A Generic Platform for ITA Related Applications

1
A Generic Platform forITA Related Applications

• Yan Luo, Ouri Wolfson, Bo Xu
• 02/11/2008

2
Outline

• Motivations and Objects
• Introductions and Related Projects
• Hybrid and Layered Architectures
• Data Models and Query Languages
• Case Studies and Future Plans

3
Motivations

• Why do we need this generic platform?
• Systematically develop ITA applications
• Easily apply IGERT research results
• Quickly compare different algorithms
• The purpose of this presentation
• Present our current research and existing results
• RFC request for comments (and suggestions)
• Complete the detailed design after the
  presentation

4
Objects

• Design and develop a generic platform for a
  variety of ITA related applications
• The platform provides a set of services for
  application designers with various interfaces
• The fundamental low-level primitives are
  transparent to application designers.
• To design and implement these services, data
  models, query languages, and related algorithms
  will be defined and proposed.

5
Introduction

• ITA and Related Applications
• Transportation safety and efficiency
• Mobile E-commerce
• Airport applications
• Social networks
• Emergency response
• What is a Platform?
• Think about the platform like an OS (Operating
  System)?
• But actually upon the traditional OS, e.g.,
  Windows CE and Linux
• Characteristics of the running environment for
  ITA
• Variety of communication channels with different
  trans ranges
• Variety of objects high mobility, low mobility,
  and even static
• Dynamic unstructured network topology for P2P
  communications
• Bandwidth, memory, even power constraints for
  different cases

6
Some Example Applications

• User 1 is requesting a ride-share via local
  wireless peer-to-peer communication
• User 2 is requesting a best route based on
  current conditions
• User 3 is notified of an ice patch ahead by the
  anti-lock brake sensor in another vehicle.
• User 4 receives a message from the parking meter,
  parks, and takes the train.

7
Related Projects

• CarTalk2000
• Developed a cooperative driver assistance system
  based on inter-vehicle communication and mobile
  peer-to-peer databases via self-organizing VANET.
• Grassroots and TrafficView
• Developed an environment in which each vehicle
  contributes a small piece of traffic information
  to the network via the P2P paradigm, and each
  vehicle aggregates pieces of the information into
  a useful picture of the local traffic
  information.
• FleetNet
• Developed a wireless multi-hop ad hoc network for
  inter-vehicle communication to improve driver's
  and passenger's safety and comfort.
• Proposed A data dissemination method called
  "contention-based forwarding" (CBF).
• VII (Vehicle Infrastructure Integration)
• Deploy advanced vehicle-to-vehicle (mobile
  peer-to-peer paradigm) and vehicle-to-infrastructu
  re communications that could keep vehicles from
  leaving the road and enhance their safe movement
  through intersections.
• TinyDB
• Focused on data-models and languages for sensors,
  but considers query processing in an environment
  of static peers.
• CarTel
• CarTel is a distributed, mobile sensor network
  and telemetric system. Applications built on top
  of this system can collect, process, deliver,
  analyze, and visualize data from sensors located
  on mobile units such as automobiles.

8
Different Views of Architecture

• Hybrid Communication Architectures
• Client-Server
• Hierarchical Servers (Region Server, Global
  Server)
• P2P (Peer-to-Peer) is an extension and
  supplement to Client-Server
• Wired and Wireless
• Static and Mobile
• Layered Architecture
• ---- Semantic View for easily
  understanding and application design
• Network layer
• Data exchange layer
• Database layer
• Service layer
• Application layer
• Component-based Architecture
• ---- Software Engineering View for
  implementation, testing, and integration
• Modules e.g., Communication, Localization,
  Database modules

9
?Application Layer ?Service Layer ?Database
Layer ?Data Exchange Layer ?Wireless Network
Layer
Upper Layers ? (accessible by application
designers) --------------------- Lower
Layers? (transparent to application
designers) Hybrid Communication Architectures ?
10
(No Transcript)
11
Service Abstraction and Interface

• We will abstract a set of services in the service
  layer and define various interfaces for
  application designers to easily access these
  services to build different ITA applications.
• Define the detailed interface for existing
  services.
• For example, "Get Vehicle Diagnostic Info", we
  define
• Input mode (snapshot, continuous, trigger),
  sensors, conditions
• Output values of sensors, alert (trigger mode)
• To get an alert when ABS engaged and outside temp
  is below 32 degrees, we can call the service
  with
• Input trigger, ABS_Sensor, Out_Temp_Sensor,
  ABS_Sensor.statusEngaged
  Out_Temp_Sensor.value lt 32
• Output an alert when the conditions are satisfied

12
Other Services Interfaces

• Get GPS Data
• Input mode (snapshot or continuous), frequency
  (if continuous)
• Output timestamp, latitude, longitude, speed,
  moving direction
• Map Mapping
• Input latitude, longitude, moving direction
• Output the most possible point on a road segment
  on a map
• Navigation
• Input origin, destination, mode (shortest,
  fastest, avoid HW, )
• Output a route from origin to destination based
  on mode
• A more complicated navigation is traffic
  condition based navigation

13
Other Services Interfaces

• Get Vehicle Density
• Input expected location, direction, time period,

• Output vehicle density, actual location,
  timestamp
• Get Traffic Information
• Input a road segment, direction, time period
• Output vehicle density, average travel time,
  other info
• Get Infrastructure Availability
• Input mode (snapshot query or trigger)
• Output infrastructure type, availability, alert
  (trigger mode)
• Broadcast Dissemination
• Input mode (once, repeat), report, location,
  direction, spatial limit, expiring time
• Output broadcast the report in the direction
  from the location within the spatial limit and
  before the expiring time

14
An Application Example Scenario

• Broadcast ABS alert to behind cars within 200
  yards
• Get ABS alert by using "Get Vehicle Diagnostic
  Info" service (trigger mode)
• When receiving ABS alert, get current location
  and moving direction by using "Get GPS Data"
  service (snapshot query mode) and "Map Mapping"
  service
• Generate the spatial-temporal ABS alert report
  (this service could be in the database layer
  since the designer may want to store the report
  into the database for future and other access)
• Broadcast the report to behind cars on the same
  road within 200 yards by using "Broadcast
  Dissemination" service in the data exchange layer

15
Another Application Example Scenario

• What is the average speed one mile ahead?
• Get current location and direction by using "Get
  GPS Data" and "Map Mapping" services (snapshot
  query mode)
• Generate the spatial-temporal query for the
  average speed one mile ahead by using "Query
  Wizard" service
• Try to process the query in the local database by
  using "Query Processing" service (if get the
  result, then exit)
• Get the nearby infrastructure access availability
  by using "Get Infrastructure Availability"
  service
• If the infrastructure is available, send the
  query to the central server for processing by
  using "Infrastructure Dissemination" service
• If the infrastructure is not available,
  disseminate the query to the location one mile
  ahead on the same road by using "Broadcast
  Dissemination" service
• When the result is received, pass the result to
  the application layer and display it to the user
  by the "Graphic User Interface" service

16
Data Dissemination in Data Exchange Layer
17
Database Layer

• Mobile P2P Communication is more effective and
  efficient when Infrastructures not available

• An Example of Mobile P2P Databases
• Local Distributed Databases
• Store-and-Forward
• Transitive Multi-Hop Transmissions

18
Database Layer

• Data Models
• Temporal Data Model
• Spatial Data Model
• Spatial-Temporal Data Model
• Query Languages
• STQL Spatial Temporal Query Language
• SQLST Spatial Temporal Extensions to SQL
• Other data models and query languages used in
  other projects (CarTel ICEDB)
• Although we have defined our own data models and
  query languages in the previous paper, it is
  better to use a standard existing one and augment
  it when necessary

19
Temporal Data Model

• Discrete time model
• Integers, reality is a sequence of snapshots
• Continuous time model
• Reals, use formula or equation to represent
  movings
• Temporal predicates (operators?)
• Overlap
• Precede
• Contain
• Equal
• Meet
• Intersect
• Duration

20
Spatial Data Model

• Spatial objects
• Point vehicle, person, or other no-area objects
• Line road, route, or path
• Region park, water, or other has-area objects
• Spatial predicates
• equal, disjoint, overlap, meet, contain,
  adjacent, common_border
• Spatial operators
• intersect, area, perimeter, distance

21
STQL

• A relation scheme R(A1 D1, , An Dn) where
  Ai are the attributes and the Di are their
  respective value domains. The domains can be
  standard types like integers, reals, booleans,
  strings, or more complex spatial data types like
  points, lines, regions, and graphs.
• A continuous time model, that is, time IR.
• A temporal function of type t(a) time ? a. For
  example, a point that changes its location over
  time is an element of type t(point) and is called
  a moving point. t(region) is a region that can
  move and/or grow/shrink, called a evolving
  region.
• Denote non-temporal types, entities, functions,
  and predicates by lower case letters while their
  temporal counterparts start with capital letters.

22
STQL

• Temporal Lifting non-temporal operation is
  lifted to work on temporal objects
• Distance ?distance t(point) t(region) ?
  t(real)
• Temporal lifting is also applicable to spatial
  predicates
• inside point region ? bool
• Inside ?inside Point Region ? Bool
• A Spatial-Temporal Predicate is a function of
  type t(a) t(ß) ? IB for a, ß ? point, region
• Instant Predicates equal, meet, covers,
  coveredBy.
• Period Predicates disjoint, overlap, inside,
  contains. Spatial-temporal predicates
  composition, written as "?". For examples
• Disjoint ? Meet
• Disjoint ? meet ? Inside

23
SQLST

• A point-based time model and a polygon-oriented
  spatial object model.
• SQLST views reality as a sequence of snapshots of
  objects that are moving and or changing in shape.
• Temporal operators overlap, precede, contain,
  equal, meet, intersect.
• Spatial objects point, line, region (which is
  represented as a set of directed triangles).
• Spatial predicates equal, disjoint, overlap,
  meet, contain, adjacent, common_border.
• Spatial operators intersect, area, perimeter,
  distance.

24
SQLST

• Spatial Predicates

25
SQLST

• Spatial Operators

26
Query Examples (STQL)

• Flight and weather conditions
• flights ( id string, Route Point )
• weather ( kind string, Extent Region )

27
Query Examples (STQL)
28
Query Examples (STQL)

• Forest fire control management
• forest ( forestname string, Territory Region
  )
• forest_fire ( firename string, Extent Region
  )
• fire_fighter ( fightername string, Location
  Point )

29
Query Examples (STQL)
30
Query Examples (SQLST)

• Forest Fire Control Management

31
Query Examples (SQLST)

• Forest Fire Control Management

32
Case Studies and Future Plans

• Apply SQLST and STQL to write our own query
  examples example (how to use their elements?)
• Vehicle Status and Movement Monitoring
• Traffic Condition Monitoring and Dynamic
  Navigation
• Public Transportation Monitoring and Scheduling
• Parking Lot Status Monitoring, Ride Sharing
  Management
• File (Photos/Videos/Coupons) Sharing and Exchange

33
Questions and Discussions

• Thank you
