Single Subject Design

1
Single Subject Design

• Psyc 3000
• John Stanton

2
Single subject design defined

• Objective 1 Be able to describe what a single
  subject research design is.
• Single subject research designs use one subject
  at a time to investigate the effects of a
  particular independent variable (treatment).
• Use multiple participants (replications) to
  increase external validity

3
Example of SSD
4
Characteristics of SSD

• Uses repeated measures
• Need reliable measurement/instrumentation
• Requires a clear description of conditions and
  the DV
• Measurement, IV and DV operationally defined
• 2 general types of phases (could have probes,
  etc.)
• Baseline and treatment conditions

5
Phases of SSD

• Objective 2 Be able to list and describe the 2
  phases of a SSD.
• 1. Baseline
• Period of no treatment (reflects natural state)
• Provide standard for evaluating the effect of IV
  and to determine if extraneous variables are
  operating (i.e. the control condition)

6
Phases of SSD

• 2. Treatment
• Introduction of the IV
• Phase length should be approximately as long as
  baseline (for comparison purposes)
• Repeated measurement of the DV continues

7
General rules for SSD

• Objective3 Know the general rules when using
  single subject designs
• Shouldnt change baseline until
• Little variability
• No trends
• Unless the trend is in the opposite direction of
  expected effect
• Only change one variable at a time

8
General rules for SSD

• Length of phase (suggestions)
• Keep all the same length
• Controls for maturation
• To reduce carry over effects use shorter phases
  (treatment)
• Extend phases to include cyclic subject variables
• i.e. menstrual cycle, daily issues

9
Types of SSD

• Reversal design
• Alternating treatments design
• Multiple baseline design
• Changing criterion design

10
Reversal design

• Objective 4 Know the critical features for the
  reversal design.
• Critical features
• At least 2 conditions
• Baseline
• Treatment
• Same condition present for consecutive sessions
• Conditions dont alternate rapidly
• Types
• AB
• ABA
• ABAB

11
AB

• 1 baseline and 1 treatment phase
• Ex. Kid having trouble working on school work
  (i.e. staying on task), the treatment is setting
  up a reinforcement contingency that gives him a
  dollar for every minute he stays on task

12
AB
A
B
13
AB

• Problems
• Limited control over threats to internal validity
• No control for extraneous variables - that is
  changes in the DV could be caused by numerous
  things

14
ABA

• Baseline (A) Treatment (B) Baseline (A)
  (withdrawal)
• The withdrawal strengthens the relationship
  between the IV and DV
• Ex. Kid having trouble working on school work
  (i.e. staying on task), the treatment is setting
  up a reinforcement contingency that gives him a
  dollar for every minute he stays on task

15
ABA
A
B
A
16
ABA

• Problems
• Doesnt completely control for extraneous
  variables (but more evidence!)
• Irreversibility
• Some IVs cant be withdrawn
• Some behaviors cant be reversed
• Ethical and legal issues
• Sequence effects

17
ABAB

• Baseline Treatment Baseline Treatment
• Increases the confidence in the treatment effect
• Better controls for extraneous variables
• Ex. Kid having trouble working on school work
  (i.e. staying on task), the treatment is setting
  up a reinforcement contingency that gives him a
  dollar for every minute he stays on task

18
ABAB
A
B
A
B
19
ABAB

• Problems
• Irreversibility (same as in ABA)
• Sequence effects

20
Alternating treatments

• Objective5 Know the critical features of the
  alternating treatments design.
• Critical features
• 2 or more treatments presented
• Treatment phases are rapidly alternated
• In a pseudo random fashion
• Generally a baseline phase (not required)

21
Alternating treatments
22
Alternating treatments

• Advantages
• No treatment withdrawal
• Faster comparison of treatments
• Variable data is okay
• Problems
• Artificiality
• Interference between treatment phases
• Treatments must sufficiently differ

23
Multiple baseline design

• Objective 6 Know the critical features of the
  multiple baseline design.
• Critical features
• More than one baseline
• recorded during the same time period for
  different lengths of time
• Introduce treatment in one condition at a time
• Sequentially in order of baseline stability
• No withdrawal or reversal
• Avoids any associated problems
• Must have overlap in terms of setting,
  researchers used, participants used, etc. to
  detect potential extraneous variables otherwise
  it is simply a series of stacked AB designs

24
Multiple baseline design
Bob
Minutes on Task
Carol
Joe
Sessions
Sessions
25
Multiple baseline design

• 3 types
• Across participants
• Same settings and behavior, but different
  participants
• Across behaviors
• Same participant and setting, but different
  behaviors
• Across settings
• Same participants and behavior, but different
  settings

26
Across participants
Bob
Homeroom
Minutes on Task
Carol
Homeroom
Joe
Homeroom
Sessions
27
Across behaviors
Min. on Task
Homeroom
Bob
Min. In Seat
Homeroom
Min. w/ No Talkouts
Homeroom
Sessions
28
Across Settings
Homeroom
Bob
Minutes on Task
Math
Bob
Reading
Bob
Sessions
29
Changing criterion design

• Objective 7 Know the critical features of the
  changing criterion design.
• Critical features
• Uses the same, behavior, participant, and setting
• Baseline phase
• Shows experimental control by demonstrating that
  changes in the DV occur only when the criterion
  changes

30
Changing criterion design
31
Changing criterion design

• Considerations
• Length of phase
• Considerable variation for control purposes
• Size of incremental change
• Considerable variation for control purposes
• of phases
• More better

32
Analysis of SSD

• Objective 8 Know how single subject designs are
  most commonly analyzed.
• Visual analysis most common
• Assess trends and levels between adjacent phases
• Level value of DV
• Trend direction of the level of DV
• Increasing, decreasing, stable, variable
