Parallel Computing using JavaSpaces

1
Parallel Computing using JavaSpaces

• -Presented by Shilpi Basak
• Advisor Prof Dick Steflik

2

• Traditionally, operating systems have been
  designed with the assumption that a computer will
  have a processor, some memory, and a disk.
  Nowadays trend in the hardware environment is
  from disk-centric to network-centric This will
  affect how we organize our software -- and that's
  where JINI comes in.
• Given the rising importance of the network and
  the proliferation of processors in devices, that
  are from many different vendors makes the
  network very dynamic -- devices and services will
  be added and removed regularly.

3

• JINI provides mechanisms to enable smooth adding,
  removal, and finding of devices and services on
  the network. In addition, JINI provides a
  programming model that makes it easier for
  programmers to get their devices talking to each
  other.
• JINI is a set of APIs and network protocols that
  can help you build and deploy distributed systems
  that are organized as federations of services

4

• Federation in JINI view is a network
• - Does not involve a central controlling
  authority
• - Group composed of equal peers.
• - JINI API and runtime infrastructure provides
  a way for clients and services to find each


  other
• - Once services locate each other, they are on
  their own.
• - Client and its enlisted services perform their
  task independently of the JINI runtime
  infrastructure.

5

• Document and object metaphor
• While we can have server side scripting that
  execute code depending upon client request, it
  assumes that the result are going to be viewed in
  context of a web page hence send it as HTML /XML
• While JINI doesnt assume anything as to how is
  it going to be delivered. It basically brings all
  the possibilities what we can do with standalone
  OO Java Programs to be done over the network in a
  distributed fashion.
• An object can perform services for clients
  because objects embody behavior. An object uses
  its state to decide how to behave when its
  methods are invoked.
• The key difference between a network-mobile
  object and a network-mobile document, therefore,
  is that when you send a document across a
  network, you're sending data, but when you send
  an object across the network, you're sending data
  plus code -- a combination that yields behavior.

6
Remote method Invocation (RMI)

• All the features of OO programming as compared to
  only limited programming capabilities as
  available for the document model.
• RMI transferring local computation to multiple
  machines by distributing objects
• RMI allows definition and implementation are
  separate, can run on separate JVM
• Used to invoke methods on remote objects that can
  be looked up in the RMI registry
• The service provider registers the remote object

7
Interface for the Service extends
java.rmi.Remote
Server Machine
Client Machine
OBJECT B implements interface IService
Object A STUB for the Remote Object B
RMI Layer managing connectivity between the stub
(proxy) and the remote object Transport layer
stack
8

• The objects that can be transferred across
  networks are remote objects that does
• - extends Remote interface
• - each method does declares java.rmi.RemoteExcept
  ion in its throws clause, in addition to any
  application-specific exceptions
• Compared to a normal object, when a remote object
  is passed a stub is created in the receiver, that
  acts as a proxy to the remote object and acts as
  remote ref. to the caller.
• Internally this local stub on which remote
  methods are invoked have a Remote Ref in the RMI
  layer that manages the whole network connection
  with the actual remote object
• Only the methods defined in the Remote interface
  are allowed to be called by the client via the
  stub. The remote object may also implement other
  interfaces that do not extend java.rmi.Remote,
  these would not be available to the client.

9

• RMI code

10

• Main Advantages of RMI
• - Dynamic class loading bytecode can be
  downloaded from a remote machine, meaning we can
  introduce new types in an existing system and
  make application extensible.
• - Separation of interface from implementation
  Clients program to remote interfaces, not to the
  implementation classes of those interfaces
• Limitations
• Need to coded in Java.
• Client needs to know the exact location and name
  of the service to locate them using the RMI
  registry.
• Does not offer much flexibility to configure
  using the policy files

11

• Steps in designing an RMI application
• Declare the remote interfaces being implemented
• Define the remote object, implementation for the
  remote methods as well as local methods
• The server needs to create and install the remote
  objects, load RMISecuritymanager and bind the
  remote object to the registry.
• Implement the client object, lookup for the
  remote object.

12

• When we pass remote objects as method parameters,
  they are passed by reference meaning a stub is
  passed and any changes made via method invocation
  are available at the original remote object.
• Local objects are passed by value( a copy is
  created in the receiving VM), all fields are
  serialized except one declared static or
  transient.
• The java.rmi.Naming interface is used as a
  front-end API for binding, or registering, and
  looking up remote objects in the registry. Once a
  remote object is registered with the RMI registry
  on the local host, callers on any host can look
  up the remote object by name, obtain its
  reference, and then invoke remote methods on the
  object.

13

• JINI
• Runtime infrastructure of Jini consists of
• - Lookup service (central organizing mechanism)
• Clients
• Services
• Communication between the three requires
  following
• - Discovery protocol (to locate a lookup service)
• Lookup (client lookups a service)
• Join (service registers itself with the lookup)

14

• Discovery process
• When a service connects to a network, it
  broadcasts a presence announcement by dropping a
  multicast packet onto a well-known port. Included
  in the presence announcement is an IP address and
  port number where the disk drive can be contacted
  by a lookup service.
• Lookup services monitor the well-known port for
  presence announcement packets. When a lookup
  service receives a presence announcement, it
  opens and inspects the packet.
• If it decides to contact the service , it makes a
  single dedicated connection to the service using
  the IP address and port from the muticast
  announcement packet

15

• Using RMI the lookup service sends an object,
  called a service registrar, across the network to
  the originator of the packet. The purpose of the
  service registrar object is to facilitate further
  communication with the lookup service.
• Using the Service registrar object, the service
  provider does a join to register itself with the
  JINI federation so that clients can then use its
  services.
• The Service Registrar object implements a set of
  interface that allow client and services to do
  joins and lookups

16
Figure 1 Querying for a service locator
Figure 2 Registrar returned
17
Figure 3 Service uploaded
Service object. Register() method
ServiceRegistration object returned from register
Service Proxy Object
18

• public class PrintServer implements
  DiscoveryListener
• public PrintServer()
• LookupDiscovery discover null
• discover.addDiscoveryListener(this)
• public void discovered(DiscoveryEvent evt)
• ServiceRegistrar registrar
  evt.getRegistrars()0 //discovered a lookup
  service
• // Create information about a service
• ServiceItem item new PrintService
  (null, new PrintService(), null)
• // Export a service
• ServiceRegistration reg
  registrar.register(item, Lease.FOREVER)


19

• Join
• To do a join the service provider
• - Invokes the register() method on the
  Service Registrar
• - Passes an object called a service item
  describe the service.
• - The register() method sends a copy of the
  service item up to the lookup service
• - The service item is stored. Once this has
  completed, the service provider has finished the
  join process
• - The service gets back the handle to the
  object the reference is maintained at the lookup
• ServiceRegistration register(ServiceItem ite
  m, long leaseDuration)

20

• Lookup
• To find a service, clients query lookup services
  via a process called lookup.
• The client needs to create a ServiceTemplate
  object that has the following fields
• public Entry attributeSetTemplates
• public ServiceID serviceID
• public Class serviceTypes
• The lookup() method on a service registrar
  object., returns an Object object that represents
  the service item.

21

•  ServiceMatches lookup (ServiceTemplate tmpl,
  int maxMatches)
• Returns at most maxMatches items matching
  the template, plus the total number of items that
  match the template
• The client
• - Passes a service template
• - The service template can include a
  reference to an array of Class objects. These
  Class objects indicate to the lookup service the
  Java type (or types) of the service object
  desired by the client.
• The service template can be an exact matching
  service ID
• The service template can also contain wildcards
  for any of these fields. A wildcard will match
  any service ID.
• The client gets a reference to the matching
  service objects as the return value of the
  lookup() method.

22

• public class PrintClient
• public PrintClient()
• LookupLocator lookup null
• ServiceRegistrar registrar null
• FileClassifier classifier null // Prepare
  for discovery
• lookup new LookupLocator(ltURLgt")
• //Discover a lookup service
• registrar lookup.getRegistrar()

• // Prepare a template for search
• ServiceTemplate template new
  ServiceTemplate(null, printserv , null)
• printservice (PrintService)
  registrar.lookup(template)
• // Call the service object methods
• printservice.method1()

23
Figure 6 Querying for a service locator
24
Figure 7 Registrar returned
25
Figure 9 Service returned
26

• In addition to the two lookup() methods, the
  ServiceRegistrar has three methods called
  browsing methods that let clients get information
  about registered service items. These three
  methods -- getServiceTypes(), getEntryClasses(),
  and getFieldValues()
• package net.jini.core.lookup
• public Class ServiceItem
• public ServiceID serviceID
• public java.lang.Object service
• public Entry attributeSets
• public ServiceItem(ServiceID serviceID,
• java.lang.Object service,
• Entry attrSets)

27

• Division of work
• The object can actually represent the entire
  service, which is downloaded to the client during
  lookup and then executed locally.
• Or the service object can serve merely as a proxy
  to a remote server. When the client invokes
  methods on the service object, it sends the
  requests across the network to the server, which
  does the real work.
• The local service object and a remote server can
  each do part of the work as well.
• As the client communicates with the servers
  proxy stub, the network protocol or the othre
  underlying implementation details of the service
  are hidden from the client, could be RMI, CORBA
  or DCOM
• Typically a Jini application should be designed
  with separation of UI from the functionality.
  This enables to use the service from clients that
  are not capable to display an UI as well as
  allows different UIs to be attached to one service

28
The client talks to the service through a
well-known interface
29

• Space Based programming
• Typically in distributed applications involves
  passing messages between processes and invoking
  methods on remote objects like in RPC, RMI.
• Space is like a shared memory that processes
  physically located on different machines can
  communicate with each other
• Dr. David Gelernter developed a tool called Linda
  for creating distributed applications. Linda
  consists of a small number of operations combined
  with a persistent store called a tuple space .
• While JavaSpaces inherited the space model from
  Linda, the designers of JavaSpaces have updated
  the model in significant ways, leveraging the
  power of Java objects, JINI, RMI, and object
  serialization.

30

• Space

Process B
Process A
Write
Read
Space containing Entry Objects
Read
Waiting
Take
Process C
Process D
31

• Properties of spaces
• Spaces are shared Multiple processes physically
  located on same or different machines can
  interact with a space concurrently with the sapce
  handling all the protocol of concurrent access
• Spaces are persistent Objects can be stored
  reliably in a space for a lease time or
  indefinitely until they are removed. Also lease
  time can be extended by renewing the lease
• Spaces are associative Objects in a space are
  retrieved located via associative lookup, meaning
  we can prepare a template of one /multiple fields
  representing the query and get result back. This
  allows a lot of advantages to query using simple
  expressions rather than remembering object Id or
  the name

32

• Spaces are transactionally secure JavaSpaces
  transactions have the inbuilt ACID properties.
  Every operation in the space is atomic.
  Transactions are supported for single operations
  on a single space, as well as multiple operations
  over one or more spaces.
• Spaces let you exchange executable content While
  in a space, objects are just passive data -- you
  can't modify them or invoke their methods.
  However, when you read or take an object from a
  space, a local copy of the object is created. As
  with any other local object, you can modify its
  public fields and invoke its methods, even if
  you've never seen an object like it before. This
  coupled with associative lookup offers advantages
  as compared to RMI.

33

• Javaspaces is a set of API that provides a
  special kind of service to a JINI federation. It
  can operate as part of a bigger JINI federation
  or be in a single federation on its own.
• Every object in the space is of type Entry
  which is a interface in net.jini.core.entry
  package
• For example, we have to write a Task object in
  space, its definition would be
• public class Task implements Entry
          public String content       // a
  no-arg constructor        public Task()

• Its a no-marker interface, all members of the
  class should be public as this lets to lookup
  objects in space using associative lookup, should
  have a no argument constructor to facilitate
  serialization to transfer objects in and out of
  space

34

• Conventions that our entries
• An entry must have a public constructor that
  takes no arguments
• Another convention is that fields of an entry
  should be declared public
• A third convention is that fields of an entry
  must contain references to objects, rather than
  primitive types

35

• API
• write Places one copy of an entry into a space.
  If called multiple times with the same entry,
  then multiple copies of the entry are written
  into the space.
• read Takes an entry that is used as a template
  and returns a copy of an object in the space that
  matches the template. If no matching objects are
  in the space, then read may wait a user-specified
  amount of time until a matching entry arrives in
  the space.
• take Works like read, except that the matching
  entry is removed from the space and returned as
  the result of the take.
• In addition, the JavaSpace interface supplies the
  following methods, which can be useful in many
  applications

36

• notify Takes a template and an object and asks
  the space to notify the object whenever entries
  that match the template are added to the space.
  This notification mechanism, which is built on
  Jini's distributed event model, is useful when
  you want to interact with a space using a
  reactive style of programming.
• snapshot Provides a method of minimizing the
  serialization that occurs whenever entries or
  templates are used you can use snapshot to
  optimize certain entry usage patterns in your
  applications. We will cover this method in detail
  in a later article.

37

• Project involved developing a computation server
  for carrying out parallel computation of
  computation intensive problems
• Task entry computes the Fourier transform of a
  given set of input numbers.
• Also made some other task entries like matrix
  multiplication of really huge matrices, or
  arithmetic functions of large numbers

38
(No Transcript)
39

• Application Design
• Uses Command pattern client publishes code or
  implementation for any particular task entry.
  Service picks up the task entry and executes code
  provided by clients
• Server need not have any knowledge of
  implementation details of task, just needs to
  have the computation capability
• Can easily be extended to include new tasks as
  and when required provided they adhere to some
  simple rules

40

• FTT of a given set of real numbers

41

• Examples of systems using Space Based
  programming
• Chat Systems A JS represents the chat room,
  objects within the space can represent buddy list
  members, messages or any other information needed
  to maintain the chat room
• Broker System
