Waterproofing

1
Roof Garden
Waterproofing System
2
Roof Garden Todays Advantages

• Reduces urban heat island effects
• Storm water runoff management
• Adds valuable/useable space providing economic
  benefits
• Energy efficiency year-round
• Could earn LEED points

3
Roof Gardens
Kaiser Resources Vancouver, BC After
Before
Create high value, usable space
4
Roof Gardens
Rockefeller Center 1933
Enhances view from neighboring buildings
5
Roof Garden - Design Principles
For Effective Waterproofing Systems

• Select highly puncture resistant membrane
• Establish redundancy Splice overlayment
• Provide positive drainage at membrane level

6
Roof Garden - Design Principles

• Ensure proper system protection
• Incorporate drainage layer/root barrier
• Utilize Moisture Retention Mat (where applicable)

7
Roof Garden Assembly Types

• Ultra-Extensive/Shallow lt 4 deep
• Extensive/Medium 4 - 8 deep
• Intensive/Deep gt 8 deep

8
Shallow Assembly

• ? Growth Media
• Moisture Retention Mat
• Drainage Board
• Protection Fabric
• Membrane ( Adhered )
• ? Dens-Deck
• Approved Insulation
• ? Substrate

9
Ultra-Extensive/Shallow Assembly
Growth Media Sedum
10
Ultra-Extensive/Shallow Assembly
11
Medium Assembly

• ? Growth Media
• Moisture Retention Mat
• Drainage Board
• Root Barrier
• ? Protection Fabric
• ? Membrane ( Adhered )
• ? Dens-Deck
• ? Approved Insulation
• ? Substrate

12
Roof Garden Medium Assembly
13
Deep Assembly

• ? Growth Media
• ? Protection Fabric
• ? Drainage Gravel
• Protection Fabric
• Root Barrier
• Extruded Polystyrene
• ? Membrane ( Adhered )
• ? Dens-Deck
• ? Approved Insulation

14
Intensive Assembly/Deep
15
Protection/Drainage Components
In addition to the waterproofing material, other
components must be utilized to ensure proper
function

• Protection Fabric
• Drainage Boards
• Moisture Retention Mat
• Extruded Polystyrene Insulation
• Root Barrier

16
Planting Media

• Planting media should meet the following
  criteria
• Not include silt that can clog drainage fabric
• Provide permanent aeration
• Provide adequate drainage
• Supply or absorb water and nutrients
• Retain its original volume

17
Planting Media

• Planting Media Mix
• A mix suitable for most roof garden applications
  should be similar in content and percentage or
  composed of
• 45 graded sand ( with no fines )
• 45 expanded shale
• 10 humus ( pine bark )

18
Weights of Plant Media lbs/ft3
19
Roof Garden
Waterproofing System
