Lesson 5 Intrusion Detection Systems

1
Lesson 5Intrusion Detection Systems
2
Overview

• History
• Definitions
• Common Commercial IDS
• Specialized IDS

3
Why Even Bother?

• One of the problems with anomaly detection is
  that even the current best research systems have
  something like a 75 success rate.
• Marcus Ranum
• Network Flight Recorder

4
Intrusion Detection Defined

• The process of monitoring the events occuring in
  a computer system or network and analyzing them
  for signs of intrusions, defined as attempts to
  compromise the confidentiality, integrity,
  availability, or to bypass the security
  mechanisms of a computer or network.

5
General Thoughts about ID

• No Defense is Impenetrable
• Vulnerabilities exist to bypass system security
  precautions
• Automated tools exist to find and exploit
  vulnerabilities
• A methodology to detect and report suspicious
  host and network activity must be implemented
• IDS Goal to characterize attack manifestations
  to positively identify all true attacks without
  falsely identifying non-attacks
• ID is an instance of the general signal detection
  problem

6
Why use ID?

• Increase the perceived risk of discovery and
  punishment
• To detect attacks not prevented by other means
• Detect and deal with probing
• Document existing threats
• QC for security design and admin
• Forensics for improved security or prosecution

7
Goals of IDS

• Accountability - I can deal with security
  attacks that occur on my systems as long as I
  know who did it (and where to find them.)
• Response - I dont care who attacks my system as
  long as I can recognize that the attack is taking
  place and block it.

8
History of ID

• 1980 - John Andersons Computer Security Threat
  Monitoring and Surveillance
• 1987 - Dorothy Denning An Intrusion Detection
  Model
• Laid groundwork for commercial products
• First IDS, circa 1993 USAF ASIM

9
Generic Intrusion Detection Model
Activity Profile
Design New Profiles
Event Generator
Update Profile State
Create Anomaly Records
Rule Set/ Detection Engine
Define new modify existing rules
Audit trails, network packets application logs
CLOCK
10
Model Components

• Rule Set - inference engine decides whether an
  intrusion has occurred
• or
• Generic detector examing events and state data
  using models, rules, patterns and statistics to
  flag intrusive behavior

• Activity Profile -
• Maintains state of system or network being
  monitored
• Feedback critical
• No architectural limitations
• Rule base can learn if programmed

11
Haystack
Canonical Audit trail
9-track Tape
Preprocessor
Statistical Analysis
Z-248 PC
Audit Data
Reports
Unisys 1100
12
Intrusion Detection Expert System (IDES)
Receiver
Audit Records
Audit Data
Expert System
Active Data Collector
Active Data
Anomaly Data
Profile Updater
Anomaly Detector
Security Admin Interface
Profile Data
13
Multics Intrusion Detection and Alerting System
(MIDAS)
Command Monitor
Audit Records
Preprocessor
Network Interface
Multics
Fact Base
Statistical Data Base
System Security Monitor
Rule Base
Symbolics
14
Network Security Monitor (NSM)
Network Traffic
Packet Catcher
Filter
Object Detector analyzer
Report Generator
Traffic Archive
Network Profile which systems normally connect
to which others using what service. During a 2
month period, 110,000 connections analyzed at
UC-Davis, NSM correctly identified over 300
intrusions, only 1 had been detected by admins.
15
Distributed IDS (DIDS)
Unmonitored host
Monitored Host
Monitored Host
DIDS Director
Unmonitored host
LAN Monitor
Monitored Host
16
Cooperating Security Monitors (CSM)
Command Monitor
User Interface
Other CSMs
Local IDS
CSM
Intruder Handler
17
Current IDS Trends

• Immature
• Manpower intensive
• High false alarm rates
• Dynamic to the point of instability
• Quietly Evolving

18
Type of IDS

• Signature based system
• Attack description that can be matched to sense
  attack manifestations
• Anomaly based detectors
• equate unusual or abnormal as intrusions

19
IDS Classification

• Can base classification on what they sense
• Network based systems (NIDS)
• Sense packets on a network segment
• Easy to deploy, but they suffer throughout
  problems
• Host-based systems (HIDS)
• Inspect audit or log data
• Can affect performance on host
• Hybrids
• Combine the best of both

20
Intrusion Detection System--Network Based A
Layer in the Defense
Adversary
INTERNET
External ROUTER
FIREWALL
DMZ Server(s)
INTERNAL NETWORK
21
Network Based IDS

• Some detect intrusions after the bad guy is
  inside.but at least you know
• Others detect attacks (attack detect systems)
• Location in architecture determines which one you
  have
• Number of IDSes in architecture can add
  protetection
• Balance comes between being inundated with false
  alarms or alert conditions requiring action
• Ideal NIDs installation start buy adding as few
  sensors as possible

22
Host based IDS

• Setup a HIDs like a selective burglar alarm
• Deploy HIDs on critical servers devoid of
  interactive users
• Configuration optios
• Critical file modification
• When log files get smaller
• Process table grows larger than normal or too fast

23
What the different levels of IDS do

• Host-based Intrusion Detection
• Will catch users logged directly into a system
• Will miss network actions (the network as a
  whole)
• Network-based Intrusion Detection
• Will miss individual actions on the host the user
  is logged directly into.
• Will be able to see attacks on multiple hosts
  (door knob rattling).
• Where do you place the IDS? On the LAN or on the
  outside of the router (the connection to the
  Internet)?

24
Five Functional Areas of HIDS
Log/Event Monitoring
File Integrity Checking
Policy Compliance
Network Traffic Monitoring
System Monitoring
Ref Rasmussen, ISSA, Mar 02
25
And what about IDS and the PSTN?

• Two aspects
• Detection of intrusions into the IP network from
  the PSTN
• Detection of intrusions into the PSTN and its
  systems
• Do you
• Have a separate system, or
• Feed current IDS with data from the PSTN?

26
Strengths of IDSes

• Monitor and analysis of system events and user
  behaviors
• Testing security states of system configurations
• Recognizing known attack patterns
• Recognizing anomalies
• Measuring security policy enforcement
• Managing Data Flow

27
Weaknesses of IDSes

• Compensating for weak or missing security
  mechanisms
• Instantaneous detection, reporting, and attack
  response
• Detecting newly published attacks
• Compensating for info source fidelity
• Reducing manpower needs

28
IDS Adjusted Expectations

• Consider a building with motion detectors
• Works great when building is empty
• But if activated during day many false positives
• Building managers dont expect them to work
  during the day
• Its possible to set up network-based IDS (NIDS)
  and a host-based IDS (HIDS) to limit false
  positives

29
Monitoring and the Law

• Issue is expectation of privacy does the
  individual have one?
• You generally need to inform individuals using
  the system that their actions are subject to
  monitoring.
• Government systems have the warning banner.
• This advice also issued by CERT (CA-9219) for
  anybody wanting to monitor keystrokes.
• Note that it is considered not enough to notify
  all authorized users (when they are issued their
  initial password for example), it must be
  displayed each time at login.

30
IDS Fad

• People buy the hottest IDS tool that will be
  very good about telling them about DOS in the
  network, but is useless detecting problems inside
  the host.
• Matt Bishop, UC Davis

31
Summary

• Detection of Incidents
• Basic IDS Model-History
• IDS Types and Classification
