Spyware and Trojan Horses

1
Spyware and Trojan Horses
2
Your computer could be watching your every move!
3
Introduction
4
Overview

• Introduction to Spyware / Trojan Horses
• Spyware Examples, Mechanics, Effects, Solutions
• Tracking Cookies Mechanics, Effects, Solutions
• Trojan Horses Mechanics, Effects, More Examples
• Solutions to the problems posed
• Human Factors Human interaction with Spyware
• Conclusions Including our proposals for
  solutions

5
Definitions

• A general term for a program that monitors your
  actions. While they are sometimes malicious, like
  a remote control program used by a hacker,
  software companies have been known to use Spyware
  to gather data about customers.

SPYWARE
Definition from BlackICE Internet Security
Systems - http//blackice.iss.net/glossary.php
TROJAN HORSE
An apparently useful and innocent program
containing additional hidden code which allows
the unauthorized collection, exploitation,
falsification, or destruction of data.
Definition from Texas State Library and
Archives Commission - http//www.tsl.state.tx.us/l
d/pubs/compsecurity/glossary.html
6
Symptoms

• Targeted Pop-ups
• Slow Connection
• Targeted E-Mail (Spam)
• Unauthorized Access
• Spam
• System Crash
• Program Customisation

SPYWARE
SPYWARE / TROJAN
SPYWARE
TROJAN HORSE
TROJAN HORSE
SPYWARE / TROJAN
SPYWARE
7
Summary of Effects

• Collection of data from your computer without
  consent
• Execution of code without consent
• Assignment of a unique code to identify you
• Collection of data pertaining to your habitual
  use
• Installation on your computer without your
  consent
• Inability to remove the software
• Performing other undesirable tasks without
  consent

8
Similarities / Differences
Source Table derived and produced by Andrew
Brown, Tim Cocks and Kumutha Swampillai, February
2004.
9
Spyware
Image Source The Gator Corporation
http//www.gator.com
10
Software Examples

• GAIN / Gator
• Gator E-Wallet
• Cydoor
• BonziBuddy
• MySearch Toolbar
• DownloadWare
• BrowserAid
• Dogpile Toolbar

Image Sources GAIN Logo The Gator Corporation
http//www.gator.com BonziBuddy Logo
Bonzi.com - http//images.bonzi.com/images/gorill
atalk.gif DownloadWare Logo DownloadWare -
http//www.downloadware.net
11
Advantages

• Precision Marketing
• Relevant pop-ups are better than all of them!
• You may get some useful adverts!
• Useful Software
• DivX Pro, IMesh, Winamp Pro
• (Experienced) people understand what they are
  installing.
• Enhanced Website Interaction
• Targeted banner adverts
• Website customisation

User Perspective - I
12
Disadvantages

• Browsing profiles created for users without
  consent
• Used for target marketing and statistical
  analysis
• Unable to remove Spyware programs or disable them
• Increased number of misleading / inappropriate
  pop-ups
• Invasion of user privacy (hidden from user)
• Often badly written programs corrupt user system
• Automatically provides unwanted helpful tools
• 20 million people have Spyware on their
  machines.
• Source - Dec 02 GartnerG2 Report

User Perspective - II
13
Example Pop-up
Misleading Pop-up
User Perspective - III
Image Source Browser Cleanser Directed pop-up
from http//www.browsercleanser.com/
14
Client-Side Operation
Technical Analysis - II
Image Source Image derived and produced by
Andrew Brown, Tim Cocks and Kumutha Swampillai,
February 2004.
15
GAIN Case Study

• Installed IMesh, which includes Gator
  Installation
• We accessed multiple internet sites
• We simultaneously analyzed network traffic (using
  IRIS)
• We found the packets of data being sent to GAIN
• Packets were encrypted and we could not decrypt
  them
• See Example -

16
Spyware Removers

• Ad-aware (by Lavasoft)
• Reverse Engineer Spyware
• Scans Memory, Registry and Hard Drive for
• Data Mining components
• Aggressive advertising components
• Tracking components
• Updates from Lavasoft
• Plug-ins available
• Extra file information
• Disable Windows Messenger Service

Image Source Screenshot of Ad-aware 6.0.
LavaSoft. See http//www.lavasoft.com
17
Vulnerable Systems

• Those with an internet connection!
• Microsoft Windows 9x/Me/NT/2000/XP
• Non - fire-walled systems
• Internet Explorer
• Other browsers not affected

18
Tracking Cookies
19
Cookies

• A Cookie is a small text file sent to the user
  from a website.
• Contains Website visited
• Provides client-side personalisation
• Supports easy Login
• Cookies are controlled by
• Websites Application Server
• Client-side Java Script
• The website is effectively able to remember the
  user and their activity on previous visits.
• Spyware companies working with websites are able
  to use this relatively innocent technology to
  deliver targeted REAL TIME marketing, based on
  cookies and profiles.

20
Case Study - DoubleClick

• Most regular web users will have a
  doubleclick.net cookie.
• Affiliated sites request the DoubleClick cookie
  on the users computer.
• The site then sends
• Who you are
• All other information in your cookie file
• In return for
• All available marketing information on you -
  collected from other affiliated sites which the
  you have hit.

21
Case Study DoubleClick

• Site targets banner adverts, e-mails and pop-ups
  to the user.
• If the user visits an affiliated site without a
  DoubleClick cookie, then one is sent to the user.
• The whole process is opaque to the user and
  occurs without their consent.

22
Trojan Horses
23
Installation

• Secretly installed when an infected executable is
  run
• Much like a virus
• Executables typically come from P2P networks or
  unscrupulous websites
• ActiveX controls on websites
• ActiveX allows automatic installation of software
  from websites
• User probably does not know what they are running
• Misleading descriptions often given
• Not sandboxed!
• Digital signatures used, signing not necessary

24
Installation

• Certificate Authority
• Misleading Certificate Description
• Who is trusted?

Image Source Screenshot of Microsoft Internet
Explorer 6 security warning, prior to the
installation of an ActiveX Control from Roings.
25
Effects

• Allows remote access
• To spy
• To disrupt
• To relay a malicious connection, so as to
  disguise the attackers location (spam, hacking)
• To access resources (i.e. bandwidth, files)
• To launch a DDoS attack

26
Operation

• Listen for connections
• Memory resident
• Start at boot-up
• Disguise presence
• Rootkits integrate with kernel
• Password Protected

27
Trojan Horse Examples

• M Rootkit
• Integrates with the NT kernel
• Very dangerous
• Virtually undetectable once installed
• Hides from administrator as well as user
• Private TCP/IP stack (LAN only)

28
Trojan Horse Examples

• iSpyNOW
• Commercial
• Web-based client
• Assassin Trojan
• Custom builds may be purchased
• These are not found by virus scanners
• Firewall circumvention technology

29
Trojan Horse Examples

• Hardware
• Key loggers
• More advanced?
• Magic Lantern
• FBI developed
• Legal grey area (until recently!)
• Split virus checking world

30
Demonstration
31
Vulnerable Systems

• Number of trojans in common use

DANGEROUS
RELATIVELY SAFE
MacOS
WinNT
Win 9x
MacOS X
Linux/Unix
WinNT refers to Windows NT 4, 2000, XP and Server
2003. Win9x refers to Windows 95, 95SE, 98 and
ME.Information Source McAfee Security -
http//us.mcafee.com/
Image Source Image derived and produced by
Andrew Brown, Tim Cocks and Kumutha Swampillai,
February 2004.
32
Vulnerable Systems

• Ease of compromise

DANGEROUS
RELATIVELY SAFE
Win 9x
WinNT
MacOS
MacOS X
Linux/Unix
WinNT refers to Windows NT 4, 2000, XP and Server
2003. Win9x refers to Windows 95, 95SE, 98 and
ME.Information Source McAfee Security -
http//us.mcafee.com/
Image Source Image derived and produced by
Andrew Brown, Tim Cocks and Kumutha Swampillai,
February 2004.
33
Conclusions
34
Security Implications

• Divulge personal data
• Backdoors into system
• System corruption
• Disruption / Irritation
• Aids identity theft
• Easy virus distribution
• Increased spam

Short Term
Long Term

• Mass data collection
• Consequences unknown
• Web becomes unusable
• Web cons outweigh pros
• Cost of preventions
• More development work

35
Solutions

• Firewall
• Virus Checker
• Spyware Remover
• Frequent OS updates
• Frequent back-up
• Learning problems

Short Term
Long Term

• Add Spyware to Anti-Virus
• Automatic maintenance
• Legislation
• Education on problems

36
Questions
Image Source Penny Arcade - http//www.penny-arc
ade.com/view.php3?date2002-07-19resl
37
Bibliography / Links

• 1 "Spyware" Definition - BlackICE Internet
  Security Systems - http//blackice.iss.net/glossar
  y.php
• 2 "Trojan Horse" Definition
• Texas State Library and Archives Commission -
  http//www.tsl.state.tx.us/ld/pubs/compsecurity/gl
  ossary.html
• 3 Zeinalipour-Yazti, D. Exploiting the
  Security Weaknesses of the Gnutella Protocol,
  University of California.
• 4 Joshi, R. Network Security Applications,
  Merchantile Communications, CANIT Conference
  2003.
• 5 CERT Advisory CA-1999-02 http//www.cert.org/
  advisories/CA-1999-02.html
• 6 Spyware Guide http//www.spyware-guide.com
• 7 Trojan Horses - http//www.mpsmits.com/highlig
  hts/trojan_horses.shtml
• 8 Trojan Horse - Back Orifice -
  http//www.nwinternet.com/pchelp/bo/bo.html
• 9 NetBus - http//www.nwinternet.com/pchelp/nb/
  netbus.htm
• 10 BBC News - http//news.bbc.co.uk/1/hi/technol
  ogy/3153229.stm
• 11 Wired News Judge takes bite out of Gator
  www.wired.com/news/politics/0,1283,53875,00.html
• 12 Tracking Cookies Demonstration at
  http//www.irt.org/instant/chapter10/tracker/index
  4.htm
• 13 BonziBuddy - http//www.bonzi.com/bonzibuddy/
  bonzibuddyfreehom.asp
• 14 Unwanted Links (Spyware)
  http//www.unwantedlinks.com
• 15 Andersen, R. "Security Engineering", First
  Edition, J. Wiley and Sons, 2001.
• 16 Scacchi, W. Privacy and Other Social
  Issues, Addison-Wesley, 2003.
• http//www.ics.uci.edu/wscacchi/Tech-EC/Security
  Privacy/Privacy.ppt
