Lecture 1: Introduction

1
Lecture 1 Introduction
2
Why Parallel Programming

• Faster Computation
• Solve compute-intensive problems faster
• Make infeasible problems feasible
• Reduce Design Time
• Solve larger problems in same amount of time
• Improve answers precision
• Reduce Design Time

3
Definitions

• Parallel Computing Use of parallel computers to
  reduce the time needed to solve a single
  computational problem

• Parallel Computer A multi-processor computer
  system supporting parallel programming

• Multicomputer Parallel computer with multiple
  computers and
• interconnecting networks
• Centralized Multiprocessor (Symmetrical
  Multiprocessor SMP)
• All CPUs share access to a single global memory

• Parallel Programming Programming in a language
  that supports concurrency explicitly

4
Parallel Programming Libraries

• MPI (Message Passing Interface)
• Standard specification for message-passing
  libraries
• Libraries available on virtually all parallel
  computers
• Free libraries also available for networks of
  workstations or commodity clusters
• Open MP
• Application programming interface (API) for
  shared-memory systems
• Supports higher performance parallel programming
  of symmetrical multiprocessors
• Hybird MPI/OpenMP

5
Classical Science vs Modern Methods
Test car models Simulation of Earthquakes and
Volcanoes Protein Folding Climate Change
Nature
Observation
Physical Experimentation
Theory
6
Evolution of Supercomputers

• 1906 Lee De Forest Electronic Valve

• 1936 Z1 Konrad Zuse calculations for Henschel
  Aircraft Company

• 1943 Church Turing Thesis Alan Turing and Alonzo
  Church

"I think there is a world market for maybe five
computers.", Thomas Watson, chairman of IBM.

• 1944 Harvard Mark 1 Howard Aiken and Grace
  Hopper gunnery and ballistic calculations

• 1946 ENIAC I John Mauchly and J Presper Eckert
  used for writing artillery-firing tables

• 1947 First Transistor (William B. Shockley, John
  Bardeen and Walter H. Brattain), Magnetic Drum
  Storage

• 1949-52 EDVAC von Neumann First Magnetic Tape

"Computers in the future may weigh no more than
1.5 tons. Popular Mechanics

• 1950 Alan Turing Test of Machine Intelligence

• 1954 IBM 650 first mass-produced computers

"I have traveled the length and breadth of this
country and talked with the best people, and I
can assure you that data processing is a fad that
won't last out the year. The editor in charge of
business books for Prentice Hall.
7

• 1958 Jack Kilby and Robert Noyce Integrated
  Circuit

• 1965 CDC 6600 Seymour Cray (first
  supercomputer)

• 1970 Unix Dennis Ritchie and Kenneth Thompson

• 1971 First Microprocessor developed by Intel

• 1976 Crayl first commercially developed
  supercomputers Seymour Cray

"There is no reason anyone would want a computer
in their home." Ken Olson, Digital Equipment Corp.

• 1978 8086 by Intel, first PC First Video Game

• 1981 Cosmic Cube Charles Seitz and Geoffery Fox

• 1984 Macintosh Released

• 1985 Microsoft Windows released

• 1986 Connection Machine, Thinking Machine
  Corporation parallel processing introduced

8

• 1989 World Wide Web Tim Berners-Lee

""Windows NT addresses 2 Gigabytes of RAM which
is more than any application will ever need".
Microsoft

• 1994 Beowulf Thomas Sterling and Don Becker
  NASAs Goddard Space Flight Center

• 1997-2000 ASCI Red, ASCI Blue Pacific, ASCI
  White IBM

• 2002 Earth Simulator NASDA, JAERI, and JAMSTEC

• 2005 Blue Gene IBM, MHD, ITER(Nuclear Fusion)

9
60 Years of Speed Increases
One Billion Times Faster!
10
CPUs 1 Million Times Faster

• Moores Law(1965)--the number of transistors on
  an integrated circuit (computing power) doubles
  every 24 months
• Faster clock speeds
• Greater system concurrency
• Multiple functional units
• Concurrent instruction execution
• Speculative instruction execution

11
Systems 1 Billion Times Faster

• Processors are 1 million (106) times faster
• Combine thousands of processors
• Parallel computer
• Multiple processors
• Supports parallel programming
• Parallel computing Using a parallel computer to
  execute a program faster

12
Copy-cat Strategy

• Microprocessor
• 1 speed of supercomputer
• 0.1 cost of supercomputer
• Parallel computer 1000 microprocessors
• 10 x speed of supercomputer
• Same cost as supercomputer

13
Why Didnt Everybody Buy One?

• Supercomputer ? ? CPUs
• Computation rate ? throughput
• Inadequate I/O putation rate ? throughput
• Software
• Inadequate operating systems
• Inadequate programming environments

14
Beowulf Concept

• NASA (Sterling and Becker)
• Commodity processors
• Commodity interconnect
• Linux operating system
• Message Passing Interface (MPI) library
• High performance/ for certain applications

15
Concurrency Leads to Parallelism

• Identify concurrent operations
• Data dependency graphs
• Directed graph
• Vertices tasks
• Edges dependencies

16
Three Examples

• Find n!

• Divide the numbers into k processors
• Compute sequential products on elements in each
  processor
• Multiply the results from each processor

17
Three Examples

• Find the roots of ax2bxc0

1. v12a 2. v24a 3. v3bb
4. v4v2c
5. v5v3-v4
6. v6sqrt(v5)
7. v7v6-b 8. v8-v6-b

• 9. R1v7/v1
• 10. R2v8/v1

18
Three Examples

• Find 1! to n!

• For k2 to n
• Calculate (k-1)!
• Send output to next unit
• Multiply by k

19
Different Forms of Parallelism

• Data Parallelism
• Independent tasks apply same operation to
  different elements of a data set
• Functional Parallelism
• Independent tasks apply different operations to
  different data elements
• Pipelining
• Divide into several stages

20
Example Data Clustering

• Data mining looking for meaningful patterns in
  large data sets
• Data clustering organizing a data set into
  clusters of similar items
• Data clustering can speed retrieval of related
  items

21
Document Vectors
Moon
The Geology of Moon Rocks
The Story of Apollo 11
A Biography of Jules Verne
Alice in Wonderland
Rocket
22
Document Clustering
23
Data Clustering

• Input N documents
• For each N documents, generate a document vector
• Choose K initial clusters
• Repeat
• For each document find closest center and compute
  the performance function
• Adjust K clusters to improve value of
  performance function
• Output K centers

24
Data Dependence Graph
Input document 2
Input document N
Input document 1
Build document vector N
Build document vector 2
Build document vector 1
Choose cluster center 1
Output Clusters
Database
Choose cluster center 2
Choose cluster center K
Find closest center to vector N calculate
function
Find closest center to vector 1 calculate
function
Find closest center to vector 0 calculate
function
Adjust centers
25
Opportunities for Parallelism

• Data Parallelism
• Input Documents
• Generating document vectors
• Picking initial values of cluster centers
• Finding closest center to each vector
• Functional Parallelism
• Generating document vectors
• Picking initial values of the clusters

26
Programming Parallel Computers

• Extend compilers translate sequential programs
  into parallel programs
• Extend languages add parallel operations
• Add parallel language layer on top of sequential
  language
• Define totally new parallel language and compiler
  system

27
Extend Compilers

• Parallelizing compiler
• Detect parallelism in sequential program
• Produce parallel executable program
• Focus on making Fortran programs parallel

28
Extend Compilers

• Advantages

• Can leverage millions of lines of existing
  serial programs
• Saves time and labor
• Requires no retraining of programmers
• Sequential programming easier than parallel
  programming

• Disadvantages

• Parallelism may be irretrievably lost when
  programs written
• in sequential languages
• Performance of parallelizing compilers on broad
  range of
• applications still up in air

29
Extend Language

• Add functions to a sequential language
• Create and terminate processes
• Synchronize processes
• Allow processes to communicate
• Ways to distinguish between public data and
  private data

30
Extend Language

• Advantages

• Easiest, quickest, and least expensive
• Allows existing compiler technology to be
  leveraged
• New libraries can be ready soon after new
  parallel computers are
• available
• Flexibility for code development

• Disadvantages

• Lack of compiler support to catch errors
• Easy to write programs that are difficult to
  debug
• Extensions may not be sufficient to express all
  parallelism in the
• application
• Takes longer to compile

31
Add a Parallel Programming Layer

• Lower layer (Sequential Part)
• Core of computation
• Process manipulates its portion of data to
  produce its portion of result
• Upper layer (Parallel Part)
• Creation and synchronization of processes
• Partitioning of data among processes
• Compiler support for translating the two-layered
  program
• A few research prototypes have been built based
  on these principles

32
Create a Parallel Language

• Develop a parallel language from scratch
• Supports sequential and parallel execution
• Automatic communication and synchronization
• Add parallel constructs to an existing language
• Manipulation of multidimensional arrays
• Compiler directives to specify data mapping
• Examples Fortran 90, High Performance Fortran,
  C

33
New Parallel Languages

• Advantages

• Allows programmer to communicate parallelism to
  compiler
• Improves probability that executable will
  achieve high
• performance

• Disadvantages

• Requires development of new compilers
• New languages may not become standards
• Programmer resistance

34
Current Status

• Low-level approach is most popular
• Augment existing language with low-level parallel
  constructs
• MPI and OpenMP are examples
• Advantages of low-level approach
• Efficiency
• Portability
• Disadvantage More difficult to program and debug

35
