Title: Web Engineering


1
Web Engineering
  • Geert-Jan Houben

2
Contents
  • Web Information System (WIS)
  • Evolution in WIS
  • WIS Engineering

3
Web Information System (WIS)
4
Information system
  • Exchanges information with Object System (
    business process)
  • Stores and manages information data-intensive
  • Requires careful engineering of information
    exchange
  • Requires careful engineering and modeling of
    object system
  • Traditionally database-oriented

5
Web Information System
  • Information System based on Web technology
    (Web-based, Web-aware, Web-enabled etc.)
  • Web technology can be used as front-end, e.g.
    application is available on the Web (or Intranet)
    via a browser
  • Enables easy use and maintenance of
    (personalized) end-user access
  • Web metaphor is appealing for end-users
  • Requires different techniques for engineering the
    systems interfaces

6
Web Information System
  • Web technology can also be used in back-end of
    information system
  • Organize (connect) the data inside the system
    using Web technology
  • Use World Wide Web as provider of data (or
    Intranet)
  • Typically highly volatile information
    (distributed and heterogeneous)
  • Requires different techniques for engineering the
    implementation

7
Examples
  • Real-estate sales
  • Employee databases
  • Museum databases
  • Digital libraries
  • Mail order catalogs
  • Reservation systems
  • Auctions, virtual marketplaces
  • EPG (Electronic TV Program Guide)
  • Ref Special section on Web Information Systems
    in Communications of the ACM, July 1998, Vol. 41,
    No. 7

8
Research
  • In WIS how to (automatically) generate hypermedia
    access to the information?
  • Hypermedia access navigation
  • Personalization, customization adaptation
  • Information integration (logistics of)
    information retrieval from available,
    heterogeneous sources
  • Interoperability for e-business, business rules,
    service integration
  • Querying and transforming (data and metadata)
  • Ref wwwis.win.tue.nl/hera

9
Evolution in WIS
10
Hypermedia
  • Hypertext multimedia
  • Information objects (text, images, animations,
    audio, video)
  • Not possible to show everything at once
  • Layout
  • Timing
  • Navigation
  • Design (generate) presentation for WWW, WAP,
    PDAs, etc.
  • W3C expects that majority of surfers will not be
    using a PC

11
Evolution in hypermedia
  • First standalone special-purpose systems
  • Now Web-based
  • From authoring to designing to generating
  • From static to dynamic (generated from database
    query result)
  • From single site to portals (integrated access
    service)
  • From read-only to interactive and often
    collaborative (read-write)

12
Three Generations of Web
  • HTML written by author
  • Easy, uniform interface
  • Large effort for maintenance
  • Not suited for changing information
  • Automatically generating information
  • First, using templates (and databases)
  • Later, using XML and XSLT transformations
  • Automatic processing of information
  • Explicit metadata (RDF)
  • Agreement on meaning (ontologies)

13
Future developments
  • Semantic Web research aims at even further
    developments in Web applications
  • From human-readable via machine-readable to
    machine-processable

14
Layer Cake
15
Web-based IS
  • Web-browser as front-end
  • Data repository (data base) as back-end
  • Design
  • Data (content) structures ER-modeling
  • Navigation
  • Presentation layout
  • Implementation
  • On-line (direct database access)
  • Off-line (generated from database)

16
WebML View
  • A Web-enabled software system whose main purpose
    is to publish and maintain large amounts of data
  • Interfaces directed to general public
  • exploratory
  • browsing-oriented
  • personalized (1 to 1)
  • Data stored by means of DBMS technology
  • Possibly pre-existing the Web application
  • Normally volatile
  • With severe freshness requirements
  • May be distributed and heterogeneous

17
OOHDM View (1)
  • Object-Oriented Hypermedia Design Method
  • WWW brought new generation of IS
  • navigation through heterogeneous information
    space
  • operations querying or affecting that information
  • Introduced hypertext (hypermedia) paradigm
  • Applications are constantly modified, enriched
    with new services, and new navigation and
    interface features are added

18
OOHDM View (2)
  • Web-based application, first good hypermedia
    applications
  • Traditional (SE) methodologies have no notion of
    linking little is said about incorporating
    hypertext into interface
  • Size and complexity imply systematic approach for
    evolution and reuse of design knowledge

19
RMMs View
  • History graphics designers programmers
  • Experience central information architecture and
    shared, common mechanisms/services helpful for
    coping with problems of scalability and
    information anarchy

20
Nielsens View
  • On the Web, the only constant is change. A site
    that works perfectly as long as its stays the
    same will quickly die.
  • Healthy navigation structure key to success
  • Building interface is also complex, connecting
    interface objects to rest of application

21
WIS Engineering
22
WIS Engineering Methodology
  • Design of WIS requires careful engineering of
    information exchange between IS and OS
  • Implies engineering of front-end (interface) and
    back-end (storage retrieval)
  • Professional applications from art to
    engineering
  • well-founded (software) engineering methodologies
  • model-driven

23
More engineering issues
  • Personalization (1-1)
  • Multiple output devices
  • Development and maintenance costs
  • e.g. documentation

24
Modeling
  • Presentation level
  • Network of Web pages
  • Storage level
  • HTML pages, report and scripts, graphics,
    animation
  • Logical level
  • E-R diagram (for storage)
  • Application diagram
  • (M-)slices (for presentation)

25
RMM
  • Relationship Management Methodology
  • Entity-Relationship modeling
  • Transformation from data model to datanavigation
    model
  • RMDM Relationship Management Data Model
    represents objects and navigational relationships
    (navigational design of application)
  • Design method for Web (hypermedia) applications
  • Ref RMM A Methodology for Structured Hypermedia
    Design, by Isakowitz, Stohr and Balasubramanian
    et al in Comm. ACM, Vol 38, No 8

26
RMM methodology
  • Requirements analysis
  • E-R diagram
  • Application diagram (top-down)
  • Slice design
  • Application diagram (bottom-up)
  • User interface design
  • Implementation

27
RMDM
  • (Application) domain model primitives
  • Entities
  • Attributes
  • Relationships
  • Slices from large objects (with many attributes)
    to smaller units (with coherent attributes,
    possibly from different objects)
  • From semantical aspect to navigational
    (presentation) aspect (w.r.t. complexity and size)

28
RMDM Schema
29
Hera motivation
  • Methodologies exist for manual hypermedia
    presentation design, Hera targets automated
    presentation
  • Automated presentation is important for databased
    content (the deep web) as opposed to manually
    crafted content (the surface web) most WIS are
    data driven
  • Presentations must be adaptable to different
    users/user platforms

30
Hera Methodology
  • Model-driven methodology, defines design phases
  • Conceptual Design that results in Conceptual
    Model (CM, describes data content used for
    generation of hypermedia presentations)
    construction
  • Application Design that results in Application
    Model (AM, describes the navigation structure and
    functionality) construction
  • Presentation Design that results in Presentation
    Model (PM, describes spatial layout and rendering
    of hypermedia presentations) construction

31
Hera Models
  • Fully specify dynamic hypermedia applications
    hence, there is no need of additional programming
  • Are used by a generic Hera engine for generation
    of hypermedia application pages (by on-demand
    instantiations of model subsets)

32
Conceptual Model
  • Provides a uniform semantic view over different
    data sources that are integrated within a given
    Web application.
  • Consists of hierarchies of concepts relevant
    within the given domain, their properties, and
    relations.

33
Conceptual Model
  • Defines the data content in terms of RDFS
    (concepts, attributes, properties)

34
Application Model
  • Navigation structure of a hypermedia application
    on top of CM
  • Hypermedia dynamics (navigation structure updates
    and application functionality) of a hypermedia
    application

35
Navigation Structure in Application Model
  • Navigation nodes (pages) specification in terms
    of slices (collections of concepts attributes to
    be displayed)
  • Node composition in terms of slice aggregation
    relationships
  • Navigation edges (hyperlinks) in terms of slice
    references

36
Slices
  • Meaningful collection of attributes of one or
    more related concepts
  • Represent a presentation page or its part

37
Dynamics in Application Model
  • User input specification in terms of Input Forms
  • Application context (state) specification in
    terms of Application Context Model
  • Context manipulation specification in terms of
    queries

38
Input Forms
  • Specify user data entries contain sets of input
    fields with
  • Input method (selection from offered items, text
    input, etc.)
  • How the offered items are created (for
    selections)
  • Determine data manipulation operation associated
    with a form (form processing)

39
Application Context Model
  • Extends CM with additional data structures needed
    for application functionality (to store
    application/navigation state, user inputs, user
    model, etc.)
  • Example storing the user selection (shopping
    basket)

40
AM Example
41
Data Manipulations
  • Update application context information
  • Defined as SeRQL queries
  • Used for processing forms (handle user input)
  • Q1 creates instances of SelectedPainting
    according to the SelectForm form content

CONSTRUCT PltrdftypegtacmSelectedPaintinggt
FROM PltrdftypegtcmPainting
ltcmanamegtPaname WHERE Paname IN SELECT
Faname FROM SFltformanamegtFaname,
SFltrdfIDgtFormName
WHERE FormName SelectForm
creates
42
Hera Architecture
  • Defines how the models are used for automatic
    generation of hypermedia presentation

43
Hera Implementation
  • HPG 2.0 (Hera Presentation Generator, dynamic
    version) implemented in Java as a servlet
  • Uses RDF API HP Jena for RDF data transformations
    based on RDFS models (CM, AM)
  • Can use XForms processor
  • Uses Sesame as main content repository and
    application context repository uses SeRQL/RQL as
    query languages
  • Set of graphical tools for designers for CM and
    AM based on Visio

44
Device Adaptation
45
OOHDM
  • Object-Oriented Hypermedia Design Method
  • Modeling/analysis, design, implementation,
    testing, and maintenance
  • Conceptual Design Navigation Design Abstract
    Interface Design Implementation
  • navigation objects are views of conceptual
    objects
  • abstractions to organize the navigation space,
    e.g. navigational contexts
  • separation of interface issues from navigation
    issues
  • some design decisions must only be made at
    implementation time

46
Other Methodologies
  • UWE UML-based Web Engineering
  • Conceptual, navigation, presentation model
  • Storyboarding and presentation flow
  • WSDM
  • Information modeling, functional modeling and
    navigation design
  • WebML Web Modeling Language
  • Structural model, derivation model (extend to
    adapt), hypertext model (composition and
    navigation), presentation model (XSL)
  • OO-H Object Oriented Hypermedia
  • Navigational access diagram, abstract
    presentation diagram

47
WIS Engineering and Adaptation
  • adaptation (and personalization) is a design
    aspect that gained much more attention, but still
    is lightly supported in methodologies
  • difficult to specify
  • not many tools
  • difficult combination with other aspects
  • examples My-portals, device-dependency

48
Adaptation Model
49
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
