Title: Realtime Videocompression based on 3DDCT


1
Real-time Videocompressionbased on 3D-DCT
2
Presentation Overview
  • Algorithm
  • Demo
  • Design
  • Functional Summary

3
Basics
  • decorrelation of subsequent frames(transform to
    frequency domain)
  • lossy compression

4
3D-DCT transformation
5
3D-DCT transformation
  • Different cube depths (1, 4, 8)
  • better compression ratio
  • latency
  • cross fading over scene cuts

6
Decorrelation of adjacent cubes
  • DC - Prediction
  • differential encoding of DC coefficient of
    adjacent cubes
  • especially efficient with strong quantization
  • no loss in quality
  • Differential - Prediction
  • uses a frame as a predictor for subsequent
    frames
  • improves compression ratio w/o increasing
    latency
  • involves loss in quality

7
Entropy reduction / Streaming
  • Quantization
  • goal remove information that is less important
    to the human visual system
  • suppress high frequencies
  • use YUV representation
  • Streaming
  • goal optimizing the stream for the subsequent
    source coding
  • read the cube in diagonal planes
  • rearrange Y-/U-/V-channels

8
Source Coding
  • Actual Compression
  • goal exploit special ordering and
    probability distribution of the data stream
  • Zero Run Length coding
  • Variable Length coding

9
Source Coding (VLC)
  • Symmetry ? code only absolute value
  • Limited range ? use prefix coding
  • Terminator code for word alignment

10
Image Quality
  • Factors
  • desired compression ratio (quantization)
  • type of sequence
  • static
  • morphologic
  • translatoric
  • Measurement
  • mathematical (PSNR)
  • subjective (human estimation)

11
Image Quality
  • Typical example for video conferencing
  • static background
  • morphologic motion

12
MPEG
3D-DCT
13
Image Quality
  • Typical example for a movie scene
  • motion blur
  • fast, translatoric motion
  • scene cuts

14
3D-DCT
MPEG
15
Design
16
Frontend
  • Video Frontend frame buffering

17
Frontend
  • Video modes
  • Interlaced
  • Up-/down-sampling
  • Video preprocessing
  • YUV conversion
  • Color offset correction
  • Differential Prediction

18
3D-DCT
  • 3D-DCT cube extraction

19
3D-DCT
  • Requirements
  • DCT/IDCT, Cubedepths 1,4,8
  • 72000 cubes/s (PAL)
  • 13800000 1D-DCT/s
  • Architecture
  • Parallel processing of the three color channels
  • 3D-DCT ? 364 1D-DCT ? Butterfly
  • controlled via ?Code-ROM

20
Post Processing
  • Stream unit continuos data flow

21
Stream processing
  • Streamer
  • Reordering of the cube in diagonal planes
  • Separation of the Y-channel from the
    U/V-channels
  • DC-Prediction
  • Quantization
  • Loadable 16 bit quantization table for each
    channel
  • ZRL-En/Decoder
  • Symmetrical run length representation

22
VLC
  • Requirements
  • limited range from -256 to 256 (sign symmetry)
  • maximum code length 22 bit
  • throughput 50 Mcodes/s
  • Encode with direct lookup
  • configurable memory table 256 ? 22 bit
  • three onchip ROMs 3 ? 0.057 mm2

23
VLC
  • Decode with direct lookup
  • configurable memory 22 bit address decoder (8
    MB)
  • three onchip ROMs 3 ? 0.084 mm2

A
0101011100100
101011100100
C
011100100
A
24
Functional Summary
  • Single chip Video-compression system

25
Outlook
  • Exploration of different quantizations (with
    respect to the human visual system)
  • Improvements with adaptive features for
  • quantization
  • cube depth
  • differential encoding
  • Exploration of QoS aspects
  • transmission over lossy channels
  • adaptive compression ratio

26
  • Physical Data
  • System clock 100 MHz
  • Video Interface 15 MHz
  • 70000 standard cells
  • 92 kbit memory
  • die area 22.6 mm2
  • process 0.35, 5-metal

Questions ??
