Offers Copper Bonded Earthing Electrode

1
Copper Bonded Earthing Electrode
2
Copper bonded earthing electrode is the best
solution for earthing. The most copper-coated
earth electrode is saved by the copper bonding
from corrosion and therefore the crystalline
mixture is filled within the electrode. With a
crystalline mixture, the annular space between
the inner conductor and therefore the external
conductor is filled.
3
Benefits of Copper Bonded Earthing Electrode

• CPRI Tested.
• 2. 100 microns coating on iron Electrode.
• 3. Cost Effective.
• 4. Less space requires at the time of
  Installation.
• 5. High Conduction on external Section.
• 6. No Maintenance.

4
Model Electrode Diameter (MM) Length(MM) Internal Strip Size (MM) Conductive mineral filled
SG2402503 CB 40 2000 25 X 03 Yes
SG2402504 CB 40 2000 25 X 04 Yes
SG3402504 CB 40 3000 25 X 04 Yes
SG2503004 CB 50 2000 30 X 04 Yes
SG3503004 CB 50 3000 30 X 04 Yes
SG2755006 CB 75 2000 50 X 06 Yes
SG3755006 CB 75 3000 50 X 06 Yes
5
