
16
Iteration with recurrence
msg1()
iteration clause
17
Iteration clause Multiple messages
msg1() for i 1 to 10 myB.msg2() myC.
meg3()
equal iteration clauses
18
Creation
new created instance
create message with optional parameter
for initialization. Note that use of the name
create is a UML convention.
19
Languages and create
C
Automatic allocation, or new() operator followed
by constructor call.
Java
new() operator followed by a constructor call.
20
Message sequence numbering
classA
classB
classC
21
Conditional message
Post
Sale
SalesLineItem
22
Mutually exclusive conditional messages
23
Collections
24
Messages to Multiobjects

25
Messages to multiobjects and an element 1
26
Design Guidelines

• OO system consists of interacting objects.

• How does one determine the assignment of
  responsibilities to various objects?

• There is no unique assignment and hence good
  and poor designs, beautiful and ugly
  designs, efficient and inefficient designs.

• Design guidelines assist in the derivation of a
  good design.

27
GRASP Patterns

• GRASP
• General Responsibility Assignment Software
  Patterns

• These are best considered as design guidelines
  and principles. These could also be considered as
  thought patterns useful in software design.

28
Guidelines and principles

• We first consider three useful guidelines

• Expert

• Creator

• Controller

and two widely applicable principles

• High cohesion
• Low coupling

29
POS Partial Domain Model
Contains
1
1
Used-by
1

1
Describes
1..

Stocks
Contained-in
1

1
Houses
1
Captured-on

Started-by
1
1
Paid-by
1
1
1
1
1
1
Initiated-by
Records-sale-on
1
1
30
Expert

• Question
• How does one assign responsibilities ?

• Answer
• Assign a responsibility to an information
  expert, i.e. to a class that has the information
  needed to fulfill that responsibility.

31
Expert Example 1
In POS, some class needs to know the grand total
of a sale. Who should be responsible for knowing
the grand total of a sale ?
32
Expert Example 2

• From the model, identify the class that contains
  the information needed to obtain the grand total.

• Information needed to obtain the grand total
• Knowledge of all SaleItems
• Sum of their subtotals

• Only a Sale object possesses this knowledge.

• Sale being the information expert, we assign this
  responsibility to Sale.

33
Partial collaboration diagram 1
Sale
34
Expert Example 3

• What information is needed to determine subtotal ?

• We need
• Quantity of each SalesLineItem and its price.
• Quantity is available with SalesLineItem and
  price with ProductSpecification.

• Hence SalesLineItem is assigned the
  responsibility to compute the subtotal.

35
Partial collaboration diagram 2
36
Summary Example 4
37
Expert Discussion

• Expert guideline used often.

• Fulfillment of a responsibility often requires
  interaction amongst several objects (3 in our
  example). There are many semi-experts who
  collaborate in performing a task.

• Use of the Expert guideline allows us to retain
  encapsulation of information.

• It often leads to lightweight classes
  collaborating to fulfill a responsibility.

38
Expert Disadvantages

• On some occasions the Expert guideline might not
  suggest a desirable solution.

• Example Who should save Sale in a database ?

• As all the information to be saved is in the Sale
  class, it should be responsible for saving the
  information.

• This implies that the Sale class must know about
  handling databases. Adding database related
  methods to sale class will make it in-cohesive.

• It also violates the separation of concerns
  principle.

39
Expert Benefits

• Objects use their own information to fulfill
  tasks, hence encapsulation is maintained.

• This leads to low coupling.

• Behavior is distributed across cohesive and
  lightweight classes.

40
Creator 1

• Question
• Who should be responsible for creating an
  instance of a class ?

• Answer
• Assign to B the responsibility to create an
  object of class A if the following is true

41
Creator 2

• B aggregates objects of type A.

• B contains objects of type A.

• B records instances of objects of type A.

• B closely uses objects of type A.

• B has the data passed to A when A is created.

Implication B is an expert in the creation of A.
42
Creator Example 1
Who should be responsible for creating a
SalesLineItem ?
43
Creator Example 2

• Sale contains many SalesLineItem objects.

• This implies that Sale is a good candidate for
  creating a SalesLineItem.

• This leads to the following collaboration diagram.

44
Sequence diagram for the creation of
SalesLineItem
45
Partial collaboration diagram
Sale
SalesLineItem
46
Creator Discussion

• Creator guides the assignment of responsibility
  of creating objects.

• Creator suggests that the enclosing container or
  aggregate class is a good candidate for the
  creation of the object contained.

47
Controller 1

• Question
• Who should be responsible for handling system
  events ?

Recall that a system event is a high level
event, an external event, generated by a system
actor.

• Answer
• Assign a responsibility to handle a system event
  to a controller.

48
Controller 2

• A controller is a non-user interface object that
  handles system events. Here is a list of
  controllers

Façade controller Represents the overall system,
device, or business.
Use case controller Represents an artificial
handler of all events of a use case.
49
Controller 3

• window, applet, view, document do not qualify as
  controllers. They typically receive system events
  and delegate them to a controller.

• System event examples

• Pressing the end of sale button.

• Request Spell Check.

• Request Engine Start.

50
System operations
System
endSale() enterItem() makePayment()
During system behavior analysis, system
operations are assigned to the class System. It
does not imply that the class named System
performs these during design. Instead, during
design, a controller class is assigned to
perform these operations.
51
Controller Example (1)
Which object should be responsible for handling
the enterItem() system event message ?
52
Controller Example 1
Represents the overall system
Represents overall business
Represents a real world actor
Represents an artificial handler
53
Controller Example 2
System operations discovered during analysis
Allocation of system operations during design
During design the system operations, identified
during analysis, are assigned to one or more of
controller classes.
54
Controller Discussion 1

• Controllers must be chosen to handle incoming
  events.

• Use the same controller class for events of one
  use case. This allows maintenance of the state of
  a use case.

• Do not assign too much responsibility to a
  controller. A controller should delegate to other
  objects work that needs to be done while
  coordinating an activity.

55
Controller Discussion 2

• Façade controllers are suitable when there are
  only a few system events.

• They are also useful when it is not possible to
  redirect system events to other controllers as,
  for example, in a message processing system.

• Selecting a use case controller leads to a
  different controller for each use case. This
  controller is not a domain object. For example,
  for Buy items use case one might construct a
  BuyItemsHandler class.

56
Controller Discussion 3

• When an existing controller becomes too large,
  one may choose a use case controller. This will
  likely help in maintaining low coupling and high
  cohesion.

• Corollary External interfacing objects should
  not have the responsibility for handling system
  events. Instead, these should be handled in the
  domain layer objects as opposed to being handled
  in application layer objects.

57
Bloated controller

• Signs of a bloated controller

• There is only one controller receiving all system
  events.

• The controller performs all tasks itself without
  delegating any task to other objects.

• A controller has many attributes and maintains
  significant information about the domain.

• A controller duplicates information found in
  other objects.

58
Avoiding bloated controller

• Add more controllers. If necessary, use
  role-controllers and use-case controllers.

• An airline reservation system may contain the
  following controllers

59
Presentation (Interface) Layer 1

• Avoid using presentation layer to handle system
  events.

• Use of domain layer objects to handle system
  events is preferred.

• Example
• Assume that POS application has a window that
  displays sale information and captures cashiers
  operations. Suppose that a Java applet displays
  the window. Let us see how the presentation and
  domain layers can be coupled.

60
Sample GUI for Point of Sale Terminal
_
x
61
Sample course of events
62
Sample course of events(2)
Actor
System
63
Presentation layer 2
SaleJFrame
Sale
POST
64
Presentation layer 3

• SaleJFrame passes on the enterItem() message to
  the domain layer.

• It does not get involved in the processing of
  this message.

• Thus, business processing logic is in a domain
  object, not in the presentation object.

• Presentation layer objects have lower opportunity
  for re-use due to their coupling with the
  environment.

65
Presentation layer undesirable coupling 4
Business logic embedded in presentation layer.
SaleJFrame
Presentation layer
Domain layer
66
Presentation layer 5

• Some applications do not have a user interface.
  They receive messages from an external system.
  For example, LDAP (Light Weight Directory
  Protocol) might receive a message from a CGI
  script.

• In these cases the messages is encoded in a
  stream or as a CORBA message.

67
Presentation layer 6

• In applications with windows, the window might
  choose who the controller will be.

• Different windows may collaborate with different
  controllers.

• However, in a message handling application, the
  Command design pattern is useful.

68
Low coupling

• How to achieve low dependency and increased
  reuse?

• A class with high coupling is undesirable because

• Changes in related classes force local changes.

• This class is harder to understand in isolation.

• This class is harder to reuse because its use
  requires the inclusion of all classes it is
  dependent upon.

69
Low coupling Example (1)
Consider the following partial conceptual model
What class should be responsible for creating an
instance of Payment ?
70
Low coupling Example 1
One solution is to let POST create an instance of
Payment and pass a reference this Payment to
Sale. This solution is suggested as POST records
a Payment.
71
Low coupling Example 3
Another solution is to let Sale create
an instance of Payment.
Which of the two solutions is preferable from
the point of view of coupling?
72
Low coupling Discussion 1

• Encourages assigning a responsibility to keep
  coupling low.

• Supports design of relatively independent, hence
  more reusable, classes.

• Reusable classes have a positive effect on
  productivity, i.e. may lead to higher
  productivity.

• However, the quest for low coupling to achieve
  reusability in a future (mythical!) project may
  lead to increased project cost.

73
Low coupling Discussion 2

• It is important for the designer to assess the
  current level of coupling and attempt to reduce
  it if it is likely to cause problems.

• It is important to note that a moderate degree of
  coupling between classes is normal. After all an
  OO application is a collection of communicating
  objects!

74
High cohesion

• Question
• How to keep design complexity manageable.

• Answer
• Assign responsibilities while maintaining high
  cohesion.

75
High cohesion Example 1

• Creation of a Payment can be assigned to POST as
  it records a payment in real world. This is
  suggested by the guidelines associated with
  Creator.

• This is acceptable. However, if this logic is
  applied in several other similar situations, more
  and more work is likely to be assigned to one
  class.

• This might lead to an in-cohesive class.

76
High cohesion Example 2

• For example, if there are 50 system operations,
  and POST does some work related to each, the POST
  will be a large incohesive class.

• In contrast, a design that lets Sale create
  Payment, supports higher cohesion in POST.

• This design supports both high cohesion and low
  coupling and hence is preferred over the first
  one.

77
Interaction diagrams and system events

• We now consider two use cases and their
  associated events

• Buy items
• enterItem
• endSale
• makePayment

• Start up
• startUp

• For each system event we create a collaboration
  diagram whose starting message is the system
  event message. What should be our controller
  class?

78
Choosing the controller class

• Choices
• POST or a new class such as RetailSystem
  represents the entire system.
• Store represents the business.
• Cashier represents a real-world entity.
• BuyItemsHandler represents an artificial
  handler.
• We select POST as there are only a few system
  operations.

79
Choosing the controller class

• 1. Choices

POST or a new class such as RetailSystem
represents the entire system.
Store represents the business.
Cashier represents a real-world entity.
BuyItemsHandler represents an artificial handler.
2. We select POST as there are only a few system
operations.
80
System events
We select the POST class to handle system events.
81
Interaction diagrams and contracts

• For each contract work through the
  responsibilities and post-conditions, and design
  message interactions.

• Example
• The enterItem() system operation requires a Sale
  to be created in its contract.

• A collaboration diagram that satisfies this state
  change

82
Partial collaboration diagram enterItem()
POST
Sale
Post-condition If a new sale, Sale was created
(instance creation).
83
On the value of post-conditions

• Post-conditions are only an initial estimate of
  what must be achieved.

• Thus, treat contracts as a starting point for
  determining what must be done.

• New post-conditions might arise during design and
  old ones might be found redundant.

• Recall...we are encouraging iterative development!

84
Collaboration diagrams and the conceptual model

• Some objects in collaboration diagrams are drawn
  from the conceptual model.

• Responsibility assignment depends to some extent
  upon information in the conceptual model.

• New concepts might be discovered during design
  and previously identified concepts might be
  ignored.

85
Collaboration diagram enterItem (1)

• Name enterItem
• (upc number, quantity int)
• Responsibilities Enter sale of an item and
• add it to the sale. Display the item
  description and price.
• Type System
• Cross reference Use cases Buy items
• Exceptions If the UPC is not valid, indicate
  that it was an error.

86
Collaboration diagram enterItem (2)

• Pre-condition UPC is known to the system.

Post-conditions

• If a new sale, a Sale was created (instance
  creation)

• If a new sale, Sale was associated with the POST
  (association formed).

• SalesLineItem.quantity was set to quantity
  (attribute modification).

• The SalesLineItem was associated with
  ProductSpecification based on UPC match
  (association formed).

87
Collaboration diagram (1)
enterItem(upc,quantity)
POST
Collaboration diagram begins by some object
sending an enterItem() message to an instance of
POST.
88
Making a new Sale

• Contract post-conditions related to new Sale
• If a new Sale, a Sale was created (instance
  creation).
• If a new sale, the new Sale was associated with
  the POST (association formed).
• POST can be considered as one that records Thus,
  POST is a reasonable choice as a creator of Sale.
  POST will then also have a reference to this
  instance of Sale.
• A container SalesLineItem must be created by Sale.

89
Collaboration diagram
enterItem(upc,quantity)
1 new sale create()
POST
Sale
1.1 create()
by controller
by creator
an empty collection that will eventually
hold instances of SalesLineItem
Display of the item description and its price is
ignored for now.
90
Creating a new SalesLineItem (1)

• More enterItem contract post-conditions
• A SalesLineItem was created (instance creation).
• The SalesLineItem was associated with the Sale
  (association formed).
• SalesLineItem.quantity was set to quantity
  (attribute modification)
• The SalesLineItem was associated with a
  ProductSpecification (association formed).

91
Creating a new SalesLineItem (2)

• Sale contains SalesLineItem objects. Hence Sale
  should create SalesLineItem.
• SalesLineItem can be associated with Sale by
  string it in the container of line items.
• POST must pass the quantity to Sale with the
  create message.
• A makeLineItem message is sent to Sale for it to
  create a SalesLineItem.

92
Finding a product specification

• It is necessary to retrieve ProductSpecification
  based on the UPC of a SalesLineItem.
• Question
• Who should have the responsibility for knowing a
  ProductSpecification ?
• Expert guidelines suggest that ProductCatalog is
  a good candidate for this responsibility.

93
Visibility to a ProductCatalog

• Who should send the specification message to the
  ProductCatalog to ask for a ProductSpecification
  ?
• We assume that POST and ProductCatalog were
  instantiated during the StartUp use case and that
  the are connected permanently.
• Thus we let POST send the specification message
  to ProductCatalog.
• Note that POST knows how to get to
  ProductCatalog. We say that POST has visibility
  to ProductCatalog.

94
The enterItem() collaboration diagram
1 new sale create()
enterItem(upc,qty)
3 makeLineItem(spec,qty)
POST
Sale
2 specspecification(upc)
1.1 create()
3.1 create(spec,qty)
Product Catalog
by expert
3.2 add(s))
2.1 specfind(upc)
slSalesLineItem
95
Collaboration diagram endSale (1)

• Name endSale()
• Responsibilities Record the end of sale and
• display sale total.
• Type System
• Cross reference Use cases Buy items
• Exceptions If a sale is not underway,
  indicate that it was an error.

96
Collaboration diagram endSale (2)

• Pre-condition UPC is known to the system.
• Post-conditions
• Sale.isComplete was set to true (attribute
  modification).

97
Choosing the controller class

• Who should be responsible for receiving the
  endSale message?
• We continue to use POST as the controller.

98
Setting the Sale.isComplete

• Who should be responsible for ensuring the
  post-condition?
• As Sale knows and maintains the isComplete
  attribute, it should have the responsibility of
  setting isComplete.

99
Collaboration diagram endSale()
endSale()
1 saleComplete()
POST
Sale
by controller
by expert
100
Display of information

• One responsibility in the endSale contract is
  that the sale total must be displayed.
• Do not use the domain layer objects to
  communicate with windows or presentation layer
  objects.
• Use the Observer pattern.
• Note that Sale must know the total before it can
  be displayed!!

101
Computing the sale total-Review

• Who should be responsible form computing the sale
  total? ObviouslySale as it is the expert !
• What information is required to compute the total
  ?
• Sub-totals of all SalesLineItem.
• Who should be responsible for computing the
  sub-totals? ObviouslySalesLineItem as it is the
  expert in this case.
• Who has the price for each SalesLineItem?ProductS
  pecification. Hence SalesLineItem must
  communicate with ProductSpecification to obtain
  the price.

102
The Sale total collaboration diagram
by expert
tottotal()
2 stsubtotal()
Sale
sliSalesLineItem
1 for each slinext())
by expert
2.1 prprice()
Sale--total() total0 for each
SalesLineItem.sli tottotsli.subtotal() return
tot
prodSpec Product specification
103
Collaboration diagram makePayment (1)

• Name makePayment(amountfloat)
• Responsibilities Record the payment, compute
  balance, and print a receipt.
• Type System
• Cross reference Use cases Buy items
• Exceptions If a sale is not complete,
  indicate an error.

104
Collaboration diagram makePayment (2)

• Pre-condition None.
• Post-conditions
• A Payment was created (instance creation)
• Payment.tendered is set to amount (attribute
  modification).
• The Payment was associated with the Sale
  (relationship formed).
• The Sale was associated with the Store to add it
  to the historical log of completed sales
  (relationship formed).

105
Choosing the controller class

• Who should be responsible for receiving the
  endSale message?
• We continue to use POST as the controller.

106
Creating Payment

• Who should be responsible for creating an
  instance of Payment ?
• There are two candidates
• POST
• Sale
• Selecting Sale lightens the workload of Payment.
• Also POST does not need to know about
  Payment which leads to lower coupling in POST.

107
The makePayment collaboration diagram
by Creator, low coupling
makePayment(cashTendered)
1 makePayment(cashTendered)
POST
Sale
1.1create(cashTendered)
by controller
Payment
108
Balance computation collaboration diagram
We have ignored the display of balance.
balbalance()
1 amtamount()
Sale
Payment
Sale is responsible for knowing the balance. It
needs visibility into Payment to ask for cash
tendered. As Sale created Payment it has
visibility into it.
2 ttotal()
109
Logging the Sale (1)

• Who should be responsible for knowing all the
  logged sales and doing the logging ?
• There are two candidates
• Store
• SalesLedger (new idea from basic accounting!)
• As the design grows Store will become incohesive,
  hence SalesLedger seems to be a good idea.

110
Logging the Sale (2)

• Consider the following post-condition
• The Sale was associated with the Store to add it
  to the historical log of completed sales.
• This post-condition needs to change if we decide
  to use SalesLedger to log the sale.
• If we decide to use SalesLedger than contracts
  need to be altered to avoid design divergence.

111
The logging collaboration diagram
makePayment(cashTendered)
1 makePayment(cashTendered)
POST
sSale
2addSale(s)
1.1create(cashTendered)
by expert
Store
Payment
2.1add(s)
112
Collaboration diagram startUp() (1)

• Most systems have a StartUp() use case.
• It is recommended that the collaboration diagram
  for startUp be taken up towards the end.
• startUp() operation is often dependent on the
  programming language and the operating system
  used.
• A common approach is to create an initial domain
  object.

113
Collaboration diagram startUp() (2)

• In the initialization method of this initial
  object, create other problem domain objects.

public class POSTApplet extends Applet
public void init () post
store.getPOST() private Store store new
Store() private POST post private Sale sale
Here, Store is the initial domain object. It
creates other domain objects.
114
Collaboration diagram startUp() (3)

• Name startUp()
• Responsibilities Initialize the system
• Type System
• Post-conditions
• Store, POST, ProductCatalog, and
  ProductSpecifications created (instance
  creation).
• ProductCatalog associated with ProductSpecificatio
  ns

115
Collaboration diagram startUp() (4)

• Post-conditions
• Store, POST, ProductCatalog, and
  ProductSpecifications created (instance
  creation).
• ProductCatalog associated with ProductSpecificatio
  ns
• Store associated with POST (association formed).
• POST associated with ProductCatalog (association
  formed).

116
StartUp collaboration diagram (5)
Reference to the product catalog passed to POST.
create()
2 create(pc)
Store
POST
1.1 create()
1create()
1.2.2 add(ps)
by creator
pcProductCatalog
1.2.1 create(upc,price,description)
psproductSpecification
1.1 loadProdSpec
117
Connecting presentation and domain layers(1)
1 create()
2 pgetPOST()POST
create()
POSTApplet
store Store
First the applet creates an instance of Store.
Store in turn creates an instance of POST. Then
the applet requests Store for a reference to the
POST instance.The applet can now send messages
directly to POST as in the next diagram.
118
Connecting Presentation layer to the domain layer
(2)
Object Store
Cashier
UPC
Quantity
Cash
Cash
Balance
Presses button
onEnterItem()
Presentation layer
PostApplet
1enterItem(upc,qty)
Domain layer
POST
119
Connecting Presentation layer to the domain layer
(3)
Object Store
Cashier
UPC
Quantity
Cash
Cash
Balance
Presses button
onEnterItem()
3 ttotal() float
Presentation layer
PostApplet
1enterItem(upc,qty)
2 no sale salegetSale()Sale
Domain layer
postPOST
saleSale
120
Class notation
A class diagram exhibits classes and
their associations used in an application.
Contrast this with a conceptual model which
shows domain concepts and their associations.
A class
121
CRC cards

• CRC Class-responsibility-collaboration cards
• Instead of using diagrams to show class
  responsibilities and collaboration, CRC cards are
  suggested.
• These are index cards and one for each class.
• In a team, each person plays the role of one or
  more classes and holds the corresponding card(s).
• Helpful in group design efforts.

122
CRC cards
class name
Responsibility
Collaboration
Order
Order line item
Check if item in stock
Order line item
Determine price
Customer
Check for valid payment
Database interface
Dispatch to delivery address
123
Summary

• What did we learn?

• Design process (in part)

• Collaboration diagrams (notation)

• Design principles and guidelines

• Creation of collaboration diagrams using design
  principles and guidelines
